Summary of Contents for BenQ W7000+
-
Page 1: User Manual
W7000+/W7500 Digital Projector Home Cinema Series User Manual http://www.pureglare.com.au... -
Page 2: Table Of Contents
Table of contents Important safety instructions..3 Correcting picture distortion....25 Using the preset and user modes ..26 Overview..........6 Fine-tuning the picture quality .... 28 Shipping contents........6 Advanced picture quality controls ..29 Remote control batteries....... 7 Selecting the aspect ratio ..... 33 Remote control operation ..... -
Page 3: Important Safety Instructions
Thank you for your purchase of this quality BenQ video projector! It has been designed to provide you with an enjoyable home theater viewing experience. For the best results, please read this manual through carefully as it is your guide through the control menus and operation. - Page 4 Liquids spilled into the projector will void your images for ceiling mount installation. Use only warranty. If the projector does become wet, BenQ's Ceiling Mount Kit for mounting. disconnect it from the power point and call BenQ to have the projector repaired. Important safety instructions http://www.pureglare.com.au...
-
Page 5: Moisture Condensation
Moisture condensation 13. Never attempt to replace the lamp assembly until the projector has cooled down and is unplugged Never operate the projector immediately after from the power supply. moving it from a cold location to a hot location. When the projector is exposed to such a change in temperature, moisture may condense on the crucial internal parts. -
Page 6: Overview
Overview Shipping contents Carefully unpack and verify that you have the items below. Some of the items may not be available depending on your region of purchase. Please check with your place of purchase. Some of the accessories may vary from region to region. The warranty card is only supplied in some specific regions. -
Page 7: Remote Control Batteries
BenQ projector ceiling mount kit and that you ensure it is securely and safely installed. If you use a non-BenQ brand projector ceiling mount kit, there is a safety risk that the projector may fall from the ceiling due to an improper attachment through the use of the wrong gauge or length screws. -
Page 8: Projector Features
Projector features • Full HD compatible The projector is compatible with Standard Definition TV (SDTV) 480i, 480p, 576i, 576p, and High Definition TV (HDTV) 720p, 1080i and 1080p formats, with the 1080p format providing a true 1:1 image reproduction. • High picture quality The projector provides excellent picture quality due to its high resolution, excellent home theater brightness, super high contrast ratio, vivid color and rich gray-scale reproduction. -
Page 9: Projector Exterior View
Projector exterior view Front and upper side view 1. Control panel (See "Control panel" on page 10 for details.) 2. Lamp cover 3. Front IR sensor 4. Vent (heated air exhaust) 5. Projection lens 6. Lens shift lever Rear view 7. -
Page 10: Controls And Functions
Controls and functions Control panel For details, see the info provided behind the hand sign 6. Arrow/Keystone keys (Left , Up Right , Down / ) Moves the current On-Screen Display (OSD) menu selection in the direction of the arrow being pressed when the OSD menu is activated. -
Page 11: Remote Control
Remote control For details, see the info provided behind the hand sign 7. Arrow/Keystone keys (Left , Up Right , Down / ) Moves the current On-Screen Display (OSD) menu selection in the direction of the arrow being pressed when the OSD menu is activated. Manually corrects distorted pictures resulting from an angled projection. -
Page 12: Positioning Your Projector
Purchase the BenQ Projector Ceiling Mount Kit Note that a special rear projection screen and the from your dealer to mount your projector on the BenQ Projector Ceiling Mount Kit are required for ceiling. this installation location. *Set Front Ceiling after you turn the projector... -
Page 13: Obtaining A Preferred Projected Image Size
Obtaining a preferred projected image size The distance from the projector lens to the screen, the zoom setting, and the video format each factors in the projected image size. The projector should always be placed horizontally level (like flat on a table), and positioned directly perpendicular 90°... -
Page 14: Projection Dimensions
If you place the projector in a different position (to that recommended), you will have to tilt it down or up to center the image on the screen. In these situations, some image distortion will occur. Use the Keystone function to correct the distortion. See "Correcting picture distortion"... - Page 15 Installation for a 4:3 ratio screen The illustrations and table below are provided for those users who already have 4:3 aspect ratio screens or intend to purchase 4:3 aspect ratio screens to view 16:9 ratio projected images. Floor Installation Ceiling Installation <A>...
-
Page 16: Shifting The Projection Lens
Shifting the projection lens The lens shift control provides flexibility for installing your projector. It allows the projector to be positioned off the center of the screen. The lens shift is expressed as a percentage of the projected image height or width. It is measured as an offset from the projected image’s vertical or horizontal center. -
Page 17: Connecting With Video Equipment
Connecting with video equipment You can connect the projector to any type of video equipment, such as a VCR, DVD player, Blu-ray player, digital tuner, cable or satellite decoder, video game console or digital camera. You can also connect it to a desktop or laptop PC or Apple Macintosh system. -
Page 18: Connecting Component-Video Devices
Connecting component-video devices Be sure to match the corresponding colors between the cables and the terminals. The RCA type component video jacks are provided for connection to video output devices. You should also connect the separate audio cable to a suitable audio amplifier. AV equipment: DVD player, digital tuner, etc. -
Page 19: Connecting A Computer
Connecting a computer Connect the projector to a computer with a VGA cable. Laptop or desktop computer To audio input terminals From audio output terminal VGA cable Many laptops do not turn on their external video ports when connected to a projector. Usually a key combination like Fn + F3 or CRT/LCD key turns the external display on/off. -
Page 20: Using The Projector
Using the projector Preparations 1. Plug in and turn all of the connected equipment on. 2. If not already in, plug the supplied power cable into the AC inlet on the rear of the projector. 3. Plug the power cable into a wall power outlet and turn the wall switch on. -
Page 21: Selecting An Input Source
Selecting an input source The projector can be connected to multiple equipment at the same time. NOTE: When HDMI 1 When the projector is first turned on, it will attempt to reconnect with automatically searching for a the input source which was in use when the projector was last shut HDMI 2 valid input source, down. -
Page 22: Using The Menus
OSD menu on. to select a preferred language. Picture -- Basic System Setup Preset Mode Cinema Language English User Mode Management Splash Screen BenQ Brightness Projector Position Front Contrast Auto Off Disable Color Sleep Timer Disable Tint... -
Page 23: Utilizing The Password Function
Utilizing the password function For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the On-Screen Display (OSD) menu. Once the password is set and this function is selected, the projector is password-protected. Users who do not know the correct password can not use the projector. -
Page 24: Entering The Password Recall Procedure
2. Write down the number and turn off your projector. Recall code: 3. Seek help from the local BenQ service center to decode the number. XXX XXX XXX XXX You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector. -
Page 25: Adjusting The Projected Image
Adjusting the projected image Adjusting the projection angle There are four adjuster feet on the bottom of the projector. These can be used if necessary to change the projection angle. Screw the feet in or out as appropriate to aim and level the projection angle. If the screen and the projector are not perpendicular to each other, the projected image becomes vertical trapezoidal. -
Page 26: Using The Preset And User Modes
Using the preset and user modes Selecting a preset mode The projector is preset with several pre-defined picture modes so that you can choose one to suit your operating environment and input source picture type. To select a picture mode that suits your need: •... -
Page 27: Resetting The Picture Mode
Setting the User 1/User 2/User 3 mode There are three user-definable modes if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the selected User mode) as a starting point and customize the settings. -
Page 28: Fine-Tuning The Picture Quality
Fine-tuning the picture quality No matter what picture mode you have selected, you are able to fine-tune those settings to fit every presentation purpose. Those adjustments will be saved to the preset mode you are at when you exit the OSD menu. -
Page 29: Advanced Picture Quality Controls
Adjusting Flesh Tone This function adjusts accurate color primaries resulting in natural looking flesh tones with excellent color saturation. Highlight Flesh Tone in the Picture -- Basic menu and adjust the values by pressing on the projector or remote control. The higher the value, the more reddish the flesh tones in the picture become. -
Page 30: Setting A Preferred Color Temperature
Gamma refers to the relationship between input source and picture brightness. • Gamma 1.6/1.8/2.0/BenQ Select these values according to your preference. • Gamma 2.2 Increases the average brightness of the picture. Best for a lit environment, meeting room or family room. -
Page 31: Color Management
Color Management In most installation situations, color management will not be necessary, such as in classroom, meeting room, or lounge room situations where lights remain on, or where building external windows allow daylight into the room. Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered. - Page 32 Setting Film Mode Highlight Film Mode in the Display menu and select On by pressing on the projector or remote control. This feature helps improve picture quality when projecting video image from a film-sourced DVD or Blu- ray Disc. Setting 3D Comb Filter Highlight 3D Comb Filter in the Display menu and select On by pressing on the projector or remote control.
-
Page 33: Selecting The Aspect Ratio
Selecting the aspect ratio The "aspect ratio" is the ratio of the image width to the image height. Digital TV is usually in 16:9 ratio, which is the default for this projector, and most analog TV signals and DVDs are in 4:3 ratio. With the advent of digital signal processing, digital display devices like this projector can dynamically stretch and scale the image output to a different aspect than that of the image input source. -
Page 34: Magnifying And Searching For Details
5. Real: This setting displays the image in a one-to-one pixel mapping without alteration or resize in the center of the projection. This is most suitable for use with PC source inputs. 4:3 picture • The black portions are inactive areas and the white portions are active areas. -
Page 35: Operating In A High Altitude Environment
Operating in a high altitude environment We recommend that you activate High Altitude Mode when your environment is higher than 1500 meters (around 4920 feet) above sea level, or whenever the projector will be used for extended periods of time (>10 hours) without shutdown. To activate High Altitude Mode: 1. -
Page 36: Displaying More Than One Image Source Simultaneously
Displaying more than one image source simultaneously Your projector is capable of displaying pictures simultaneously from two input sources, which can be used to enhance your presentation in an interesting way. Ensure the signals you want to display are correctly connected to the projector. -
Page 37: Watching 3D Content
After you have connected the 3D video devices to the projector using the HDMI cable, make sure the power of BenQ 3D glasses is on. Wear the BenQ 3D glasses, and then enjoy your 3D experience! Using the 3D menus 1. -
Page 38: Personalizing The Projector Menu Display
Personalizing the projector menu display The On-Screen Display (OSD) menus can be set according to your preferences. The following settings do not affect the projection settings, operation, or performance. • Menu Display Time in the System Setup > Menu Settings menu sets the length of time the OSD will remain active after your last key press. -
Page 39: On-Screen Display (Osd) Menus
Blue Gain 0–100 Color Temperature Fine Tuning Red Offset 0–511 Picture -- Green Offset 0–511 Advanced Blue Offset 0–511 Gamma Selection 1.6/1.8/2.0/2.2/2.4/2.5/2.6/2.8/BenQ Brilliant Color On/Off Primary Color Red/Green/Blue/Cyan/Magenta/Yellow 0–100 Color Management Gain 0–100 Saturation 0–100 Dynamic Black On/Off Using the projector... -
Page 40: System Setup
On/Off 3D Sync Invert Disable/Invert Auto/Off/Frame Sequential/Frame Packing/ 3D Mode Top-Bottom/Side-by-Side/2D 3D Conversion Language Splash Screen BenQ/Black/Blue Projector Position Front/Front Ceiling/Rear/Rear Ceiling Disable/5 min/10 min/15 min/20 min/25 min/ System Setup Auto Off 30 min Disable/30 min/60 min/90 min/120 min/150 Sleep Timer... -
Page 41: Advanced Setup
Reset Lamp Timer Lamp Settings Equivalent Lamp Hour Auto HDMI Format PC Signal HDMI Settings Video Signal On/Off Baud Rate 2400/4800/9600/19200/38400/57600/115200 Advanced Test Pattern Setup Closed Caption Enable On/Off Closed Caption Caption Version CC1/CC2/CC3/CC4 High Altitude Mode On/Off Change Password Password Power On Lock On/Off (inputs current password) - Page 42 Picture -- Basic menu Function Description Pre-defined picture modes are provided so you can optimize your projector Preset Mode picture set-up to suit your program type. See "Selecting a preset mode" on page 26 for details. Selects a preset mode that most suits your need for the picture quality and User Mode further fine-tune the picture based on the selections listed below.
-
Page 43: Display Menu
Display menu Function Description There are several options to set the picture’s aspect ratio depending on your Aspect Ratio input source. See "Selecting the aspect ratio" on page 33 for details. Corrects any keystoning of the picture. See "Correcting picture distortion" on Keystone page 25 for details. -
Page 44: System Setup Menu
Allows you to select which logo screen will display during projector start-up. Splash Screen You can choose BenQ logo screen, Blue screen or Black screen. The projector can be installed on a ceiling or behind a screen, or with one or Projector Position more mirrors. -
Page 45: Information Menu
BenQ video display devices. Accordingly, we recommend that setup and calibration be performed by an ISF certified installation technician. -
Page 46: Additional Information
Additional information Care of the projector Your projector needs little maintenance. The only thing you have to do on a regular basis is keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer or local customer service center if the projector fails to operate as expected. -
Page 47: Lamp Information
An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. Go to http://lamp.BenQ.com for a replacement lamp. The Lamp indicator light and Temperature warning light will light up if the lamp becomes too hot. Turn the power off and let the projector cool for 45 minutes. -
Page 48: Replacing The Lamp
NOTICE: Replace lamp soon whenever you notice that the brightness level has significantly Lamp > XXXX hrs diminished. Order a new lamp at lamp.benq.com Press ENTER to dismiss the message. The lamp MUST be replaced before the projector will operate WARNING normally. - Page 49 Turn the power off and disconnect the Notes projector from the power outlet. Turn off all • Pulling it too quickly may cause the lamp to connected equipment and disconnect all other break and scatter broken glass in the projector. cables.
-
Page 50: Resetting The Lamp Timer
Resetting the lamp timer Do not reset the lamp timer if the lamp has not been replaced as this could cause damage. 1. After the start-up logo, press MENU and then press until the Advanced Setup menu is highlighted. 2. Press to highlight Lamp Settings and press ENTER. -
Page 51: Indicators
Power Temp Lamp Status & Description • The lamp has been damaged. Please contact your local BenQ customer center for purchasing a new lamp. • The lamp is not properly attached. • The lamp has been damaged. Please contact your local BenQ Flashing customer center for purchasing a new lamp. -
Page 52: Troubleshooting
Troubleshooting Problem Cause Remedy Plug the power cable into the AC inlet on the rear of the projector, and plug the power There is no power from the power cable into to the power outlet. If the power cable. outlet has a switch, make sure that it is The projector does switched on. -
Page 53: Specifications
Specifications All specifications are subject to change without notice. Optical Projection system Single-chip DLP system DMD chip 0.65" DLP (1920 x 1080) Lens F = 2.48 to 2.81, f = 24.1 to 36.15 mm Projection screen size 28" to 300" Lamp 300W Electrical... -
Page 54: Ceiling Mount Installation
Dimensions 428 mm x 317 mm x 145 mm (W x D x H) Ceiling mount installation Ceiling mount screws: M6 x 8 (Max. L = 8 mm) 151.2 211.7 Unit: mm 324.1 424.4 Using the projector http://www.pureglare.com.au... -
Page 55: Timing Chart
1024 x 768* XGA_75 75.029 60.023 78.750 XGA_85 84.997 68.667 94.500 1152 x 864* 1152 x 864_75 75.00 67.500 108.000 BenQ Notebook 1024 x 576* 60.00 35.820 46.996 Timing BenQ Notebook 1024 x 600* 64.995 41.467 51.419 Timing 1280 x 768_60 47.396 68.25... - Page 56 1400 x 1050* SXGA+_60 59.978 65.317 121.750 1600 x 1200* UXGA 60.000 75.000 162.000 1680 x 1050_60 1680 x 1050* 59.883 64.674 119.000 (Reduce Blanking) 640 x 480 MAC13 66.667 35.000 30.240 @67Hz* 832 x 624 MAC16 74.546 49.722 57.280 @75Hz* 1024 x 768 MAC19...
- Page 57 84.997 68.667 94.500 XGA_120** 119.989 97.551 115.500 (Reduce Blanking) 1152 x 864 1152 x 864_75* 75.00 67.500 108.000 BenQ Notebook 1024 x 576 60.00 35.820 46.996 Timing* BenQ Notebook 1024 x 600 64.995 41.467 51.419 Timing* 1280 x 720_60* 45.000 74.250...
- Page 58 1280 x 960_60* 60.000 60.000 1280 x 960 1280 x 960_85* 85.002 85.938 148.500 1360 x 768 1360 x 768_60* 60.015 47.712 85.500 1440 x 900 WXGA+_60* 59.887 55.935 106.500 1400 x1050 SXGA+_60* 59.978 65.317 121.750 1600 x1200 UXGA* 60.000 75.000 162.000 640 x 480...
- Page 59 Supported timing for EDTV and HDTV (via Component 1/ Component 2 inputs) Timing Resolution H. Freq. (KHz) V. Freq. (Hz) Dot Clock Freq. (MHz) 480i 720 x 480* 15.73 59.94 13.5 480p 720 x 480* 31.47 59.94 576i 720 x 576* 15.63 13.5 576p...
-
Page 60: Warranty And Copyright Information
Further, BenQ Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of BenQ Corporation to notify any person of such revision or changes.
