Item Description
Fan 4/12 power LED
4
Fan 3/11 power LED
5
Fan 1/9 power LED
6
Fan 2/10 power LED
7
Power supply 1 power LED Green—Normal
8
Power supply 2 power LED Green—Normal
9
Power supply 3 power LED Green—Normal
10
Power supply 4 power LED Green—Normal
11
Fan 5/13 power LED
12
Fan 6/14 power LED
13

System board components

Item Description
Cache module connector
1
x24 riser connector
2
SATA hard drive connector 1
3
Status
Flashing blue—System is being remotely
managed.
Off—Deactivated
Off—Normal
Amber—Fan has failed.
Off—Normal
Amber—Fan has failed.
Off—Normal
Amber—Fan has failed.
Off—Normal
Amber—Fan has failed.
Off—No AC power
Off—No AC power
Off—No AC power
Off—No AC power
Off—Normal
Amber—Fan has failed.
Off—Normal
Amber—Fan has failed.
