Summary of Contents for PTN SUH4T
- Page 1 User Manual SUH4T PTN 4K HDBT Splitter 1x4 with PoC www.av-box.ru...
- Page 2 4K HDBT Splitter 1x4 with PoC SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
- Page 3 Please refer to the dealers for the latest details. This manual is copyright PTN Electronics Limited. All rights reserved. No part of this publication may be copied or reproduced without the prior written consent of PTN Electronics Limited.
-
Page 4: Table Of Contents
4K HDBT Splitter 1x4 with PoC Contents 1. Introduction ......................... 1 1.1 Introduction to SUH4T ..................1 1.2 Features ......................1 1.3 Package List ...................... 1 2. Panel Description ......................2 2.1 Front Panel ......................2 2.2 Rear Panel ......................3 3. -
Page 5: Introduction
1. Introduction 1.1 Introduction to SUH4T SUH4T is an HDBT Splitter accepting 1 HDMI input and distributing to 4 HDBT outputs, plus 1 HDMI local output. The HDMI output socket can be used to monitor local devices or cascade with additional splitter. -
Page 6: Panel Description
4K HDBT Splitter 1x4 with PoC 2. Panel Description 2.1 Front Panel Name Description Power ① Illuminate red once powered on indicator ② FIRMWARE USB port, used for firmware update. Iluminate green when there is input signal, remain off when ③... -
Page 7: Rear Panel
IR IN socket OUT: Connect with IR emitter to emit the IR signal received from the receiver side. Assign ID for SUH4T to identify every unit, the value may vary ④ ID PRESET from 0~F. -
Page 8: System Connection
PTN control panel TPHD402PR IR Emitter TPHD402PR IR Emitter HDTV HDTV TPHD402PR HDTV IR Emitter IR Emitter HDTV HDTV 3.3 Connection Procedure Step1. Connect a HDMI source device (e.g. Blue-ray DVD) to the HDMI INPUT socket of SUH4T with HDMI cable. www.av-box.ru... -
Page 9: Cascade Connection
TPHD402PR(s). If you want to cascade IR signal among several SUH4T, connect the IR LOOP socket of one of them and the IR IN socket of the next until all SUH4T have been connected. Step6. Connect a DC 24V power adapter to the power port of SUH4T, TPHD402PR is able to be energized by SUH4T with PoC solution. -
Page 10: Twisted Pair Cable Connection
Cascade through IR Loop Connect the IR LOOP socket of the first SUH4T and the IR IN socket of the next until all SUH4T have been connected. Sending IR signals to the IR Receiver connected to the first SUH4T will control all cascaded SUH4T. -
Page 11: Control Modes
SUH4T can be controlled via IR, RS232 commands and EDID management. 4.1 IR Control SUH4T provides with an IR IN port. Connect an IR receiver to the IR IN port, users can control SUH4T/ far-end device from local or control local devices from remote via corresponding IR remote. -
Page 12: Control Local Device From Remote
4.1.2 Control local device from remote Control SUH4T or local displayer from remote via corresponding IR remote. Figure 4- 2 Control local device from remote 4.2 RS232 Control As RS232 can be transmitted bi-directionally between SUH4T and TPHD402PR, so it is www.av-box.ru... -
Page 13: Installation/Uninstallation Of Rs232 Control Software
4K HDBT Splitter 1x4 with PoC able to control a third party RS232 device from local or control SUH4T from remote. When to control a third party RS232 device, the baud rate of this device should be 9600. 4.2.1 Installation/uninstallation of RS232 Control Software ... -
Page 14: Control Far-End Device From Local
Of which port number stands for the HDBT port that the device to be controlled is connected to, the value varies from 1~4. For example, if the ID of the SUH4T is 01, and the device to be controlled is connected to HDBT port 2, then send the command “1B1.” as “0121B1.”. -
Page 15: Edid Management
Figure 4- 4 Control local device from remote 4.3 EDID Management SUH4T provides with a 4-pin EDID DIP switcher, “1” stands for “On”, “0” stands for “Off”. Dial the switches to change EDID data refering to the following explainations: Switcher Status... -
Page 16: Specification
176.4 kHz and 192 kHz Power Supply DC 24V 60m (196feet) with HDMI video, RS232 & IR control, PoC HDBT supports PTN TPHD402PR / TPHD403PR / TPHD403PLR RS232 & IR Full function pass though; Control RS232 port ID selectable for cascading; Dimensions... -
Page 17: Panel Drawing
4K HDBT Splitter 1x4 with PoC 6. Panel Drawing www.av-box.ru... -
Page 18: Troubleshooting & Maintenance
No HDMI signal output in SUH4T while local HDMI input is in normal working state Wrong RS232 Cannot control SUH4T by Make sure the RS232 communication parameters control device (e.g. -
Page 19: After-Sales Service
4K HDBT Splitter 1x4 with PoC 8. After-sales Service If there appear some problems when running SUH4T, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. - Page 20 www.av-box.ru Tel: 8 804 333-18-83 Email: i@av-box.ru Website: www.av-box.ru...
