Desa F48H Owner's Operation And Installation Manual

Plantation 48" wood burning fireplace with herringbone masonry brick
Hide thumbs Also See for F48H:
Table of Contents

Advertisement

Quick Links

Download this manual
F48H AND VF48H
PLANTATION
48" WOOD BURNING
FIREPLACE
WITH HERRINGBONE
MASONRY BRICK
IF FIREPLACE IS TO BE INSTALLED DIRECTLY ON
ANY COMBUSTIBLE MATERIAL, A HEARTH SPACER
IS REQUIRED.
This book is valuable. In addition to instructing you
on how to install and maintain your appliance, it also
contains information that will enable you to obtain re-
placement parts or accessory items when needed. Keep
it with your other important papers.
ANS Z21.60, Z21.84 or RGA 2-72 standards or for use
with a vent-free gas log heater approved to ANS Z21.11.2
standard.
CAN/ULS-S610-M87 standard as a FACTORY BUILT
APPLIANCE.
FOR CANADA: The authority having jurisdiction (such
etc.) should be contacted before installation to deter-
mine the need to obtain a permit.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
SAVE THIS BOOK
For more information, visit www.desatech.com
RESIDENTIAL WOOD BURNING
FIREPLACE
OWNER'S OPERATION AND
INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F48H and is the answer not in the manual?

Questions and answers

Related Manuals for Desa F48H

Summary of Contents for Desa F48H

  • Page 1 RESIDENTIAL WOOD BURNING FIREPLACE OWNER’S OPERATION AND INSTALLATION MANUAL F48H AND VF48H PLANTATION 48" WOOD BURNING FIREPLACE WITH HERRINGBONE MASONRY BRICK IF FIREPLACE IS TO BE INSTALLED DIRECTLY ON ANY COMBUSTIBLE MATERIAL, A HEARTH SPACER IS REQUIRED. SAVE THIS BOOK This book is valuable.

  • Page 2: Table Of Contents

    • Due to high temperatures, the • The DESA Heating, LLC warranty will be appliance should be located voided by and DESA Heating, LLC disclaims any responsibility for the following actions.
  • Page 3 WARNING: Always leave glass doors fully opened or fully closed to be installed on combustible material, a Hearth Spacer must be used. See Replacement and Accessory Parts on page 18. SPECIFICATIONS MODELS F48H AND VF48H SQUARE ROUND TOP CHASE-TOP TERMINATION TERMINATION No Combustible 2"...

  • Page 4: Fireplace Installation

    FIREPLACE INSTALLATION SELECTING LOCATION touch the side framing. consideration the following guidelines: sheet metal if necessary. 1. The location must allow for proper clear- ances (see Figures 1 and 2). 5. Before securing fireplace to prepared framing, ember protector (provided) must will not be affected by drafts, air condition- be placed between hearth extension (not ing ducts, windows or doors.

  • Page 5: Venting Installation

    FIREPLACE INSTALLATION Continued HEARTH EXTENSION A hearth extension projecting a minimum of is to be installed only as shown 20" in front of and a minimum of 12" beyond in Figure 3. MANTELS using a material which meets the following A mantel may be installed if desired (see Figure 4).
  • Page 6 " Figure 5 - Outside Air Kit Stainless Inner Pipe CHIMNEY PIPE The DESA Heating, LLC chimney system Figure 6 - Lineal Gain lock, double-wall pipe segments, planned ASSEMBLY AND INSTALLATION OF for maximum adaptability to individual site DOUBLE WALL CHIMNEY SYSTEM requirements.
  • Page 7 VENTING INSTALLATION Continued USING ELBOW OFFSETS (30E-12DM) 2. Chimney weight above offset rests on return elbow. Straps must be securely 1. To achieve desired offset, you may install nailed to rafters or joists (see Figure 8, combinations of 12", 18", 24", 36" and 48" details A and B).
  • Page 8 VENTING INSTALLATION Continued PENETRATING THE ROOF To maintain a 2" clearance to the pipe on a roof with a pitch, a rectangular opening must be cut. Screws 1. Determine center point through which pipe will penetrate roof. 2. Determine center point of roof. Pitch is the distance the roof drops over a given span, usually 12".
  • Page 9 VENTING INSTALLATION Continued FLASHING INSTALLATION (V6F-10DM Terminations/Spark Arrestor OR V12F-10DM) the listed round top or chase terminations. In any case, refer to installation instructions supplied with termination. CAUTION: Do not seal open- base. Secure in position by nailing through shingles (see Figure 13). DO NOT NAIL low the installation instructions THROUGH FLASHING CONE.

  • Page 10: Optional Gas Line Installation

    VENTING INSTALLATION Continued Level of Flue Gas Outlet 18" Min. Typ. 24" Min. Figure 17 - 10 Foot Rule 24" Min. FINISHING FIREPLACE Combustible materials, such as wallboard, Figure 16 - Multiple Chase Installation gypsum board, sheet rock, drywall, plywood, 10 FOOT RULE etc.

  • Page 11: Brick Installation

    OPTIONAL GAS LINE INSTALLATION Continued must comply with the Standard for Decorative CAUTION: All gas piping Gas Appliance for Installation in Solid Fuel and connections must be tested and shall also be installed in accor- for leaks after the installation dance with the National Fuel Gas Code, ANSI is completed.
  • Page 12 BRICK INSTALLATION Continued RIGHT PANEL NOTICE: An ash lip kit is avail- placement and Accessory Parts, page 18). If using ash lip kit, the standard optional glass door kit BRICK “PU” not be installed. If using ash lip, obtain ash lip kit prior to brick LEFT PANEL installation.
  • Page 13 BRICK INSTALLATION Continued HERRINGBONE BRICK MATRIX BRICK MATRIX BRICK MATRIX Full AAA AAB AAC AAD AAE AAF AAK AW H PA PAA Box #1 Hearth Box #2 Rear - Lower Box #3 Rear - Upper Box #4 Left Box #5 Right TOTAL BRICK MATRIX (Continued) BRICK MATRIX...
  • Page 14 BRICK INSTALLATION Continued INSTALLING Z-SHAPED GRATE spilling. Place a wet towel over bucket making sure it is directly on the surface of RETAINER BRACKET grout mixture. This will keep mixture moist and it will not dry out before use. grate retainer brackets on top of hearth bricks 5.

  • Page 15: Glass Door Installation

    GLASS DOOR INSTALLATION 5. Place rail back on bricks and align holes. IMPORTANT: Install top and bot- Secure using 9 concrete screws provided tom rails and hardware before with glass door kit. installing glass door panels. 6. Secure mounting clips to top and bottom rails (see Figure 24).

  • Page 16: Operation And Maintenance Guidelines

    GLASS DOOR INSTALLATION Continued DOOR ADJUSTMENT Remove doors and slightly loosen upper spring clips. Replace and fully close doors. Use 1/8" shims (any material) to level doors. Slide Top Once proper setting is achieved, carefully Pin Into Top open doors enough to access top retaining Retaining Clip clips with a Phillips screwdriver.
  • Page 17 CAUTION: When operating damper door, please be aware of sharp edges and corners. Open and close damper door slowly to avoid injury. place grate with DESA model 109496-01 grate only. This grate has been designed to keep the www.desatech.com 118116-01D...

  • Page 18: Replacement And Accessory Parts

    REPLACEMENT AND ACCESSORY PARTS OPTIONAL OUTSIDE AIR KIT FOR FLOOR INSTALLATION - AK4F BI-FOLD GLASS MASONRY DOOR BDMO48E - 48" Ebony BDMO48G - 48" Pewter BDMO48C - 48" Oiled Bronze OPTIONAL OUTSIDE AIR KIT FOR DOUBLE WALL PIPE - 12-12DM, SIDEWALL INSTALLATION - AK4 18-12DM, 24-12DM, 36-12DM, 48-12DM, 12-12HT, 18-12HT, 24-12HT, 36-12HT and...

  • Page 19: Technical Service

    OPTIONAL ASH LIP KIT (BRICKS) AL48 TECHNICAL SERVICE You may have further questions about installa- You can also visit DESA Heating, LLC’s web tion, operation, or troubleshooting. If so, con- site at www.desatech.com. tact DESA Heating, LLC at 1-866-672-6040. When calling please have your model and serial numbers of your heater ready.
  • Page 20 DESA Heating, LLC 2701 Industrial Drive P.O. Box 90004 Bowling Green, KY 42102-9004 www.desatech.com 1-866-672-6040 118116-01 Rev. D 118116 01 10/07 NOT A UPC...
