Regency Plateau
Outdoor Decorative Gas Appliances
www.regency-fire.com
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a authorised installer,
service agency or the gas supplier,
in accordance with this manual.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-065e
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open flame.
•If odor continues, keep away from the appliance and im-
•Do not touch any electrical switch: do not use any phone
•Immediately call your gas supplier from a neighbour's
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire
Do not store or use gasoline or other flammable vapours
and liquids in the vicinity of this or any other appliance.
A LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Series
®
WARNING: FOR OUTDOOR USE ONLY
WARNING - FOR YOUR SAFETY
mediately call your gas supplier or fire department.
in your building.
phone.
department.
WARNING:
Owners &
Installation Manual
MODELS: PTO30CFT
PTO30IST
PTO30CKT
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS4565 / AS4558
and have been certified by the IAMPO
Oceana for installation and operation
as described in these Installation and
Operating Instructions.
Your unit should be serviced annually
by an authorised service person.
04.07.15
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products Plateau PTO30CFT
Summary of Contents for Regency Fireplace Products Plateau PTO30CFT
- Page 1 Owners & Installation Manual Regency Plateau Series ® MODELS: PTO30CFT Outdoor Decorative Gas Appliances PTO30IST PTO30CKT LISTINGS AND CODE APPROVALS These gas appliances have been tested in accordance with AS4565 / AS4558 and have been certified by the IAMPO Oceana for installation and operation as described in these Installation and Operating Instructions.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The ® Plateau Series Outdoor Decorative Gas Appliance has been designed to provide you with all the ® charm of a fire at the flick of a switch. The Plateau Series Outdoor Decorative Gas Appliance ®...
-
Page 3: Table Of Contents
Wiring Diagram ............12 Gas Connection ............13 Conversion from Ng to LPG / uLpg ......14 PTO30cft -Coffee Table leg installation ......16 LP Tank installation - PTO30cft only ......17 LP Tank Installation ............18 PTO30IST/PTO30CKT ONly ........18 LP Tank removal ............18 Switch connection............19 Battery Install ...............19... -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies each Plateau ® Series Outdoor decorative gas appliance. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being ® improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Dimensions
DIMENSIONS UNIT DIMENSIONS - COFFEE TABLE TOP VIEW 3-5/8”(91mm) 38”(965mm) 2-9/16”(64mm) 4.5KG TANK 4.5KG TANK 2-1/16”(52mm) 16-11/16”(423mm) 40-5/8”(1030mm) SIDE VIEW END VIEW Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 6: Unit Dimensions - Island Table
DIMENSIONS UNIT DIMENSIONS - ISLAND TABLE 62" (1575mm) 14-1/4" (361mm) 12-3/16" (309mm) BURNER GLASS OUTER EDGE OUTER EDGE 36" (914mm) 1-5/8” (39mm) 6-3/16 ” (156mm) 28-7/8” (733mm) 9KG TANK 9KG TANK 1” 20lb tank 20lb tank (25mm) 40-3/8” 20-11/16” Floor level (1031mm) 3-1/8”... -
Page 7: Unit Dimensions - Cocktail Table
DIMENSIONS UNIT DIMENSIONS - COCKTAIL TABLE 62" (1575mm) 14-1/4" (361mm) 12-3/16" (309mm) BURNER GLASS OUTER EDGE OUTER EDGE 36" 914mm TOP VIEW 16 " 16 " 963mm 325mm 8 " 4 " 1248mm 742mm SIDE VIEW END VIEW Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 8: Installation
INSTALLATION IMPORTANT MESSAGE 5) DO NOT SIT OR STAND ON DECORATIVE DO NOT USE THIS APPLIANCE IF GAS APPLIANCE SAVE THESE ANY PART HAS BEEN UNDER WATER. IMMEDIATELY CALL A QUALIFIED 6) To prevent injury, do not allow anyone who INSTRUCTIONS SERVICE TECHNICIAN TO INSPECT is unfamiliar with the operation to use the... -
Page 9: Installation Checklist
INSTALLATION LOCATING YOUR INSTALLATION OUTDOOR DECORATIVE GAS APPLIANCE CHECKLIST THE COFFEE TABLE REQUIRES THE INSTALLATION OF THE DECORATIVE GLASS Please refer to the requirements of SURROUND KIT TO REDUCE THE RISK OF HARM TO CHILDREN AS / NZS5601 and local authorities. 1) When selecting a location for your decorative gas appliance, ensure that the clearances are met. -
Page 10: Minimum Clearances To Combustibles
INSTALLATION MINIMUM CLEARANCES TO COMBUSTIBLES The clearances listed below are Minimum distances unless otherwise stated: A major cause of fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this decorative gas appliance be installed only in accordance with these instructions. WARNING Caution Requirements Fire hazard is an extreme risk... -
Page 11: High Elevation
INSTALLATION 886 S.I.T. VALVE PILOT ADJUSTMENT PLATEAU ® SERIES-NG SYSTEM DESCRIPTION DATA Max. Supply Pressure 14" WC (3.49 kpa) Periodically check the pilot flames. Correct flame pattern has two strong blue flames: 1 flowing Min. Supply Pressure 5" WC (1.25 kpa) around the flame sensor and 1 flowing across Manifold Pressure 3.5"... -
Page 12: Wiring Diagram
INSTALLATION WIRING DIAGRAM This appliance does not require a 120V A.C. supply for operation. Proflame System 0.886.001 Proflame Valve Standard Main On/Off Switch or Optional Wall Switch Important: The AA batteries in the battery pack operate the burner switch. If the batteries become weak they will need to be replaced with quality alka- line batteries. -
Page 13: Gas Connection
INSTALLATION GAS CONNECTION 1) Remove end panel (end with the ON/OFF switch). Panels are held in place 3) Connect gas line.. by magnets. Place panel on a soft clean surface. Gas connection @ unit 4) Check all gas connections (both valve train & propane tank or NG source) under normal operating pressure, for leaks, with soapy water. -
Page 14: Conversion From Ng To Lpg / Ulpg
PLATEAU SERIES INSTALLATION CONVERSION FROM NG TO LPG / ULPG CONVERSION FROM NG TO LPG / ULPG THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 4) Remove burner orifi ce with a 1/2" wrench. Use another wrench to hold on Each Kit contains one LPG/ULPG Conversion Kit to the elbow behind the orifi... - Page 15 PLATEAU SERIES INSTALLATION 9) Remove end panel (panel w/ switch) from unit. 14) Remove NG gas line, if installed - replace with LP regulator and quick connection. Gas connection @ unit 15) Check all gas connections (both valve train & LP tank) under normal operating pressure, for leaks, with soapy water.
-
Page 16: Pto30Cft -Coffee Table Leg Installation
INSTALLATION PTO30CFT -COFFEE TABLE LEG INSTALLATION It is required the coffee table unit be used with the legs and decorative 3. Install each leg from the bottom up with supplied bolt, in the same loca- glass surround guard. This is a safety measure to ensure protection. Please tion rubber foot was removed from. -
Page 17: Lp Tank Installation - Pto30Cft Only
INSTALLATION LP TANK INSTALLATION - PTO30CFT ONLY NOTE: Max tank size 11lb or 4.5kg. 1) Remove end panel (opposite end of switch panel),. 2) Remove long side panel (left panel if facing ON/OFF switch end), to ac- cess the 3/8" fitting to the gas control. -
Page 18: Lp Tank Installation
INSTALLATION LP TANK INSTALLATION LP TANK REMOVAL PTO30IST/PTO30CKT ONLY NOTE: Max tank size 20lb or 9kg. 1) Remove end panel (opposite end of switch panel). 1) Remove end panel (opposite end of switch panel). 2) Slide out LP gas tank by pulling from handle on slide out tray. 2) Ensure tank is fully closed. -
Page 19: Switch Connection
INSTALLATION SWITCH CONNECTION BATTERY INSTALL 1) Remove the end panel (side with switch assembly mounted on it) from unit. 1) Remove left side (with switch assembly) end panel from unit. 2) Pull down battery compartment - located below the DFC panel. Battery compartment 2) Connect 2 wires to the switch. -
Page 20: Table Top Installation - Coffee Table Unit
Plateau series INSTALLATION taBle toP installation - Built-in unit & coFFee taBle unit TABLE TOP INSTALLATION - COFFEE TABLE UNIT Before installation,stainless steel must be handled and cleaned as per instructions noted below: stainless steel table top • Stainless table top must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. -
Page 21: (For Island And Cocktail Units Only)
INSTALLATION PLATEAU SERIES TABLE TOP INSTALLATION TABLE TOP INSTALLATION (FOR ISLAND AND COCKTAIL UNITS ONLY) (FOR ISLAND AND COCKTAIL UNITS ONLY) 5) Install tiles - starting with 4 corner tiles. Table Top Components. Tiles Tiles (small inner) Filler Brackets. Table Top Frame Inner frame NOTE: TAKE CARE WHEN HANDLING AND INSTALLING TILES. -
Page 22: Glass Crystal Installation
INSTALLATION GLASS CRYSTALS OR OPTIONAL CERAMIC SPA / VOLCANIC STONES GLASS CRYSTAL INSTALLATION INSTALLATION ON BURNER Evenly spread the Glass Crystals or optional Ceramic Spa Stones over the burner. Ensure the crystals (or stones) do not overlap too much as this will effect the fl... -
Page 23: Optional Volcanic Stones Installation On Burner
INSTALLATION OPTIONAL VOLCANIC STONES INSTALLATION ON BURNER Evenly spread the glass crystals and volcanic stones over the burner. Ensure the stones do not overlap too much as this will effect the flame pattern. IMPORTANT NOTE: Only the supplied approved Volcanic Stones are to be used with these fireplaces. Use of any other type of stones can alter the unit's performance, any damage caused by the use of any unapproved glass or stones will not be covered under warranty. -
Page 24: Glass Surround Installation
INSTALLATION OUTDOOR SERIES GLASS SURROUND INSTALLATION THE GUARD IS FITTED TO THIS APPLIANCE TO REDUCE THE RISK OF FIRE OR INJURY FROM BURNS AND NO PART OF IT SHOULD BE OPTIONAL GLASS SURROUND/WINDSHIELD INSTALLATION PERMANENTLY REMOVED. FOR PROTECTION OF YOUNG CHILDREN OR THE INFIRM , A SECONDARY GUARD IS REQUIRED. 4 Piece Glass Surround PTO 30-1 PTO60-1... -
Page 25: Riser Installation
INSTALLATION RISER INSTALLATION (TO CONVERT ISLAND INTO COCKTAIL TABLE) A riser may be installed at the base of the island table to convert it into a 5) Install the 4 adjustable rubber feet into the bottom of the island riser. cocktail table. - Page 26 INSTALLATION 5) Install 12 screws in locations shown below to secure island frame to riser base. 5) Reinstall LP tank and reconnect or reconnect NG gas line. Reinstall panels, table top and glass surround and glass crystals to com- plete installation. Regency Plateau™...
-
Page 27: Plateau ® Table Cover Installations
INSTALLATION PLATEAU TABLE COVER INSTALLATIONS ® DINING LEAF GLASS SURROUND COVER For all units: For all units with glass surround installed: 1) Place the dining leaf cover over the burner of the unit when not in use. 1) Place the weather cover over the glass surround when not in use. WEATHER COVER CAUTION: For all units:... -
Page 28: Operating Instructions
OPERATING INSTRUCTIONS OPERATING FIRST FIRE INSTRUCTIONS The first fire in your decorative gas appliance is part of the paint curing process. To ensure that the paint 1) Read and understand these instructions before is properly cured, it is recommended that you burn operating this appliance. -
Page 29: Copy Of Lighting Plate Instructions
OPERATING INSTRUCTIONS INSTALLATION COPY OF LIGHTING PLATE INSTRUCTIONS The lighting plate is located on the underside of the front access panel in the unit. FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. -
Page 30: Maintenance Instructions
MAINTENANCE MAINTENANCE INSTRUCTIONS 1) Always turn off the gas valve and unplug the batteries before cleaning. For relighting, refer to lighting instructions. Keep the burner and control compartment clean by brushing and vacuuming at least once a year. When cleaning the logs, use a soft clean paint brush as the logs are fragile and easily damaged. 2) Clean off leaves etc. -
Page 31: Switch Replacement
MAINTENANCE SWITCH REPLACEMENT 1) Remove the end panel (side with switch assembly mounted on it) from unit. 2) Remove 2 wire from the switch. 3) Remove 2 screws from switch cover to release switch. 4) Replace switch and reverse steps. Regency Plateau™... -
Page 32: Valve Assembly Replacement
MAINTENANCE VALVE ASSEMBLY REPLACEMENT Turn the unit off and allow to cool to room temperature. 8) Manuover valve assembly up and out. 1) Remove burner buy removing 6 screws in locations shown below. 2) Slide the burner to the left and lift out. 9) Replace gasket if required. -
Page 33: Digital Fireplace Control Replacement
MAINTENANCE DIGITAL FIREPLACE CONTROL REPLACEMENT 4) Disconnect spark electrode wire. 1) Remove left side (with switch assembly) end panel from unit. Disconnect flame sensor (red) Disconnect ground. Disconnect wire harness. Wire harness Ground Spark Electrode Flame sensor 5) Remove 4 screws to remove DFC box. 6) Replace with new DFC box and reverse steps 5-1. -
Page 34: Parts
PARTS LIST PARTS Part # Description Part # Description 946-775 *Fireglass crystals - Blk 376-526 Burner Assembly LP/NG 946-776 *Fireglass crystals - Copper 911-006 Pilot Assembly - NG 946-777 *Fireglass crystals -Starfire 911-007 Pilot Assembly - LP 946-778 *Fireglass crystals - Colbalt Blue 376-574/P Valve Assembly - NG *Glass crystals in 5lb bags - 2 required... -
Page 35: Warranty
Regency shall in no event be liable for any special, indirect consequential damages of any nature whatsoever which are in excess of the original purchase price of the product. Any alteration to the unit which causes sooting or carboning that results in damage to the exterior facia is not the responsibility of Regency Fireplace Products. -
Page 36: Limited Warranty
Register your Regency warranty online ® www.regency-fire.com.au Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notification of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
