INSTRUCTIONS AND ADVICE FOR THE
USE, INSTALLATION AND MAINTENANCE
Dear Customer,
Thank you for having purchased one of our products.
We are certain that this new, modern, functional and practical appliance, built with the very highest
quality materials, will meet your requirements in the best possible way. This appliance is easy to
use. It is, however, important to thoroughly read the instructions in this handbook in order to obtain
the best results.
These instructions are only valid for the countries of destination, the identification symbols of
which are indicated on the cover of the instruction manual and on the appliance itself.
The manufacturer shall not be held responsible for any damages to persons or property caused
by incorrect installation or use of the appliance.
MODEL: ZPL3GWK - SS
The Manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or
transcription errors; the designs in the figures are purely indicative. The Manufacturer also reserves the right
to make any modifications to the products as may be considered necessary or useful, also in the interests
of the user, without jeopardizing the main functional and safety features of the products themselves.
OF A BUILT-IN GAS HOB
3GAS + WOK COOKTOP
COD. 01088GG - 14.06.2005
Advertisement
Table of Contents
Related Manuals for Platinum ZPL3GWK-SS
Summary of Contents for Platinum ZPL3GWK-SS
- Page 1 INSTRUCTIONS AND ADVICE FOR THE USE, INSTALLATION AND MAINTENANCE OF A BUILT-IN GAS HOB Dear Customer, Thank you for having purchased one of our products. We are certain that this new, modern, functional and practical appliance, built with the very highest quality materials, will meet your requirements in the best possible way.
- Page 2 DESCRIPTION OF THE HOT PLATES TYPES: PMZ 60 N2 - PMZ 60 V2 1 Rapid gas burner 10.8 MJ/h 2 Semi-rapid gas burner 6.3 MJ/h 3 Auxiliary gas burner 3.6 MJ/h 4 Normal plate Ø 145 of 1000 W 5 Rapid plate Ø 145 of 1500 W 6 Enamelled steel trivet 1 burner 7 Enamelled steel trivet 2 burner...
- Page 3 - When the pan comes to the boil, set the knob to the 1) BURNERS reduced rate position (small flame fig. 1). A diagram is screen-printed above each knob on - Always place a lid on the pans. the front panel. This diagram indicates to which burner the knob in question corresponds.
- Page 4 Notes: Use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated by keeping the natural air vents clear (fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig. 4 and fig. 5). Intensive and lengthy use of the appliance may require additional ventilation.
- Page 5 is screen-printed above each knob on the front 2) HOW TO USE THE ELECTRIC panel. This diagram indicates to which electric plate PLATES the knob in question corresponds (see fig. 6). A red warning light will come on to indicate that the plate Mixed hot plates may be equipped with a normal or is operating.
- Page 6 CLEANING IMPORTANT: WARNINGS: Comply with the following instructions, before Always disconnect the appliance from the gas remounting the parts: and electricity mains before carrying out any - Check that burner head slots have not become cleaning operation. clogged by foreign bodies. 3) HOT PLATE - Check that enamelled burner cap “A”, “B”...
-
Page 7: Installation
INSTALLATION this clearance to any surface be less than 450 mm. TECHNICAL INFORMATION FOR THE Where B, measured from the periphery of the INSTALLER nearest burner to any vertical combustible surface, is less than 200 mm, the surface shall be protected Installation, adjustments of controls and in accordance with: AGA 601 - 1995 Clause maintenance must only be carried out by a... -
Page 8: Location And Ventilation
INSTALLATION 7) LOCATION AND VENTILATION 9) ELECTRICAL CONNECTIONS Gas cooking appliances must always dispose of The data label can be found on the underside of the their combustion fumes through hoods. These must cooktop. Check that the voltage rating of the be connected to flues, chimneys or straight outside appliance corresponds to the supply voltage. - Page 9 ADJUSTMENTS Always turn off electrical ignition before making - Insert a small screwdriver “D” into hole “C” (fig. 13) any adjustments. and turn the throttle screw to the right or left until All seals must be replaced by the technician at the burner flame has been adequately regulated to the end of any adjustments or regulations.
-
Page 10: Replacing The Injectors
CONVERSIONS and affix the label corresponding to the new gas 11) REPLACING THE INJECTORS regulation on the appliance instead of the already The burners can be adapted to different types of gas existing one. This label is supplied in the packet by installing injectors suited to the type of gas containing the spare injectors. - Page 11 SERVICING Always turn off the electrical ignition before Greasing the taps (see fig. 16 – 17) proceeding with any servicing operation. If a tap becomes stiff to operate, it must be immediately greased in compliance with the 12) REPLACING HOT PLATE PARTS following instructions: To replace the components fit inside the hob, take - Remove the tap.
- Page 12 TECHNICAL ASSISTENCE AND SPARE PARTS Before leaving the factory, this appliance will have been tested and regulated by expert and specialized personnel in order to guarantee the best performances. Any repairs or adjustments which may be subsequently required may only be carried out by qualified personnel with the utmost care and attention.
