UNVENTED (VENT-FREE) 32" LogMaTE
UNIVERSaL FIREBoX
®
oWNER'S MaNUaL
Shown with optional
accessories.
f i r e - p a r t s . c o m
MoDEL FB32CB WITH CIRCULaTINg LoUVERS aND
MoDEL FB32NCB WITH NoNCIRCULaTINg SMooTH FaCE
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
For use only with a listed gas-fired unvented decorative
room heater. Not to exceed 40,000 Btu/Hr. Do not build
a wood fire.
Carefully review the instructions supplied with the
decorative type unvented room heater for the minimum
fireplace size requirement.
Do not install an appliance in this firebox unless this
firebox meets the minimum dimensions required for
the installation.
This firebox has been tested and approved by CSA
under ANSI Z21.91 for use with any ANSI Z21.11.2 ap-
proved gas logs.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For more information, visit www.desatech.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Desa VANGUARD LOGMATE FB32CB
Summary of Contents for Desa VANGUARD LOGMATE FB32CB
- Page 1 ® UNVENTED (VENT-FREE) 32" LogMaTE UNIVERSaL FIREBoX ® oWNER’S MaNUaL Shown with optional accessories. f i r e - p a r t s . c o m MoDEL FB32CB WITH CIRCULaTINg LoUVERS aND MoDEL FB32NCB WITH NoNCIRCULaTINg SMooTH FaCE WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TaBLE oF CoNTENTS Safety ..............2 Installation ............7 Local Codes............3 Parts ..............14 Unpacking............4 Replacement Parts ..........18 Product Specifications ......... 4 Technical Service..........18 Product Features ..........5 Accessories ............19 Locating Firebox ..........5 Warranty ..........Back Cover Air for Combustion and Ventilation ...... -
Page 3: Local Codes
SaFETy Continued 3. Do not use this firebox as a wood-burning Firebox front and screen become fireplace. Use only decorative unvented very hot when running firebox. room heaters (log sets). Keep children and adults away 4. Do not add extra logs or ornaments such from hot surfaces to avoid burns as pine cones, vermiculite or rock wool. -
Page 4: Unpacking
• Screen assembly (2) 3. Check heater for any shipping damage. • Screen support rod (2) If heater is damaged call DESA Heat- ing, LLC at 1-866-672-6040 for replace- • Hood ment parts before returning to dealer. -
Page 5: Product Features
pRoDUCT FEaTURES OPERATION the firebox requires no electricity making it ideal for emergency backup heat. This firebox is designed for use with approved ANSI Z21.1.2 decorative type unvented room BLOWER ACCESSORY heaters. (Physical size limitations apply. Refer The FB32CB firebox will accept the GA3750A to minimum firebox requirements supplied accessory. - Page 6 aIR FoR CoMBUSTIoN aND VENTILaTIoN Continued If your home does not meet all of the three pre- 3. Add the Btu/Hr of all fuel burning appli- vious criteria, proceed to Determining Fresh- ances in the space. Air Flow For Firebox Location, page 6. Vent-free heater ________ Btu/Hr Gas water heater*...
-
Page 7: Installation
aIR FoR CoMBUSTIoN aND VENTILaTIoN Continued ceiling and one within 12" of the floor on the WARNING: If the area in which wall connecting the two spaces (see options 1 the heater may be operated does and 2, Figure 4). You can also remove door into not meet the required volume for adjoining room (see option 3, Figure 4). - Page 8 INSTaLLaTIoN Continued IMPORTANT: Vent-free gas log heaters add B. Clearances from the top of the fireplace moisture to the air. Although this is beneficial, opening to the ceiling should not be less installing firebox in rooms without enough than 42". ventilation air may cause mildew to form from MINIMUM CLEARANCE TO too much moisture.
- Page 9 INSTaLLaTIoN Continued INSTALLING BLOWER ACCESSORY 3. Be certain that all wire terminals are securely attached to terminals on blower (Model FB32CB Only) motor and that the screw retaining green You may install blower accessory GA3750A ground wire is tight. with conventional installation (below) or with built-in installation (page 11).
- Page 10 INSTaLLaTIoN Continued 7. Plug in blower power cord. NOTICE: A qualified electrician a. If your firebox is installed as a freestand- must connect electrical wiring to ing unit, determine whether power cord duplex outlet for built-in instal- will exit left side or right side of firebox. lation.
- Page 11 INSTaLLaTIoN Continued Operating Blower Light your gas appliance with the blower off. After about 15 minutes, turn blower on to de- liver heated air at the top louvers. The blower Screws features a variable control which allows you to select the speed you desire. Note: Periodically check louvers of the firebox and remove any dust, dirt or other obstructions.
- Page 12 INSTaLLaTIoN INSTALLING FIREPLACE SCREEN Continued 1. Insert each rod through nine rings located at top of screen. Trim 2. Insert first rod into rear hole in left side Hanging of firebox. Fasten rod to rear hole near Screws center of firebox using black shoulder screw.
- Page 13 INSTaLLaTIoN WARNING: Use only non- Continued combustible mortar or adhe- 2. Install gas piping to firebox location. This sives when overlapping the front installation includes an approved flexible facing with noncombustible gas line (if allowed by local codes) after facing material. the manual shutoff valve.
-
Page 14: Parts
paRTS MODEL FB32CB f i r e - p a r t s . c o m www.desatech.com 116662-01G... - Page 15 paRTS MODEL FB32CB This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 18 of this manual. NO. PART NO. DESCRIPTION QTY. 101872-03 Firebox Top 101889-01 Firebrick Retainer 117538-01 Firebrick Kit 103457-01 Button Plug...
- Page 16 paRTS MODEL FB32NCB f i r e - p a r t s . c o m www.desatech.com 116662-01G...
- Page 17 paRTS MODEL FB32NCB This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 18 of this manual. NO. PART NO. DESCRIPTION QTY. 101872-03 Firebox Top 101889-01 Firebrick Retainer 117538-01 Firebrick Kit 099230-02 Shoulder Screw...
-
Page 18: Replacement Parts
• how heater was malfunctioning • purchase date TECHNICaL SERVICE You may have further questions about installa- You can also visit DESA Heating, LLC’s web tion, operation, or troubleshooting. If so, con- site at www.desatech.com. tact DESA Heating, LLC at 1-866-672-6040. -
Page 19: Accessories
CORNER CABINET MANTEL WITH Purchase these accessories from your local dealer. If they can not supply these BASE AND BLACK PERIMETER accessories call DESA Heating, LLC at TRIM 1-866-672-6040 for information. You can also C32AU - Unfinished, Traditional Design write to the address listed on the back page C32AOS - Light Oak Finish, Traditional of this manual. -
Page 20: Warranty
This is DESA Heating, LLC’s exclusive warranty, and to the full extent allowed by law; this express warranty excludes any and all other warranties, express or implied, written or verbal and limits the duration of any and all implied warranties, including warranties of merchantability and fitness for a particular purpose to four (4) years on new products and 30 days on factory reconditioned products from the date of first purchase.
