Page 1 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Two Wheel Drive Four Wheel Drive Anti-Lock Brake System Accessory Automatic Locking Retractor A-TRAC Active Traction Control AUTO LSD Automatic Limited Slip Differential Child Restraint System Downhill assist control Electronic Control Unit Event Data Recorder Emergency Locking Retractor GAWR Gross Axle Weight Rating...
Page 2 Abbreviation list ABBREVIATIONS MEANING Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Treadwear indicators Trailer Weight Rating Vehicle Identification Number Vehicle Stability Control I n f o r ma t i o n P r o v i d e d b y :...
Page 3: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 4 ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. Scrapping your Toyota The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals.
Page 5 The computers do not record conversations, sound or pictures. ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: •...
Page 6 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained •...
Page 7 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 8 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 9 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior and Air conditioning and audio systems, as well as other in- exterior features terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 10 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 534)
Page 11 1-1. Key information NOTICE ■ To prevent key damage (vehicles with engine immobilizer system) ● Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. ● Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
Page 12 1-2. Opening, closing and locking the doors ∗ Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.
Page 13 ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control system) can be changed. (Customizable features →P. 583)
Page 14 1-2. Opening, closing and locking the doors ■ Certification for wireless remote control MODEL/FCC IDs: Transmitter: GQ43VT20T Receiver: GQ4-34R IC (Canada) IDs: Transmitter: 1470A-1T Receiver: 1470A-6R MADE IN U.S.A. This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Page 15 1-2. Opening, closing and locking the doors Side doors The vehicle can be locked/unlocked using the wireless remote con- trol, key or door lock switch. ■ Wireless remote control (if equipped) →P. 36 ■ Regular Cab models Locks the door Unlocks the door Access Cab and Double Cab models Locks all doors...
Page 16 1-2. Opening, closing and locking the doors ■ Door lock switch (if equipped) Driver’s door lock switch Locks all doors Unlocks all doors Passenger’s door lock switch Locks all doors Unlocks all doors ■ Inside door lock button Locks the door Unlocks the door Pulling the inside handle can open the front door even if the...
Page 17 1-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside door lock button to the lock position. Close the door. Vehicles with power door lock system The door cannot be locked if a front door is open and the key is in the engine switch.
Page 18 1-2. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 19 1-2. Opening, closing and locking the doors Access doors (Access Cab models only) The access door (rear door) can be opened using the inside handle. Open the front door widely Pull (from the outside) or push (from the inside) the inside handle of the access door.
Page 20 1-2. Opening, closing and locking the doors Tailgate The tailgate can be opened. Pull the handle Open the tailgate slowly The support cables will hold the tailgate horizontal. After closing the tailgate, try pulling it toward you to make sure it is securely locked. Removing the tailgate ■...
Page 21 1-2. Opening, closing and locking the doors To disconnect the wire harness connectors ( ), press and hold the lock of the tailgate wire harness connector (White) and pull apart. Tailgate wire harness connec- tor (White) Frame wire harness connector (Gray) Attach connector...
Page 22 1-2. Opening, closing and locking the doors Pull out the wire harness from the vehicle bed. Attach connector cover (Gray) to the tailgate wire har- ness connector (White). Tailgate wire harness connec- tor (White) Connector cover (Gray) ■ Removing the tailgate Open the tailgate to the angle where you can release the brackets on the support cables...
Page 23 1-2. Opening, closing and locking the doors Slide the tailgate a little to the right to unhook the left side. To attach the tailgate, follow the removal procedure in reverse order. Rear step bumper For rear end protection and eas- ier step-up loading.
Page 24 1-2. Opening, closing and locking the doors NOTICE ■ To prevent damage to the tailgate wire harness (vehicles with rear view monitor system) Do not pull out all of the tailgate wire harness before open the tailgate. ■ To prevent damage to the camera lens (vehicles with rear view monitor system) Store the removed tailgate with the back-up camera lens facing upward.
Page 25 1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Bench type seat Seat position adjustment lever Separated type seats Seat position adjustment lever Driver’s seat lumbar sup- port adjustment knob (if equipped) Seatback angle adjustment lever I n f o r ma t i o n P r o v i d e d b y :...
Page 26 1-3. Adjustable components (seats, mirrors, steering wheel) Moving passenger’s seat for rear seat entry (if equipped) Lift the seatback angle adjusting lever or press the pedal behind the seatback. The seat will slide forward. Move the seat to the front-most position.
Page 27 1-3. Adjustable components (seats, mirrors, steering wheel) Folding passenger’s seat (vehicles with seatback table) Pull the seatback angle adjusting lever and raise the seatback to its upright position. Pull the seatback folding lever and fold the seatback down. I n f o r ma t i o n P r o v i d e d b y :...
Page 28 1-3. Adjustable components (seats, mirrors, steering wheel) Active head restraints (Access Cab and Double Cab models only) When occupant’s back presses against the seatback during a rear-end collision, the head restraint moves slightly for- ward to help reduce the risk of whiplash on the seat occupant.
Page 29 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment ● Be careful that the seat does not hit passengers or luggage. ● Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of...
Page 30 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats (Access Cab and Double Cab models) Access Cab models The bottom cushion of the rear seats can be raised and lowered. ■ Before raising the bottom cushion Stow the seat belt buckles. This prevents the seat belt buckles from falling out when you fold the seatback.
Page 31 1-3. Adjustable components (seats, mirrors, steering wheel) Double Cab models The seatback of the rear seat can be folded. ■ Before folding rear seats Stow the rear seat belt buck- les. This prevents the seat belt buckles from falling out when you fold the seatback.
Page 32 1-3. Adjustable components (seats, mirrors, steering wheel) Attach the head restraints to the holders located on the back sides of the bottom cush- ions. Fold down the seatback by pulling the lock release strap. ■ Waterproof and water-repellent seats (if equipped) Waterproof and water-repellent seats are installed in your vehicle;...
Page 33 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ When the seatback is folded/the bottom cushion is raised Do not sit on or place anything on the seatback or auxiliary box while driving. ■ When returning the seats to their original position Observe the following precautions.
Page 34 1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. ■ Adjusting the head restraints Bench type front seat Pull the head restraints up. Down Push the head restraint down while pushing the lock release button.
Page 35 1-3. Adjustable components (seats, mirrors, steering wheel) ■ When using the rear head restraints Access Cab models To use Lift up the head restraint until it locks. To fold Pull the head restraint lock release lever to fold the head restraint.
Page 36 1-3. Adjustable components (seats, mirrors, steering wheel) Separated type seat Pull the head restraint up while pushing the lock release button. ■ Removing the rear head restraints (Double Cab models only) Pull the head restraint up while pushing the lock release button. ■...
Page 37 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Installing the rear head restraints (Double Cab models only) Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint.
Page 38 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ●...
Page 39 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 40 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front seats) Move the height adjuster up as needed until you hear a click. Down Push the lock release button and slide the height adjuster down. ■...
Page 41 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 42 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 43 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 44 ● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts. Have any necessary repairs carried out by your Toyota dealer. Inappropriate handling of the pretensioner may prevent it from operating properly resulting in death or serious injury.
Page 45 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and press the lever down. Adjust to the ideal position by moving the steering wheel horizontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 46 1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position I n f o r ma t i o n P r o v i d e d b y :...
Page 47 1-3. Adjustable components (seats, mirrors, steering wheel) Auto anti-glare inside rear view mirror (type A) In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Turns automatic mode on/off The indicator comes on when automatic mode is turned on.
Page 48 1-3. Adjustable components (seats, mirrors, steering wheel) Auto anti-glare inside rear view mirror (type B) In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Turns automatic mode on/off The indicator comes on when automatic mode is turned on.
Page 49 1-3. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror display (vehicles with auto anti-glare inside rear view mirror) The inside rear view mirror displays the following information. Also, the display and display settings can be changed. ■ Compass →P.
Page 50 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury. I n f o r ma t i o n P r o v i d e d b y :...
Page 51 1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted. Power-adjustable type Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch. I n f o r ma t i o n P r o v i d e d b y :...
Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) Manually adjustable type Adjust the mirror up, down, in or out by pushing the mirror surface. Folding back the mirrors Push backward to fold the mir- rors. ■ Mirror operating conditions (vehicles with power-adjustable type only) The engine switch is in the ACC or ON position.
Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ When driving the vehicle Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an acci- dent, resulting in death or serious injury. ●...
Page 54 1-4. Opening and closing the windows ∗ Power windows The power windows can be opened/closed using the following switches. Driver’s power window switches Closing Opening One-touch opening (driver’s window only) *: Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 55 1-4. Opening and closing the windows ■ The power windows can be operated when The engine switch is in the ON position. ■ Operating the power windows after turning the engine off The power windows can be operated for approximately 43 seconds even after the engine switch is turned to the ACC or LOCK position.
Page 56 1-4. Opening and closing the windows Back window (vehicles with sliding type) The back window can be opened and closed using the lock release lever. Open/close Push the lock release lever and slide the back window. ■ Closing the back window Make sure that the back window is securely closed after closing it.
Page 57 1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the engine switch off and ensure that all the doors and win- dows are closed. ■ Opening the fuel tank cap Open the fuel filler door.
Page 58 1-5. Refueling Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction. ■ Fuel types Use unleaded gasoline. (Octane Rating 87 [Research Octane Number 91] or higher) ■...
Page 59 ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 60 1-6. Theft deterrent system ∗ Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the key has been removed from the engine switch to indi-...
Page 61 1-6. Theft deterrent system ■ Certifications for the engine immobilizer system For vehicles sold in U.S.A. FCC ID: MOZRI-21BTY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 62 1-6. Theft deterrent system For vehicles sold in New Caledonia “Hereby, Tokai Rika Co., Ltd., declares that this Immobilizer, model RI-21BTY, is in compliance with the essential require- ments and other relevant provisions of Directive 1999/5/EC.” NOTICE ■ To ensure the system operates correctly Do not modify or remove the system.
Page 63 1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 49) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 64 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 65 1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and right front...
Page 66 1-7. Safety information Airbag system components Vehicles with bench type front seat Vehicles with separated type front seat I n f o r ma t i o n P r o v i d e d b y :...
Page 67 1-7. Safety information Front passenger airbag Driver’s seat position sen- Curtain shield airbags Driver’s seat belt buckle Side airbags switch AIR BAG ON and AIR BAG Front passenger’s seat belt OFF indicator lights buckle switch warning light Occupant detection system RSCA OFF indicator light (ECU and sensors) Driver airbag...
Page 68 1-7. Safety information In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators. A chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occupants. ■...
Page 69 1-7. Safety information ● It is possible that in some collisions where the forward deceleration of the vehicle is very close to the designed threshold level, the SRS front air- bags and the seat belt pretensioners may not activate together. ●...
Page 70 1-7. Safety information The SRS curtain shield airbags may also deploy under the situation shown in the illustration. ● The angle of vehicle tip-up is marginal. ● The vehicle skids and hits a curb stone. ■ Types of collisions that may not deploy the SRS airbag (front airbags) The SRS front airbags are generally not designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low- speed frontal collision.
Page 71 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (side airbags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 72 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 73 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 74 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
Page 75 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 76 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 77 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 78 1-7. Safety information Deactivating the curtain shield airbags in a vehicle rollover (4WD models only) On/off (hold for a few seconds) The RSCA OFF indicator turns on (only when the engine switch is in the ON position.) The roll sensing function for the curtain shield airbags and seat belt pretensioners will turn back on automatically each time the...
Page 79 1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the right front passenger seat and activates or deactivates the devices for the front passenger.
Page 80 1-7. Safety information Conditions and operation of the front passenger occupant classification system ■ Adult* AIR BAG ON and AIR BAG OFF indica- AIR BAG ON tor lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder Flashing* light Front passenger airbag Side airbag on the front passenger seat...
Page 81 1-7. Safety information ■ Unoccupied AIR BAG ON and AIR BAG OFF indica- Not illumi- tor lights nated Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Activated Curtain shield airbag in the front passen-...
Page 82 1-7. Safety information : Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 108) : In case the indicator is not illuminated, consult this manual for installing the child restraint system properly.
Page 83 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 84 1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 85 1-7. Safety information Forward facing — Convertible seat Booster seat ■ Selecting an appropriate child restraint system ● Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. ●...
Page 86 ● Access Cab and Double Cab models: Toyota strongly urges the use of a proper child restraint system that conforms to the size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 87 1-7. Safety information CAUTION ■ Child restraint precautions ● Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or an accident.
Page 88 1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 89 1-7. Safety information ■ Using the seat belts Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts except driver’s seat belt) (→P. 63) ■ Using the top tether strap Regular Cab models with bench type seat Anchor bracket (for top tether strap) Anchor bracket is provided for each passenger seat.
Page 90 1-7. Safety information Regular Cab models with separated type seat Anchor bracket (for top tether strap) Anchor bracket is provided for passenger seat. Access Cab models Anchor bracket (for top tether strap) Anchor bracket is provided for each rear seat. I n f o r ma t i o n P r o v i d e d b y :...
Page 91 1-7. Safety information Double Cab models Anchor bracket (for top tether strap) Anchor bracket is provided for each rear seat. I n f o r ma t i o n P r o v i d e d b y :...
Page 92 1-7. Safety information Installation with LATCH system (Access Cab models) Type A Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor.
Page 93 1-7. Safety information Type B Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor. For owners in Canada: A symbol on a child restraint sys- tem indicates the presence of a lower connector system.
Page 94 1-7. Safety information Installation with LATCH system (Double Cab models) Type A Widen the gap between the seat cushion and seatback slightly. Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. If the child restraint has a top tether strap, the top tether strap should be latched...
Page 95 1-7. Safety information Type B Widen the gap between the seat cushion and seatback slightly. Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor. For owners in Canada: A symbol on a child restraint sys- tem indicates the presence of a...
Page 96 1-7. Safety information Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode.
Page 97 1-7. Safety information Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode.
Page 98 1-7. Safety information ■ Booster seat Place the booster seat on the seat facing the front of the vehi- cle. Sit the child in the booster seat. Fit the seat belt to the booster seat according to the manufac- turer’s instructions and insert the plate into the buckle.
Page 99 1-7. Safety information Child restraint systems with a top tether strap (Regular Cab models) ■ Bench type seat Remove the head restraint. Installing position: Right side passenger seat Center passenger seat Swing the seatback forward slightly (→P. 50) and remove the anchor bracket covers.
Page 100 1-7. Safety information Center passenger seat Route the top tether strap through the routing device as shown in the illustration. Make sure the top tether strap is not twisted. Latch the hook onto the anchor bracket. Return the seatback to its orig- inal position.
Page 101 1-7. Safety information ■ Separated type seat Remove the head restraint. Swing the seatback forward slightly (→P. 50) and remove the anchor bracket cover. Store the removed cover in a safe place such as the glove box. Route the top tether strap through the routing device as shown in the illustration.
Page 102 1-7. Safety information Replace the head restraint. Child restraint systems with a top tether strap (Access Cab models) Remove the anchor bracket cov- ers. Store the removed covers in a safe place such as the glove box. Secure the child restraint using a seat belt or lower anchors. Route the top tether strap through the routing device as shown in the illustration.
Page 103 1-7. Safety information Child restraint systems with a top tether strap (Double Cab models) Remove the head restraint. Installing position: Outside passenger seat Center passenger seat Outside passenger seat Swing the seatback forward slightly. (→P. 55) Latch the hook onto the anchor bracket.
Page 104 1-7. Safety information Secure the child restraint using a seat belt or lower anchors, and tighten the top tether strap. Make sure the top tether strap is securely latched. Replace the head restraint. Installing position: Outside passenger seat Center passenger seat ■...
Page 105 1-7. Safety information CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode. (→P. 65) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 106 1-7. Safety information CAUTION ■ When installing a child restraint system ● When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Page 107 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine →P. 143 ■ Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. (→P. 146) Release the parking brake.
Page 108 2-1. Driving procedures ■ Parking the vehicle Automatic transmission With the shift lever in D, depress the brake pedal. Set the parking brake. (→P. 154) Shift the shift lever to P. (→P. 146) When parking on a hill, if necessary, block the wheels. Turn the engine switch to the LOCK position to stop the engine.
Page 109 ■ Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended to observe: ●...
Page 110 If the smell of exhaust is noticed inside the vehicle, open the windows and check that the back window is closed. Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. ●...
Page 111 2-1. Driving procedures CAUTION ■ When driving the vehicle ● Do not shift the shift lever to R while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to D (vehicles with an automatic transmission) or 1 (vehicles with a manual transmission) while the vehicle is moving back- ward.
Page 112 2-1. Driving procedures CAUTION ■ When driving the vehicle ● Do not drive in excess of the speed limit. Even if the legal speed limit per- mits it, do not drive over 85 mph (140 km/h) unless your vehicle has high- speed capability tires.
Page 113 2-1. Driving procedures CAUTION ■ When the vehicle is stopped ● If the vehicle is stopped on an incline, in order to prevent accidents caused by the vehicle rolling forward or backward, always depress the brake pedal and securely apply the parking brake as needed. ●...
Page 114 ● Toyota does not recommend occupying the rear cargo area when it is fitted with a slide-in camper, camper shell or other type cover while the engine is running. This caution applies to both driving and stopped or parked situa- tions with the engine running.
Page 115 2-1. Driving procedures CAUTION ■ When braking the vehicle ● Do not pump the brake pedal if the engine stalls. Each push on the brake pedal uses up the reserve for the power-assisted brakes. ● The brake system consists of 2 individual hydraulic systems: If one of the systems fails, the other will still operate.
Page 116 If you hear a squealing or scraping noise while driving (brake pad wear limit indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
Page 117 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. ● Brake function ●...
Page 118 2-1. Driving procedures Engine (ignition) switch ■ Engine switch LOCK The steering wheel is locked and the key can be removed. (Vehicles with an automatic transmission: The key can be removed only when the shift lever is in P.) Some electrical components such as the audio system can be used.
Page 119 2-1. Driving procedures ■ Turning the key from ACC to LOCK Shift the shift lever to P (auto- matic transmission) or N (man- ual transmission). (→P. 146, 150) Push in the key and turn to the LOCK position. ■ Steering lock release When starting the engine, the engine switch may seem stuck in the LOCK posi- tion.
Page 120 2-1. Driving procedures CAUTION ■ Caution while driving Do not turn the engine switch to the LOCK position. If in an emergency, you must turn the engine off while the vehicle is moving, turn the engine switch only to the ACC position. NOTICE ■...
Page 121 2-1. Driving procedures ∗ Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever 5-speed models While the engine switch is on, depress the brake pedal and move the shift lever. ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 122 2-1. Driving procedures 4-speed models While the engine switch is on, depress the brake pedal and move the shift lever. ■ Shift position uses Function Shift position 5-speed models 4-speed models Parking the vehicle or starting the engine Reversing Neutral Normal driving Position for engine brak- —...
Page 123 2-1. Driving procedures ■ Downshifting restrictions The shift lever cannot be downshifted if the following speeds are exceeded. 2WD models mph (km/h) Maximum speed Downshifting 5-speed models 4-speed models 4 → 3 81 (130) — 3 → 2 56 (90) 71 (115) 2 →...
Page 124 2-1. Driving procedures ■ When driving with the cruise control system (if equipped) The engine brake will not operate when downshifting from D to 4 (5-speed models) or 3 (4-speed models). (→P. 174) ■ If the shift lever cannot be shifted from P →P.
Page 125 2-1. Driving procedures ∗ Manual transmission ■ Shifting the shift lever 6-speed models Fully depress the clutch pedal before operating the shift lever, and then release it slowly. 5-speed models Fully depress the clutch pedal before operating the shift lever, and then release it slowly.
Page 126 2-1. Driving procedures ■ Maximum allowable speed Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary. 2WD models except PreRunner mph (km/h) Maximum speed Shift position 6-speed models 5-speed models 32 (52) 33 (53) 61 (99) 63 (101) 91 (146)
Page 127 2-1. Driving procedures 4WD models mph (km/h) Maximum speed Shift position Transfer position 6-speed models 5-speed models H2 and H4 30 (49) 30 (48) 11 (19) 11 (18) H2 and H4 58 (93) 57 (92) 22 (36) 22 (36) H2 and H4 85 (137) 82 (133) 33 (53)
Page 128 2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change. The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 129 2-1. Driving procedures Parking brake Lever type ● Sets the parking brake Fully set the parking brake U.S.A. Canada while depressing the brake pedal. At this time, the indicator will come on. ● Release the parking brake Press the button Turn the lever clockwise Press it in completely Pedal type...
Page 130 2-1. Driving procedures ■ Parking brake engaged warning buzzer The buzzer sounds to indicate that parking brake is still engaged (with the vehicle having reach a speed of 3 mph [5 km/h]). ■ Usage in winter time See “Winter driving tips” for parking brake usage in winter time. (→P. 219) NOTICE ■...
Page 131 2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 132 2-2. Gauges and meters Gauges and meters The following gauges, meters and displays illuminate when the engine switch is in the ON position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Engine coolant temperature gauge Displays the engine coolant temperature.
Page 133 2-2. Gauges and meters Odometer/trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display differ- ent distances independently.
Page 134 2-2. Gauges and meters NOTICE ■ To prevent damage to the engine and its components ● Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed. ● The engine may be overheating if the engine coolant temperature gauge is in the red zone (H).
Page 135 2-2. Gauges and meters Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel I n f o r ma t i o n P r o v i d e d b y :...
Page 136 2-2. Gauges and meters ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Slip indicator (→P. 153) (→P. 190, 192, 201) Headlight high beam VSC OFF indicator indicator (→P. 165) (→P.
Page 137 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
Page 138 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 139 2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. Turning the end of the lever turns on the lights as follows: Type A Vehicles with day- time running light system: The daytime running lights turn side marker, parking, tail, license...
Page 140 2-3. Operating the lights and wipers Type B Vehicles with day- time running light system: The daytime running lights turn side marker, parking, tail, license plate, daytime run- Canada U.S.A. ning lights equipped) and instru- ment panel lights turn The headlights and all lights listed above (except daytime run- ning lights) turn on.
Page 141 2-3. Operating the lights and wipers ■ Daytime running light system (if equipped) ● To make your vehicle more visible to other drivers, the front turn signal lights turn on automatically whenever the engine is started and the park- ing brake is released. Daytime running lights are not designed for use at night.
Page 142 2-3. Operating the lights and wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. On/off ■ The fog lights can be turned on only when The headlights are on low beam. ∗...
Page 143 2-3. Operating the lights and wipers Windshield wipers and washer ■ Without intermittent type Type A speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation Washer operation I n f o r ma t i o n P r o v i d e d b y :...
Page 144 2-3. Operating the lights and wipers Type B speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation Washer operation I n f o r ma t i o n P r o v i d e d b y :...
Page 145 2-3. Operating the lights and wipers ■ Intermittent wiper with interval adjuster Wiper intervals can be adjusted for intermittent operation (when is selected). Type A Intermittent wind- shield wiper opera- tion speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation...
Page 146 2-3. Operating the lights and wipers Washer/wiper dual opera- tion Wipers will automatically oper- ate a couple of times after the washer squirts. Type B Intermittent wind- shield wiper opera- tion speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation...
Page 147 2-3. Operating the lights and wipers Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency STY23AF020 Washer/wiper dual opera- tion Wipers will automatically oper- ate a couple of times after the washer squirts. ■ The windshield wiper and washer can be operated when The engine switch must be in the ON position.
Page 148 2-3. Operating the lights and wipers NOTICE ■ When the windshield is dry Do not use the wipers, as they may damage the windshield. ■ When there is no washer fluid spray from the nozzle Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually.
Page 149 2-4. Using other driving systems ∗ Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicator Cruise control switch ■ Setting the vehicle speed Press the ON-OFF button to activate the cruise control. Cruise control indicator will come on.
Page 150 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 151 Have the vehicle inspected by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 152 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the ON-OFF button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 153 2-4. Using other driving systems Rear view monitor system (vehicles with auto anti-glare inside rear view mirror) The rear view monitor system assists the driver by displaying an image of the area behind the vehicle. The image is displayed in reverse on the screen.
Page 154 2-4. Using other driving systems ■ The rear view monitor system can be operated when The shift lever is in R and engine switch is ON. ■ Switching the screen on/off mode The rear view monitor display on the inside rear view mirror can be turned on/off.
Page 155 2-4. Using other driving systems ■ Displayed area The area covered by the camera is lim- ited. Objects that are close to either corner of the bumper or under the bumper cannot be seen on the screen. The area displayed on the screen may vary according to vehicle orientation or road conditions.
Page 156 2-4. Using other driving systems ■ Driving precautions When the grade behind the vehicle slopes up sharply, objects appear to be farther away than they actually are. When the grade behind the vehicle slopes down sharply, objects appear to be closer than they actually are. I n f o r ma t i o n P r o v i d e d b y :...
Page 157 2-4. Using other driving systems The distance that appears on the screen Approx. 1.5 ft. (0.5 m) between three-dimensional objects (such as vehicles) and flat surfaces (such as the road) and the actual distance differ as follows. In reality, C = A < B (C and A are equally far away;...
Page 158 2-4. Using other driving systems ■ Rear view monitor system camera The rear view monitor system camera is located on the tailgate as shown in the illustration. In the following cases, it may become dif- ficult to see the images on the screen, even when the system is functioning cor- rectly.
Page 159 Conditions which may affect the rear view monitor system ● If the back of the vehicle has been hit, the camera’s position and mounting angle may have changed. Have the vehicle inspected by your Toyota dealer. ● Rapid temperature changes, such as when hot water is poured on the vehicle in cold weather, may cause the system to function abnormally.
Page 160 2-4. Using other driving systems NOTICE ■ Handling of the camera ● As the camera has a water proof construction, do not detach, disassemble or modify it. This may cause incorrect operation. ● If the camera lens becomes dirty, it cannot transmit a clear image. If water droplets, snow, or mud adhere to the lens, rinse with water and wipe with a soft cloth.
Page 161 2-4. Using other driving systems ∗ Four-wheel drive system Use the front-wheel drive control switch to select the following transfer modes. H2 (high speed position, two-wheel drive) Use this for normal driving on dry hard-surfaced roads. This position gives greater economy, quietest ride and least wear.
Page 162 2-4. Using other driving systems Shifting between H4 and L4 ■ Shifting from H4 to L4 Automatic transmission Stop the vehicle completely with brake pedal help down. Shift the shift lever to N. Push and turn the front-wheel drive control switch fully clock- wise.
Page 163 If the indicator light continues to blink even if doing so, contact your Toyota dealer as soon as possible. There may be a trouble in the four-wheel drive system.
Page 164 2-4. Using other driving systems ■ Shifting to L4 VSC is automatically turned off. ■ Four-wheel drive usage frequency You should drive in four-wheel drive for at least 10 miles (16 km) each month. This will assure that the front-drive components are lubricated. CAUTION ■...
Page 165 2-4. Using other driving systems ∗ Active traction control system The active traction control system automatically helps prevent the spinning of 4 wheels when the vehicle is started or accelerated on slippery road surfaces. ■ System operation Vehicles with an automatic transmission: Stop the vehicle, shift the shift lever to N and put the front- wheel drive control switch in the L4 position.
Page 166 2-4. Using other driving systems ■ When the rear differential is locked (vehicles with the rear differential lock system) The active traction control system is activated only when the vehicle speed is less than 3 mph (6 km/h). ■ Sounds and vibrations caused by the active traction control system ●...
Page 167 2-4. Using other driving systems AUTO LSD system The AUTO LSD system aids traction by using the traction control system to control engine performance and braking when one of the rear wheels begins to spin. The system should be used only when one of the rear wheels spin- ning occurs in a ditch or rough surface.
Page 168 2-4. Using other driving systems ■ If the engine is turned off and restarted The AUTO LSD system and the indicators are automatically turned off. ■ Reactivation of the VSC system linked to vehicle speed When the AUTO LSD system is turned on, the VSC system will turn on auto- matically if vehicle speed increases.
Page 169 2-4. Using other driving systems ∗ Rear differential lock system The rear differential lock system is provided for use only when wheel spinning occurs in a ditch or on a slippery or rugged surface. The rear differential lock system is effective in case one of the rear wheels is spinning.
Page 170 2-4. Using other driving systems Manual transmission 4WD models: Before using the rear differential lock system. Stop the vehicle or reduce your speed to less than 2 mph (3 km/h). Depress the clutch pedal and put the front-wheel drive control switch in the L4 position to see if this is sufficient. If this has no effect, additionally use the rear differential lock system.
Page 171 2-4. Using other driving systems ■ After unlocking the rear differential To check that the indicator goes off, turn the engine switch to the ON posi- tion, but do not start the engine. CAUTION ■ To avoid an accident ● Do not use the rear differential lock system except when wheel spinning occurs in a ditch or on a slippery or ragged surface.
Page 172 2-4. Using other driving systems ∗ Downhill Assist Control system The downhill assist control system helps to prevent excessive speed on steep downhill descents. ■ System operation The system will operate when the vehicle is traveling under 15 mph (25 km/h) and the front-wheel drive control switch is in the L4 position.
Page 173 ● The downhill assist control system indicator does not come on when the DAC switch is pressed. In the above cases have your vehicle checked by your Toyota dealer. CAUTION ■ Do not rely excessively on the downhill assist control system It may not be able to maintain a low speed over road surfaces on which slid- ing can easily occur, such as extremely steep slopes or icy or muddy roads.
Page 174 2-4. Using other driving systems ∗ Clutch start cancel switch The switch allows the vehicle to be driven out of difficult situations by cranking the engine with the clutch engaged. Never use the switch for normal engine starting. Be sure to follow the starting procedure.
Page 175 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 176 2-4. Using other driving systems When the VSC/Trailer Sway Control/TRAC/hill-start assist control systems are operating If the vehicle is in danger of slip- ping or rolling backward when starting on an incline, or if any of the drive wheels spins, the slip indicator light flashes to indicate that the VSC/Trailer Sway Con- trol/TRAC/hill-start assist control...
Page 177 2-4. Using other driving systems To disable VSC, Trailer Sway Control and TRAC (2WD models and 2WD mode on 4WD models) If the vehicle gets stuck in fresh snow or mud, VSC, Trailer Sway Control and TRAC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
Page 178 2-4. Using other driving systems To disable VSC, Trailer Sway Control and/or TRAC (4WD mode on 4WD models) If the vehicle gets stuck in fresh snow or mud, VSC, Trailer Sway Control and TRAC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
Page 179 When the TRAC OFF indicator light comes on even if the VSC OFF switch has not been pressed TRAC, hill-start assist control, downhill assist control system cannot be oper- ated. Contact your Toyota dealer. ■ Reactivation of the TRAC, VSC and Trailer Sway Control systems after...
Page 180 2-4. Using other driving systems ■ Hill-start assist control will not operate when (if equipped) ● The shift lever is in the P, R or N positions. ● The rear differential is locked. ■ If the brake system overheats TRAC and hill-start control will cease operation and a buzzer will sound to alert the driver.
Page 181 The ABS, VSC, TRAC and Trailer Sway Control will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
Page 182 2-5. Driving information Off-road precautions (4WD models and PreRunner) This vehicle has higher ground clearance and narrower tread in rela- tion to the height of its center of gravity to make it capable of per- forming in a wide variety of off-road applications. Off-road vehicle feature ●...
Page 183 2-5. Driving information CAUTION ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 184 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 185 2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to minimize the risk of serious injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places. ●...
Page 186 2-5. Driving information NOTICE ■ To prevent the water damage ● Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
Page 187 ● For better fuel economy, do not carry unnecessary weight. ■ Deck rails Headboard rail Side rails To use the deck rails, you must install genuine Toyota accessories or their equiva- lent for the deck rails. Follow manufacturer’s instructions and precautions...
Page 188 2-5. Driving information CAUTION ■ When you secure cargo with the deck rails ● Spread out tie-down/support locations evenly along the length of the rails. ● Do not exceed a total tensile load of 440 lb. (200 kg) per deck rail. ●...
Page 189 2-5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Example on your vehicle Cargo capacity Total load capacity...
Page 190 2-5. Driving information CAUTION ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment. ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury.
Page 191 2-5. Driving information CAUTION ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
Page 192 2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ■ Total load capacity: (→P. 549) Total load capacity means the combined weight of occupants, cargo and luggage. ■...
Page 193 2-5. Driving information CAUTION ■ Overloading the vehicle Do not overload the vehicle. It may not only cause damage to the tires, but also degrade steering and braking ability, resulting in an accident. I n f o r ma t i o n P r o v i d e d b y :...
Page 194 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 195 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans- mission) or 1 or R (manual transmission) without setting the parking brake.
Page 196 2-5. Driving information ■ Snow chain installation Observe the following precautions when installing and removing chains. ● Install and remove tire chains in a safe location. ● Install tire chains on the rear tires only. Do not install tire chains on the front tires.
Page 197 NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 198 To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating condi- tions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional requirements such as towing kits, etc.
Page 199 2-5. Driving information Towing related terms ■ GCWR (Gross Combination Weight Rating) The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 200 2-5. Driving information ■ GAWR (Gross Axle Weight Rating) The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight.
Page 201 2-5. Driving information ■ Unbraked TWR (Unbraked Trailer Weight Rating) The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. ■ Tongue Weight The load placed on the trailer hitch ball. (→P. 232) I n f o r ma t i o n P r o v i d e d b y :...
Page 202 2-5. Driving information Weight limits ● The gross trailer weight must never exceed the TWR described in the table. (→P. 228, 551) ● The gross combination weight must never exceed the GCWR described in the table. (→P. 228) Regular Cab models and Double Cab models ●...
Page 203 2-5. Driving information GCWR, TWR, Unbraked TWR, Fifth wheel and Gooseneck towing TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. ■ GCWR and TWR Regular Cab models Driving Model code...
Page 204 2-5. Driving information Access Cab models Driving Model code Engine GCWR system TRN225L- 7440 lb. CRMDKA (3370 kg) TRN225L- 7470 lb. (3385 kg) CRPDKA 2.7 L TRN245L- 4-cylinder 7850 lb. 3500 lb. CRMDKA (2TR-FE) (3560 kg) (1585 kg) engine TRN245L- 7870 lb.
Page 205 2-5. Driving information Double Cab models Driving Model code Engine GCWR system TRN225L- 7450 lb. 3400 lb. 2.7 L PRPDKA (3375 kg) (1540 kg) 4-cylinder (2TR-FE) TRN265L- 7710 lb. 3500 lb. engine PRPDKA (3495 kg) (1585 kg) 8040 lb. 3500 lb. (3645 kg) (1585 kg) GRN245L-...
Page 206 1000 lb. (450 kg) ■ Fifth wheel and gooseneck towing TWR Toyota does not recommend fifth wheel and gooseneck towing. : These models meet the tow-vehicle trailering requirement of SAE International per SAE J2807. I n f o r ma t i o n P r o v i d e d b y :...
Page 207 2-5. Driving information Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 208 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 209 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
Page 210 2-5. Driving information Positions for towing hitch receiver and hitch ball Weight carrying ball position: 56.1 in. (1425 mm) Hitch receiver pin hole posi- tion: 44.2 in. (1123 mm) Connecting trailer lights Vehicles with 7 pin connector Use the wire harness stored in the rear end under the vehicle body.
Page 211 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 212 2-5. Driving information ● Reversing with a trailer attached is difficult and requires practice. Grip the bottom of the steering wheel and move your hand to the left to move the trailer to the left. Move your hand to the right to move the trailer to the right.
Page 213 2-5. Driving information ● Instability happens more frequently when descending steep or long downhill grades. Before descending, slow down and downshift. Do not make sudden downshifts while descending steep or long down- hill grades. ● Avoid holding the brake pedal down too long or applying the brakes too frequently.
Page 214 2-5. Driving information Release the parking brake (and also the brake pedal on vehi- cles with an automatic transmission), and slowly pull or back away from the wheel blocks. Stop and apply the brakes. Have someone retrieve the blocks. ■ Matching trailer ball height to trailer coupler height No matter which class of tow hitch applies, for a more safe trailer hookup,...
Page 215 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 216 2-5. Driving information ● After the trailer swaying has stopped: • Stop in a safe place. Get all occupants out of the vehicle. • Check the tires of the vehicle and the trailer. • Check the load in the trailer. Make sure the load has not shifted.
Page 217 2-5. Driving information CAUTION ■ To avoid accident or injury ● Do not exceed 65 mph (104 km/h), the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest. Slow down sufficiently before making a turn, in cross winds, on wet or slippery surface, etc.
Page 218 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 219 2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. I n f o r ma t i o n P r o v i d e d b y :...
Page 220 2-5. Driving information I n f o r ma t i o n P r o v i d e d b y :...
Page 221 3-1. Using the air conditioning system and defogger Air conditioning system Temperature control dial Air outlet selection dial Fan speed control dial Outside air or recirculated Air conditioning air mode switch ON/OFF switch Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
Page 222 3-1. Using the air conditioning system and defogger ■ Selecting the air outlets Set the air outlet selection dial to an appropriate position. The positions between the air outlet selections shown below can also be selected for more detailed adjustment. When the dial is set to , air flows to the upper body.
Page 223 3-1. Using the air conditioning system and defogger When the dial is set to , air flows to the feet and the wind- shield defogger operates. The air intake selector is automat- ically set to outside air mode. To return the recirculated air mode, press Double Cab models only When the dial is set to...
Page 224 3-1. Using the air conditioning system and defogger ■ If the ambient temperature drops while using the recirculated air mode The air intake mode automatically changes from recirculated air mode to outside air mode after a few minutes. To cancel this function: Press and hold for longer than 2 seconds.
Page 225 3-1. Using the air conditioning system and defogger Right and left side outlets Direct air flow to the left or right, up or down. Opening and closing the air outlets Center outlets Open the vent. Close the vent. I n f o r ma t i o n P r o v i d e d b y :...
Page 226 3-1. Using the air conditioning system and defogger Right and left side outlets Open the vent. Close the vent. ■ For quick clearing of the windshield and side windows Press to turn the air conditioning on. ■ Using the system in recirculated air mode The windows will fog up more easily if the recirculated air mode is used for an extended period.
Page 227 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not set the air outlet selection dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 228 3-2. Using the audio system Audio system types With Display Audio system Owners of models equipped with a Display Audio system should refer to the “Display Audio System Owner’s Manual”. Without Display Audio system Type A: CD player with changer controller and AM/FM radio I n f o r ma t i o n P r o v i d e d b y :...
Page 229: Table Of Contents
3-2. Using the audio system Type B: CD player with changer controller and AM/FM radio Title Page Using the radio P. 260 Using the CD player P. 267 Playing MP3 and WMA discs P. 273 Operating an iPod P. 280 Operating a USB memory P.
Page 230 3-2. Using the audio system Language settings Vehicles with Display Audio system Refer to “Display Audio System Owner’s Manual”. Vehicles without Display Audio system (type B only) The language used for all voice guidance, voice recognition and mes- sages may be changed. Press Press (MORE).
Page 231 3-2. Using the audio system ® ■ About Bluetooth (vehicles with Display Audio system) Bluetooth is a registered trademark of Bluetooth SIG. Inc. The Bluetooth wordmark and logo are owned by Bluetooth SIG. and permission has been granted to use the trademark of licensee Panasonic Corporation.
Page 232 3-2. Using the audio system CAUTION Vehicles with Display Audio system Properly shielded a grounded cables and connectors must be used for connection to host computer and/or peripherals in order to meet FCC emission limits. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Page 233: Using The Radio
3-2. Using the audio system Using the radio Type A Power Volume Adjusting the Station selector frequency (AM, FM mode) or channel (SAT mode) Seeking Changing the frequency the channel Scanning for AM⋅SAT/FM Displaying radio mode buttons text messages receivable stations Type B Power Volume...
Page 234 3-2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) Search for desired stations by turning pressing “∧” or “∨” on Press and hold a button (from ) until you hear a beep. Type B only: Each time is pressed, station pages are changed.
Page 235 3-2. Using the audio system ■ Displaying radio text messages (FM mode only) When a new radio text message is received, “MSG” is shown on the display. To display the message, press If the text continues past the end of the display, “ ”...
Page 236 3-2. Using the audio system ■ ® Scanning XM Satellite Radio channels ● Scanning channels in the current category Press When the desired channel is reached, press again. ● Scanning the preset channels Press and hold until you hear a beep. When the desired channel is reached, press again.
Page 237 3-2. Using the audio system ■ Reception sensitivity ● Type B only: Cargo loaded on the roof luggage carrier, especially metal ® objects, may adversely affect the reception of XM Satellite Radio. ● Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
Page 238 CHECK ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
Page 239 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877- 209-0079 (Canada) ■...
Page 240: Using The Cd Player
3-2. Using the audio system Using the CD player Type A Power Volume Selector buttons CD eject Selecting a track Fast-forwarding and reversing/ Displaying text Selecting a track Searching messages Playback playback Type B Power Volume Selector buttons CD eject Selecting a track Fast-forwarding...
Page 241 3-2. Using the audio system Loading CD Insert a CD. Ejecting CD Press and remove the CD. Selecting a track Turn or press “∧” or “∨” on to select the desired track. Fast-forwarding and reversing tracks Press and hold “∧” or “∨” on Scanning tracks Press The first 10 seconds of each track will be played.
Page 242 3-2. Using the audio system Random playback Type A: Press (RAND). Songs are played in random order. To cancel, press the button again. Type B: Press (RDM). Songs are played in random order. To cancel, press the button again. Repeat play Type A: Press (RPT).
Page 243 The CD may be dirty, damaged or inserted up-side down. “PLEASE WAIT”: Operation has stopped due to a high temperature inside the player. Wait for a while and then press Contact your Toyota dealer if the CD still cannot be played back. ■ Discs that can be used Discs with the marks shown below can be used.
Page 244 3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Discs. Doing so may damage the CD player and/or the CD insert/eject function. ●...
Page 245 3-2. Using the audio system NOTICE ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. ●...
Page 246: Playing Mp3 And Wma Discs
3-2. Using the audio system Playing MP3 and WMA discs Type A Power Volume Selector buttons CD eject Selecting a file Fast-forwarding Selecting a folder and reversing/ Selecting a file Displaying text Searching Playback messages playback Type B Power Volume Selector buttons CD eject Selecting a file...
Page 247 3-2. Using the audio system Loading and ejecting MP3 and WMA discs →P. 268 Selecting and scanning a folder ■ Selecting folders one at a time Press “∧” or “∨” on to select the desired folder. ■ Scanning the first file of all the folders Press and hold until you hear a beep.
Page 248 3-2. Using the audio system Playing and pausing files (type B only) Press Random playback Type A: Press (RAND). To cancel, press the button again. Type B: Press (RDM). To cancel, press the button again. Repeat play ■ Repeating a file Type A: Press (RPT).
Page 249 “PLEASE WAIT”: Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Con- tact your Toyota dealer if the CD still cannot be played. ■ Discs that can be used →P. 270 ■...
Page 250 3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. ® WMA (Windows Media Audio) is a Microsoft audio compression format.
Page 251 3-2. Using the audio system ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
Page 252 3-2. Using the audio system ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 253: Operating An Ipod
3-2. Using the audio system ∗ Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
Page 254: Control Panel
3-2. Using the audio system ■ Control panel Power Volume Selector buttons Selector knob Fast-forwarding and reversing/ Selecting a song Playback Displaying text Playback/ messages pause I n f o r ma t i o n P r o v i d e d b y :...
Page 255 3-2. Using the audio system Selecting a play mode Press (BROWSE) to select iPod menu mode. Press as that corresponds to the desired play mode. Press (MORE) to change to the second selection list. ■ Play mode list First Second Third Fourth Play mode...
Page 256 3-2. Using the audio system ■ Selecting a list Turn to display the first selection list. Press to select the desired item. Pressing that corresponds to “MORE” changes to the second selection list. Repeat the same procedure to select the desired song name. To return to the previous selection list, press Selecting songs from a song list Press...
Page 257 3-2. Using the audio system Playing and pausing songs Press Fast-forwarding and reversing songs ∧ Press and hold “ ” or “∨” on Shuffle playback ■ Playing songs from one playlist or album in random order Press (RDM). To cancel, press the button twice. ■...
Page 258 3-2. Using the audio system ■ About iPod ● Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. ● iPod is a trademark of Apple Inc., registered in the U.S. and other coun- tries.
Page 259 3-2. Using the audio system ■ Compatible models Model Generation Software version iPod 5th generation Ver. 1.2.0 or higher iPod nano 1st generation Ver. 1.3.0 or higher 2nd generation Ver. 1.1.2 or higher 3rd generation Ver. 1.0.0 or higher iPod touch 1st generation Ver.
Page 260 3-2. Using the audio system NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player. ● Do not push down on or apply unnecessary pressure to the iPod while it is connected as this may damage the iPod or its terminal.
Page 261: Operating A Usb Memory
3-2. Using the audio system ∗ Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a USB memory. Turn on the power of the USB memory if it is not turned on.
Page 262 3-2. Using the audio system ■ Control panel Power Volume Selector buttons Selecting a file Fast-forwarding Selecting a folder and reversing/ Playback Selecting a file Searching Displaying text Playback/ playback messages pause Selecting and scanning a folder ■ Selecting a folder Press “∧”...
Page 263 3-2. Using the audio system Selecting and scanning files ■ Selecting a file Turn or press “∧” or “∨” on to select the desired file. ■ Scanning the files in a folder Press The first 10 seconds of each file will be played. To cancel, press again.
Page 264 3-2. Using the audio system Repeat play ■ Repeating a file Press (RPT). To cancel, press the button twice. ■ Repeating all the files in a folder Press (RPT) twice. To cancel, press the button again. Switching the display Press Each time is pressed, the display changes in the following order: Track title →...
Page 265 3-2. Using the audio system ■ USB memory ● Compatible device USB memory that can be used for MP3 and WMA playback. Depending on the type of USB device, playback may not be possible. ● Compatible device formats The following device formats can be used: •...
Page 266 3-2. Using the audio system ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) MPEG2.5: 8, 11.025, 12 (kHz) •...
Page 267 3-2. Using the audio system ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 268: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Type A Adjusting the sound quality and ASL Type B Selector buttons Selector knob Menu button I n f o r ma t i o n P r o v i d e d b y :...
Page 269 3-2. Using the audio system Using the audio control function ■ Changing sound quality modes Type A: Pressing selects the mode to be changed in the following order: “BAS”→“TRE”→“FAD”→“BAL”→“ASL” Type B: Press Press as corresponds to the desired mode. “BASS”, “TREB”, “FADE”, or “BAL” I n f o r ma t i o n P r o v i d e d b y :...
Page 270 3-2. Using the audio system ■ Adjusting sound quality Type A: Turning adjusts the level. Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right Bass* -5 to 5 High Treble* -5 to 5 Front/rear Shifts to volume F7 to R7...
Page 271 3-2. Using the audio system Type B: Turning adjusts the level. Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right BASS Bass* -5 to 5 High TREB Treble* -5 to 5 Front/rear Shifts to FADE volume F7 to R7...
Page 272 3-2. Using the audio system Type B: Press Press (MORE). Press (ASL). Press as corresponds to the desired mode (OFF, LOW, MID, or HIGH). ASL automatically adjusts the volume and tone quality according to vehicle speed. ■ Setting the number of preset pages (type B only) The number of preset pages desired can be set from 1 to 6.
Page 273 3-2. Using the audio system Operating the sub woofer (on some Access Cab models) LIGHT ON The sub woofer illumination turns on. In this position, the sub woofer operates. I n f o r ma t i o n P r o v i d e d b y :...
Page 274: Using The Aux Port
3-2. Using the audio system Using the AUX port This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Open the cover and connect the portable audio device. Type A I n f o r ma t i o n P r o v i d e d b y :...
Page 275 3-2. Using the audio system Type B Press ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls. All other adjustments must be made on the portable audio device itself. ■...
Page 276: Using The Steering Wheel Audio Switches
3-2. Using the audio system ∗ Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Increases/decreases vol- Radio mode: Selects radio station CD mode: Selects track/file, folder and disc iPod mode: Selects a song memory mode: Selects a file and folder...
Page 277 3-2. Using the audio system Turning the power on Press when the audio system is turned off. The audio system can be turned off by holding the switch down until you hear a beep. Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time the switch is pressed.
Page 278 3-2. Using the audio system Selecting a track/file or song Press to select the CD, iPod, USB memory or Blue- ® tooth audio mode. Press “∨” or “∧” on to select the desired track/file or song. Selecting a folder or album ®...
Page 279 3-2. Using the audio system Detachable pole antenna The antenna can be removed. ■ Removing the antenna Place the included wrench around the antenna. When not in use, the wrench is stored in glove box. Loosen the antenna with the wrench and remove it.
Page 280 3-2. Using the audio system ■ Installing the antenna Tighten the antenna by one hand until it will not turn any more. Using the wrench, tighten the antenna an additional 1/8th turn (20 to 45 degrees) to secure it in place. After tightening the antenna, remove the wrench.
Page 281 3-2. Using the audio system NOTICE ■ To avoid damaging the antenna Remove the antenna in the following situations. ● When using an automatic carwash. ● When the antenna will touch the ceiling of a garage, etc. ● When covering the vehicle with a car cover. ■...
Page 282 ® 3-3. Using the Bluetooth audio system ® ∗ Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 283 ® 3-3. Using the Bluetooth audio system ® ■ About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. ■ Compatible models ® ● Bluetooth specifications: Ver. 1.2 ● Following Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0 •...
Page 284 ® 3-3. Using the Bluetooth audio system CAUTION ■ FCC WARNING Changes or modifications in construction not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio frequency exposure. This device is approved for Mobile Application only and, to comply with applicable FCC radio frequency exposure regula- tions, must be used with a distance of at least 7.9 in.
Page 285 ® 3-3. Using the Bluetooth audio system ® ∗ Using the Bluetooth audio system ■ Audio unit Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects items such as menu...
Page 286 ® 3-3. Using the Bluetooth audio system ■ Microphone I n f o r ma t i o n P r o v i d e d b y :...
Page 287 ® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, ® voice commands enable the operation of the Bluetooth audio sys- tem without the need to check the display or operate ■...
Page 288 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: Press until “BT AUDIO”...
Page 289 ® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system ■ Normal operation Second First menu Third menu Operation detail menu “Pair Audio Registering a portable player Player” “Select Audio Selecting a portable player to Player”...
Page 290 ® 3-3. Using the Bluetooth audio system ■ When using a voice command For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. ■ Situations that the system may not recognize your voice ●...
Page 291 ® 3-3. Using the Bluetooth audio system ® ∗ Operating a Bluetooth enabled portable player Power Volume Selector buttons Selecting a track Selecting an album Fast-forwarding and reversing/ Displaying text Playback Playback/ Selecting a track messages pause Selecting an album Press “∨”...
Page 292 ® 3-3. Using the Bluetooth audio system Fast-forwarding and reversing tracks ∧ Press and hold “ ” or “∨” on Switching the display Press Each time is pressed, the display changes in the following order: Track title → Track title/Artist name → Track title/Album name → Track title/Elapsed time Using the steering wheel audio switches →P.
Page 293 ® 3-3. Using the Bluetooth audio system ® ∗ Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: ■...
Page 294 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio Player” using a voice command or , and per- form the procedure for registering a portable player. (→P. 315) Selecting a portable player to be used Select “Select Audio Player”...
Page 295 ® 3-3. Using the Bluetooth audio system Changing the registered name of a portable player Select “Change Name” using a voice command or Select the name of the portable player to be changed by either of the following methods, and select “Confirm” using a voice command or a.
Page 296 ® 3-3. Using the Bluetooth audio system Listing the registered portable players Select “List Audio Players” using a voice command or . The list of registered portable players will be read aloud. When listing is complete, the system returns to “BT•A Setup”. Pressing the talk switch while the name of a portable player is being read aloud selects the portable player, and the following functions will become available:...
Page 297 ® 3-3. Using the Bluetooth audio system Deleting a registered portable player Select “Delete Audio Player” using a voice command or Select the portable player to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a.
Page 298 ® 3-3. Using the Bluetooth audio system ∗ ® Bluetooth audio system setup ■ System setup items and operation procedures ● Setting voice guidance volume 1. “Setup” → 2. “System Setup” → 3. “Guidance Volume” (→P. 352) ® ● Displaying the Bluetooth device address and name 1.
Page 299 3-4. Using the hands-free phone system (for cellular phone) ∗ Hands-free phone system features ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone. Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”.
Page 300 3-4. Using the hands-free phone system (for cellular phone) Title Page Using the hands-free phone system ■ Operating the system by using a voice command ■ Using the hands-free phone system for P. 330 the first time ■ Menu list of the hands-free phone sys- Making a phone call ■...
Page 301 ● OPP (Object Push Profile) Ver. 1.1 ■ For detailed information about Hands-free Phone System For assistance with pairing and operating your cell phone, go to the website www.toyota.letstalk.com. ® ■ About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc.
Page 302 3-4. Using the hands-free phone system (for cellular phone) CAUTION ■ FCC WARNING Changes or modifications in construction not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio frequency exposure. This device is approved for Mobile Application only and, to comply with applicable FCC radio frequency exposure regula- tions, must be used with a distance of at least 7.9 in.
Page 303 3-4. Using the hands-free phone system (for cellular phone) ∗ Using the hands-free phone system ■ Audio unit Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters, such as an umlaut, cannot be dis- played. Displays information that is too long to be displayed at one time on the display...
Page 304 3-4. Using the hands-free phone system (for cellular phone) ■ Steering wheel Volume The voice guidance volume cannot be adjusted using this button. Off-hook switch Turns the hands-free sys- tem on/starts a call On-hook switch Turns the hands-free sys- tem off/ends a call/refuses a call Talk switch Turns the voice command...
Page 305 3-4. Using the hands-free phone system (for cellular phone) ■ Microphone I n f o r ma t i o n P r o v i d e d b y :...
Page 306 3-4. Using the hands-free phone system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands enable the operation of the hands-free phone sys- tem without the need to check the display or operate ■...
Page 307 3-4. Using the hands-free phone system (for cellular phone) Register a phone name by either of the following methods. a. Select “Record Name” by using , and say a name to be registered. b. Press the talk switch and say a name to be registered. A voice guidance instruction to confirm the input is heard.
Page 308 3-4. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in “Callback” the incoming call history memory Dialing a number stored in “Redial”...
Page 309 3-4. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu “Set PIN” Setting a PIN code “Phonebook Locking the phone book “Security” Lock” “Phonebook Unlocking the phone book Unlock” Registering the cellular phone “Pair Phone”...
Page 310 3-4. Using the hands-free phone system (for cellular phone) ■ Using a short cut key First menu Second menu Operation detail Dialing a number registered “Dial XXX (name)” in the phone book “Dial XXX (number)” Dialing the input numbers “Phone book add Adding a new number entry”...
Page 311 3-4. Using the hands-free phone system (for cellular phone) ■ Automatic volume adjustment When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. ■...
Page 312 3-4. Using the hands-free phone system (for cellular phone) ∗ Making a phone call ■ Making a phone call ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ●...
Page 313 3-4. Using the hands-free phone system (for cellular phone) Dialing by inputting a number Press the talk switch and say “Dial by number”. Press the talk switch and say the phone number. Dial by one of the following methods: a. Press the off-hook switch. b.
Page 314 3-4. Using the hands-free phone system (for cellular phone) When receiving a phone call ■ Answering the phone Press the off-hook switch. ■ Refusing the call Press the on-hook switch. Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call.
Page 315 3-4. Using the hands-free phone system (for cellular phone) Using the call history memory Follow the procedure below to use a number stored in the call history memory: Press the talk switch and say “Redial” (when using a number stored in the outgoing call history memory) or “Call back” (when using a number stored in the incoming call history memory).
Page 316 3-4. Using the hands-free phone system (for cellular phone) ■ Call history Up to 5 numbers can be stored in each of the outgoing and incoming call his- tory memories. ■ When talking on the phone ● Do not talk simultaneously with the other party. ●...
Page 317 3-4. Using the hands-free phone system (for cellular phone) ∗ Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered cellular phones: ■ Functions and operation procedures To enter the menu for each function, follow the steps below by using a voice command or...
Page 318 3-4. Using the hands-free phone system (for cellular phone) Registering a cellular phone Select “Pair Phone” by using a voice command or , and do the procedure for registering a cellular phone. (→P. 333) Selecting the cellular phone to be used Select “Select Phone”...
Page 319 3-4. Using the hands-free phone system (for cellular phone) Changing a registered name Select “Change Name” by using a voice command or Select the name of the cellular phone to be changed by either of the following methods: a. Press the talk switch and say the desired phone name, and select “Confirm”...
Page 320 3-4. Using the hands-free phone system (for cellular phone) Listing the registered cellular phones Selecting “List Phones” by using a voice command or causes the list of registered cellular phones to be read aloud. When listing is complete, the system returns to “Phone Setup”. Pressing the talk switch while the name of a cellular phone is being read selects the cellular phone, and the following functions will be available:...
Page 321 3-4. Using the hands-free phone system (for cellular phone) Changing the passkey Select “Set Passkey” by using a voice command or Press the talk switch, say a 4 to 8-digit number, and select “Confirm” by using a voice command or The number should be input 1 digit at a time.
Page 322 3-4. Using the hands-free phone system (for cellular phone) ■ Turning on the automatic connection Select “Handsfree Power” by using a voice command or Select “Turn on” by using a voice command or ■ The number of cellular phones that can be registered Up to 6 cellular phones can be registered in the system.
Page 323 3-4. Using the hands-free phone system (for cellular phone) ∗ Security and system setup To enter the menu of each setting, follow the steps below: ■ Security setting items and operation procedure ● Setting or changing the PIN (Personal Identification Number) 1.
Page 324 3-4. Using the hands-free phone system (for cellular phone) Setting or changing the PIN ■ Setting a PIN Select “Set PIN” by using a voice command or Enter a PIN by using a voice command or When using , input the code 1 digit at a time. ■...
Page 325 3-4. Using the hands-free phone system (for cellular phone) Locking or unlocking the phone book Select “Phonebook lock” or “Phonebook unlock” by using a voice command or Input the PIN by either of the following methods and select “Confirm” by using a voice command or a.
Page 326 3-4. Using the hands-free phone system (for cellular phone) ® Displaying the Bluetooth device address and name Select “Device Name” using ® Turn to display the Bluetooth device address and name. Select “Go Back” using to return to “System Setup”. Initialization Select “Initialize”...
Page 327 3-4. Using the hands-free phone system (for cellular phone) ■ Initialization ● The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code ●...
Page 328 3-4. Using the hands-free phone system (for cellular phone) ∗ Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook” → 2. “Add Entry” ● Setting speed dial 1.
Page 329 3-4. Using the hands-free phone system (for cellular phone) ■ Adding procedure Select “Add Entry” by using a voice command or Use one of the following methods to input a telephone num- ber: Inputting a telephone number by using a voice command STEP2-1 Select “By Voice”...
Page 330 3-4. Using the hands-free phone system (for cellular phone) Inputting a phone number by using STEP2-1 Select “Manual Input” by using STEP2-2 Input a phone number by using , and press once again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History”...
Page 331 3-4. Using the hands-free phone system (for cellular phone) Select the name to be registered by either of the following methods, and select “Confirm” by using a voice command or a. Press the talk switch and say the desired name. b.
Page 332 3-4. Using the hands-free phone system (for cellular phone) Setting speed dials Select “Set Speed Dial (Speed Dial)” by using a voice com- mand or Select the data to be registered as a speed dial by either of the following methods: a.
Page 333 3-4. Using the hands-free phone system (for cellular phone) Changing a registered name Select “Change Name” by using a voice command or Select the name to be changed by either of the following methods. a. Press the talk switch, say desired name, and select “Confirm”...
Page 334 3-4. Using the hands-free phone system (for cellular phone) Deleting registered data Select “Delete Entry” by using a voice command or Select the data to be deleted by either of the following meth- ods, and select “Confirm” by using a voice command or a.
Page 335 3-4. Using the hands-free phone system (for cellular phone) Listing the registered data Selecting “List names” by using a voice command causes a list of the registered data to be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following functions will be available.
Page 336 3-5. Using the interior lights Interior lights list Interior light (→P. 364) Personal lights (Access Cab and Double Cab models) (→P. 364) ■ Illuminated entry system When the interior light switch is in the DOOR position, the interior light auto- matically turns on/off according to whether the doors are locked/unlocked and whether the doors are open/closed.
Page 337 3-5. Using the interior lights Interior light and personal lights Interior light DOOR position Personal lights (Access Cab and Double Cab models) On/off I n f o r ma t i o n P r o v i d e d b y :...
Page 338 3-6. Using the storage features List of storage features Glove box Overhead console (Access Cab and Double Cab models) Bottle holders Auxiliary boxes Front console box (separated type front seat only) Cup holders CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 339 3-6. Using the storage features Glove box and front console box Glove box Pull up the lever. CAUTION ■ Caution while driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking. Front console box (Separated type front seat only) Push the button.
Page 340 3-6. Using the storage features Cup holders Cup holders Type A (Bench type front seat) Type B (Separated type front seats with an automatic transmis- sion) Type C (Separated type front seats with a manual transmission) I n f o r ma t i o n P r o v i d e d b y :...
Page 341 3-6. Using the storage features Cup holders ■ Removing the cup holder Type A (Bench type front seat) Pull the cup holder up. Type B (Separated type front seats with an automatic transmission) Pull the cup holder up. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders.
Page 342 3-6. Using the storage features Bottle holders Bottle holders Front Front console box (Separated type front seat) Rear (Double Cab models) ■ Bottle holders Depending on their size or shape, some bottles may not fit in the holders. I n f o r ma t i o n P r o v i d e d b y :...
Page 343 3-6. Using the storage features Bottle holders and auxiliary boxes NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid. The contents may spill and glasses may break.
Page 344 3-6. Using the storage features Auxiliary boxes Turn the knob counterclockwise. Open the lid. Press the lid against the bot- tom of the lower cushion until it is supported by the hook- and-loop fastener. Make sure that the lid is sup- ported to prevent it from closing unexpectedly.
Page 345 3-6. Using the storage features Auxiliary boxes and overhead console CAUTION ■ Caution while driving Keep the auxiliary boxes closed and locked. Injuries may result in the event of an accident or sudden braking. Overhead console (Access Cab and Double Cab models) The overhead console is useful for temporarily storing sunglasses and similar small items.
Page 346 3-7. Other interior features Sun visors Type A Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Type B Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide backwards.
Page 347 3-7. Other interior features Vanity mirrors Vehicles without vanity light Vehicles with vanity light Slide the cover. The light turns on when the cover is opened. I n f o r ma t i o n P r o v i d e d b y :...
Page 348 3-7. Other interior features Clock Adjusts the hours Adjusts the minutes ■ The clock is displayed when The engine switch is in the ACC or ON position. ■ When disconnecting and reconnecting battery terminals The time display will automatically be set to 1:00. I n f o r ma t i o n P r o v i d e d b y :...
Page 349 3-7. Other interior features Outside temperature display (vehicles with auto anti-glare inside rear view mirror) The temperature display shows temperatures within the ranges of -40°F (-40°C) and 122°F (50°C). ■ Outside temperature display Type A Type B ■ Ice advisory indicator If the outside temperature low- ers to 37°F (3°C) or below when the engine switch is in...
Page 350 3-7. Other interior features Changing the display The outside temperature display on the inside rear view mirror can be turned on/off and the display units can be changed. ■ Turning the outside temperature display on/off Type A: Press and hold to display “Custom Settings Menu”.
Page 351 3-7. Other interior features ■ Changing display units Type A: Press and hold to display “Custom Settings Menu”. Type B: Press to display “Custom Settings Menu”. Type A: Press and select “Outside Temperature”, then press and hold Type B: Press and select “Outside Temperature”, then press...
Page 352 3-7. Other interior features Setting the ice advisory indicator The ice advisory indicator on the inside rear view mirror can be turned on/off. Type A: Press and hold to display “Custom Settings Menu”. Type B: Press to display “Custom Settings Menu”. Type A: Press and select “Ice Advisory”.
Page 353 ■ When “– –” or “– – –” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Customization that can be configured for the inside rear view mirror display Settings (e.g.
Page 354 3-7. Other interior features Power outlets (12V DC) The power outlets can be used for 12V accessories that run on less than 10A. ■ The power outlets can be used when The engine switch is in the ACC or ON position. NOTICE ■...
Page 355 3-7. Other interior features ∗ Power outlet (120V AC) The power outlet can be used for electrical appliances. Main switch To use the power outlet, turn on the main switch. The power supply starts a few seconds after the main switch is pressed.
Page 356 3-7. Other interior features • The shift lever is in N and the clutch pedal is not depressed. (manual transmission) A maximum capacity of 400W can only be restored by turning the power outlet main switch off and then on again under condi- tion described above.
Page 357 If the power supply is not resumed even after performing the above proce- dure, have the vehicle inspected by a Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 358 Do not modify, disassemble or repair the power outlet or its inverter, in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact a Toyota dealer for any necessary repairs. ■...
Page 359 3-7. Other interior features NOTICE ■ To avoid damaging the power outlet and the plug ● Close the power outlet lid when not in use. ● Foreign objects or liquids that enter the power outlet may cause a short circuit. ●...
Page 360 If the power outlet is loose when an electrical appliance plug is con- nected Replace the outlet. Contact a Toyota dealer for any necessary replacements. ■ If the power outlet gets dirty Turn the main switch off and use a soft, clean cloth to wipe it gently.
Page 361 3-7. Other interior features ∗ Seatback table Front passenger’s seatback can be used as a temporary table only when the vehicle is stopped. Fold down the front passen- ger’s seat to use the seatback table. (→P. 51) CAUTION ■ Caution while driving Observe the following precautions to avoid death or serious injury.
Page 362 3-7. Other interior features Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eye- lets.
Page 363 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 364 3-7. Other interior features Luggage compartment features Behind the rear seat (Double Cab models only) Cargo net hooks (vehicles with sub woofer) Grocery bag hooks Flashlight holder Storage boxes Deck Auxiliary boxes Tie-down cleats Deck hooks I n f o r ma t i o n P r o v i d e d b y :...
Page 365 3-7. Other interior features Auxiliary boxes Left side Turn the knob counterclock- wise. Open the lid. Right side (vehicles without 120V power outlet) Turn the knob counterclock- wise. Open the lid. Right side (vehicles with 120V power outlet) Turn the knob counterclock- wise.
Page 366 3-7. Other interior features CAUTION ■ Caution while driving Keep the auxiliary boxes closed and locked. Injuries may result in the event of an accident or sudden braking. Deck hooks Deck hooks are provided for securing loose items. CAUTION ■ When not in use Keep the deck hooks folded.
Page 367 3-7. Other interior features Tie-down cleats The deck rail system enables you to insert and move tie-down cleats to their best location along deck rails to secure a load. Locking plate Thumb wheel Tie-down cleat ■ Installing the tie-down cleat Loosen the thumb wheel in a counterclockwise motion, and depress the wheel so that the...
Page 368 3-7. Other interior features Insert the locking plate into the deck rail, rotate the tie-down cleat 90°, and release the thumb wheel. Slide the cleat to the closest detent in the rail system. You will feel that the locking plate snaps into a detent.
Page 369 3-7. Other interior features CAUTION ■ Tie-down cleat precautions ● Properly install and tighten the tie-down cleats into the deck rail system. Failure to properly install and tighten the tie-down cleats can cause cargo to become unsecured. Unsecured cargo can cause injury when the vehi- cle is in motion.
Page 370 3-7. Other interior features Left side ■ Removing the separator Remove the separator. It can be installed in various positions as required. Flashlight holder (Double Cab models only) Flashlight holder is designed to hold the flashlight securely. I n f o r ma t i o n P r o v i d e d b y :...
Page 371 3-7. Other interior features ■ Removing the flashlight holder Remove the flashlight holder. It can be installed in various positions as required. Grocery bag hooks (Double Cab models only) Grocery bag hook is designed to hang things like grocery bag. NOTICE ■...
Page 372 3-7. Other interior features Cargo net hooks (Double Cab models with sub woofer) Cargo net hooks are designed to hang the factory-supplied cargo net. NOTICE ■ To prevent damage to the cargo net hook Do not hang items other than the cargo net. I n f o r ma t i o n P r o v i d e d b y :...
Page 373 3-7. Other interior features ∗ Garage door opener The garage door opener can be trained to operate garage doors, gates, entry doors, door locks, home lighting systems, security sys- tems, and other devices. The training procedure is displayed on the inside rear view mirror display screen.
Page 374 3-7. Other interior features ■ ® Training the HomeLink Point the remote control trans- mitter for the device 1 to 3 in. (25 ® to 75 mm) from the HomeLink control buttons. Keep indicator ® HomeLink in view while training. Press and hold down one of the ®...
Page 375 3-7. Other interior features Test operation ® HomeLink pressing newly trained button. If training a garage door opener, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the Rolling Code type.
Page 376 3-7. Other interior features ■ Training a Rolling Code system (for U.S. owners) If your device is Rolling Code equipped, follow the steps under the ® heading “Training the HomeLink ” before proceeding with the steps listed below. Locate the learn button on the ceiling mounted garage door opener motor.
Page 377 HomeLink buttons. ■ Training other devices To train other devices such as home security systems, home door locks and lighting, contact your Toyota dealer for assistance. ■ Retraining a button ® The individual HomeLink buttons cannot be erased but can be ®...
Page 378 3-7. Other interior features ® Operating HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator light should come on. ® The HomeLink compatible transceiver in your vehicle continues to send a signal for up to 20 seconds as long as the button is pressed. ®...
Page 379 3-7. Other interior features ■ Before training ● Install a new battery in the remote control transmitter. ● The battery side of the remote control transmitter must be pointed away ® from the HomeLink button. ■ Certification for the garage door opener FCC ID: NZLGHSHL4 For vehicles sold in the U.S.A.
Page 380 3-7. Other interior features ■ If the following message is displayed This message appears when training procedures have not been performed correctly. Follow the instructions on the screen to complete or cancel train- ing. Pattern A Pattern B ■ When support is necessary Visit on the web at www.homelink.com or call 1-800-355-3515.
Page 381 3-7. Other interior features CAUTION ■ When training a garage door or other remote control devices The garage door or other devices may operate, so ensure people and objects are out of danger to prevent potential harm. ■ Conforming to federal safety standards ®...
Page 382 3-7. Other interior features Compass (vehicles with auto anti-glare inside rear view mirror) The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. ■ Location Type A Type B I n f o r ma t i o n P r o v i d e d b y :...
Page 383 3-7. Other interior features ■ Displays and directions Display Direction North Northeast East Southeast South Southwest West Northwest I n f o r ma t i o n P r o v i d e d b y :...
Page 384 3-7. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies depending on the geographic position of the vehicle. If you cross over one of the map boundaries shown in the illustration, the compass will deviate.
Page 385 3-7. Other interior features Type A: Press and select “Compass”, then press and hold Type B: Press and select “Compass”, then press Type A: Press and select “Compass Display”. Type B: Press and select “Compass Display”. Type A: Press and hold and select display on/off.
Page 386 3-7. Other interior features Type A: Press and select “Zone”, then press and hold Type B: Press and select “Zone”, then press Type A: The selected country changes each time is pressed. Select the country, then press and hold confirm. Type B: The selected country changes each...
Page 387 3-7. Other interior features Circling calibration If “C” appears on the display, circling calibration needs to be per- formed. Stop the vehicle in a place where it is safe to drive in a circle. Type A: Press and hold to display “Custom Settings Menu”.
Page 388 3-7. Other interior features Drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until a direction is dis- played.
Page 389 3-7. Other interior features CAUTION ■ While driving the vehicle Do not adjust the display. Adjust the display only when the vehicle is stopped. ■ When doing the circling calibration Secure a wide space, and watch out for people and vehicles in the vicinity. Do not violate any local traffic rules while performing circling calibration.
Page 390 4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 391 4-1. Maintenance and care ■ Aluminum or chrome cladded wheels (if equipped) ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. ●...
Page 392 4-1. Maintenance and care NOTICE ● Clean the drainage hole of the deck regularly. If the drainage hole is stopped up, the water will not be able to flow, and it will cause rust. ■ Cleaning the exterior lights ● Wash carefully.
Page 393 ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. I n f o r ma t i o n P r o v i d e d b y :...
Page 394 4-1. Maintenance and care ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam. Rub in overlapping circles. Do not apply water. The excellent results are obtained when keeping the carpet as dry as possible.
Page 395 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...
Page 396 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 397 4-2. Maintenance ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 398 “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 399 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 400 4-2. Maintenance Items Check points • Moves smoothly? Steering wheel • Has correct free play? • No strange noises? Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? •...
Page 401 If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
Page 402 • FMVSS No.116 DOT 3 or SAE Brake fluid level (→P. 444) J1703 brake fluid • Rag or paper towel • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 403 4-3. Do-it-yourself maintenance Items Parts and tools • Bulb with same number and watt- age rating as original Light bulbs (→P. 484) • Phillips-head screwdriver • Conventional wrench • Automatic transmission fluid Power steering fluid level ® DEXRON II or III (→P.
Page 404 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fan and engine drive belt.
Page 405 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment. ■...
Page 406 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. I n f o r ma t i o n P r o v i d e d b y :...
Page 407 4-3. Do-it-yourself maintenance Hold the hood open by insert- ing the supporting rod into the slot. CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury.
Page 408 4-3. Do-it-yourself maintenance Engine compartment 2.7 L 4-cylinder (2TR-FE) engine Washer fluid tank (→P. 450) Engine oil level dipstick (→P. 438) Radiator cap Brake fluid reservoir Engine coolant reservoir (→P. 444) (→P. 443) Fuse box (→P. 474) Engine oil filler cap (→P.
Page 409 4-3. Do-it-yourself maintenance 4.0 L V6 (1GR-FE) engine Washer fluid tank (→P. 450) Engine oil filler cap (→P. 439) Power steering fluid reservoir (→P. 446) Brake fluid reservoir (→P. 444) Radiator cap Fuse box (→P. 474) Engine oil level dipstick (→P.
Page 410 4-3. Do-it-yourself maintenance Engine oil Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 411 4-3. Do-it-yourself maintenance 2.7 L 4-cylinder (2TR-FE) engine Full 4.0 L V6 (1GR-FE) engine Full ■ Adding engine oil 2.7 L 4-cylinder (2TR-FE) engine If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine.
Page 412 4-3. Do-it-yourself maintenance 4.0 L V6 (1GR-FE) engine Make sure to check the oil type and prepare the items needed before adding oil. →P. 556 Engine oil selection Items Clean funnel Remove the oil filler cap, turning it counterclockwise. Add engine oil slowly. Checking the dipstick.
Page 413 ● If you consume more than 1.1 qt. (1.0 L, 0.9 lmp.qt.) every 600 miles (1000 km), contact your Toyota dealer. ■ After changing the engine oil (U.S.A. only) The engine oil maintenance data should be reset. Perform the following pro- cedures: Switch the display to the trip meter A when the engine is running.
Page 414 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 415 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. ■...
Page 416 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
Page 417 4-3. Do-it-yourself maintenance Type B MAX line MIN line ■ Adding fluid Make sure to check the fluid type and prepare the necessary items. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Rag or paper towel Type B only Turn the engine off.
Page 418 4-3. Do-it-yourself maintenance CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces. If fluid gets on your hands or in your eyes, flush the affected area with clean water immediately.
Page 419 4-3. Do-it-yourself maintenance Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures. (Fluid temperature, 104°F - 175°F [40°C - 80°C]) Cold: Engine has not been run for about 5 hours. (Room tem- perature, 32°F - 104°F [0°C - 40°C]) 4.0 L V6 (1GR-FE) engine Full (when cold)
Page 420 4-3. Do-it-yourself maintenance CAUTION ■ Checking the fluid level Take care, as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
Page 421 4-3. Do-it-yourself maintenance ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive. Therefore, before recharging: ● If recharging with the battery installed on the vehicle, be sure to discon- nect the ground cable. ● Make sure the power switch on the charger is off when connecting and disconnecting the charger cables to the battery.
Page 422 4-3. Do-it-yourself maintenance CAUTION ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 423 4-3. Do-it-yourself maintenance Add washer fluid. CAUTION ■ When refilling the washer fluid Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■...
Page 424 ■ The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 508) I n f o r ma t i o n P r o v i d e d b y :...
Page 425 ID codes must be regis- tered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and trans- mitter ID codes registered by your Toyota dealer. (→P. 454) Initializing the tire pressure warning system ■...
Page 426 ID code of tire pressure warning valve and transmitter. Have the ID code registered by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 427 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 428 4-3. Do-it-yourself maintenance Access Cab models ■ Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 429 Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
Page 430 4-3. Do-it-yourself maintenance ■ Tire pressure warning system certification FCC ID: PAXPMV107J PAXPMV108J FCC ID: HYQ13BCX For vehicles sold in U.S.A. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 431 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 432 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 433 4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 564) Regular Cab and Double Cab models I n f o r ma t i o n P r o v i d e d b y :...
Page 434 4-3. Do-it-yourself maintenance Access Cab models I n f o r ma t i o n P r o v i d e d b y :...
Page 435 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. Press the tip of the tire pressure gauge onto the tire valve. Read the pressure using the graduations of the gauge. If the tire inflation pressure is not within the recommended levels, adjust inflate the tire.
Page 436 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 437 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
Page 438 ● Bent wheels that have been straightened ■ Wheel precautions ● Use only Toyota wheel nuts and wrench designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 100 miles (160 km).
Page 439 ■ When replacing wheels The wheels of your Toyota are equipped with tire pressure warning valves and transmitters (except for spare tire) that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.
Page 440 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 441 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the engine switch to the LOCK position. Open the glove box. Slide off the damper. Push in each side of the glove box to disconnect the claws.
Page 442 4-3. Do-it-yourself maintenance Open the filter door. Remove the filter. ■ Replacement method Remove the air conditioning filter and replace it with a new one. When installing the filter, follow the instructions indicated on the label. I n f o r ma t i o n P r o v i d e d b y :...
Page 443 4-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.) ■...
Page 444 4-3. Do-it-yourself maintenance ∗ Wireless remote control battery Replace the battery with a new one if it is discharged. ■ You will need the following items: Lithium battery CR2032 ■ Replacing the battery Remove the cover using a coin protected with tape etc. Remove the discharged trans- mitter battery.
Page 445 ● The operational range is reduced. ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer. ●...
Page 446 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch to the LOCK position. The fuses are located in the following places. To check the fuses, follow the instructions below.
Page 447 4-3. Do-it-yourself maintenance After a system failure, see “Fuse layout and amperage ratings” (→P. 477) for details about which fuse to check. Remove the fuse with the pull- out tool. Check if the fuse has blown. Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
Page 448 4-3. Do-it-yourself maintenance Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
Page 449 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Type A Type B I n f o r ma t i o n P r o v i d e d b y :...
Page 450 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 10 A Air conditioning system TOWING TAIL 30 A Trailer lights (tail lights) FR FOG 15 A Front fog lights Stop lights, high mounted stop- light, vehicle stability control sys- tem, anti-lock brake system, shift STOP 10 A lock system, multiport fuel injection...
Page 451 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ 20 A sequential multiport fuel injection system HORN 10 A Horn Multiport fuel injection system/ A/F HEATER 15 A sequential multiport fuel injection system Wireless remote control system, air conditioning system, multiplex communication system, meter and ECU-B 7.5 A...
Page 452 4-3. Do-it-yourself maintenance Fuse Ampere Circuit IGN and GAUGE fuses, multiport 30 A fuel injection system/sequential multiport fuel injection system Multiport fuel injection system/ A/PUMP 50 A sequential multiport fuel injection system Anti-lock brake system, vehicle sta- ABS NO.2 30 A bility control system AC SKT 100 A...
Page 453 4-3. Do-it-yourself maintenance ■ Under the instrument panel Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection system, anti-lock brake system, 15 A traction control system, vehicle sta- bility control system, SRS airbag system, front passenger occupant classification system Meter and gauge, emergency GAUGE 7.5 A...
Page 454 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Anti-lock brake system, vehicle sta- bility control system, stop lights, charging system, multiport fuel injection system/sequential multi- port fuel injection system, air condi- IG1 NO.2 10 A tioning system, instrument panel light control, anti-glare inside rear view mirror, back monitor, clutch start cancel switch, rear differential lock system, power outlets, tire...
Page 455 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
Page 456 You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 457 4-3. Do-it-yourself maintenance ■ Rear bulb locations High mounted stoplight Rear turn signal lights Stop/tail and rear side Back-up lights marker lights (bulb type only) License plate lights Replacing light bulbs ■ Headlights Unplug the connector. I n f o r ma t i o n P r o v i d e d b y :...
Page 458 4-3. Do-it-yourself maintenance Remove the rubber cover. Release bulb retaining spring. Remove the bulb. To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole. I n f o r ma t i o n P r o v i d e d b y :...
Page 459 4-3. Do-it-yourself maintenance ■ Front fog lights (if equipped) Unplug the connector while pull- ing the lock release. Turn the bulb counterclockwise. I n f o r ma t i o n P r o v i d e d b y :...
Page 460 4-3. Do-it-yourself maintenance ■ Front side marker lights Turn the bulb base counterclock- wise. Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y :...
Page 461 4-3. Do-it-yourself maintenance ■ Front turn signal lights/parking lights/daytime running lights (if equipped) Turn the bulb base counterclock- wise. Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y :...
Page 462 4-3. Do-it-yourself maintenance ■ Stop/tail lights, rear side marker lights (bulb type only), back- up lights and rear turn signal lights Remove the bolts and rear com- bination assembly. Unplug connector while depressing the lock release. Turn the bulb bases counter- clockwise.
Page 463 4-3. Do-it-yourself maintenance ■ High mounted stoplight Remove the screws and cover. Remove the light bulbs. I n f o r ma t i o n P r o v i d e d b y :...
Page 464 4-3. Do-it-yourself maintenance ■ License plate lights Remove the screw and light unit. Turn the bulb base counterclock- wise. Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y :...
Page 465 • Rear side marker lights (LED type) ■ Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations. Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction.
Page 466 4-3. Do-it-yourself maintenance I n f o r ma t i o n P r o v i d e d b y :...
Page 467 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 468 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 469 5-1. Essential information Type B Towing hook ■ Emergency towing procedure The engine switch must be in the ACC (engine off) or the ON (engine running) position. 4WD models: Put the front-wheel drive control switch in H2. Put the shift lever in N. Release the parking brake.
Page 470 5-1. Essential information NOTICE ■ Emergency towing eyelet/hook precautions ● Before emergency towing, check that the eyelet/hook is not broken or damaged. ● Fasten the towing cable or chain securely to the eyelet/hook. ● Do not jerk the eyelet/hook. Apply steady and even force. ●...
Page 471 5-1. Essential information Towing with a wheel lift-type truck from the front Vehicles with an automatic trans- mission: Use a towing dolly under the rear wheels. 2WD models with a manual transmission: We recommend to use a towing dolly under the rear wheels.
Page 472 5-1. Essential information Towing with a wheel lift-type truck from the rear 2WD models Turn the engine switch to the ACC position. 4WD models We recommend to use a towing dolly under the front wheels. When not using a towing dolly, turn the engine switch to the ACC position, shift the shift lever to N and put the front-wheel drive con-...
Page 473 5-1. Essential information Using a flat bed truck If your Toyota is transported by a Front flat bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°.
Page 474 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 475 5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 476 Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer)* •...
Page 477 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: •...
Page 478 5-2. Steps to take in an emergency Warning light Warning light/Details SRS warning light Indicates a malfunction in: • The SRS airbag system; • The front passenger occupant classification system; • The seat belt pretensioner system. ABS warning light (U.S.A.) Indicates a malfunction in: •...
Page 479 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning light Warning light/Details Correction procedure Open door warning light Check that all doors Indicates that a door is are closed.
Page 480 Toyota dealer. • When the light stays on Have the system after blinking for 1 checked by your minute: Malfunction in Toyota dealer.
Page 481 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 482 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 483 After changing the engine oil (U.S.A. only) Make sure to reset the oil maintenance data. (→P. 441) ■ Customization that can be configured at Toyota dealer The vehicle speed linked seat belt reminder buzzer can be disabled. (Customizable features →P. 583) CAUTION ■...
Page 484 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tire As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS-tire pressure warning system) that illuminates a low tire pressure telltale (tire pressure warning light) when one or more of your tires is significantly under-inflated.
Page 485 5-2. Steps to take in an emergency NOTICE ■ Precaution when installing a different tire When a tire of a different specification or maker is installed, the tire pres- sure warning system may not operate properly. I n f o r ma t i o n P r o v i d e d b y :...
Page 486 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 487 5-2. Steps to take in an emergency Access Cab models Tool bag Jack Double Cab models Tool bag Jack Taking out the jack and tool bag Regular Cab models with bench type seat Pull the lever and fold down the seatback.
Page 488 5-2. Steps to take in an emergency Regular Cab models with separated type seat Pull the lever and fold down the seatback. Unhook the strap and remove the tool bag. Loosen and remove the jack. Loosen Tighten I n f o r ma t i o n P r o v i d e d b y :...
Page 489 5-2. Steps to take in an emergency Access Cab models Pull up the lever. Raise the bottom cushion up. Turn the knob counterclockwise. Open the lid. Press the lid against the bot- tom of the lower cushion until it is supported by the hook- and-loop fastener.
Page 490 5-2. Steps to take in an emergency Loosen and remove the jack. Loosen Tighten Double Cab models Swing the bottom cushion up by pulling the lock release strap. Turn the knob counterclock- wise. Open the lid. Unhook the strap and remove the tool bag.
Page 491 5-2. Steps to take in an emergency Loosen and remove the jack. Loosen Tighten Assemble the jack handle (in the tool bag) Assemble the jack handle exten- sion as shown. Taking out the spare tire Insert the end of the jack handle extension into lowering...
Page 492 5-2. Steps to take in an emergency After the tire is lowered com- pletely to the ground, remove the holding bracket. Replacing a flat tire Chock the tires. Wheel Flat tire chock positions Behind the Left- rear right- hand hand side side tire Front...
Page 493 5-2. Steps to take in an emergency Remove the wheel ornament using the wheel nut wrench as shown. To protect the wheel and wheel ornament, place a rag between the wrench and the wheel ornament, as shown in the illustration. Type A Type B Type C...
Page 494 5-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Assemble the jack handle exten- sion as shown. Position the jack at the correct jack point as shown. Front Rear Make sure the jack is positioned on a level and solid place.
Page 495 5-2. Steps to take in an emergency Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface. Installing the tire Remove any dirt or foreign mat- ter from the wheel contact sur- face.
Page 496 5-2. Steps to take in an emergency Replacing an aluminum wheel with a steel wheel Tighten the nuts until the tapered Tapered portion portion comes into loose contact with the disc wheel sheet. Disc wheel sheet Replacing an aluminum wheel with an aluminum wheel Tighten the nuts until the washer Washer of the nut comes into loose con-...
Page 497 5-2. Steps to take in an emergency Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 83 ft·lbf (113 N·m, 11.5 kgf·m) 2WD models except PreRunner 4WD models and PreRunner Stowing the flat tire, jack and all tools Lay down the tire with the outer side facing up, and install the holding bracket.
Page 498 5-2. Steps to take in an emergency 4WD models only: Fasten the claws of the holding bracket into the wheel holes as shown in the illustration. Holding bracket Claw Then secure the tire, taking care that the tire goes straight up without catching on any other part, to prevent it from flying for- ward during a collision or sudden braking.
Page 499 5-2. Steps to take in an emergency CAUTION ■ Using the jack Improper use of the jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 500 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while the vehicle is moving.
Page 501 5-2. Steps to take in an emergency CAUTION ■ Speed limit when using the temporary spare tire Do not drive at speeds in excess of 50 mph (80 km/h) when a temporary spare tire is installed on the vehicle. The temporary spare tire is not designed for driving at high speeds. Fail- ing to observe this precaution may lead to an accident causing death or serious injury.
Page 502 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 503 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 535) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. I n f o r ma t i o n P r o v i d e d b y :...
Page 504 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 505 5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate. I n f o r ma t i o n P r o v i d e d b y :...
Page 506 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Connect the jumper cables.
Page 507 Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. I n f o r ma t i o n P r o v i d e d b y :...
Page 508 5-2. Steps to take in an emergency ■ Starting the engine when the battery is discharged (vehicles with an automatic transmission) The engine cannot be started by push-starting. ■ Avoiding a discharged battery ● Turn off the headlights and the audio system while the engine is turned off.
Page 509 5-2. Steps to take in an emergency CAUTION ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery. ● When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
Page 510 If the fan is not operating: Stop the engine immediately and call your local Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 511 (→P. 559) Have the vehicle checked at your nearest Toyota dealer as soon as possible. I n f o r ma t i o n P r o v i d e d b y :...
Page 512 5-2. Steps to take in an emergency ■ Overheating If you observe the following, your vehicle may be overheating. ● The engine coolant temperature gauge enters the red zone or a loss of power is experienced. ● Steam is coming from under the hood. CAUTION ■...
Page 513 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift lever in P (vehicles with an automatic transmission) or N (vehicles with a manual transmission).
Page 514 5-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the wheels and do not rev the engine. ● If the vehicle remains stuck after trying these procedures, the vehicle may require towing to be freed.
Page 515 5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly depress it.
Page 516 5-2. Steps to take in an emergency CAUTION ■ If the engine has to be turned off while driving ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 517 5-2. Steps to take in an emergency I n f o r ma t i o n P r o v i d e d b y :...
Page 518 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions 2WD models except PreRunner Access Cab Cab type Regular Cab Double Cab Except X-Runner X-Runner 190.4 in. Overall length 208.1 in. (5285 mm) (4835 mm) 74.0 in. 74.6 in. Overall width 72.2 in.
Page 519 : Installing accessories in addition to those installed at the factory increases vehicle weight, thereby reducing vehicle capacity weight. Contact your Toyota dealer about the weight of accessory parts. I n f o r ma t i o n P r o v i d e d b y :...
Page 520 (1GR-FE) engine Long deck : Installing accessories in addition to those installed at the factory increases vehicle weight, thereby reducing vehicle capacity weight. Contact your Toyota dealer about the weight of accessory parts. 4WD models Vehicle capacity Cab type Engine...
Page 521 6-1. Specifications TWR (Trailer Weight Rating) Regular Cab models Driving Model code Engine system TRN220L-TRMDKA TRN220L-TRPDKA 2.7 L 4-cylinder 3500 lb. (1585 kg) (2TR-FE) engine TRN240L-TRMDKA TRN240L-TRPDKA Access Cab models Driving Model code Engine system TRN225L-CRMDKA TRN225L-CRPDKA 2.7 L 4-cylinder TRN245L-CRMDKA 3500 lb.
Page 522 6-1. Specifications Double Cab models Driving Model code Engine system TRN225L-PRPDKA 3400 lb. (1540 kg) 2.7 L 4-cylinder (2TR-FE) engine TRN265L-PRPDKA 3500 lb. (1585 kg) 3500 lb. (1585 kg) GRN245L-PRADKA 6500 lb. (2945 kg) 3500 lb. (1585 kg) GRN245L-PRFDKA 6500 lb. (2945 kg) 3500 lb.
Page 523 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 524 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. 2.7 L 4-cylinder (2TR-FE) engine 4.0 L V6 (1GR-FE) engine I n f o r ma t i o n P r o v i d e d b y :...
Page 525 6-1. Specifications Engine 2.7 L 4-cylinder (2TR-FE) engine Model 2TR-FE Type 4-cylinder in line, 4-cycle, gasoline 3.74 × 3.74 in. (95.0 × 95.0 mm) Bore and stroke Displacement 164.3 cu.in. (2694 cm Drive belt tension Automatic adjustment Valve clearance (engine cold) 　Intake Automatic adjustment 　Exhaust...
Page 526 6-1. Specifications Lubrication system Oil capacity (Drain and refill - reference Without filter 2.7 L 4-cylinder (2TR-FE) engine 5.4 qt. (5.1 L, 4.5 Imp.qt.) 4.0 L V6 (1GR-FE) engine 2WD models except PreRunner: 4.4 qt. (4.2 L, 3.7 Imp.qt.) 4WD models and PreRunner: 5.2 qt.
Page 527 6-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil Recommended viscosity: 2.7 L 4-cylinder (2TR-FE) engine...
Page 528 6-1. Specifications 4.0 L V6 (1GR-FE) engine SAE 5W-30 SAE 5W-30 is the best choice for good fuel economy and good starting in cold weather. If SAE 5W-30 is not available, SAE 10W-30 oil may be used. However, it should be replaced Outside temperature with SAE 5W-30 at the next oil change.
Page 529 10.1 qt. (9.6 L, 8.4 Imp.qt.) Vehicles with a manual transmission 10.3 qt. (9.7 L, 8.5 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 530 Oil type and viscosity 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of matching quality to satisfy the above specification.
Page 531 : The fluid capacity is the quantity of reference. If replacement is necessary, contact your Toyota dealer. NOTICE ■ Automatic transmission fluid type (4-speed models) Using automatic transmission fluid other than “Toyota Genuine ATF Type T-IV” may cause deterioration in shift quality, locking up of your transmission accompanied vibration, ultimately...
Page 532 6-1. Specifications Manual transmission Gear oil capacity (Reference) 2.7 L 4-cylinder (2TR-FE) engine 2WD models 2.7 qt. (2.6 L, 2.3 Imp.qt.) 4WD models 2.3 qt. (2.2 L, 1.9 Imp.qt.) 4.0 L V6 (1GR-FE) engine 1.9 qt. (1.8 L, 1.6 Imp.qt.) Gear oil type Gear oil API GL-4 or GL-5 Recommended gear oil viscosity...
Page 533 6-1. Specifications Brakes Pedal clearance 2WD models except 4.3 in. (110 mm) PreRunner PreRunner 4.2 in. (106 mm) 4WD models Without off-road package 4.2 in. (106 mm) With off-road package 3.4 in. (88 mm) 0.04 ⎯ 0.24 in. (1 ⎯ 6 mm) Pedal free play Brake pad wear limit 0.04 in.
Page 534 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) ® Automatic transmission fluid DEXRON II or Power steering fluid type Tires and wheels Type A Tire size P215/70R15 97S Front tires: 30 psi (210 kPa, 2.1 kgf/cm or bar) Rear tires: 33 psi (230 kPa, 2.3 kgf/cm or bar)
Page 535 6-1. Specifications Type B Tire size P245/75R16 109S Front tires: 30 psi (210 kPa, 2.1 kgf/cm or bar) Rear tires: 30 psi (210 kPa, 2.1 kgf/cm or bar) Spare tire: Tire inflation pressure 30 psi (210 kPa, 2.1 kgf/cm or bar) (Recommended cold tire Driving at high speeds above 100 mph inflation pressure)
Page 536 6-1. Specifications Type D Tire size P265/65R17 110S Front tires: 29 psi (200 kPa, 2.0 kgf/cm or bar) Rear tires: 29 psi (200 kPa, 2.0 kgf/cm or bar) Spare tire: Tire inflation pressure 29 psi (200 kPa, 2.0 kgf/cm or bar) (Recommended cold tire Driving at high speeds above 100 mph inflation pressure)
Page 537 6-1. Specifications Type F Tire size P265/60R18 109H Front tires: 29 psi (200 kPa, 2.0 kgf/cm or bar) Rear tires: 29 psi (200 kPa, 2.0 kgf/cm or bar) Spare tire: Tire inflation pressure 29 psi (200 kPa, 2.0 kgf/cm or bar) (Recommended cold tire Driving at high speeds above 100 mph inflation pressure)
Page 538 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights — 60/55 Front fog lights — Front side marker — lights Front turn signal lights/parking lights/ 4157 27/8 daytime running lights Exterior Rear turn signal lights 3157A 27/8 Stop/tail and rear side 3157KX 27/8 marker lights...
Page 539 ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
Page 540 10% ethanol). (85% ethanol) ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ● Toyota does not recommend the use of gasoline containing methanol.
Page 541 (Methylcyclopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument cluster may come on. If this happens, contact your Toyota dealer for service.
Page 542 6-1. Specifications Tire information Typical tire symbols Tire size (→P. 574) DOT and Tire Identification Number (TIN) (→P. 573) Location of treadwear indicators (→P. 452) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 543 6-1. Specifications Radial tires or bias-ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias-ply tire. Summer tire or all season tire (→P. 456) An all season tire has M+S on the sidewall. A tire not marked M+S is a summer tire.
Page 544 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 545 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 546 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 547 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. Glossary of tire terminology Tire related term Meaning...
Page 548 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as Occupant distribution specified in the third column of Table 1 below The combined weight of installed regular production options weighing over 5 lb.
Page 549 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 550 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on Intended outboard the other sidewall of the tire, or sidewall...
Page 551 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between Ply separation adjacent plies A mechanical device made of rubber, chemicals, fabric and steel or other materials, Pneumatic tire that, when mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that...
Page 552 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear designed to give a visual indication of the...
Page 553 Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customizing inside rear view mirror features (vehicles with auto anti-glare inside rear view mirror)
Page 554 6-2. Customization Type A: Press and select “Layout”. Type B: Press and select “Layout”. Type A: Press and hold and choose whether outside temperature or compass display will appear on top. Type B: Press and choose whether outside tempera- ture or compass display will appear on top. To leave the “Custom Settings Menu”, select “Back to main menu”...
Page 555 6-2. Customization Type A: Each time is pressed and held, the display col- ors change in the following order: “Green” → “White” → “Orange” → “Blue” Type B: Each time is pressed, the display colors change in the following order: “Green”...
Page 556 6-2. Customization To leave the “Custom Settings Menu”, select “Back to main menu” to return to the starting screen, then either select “Exit” or wait several seconds without pressing any buttons. Customizable features Customized Item Function Default setting setting Wireless remote con- Operation signal trol...
Page 557 6-2. Customization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Engine oil maintenance After changing engine oil P.
Page 558 6-2. Customization I n f o r ma t i o n P r o v i d e d b y :...
Page 559 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 560 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. I n f o r ma t i o n P r o v i d e d b y :...
Page 561 I n f o r ma t i o n P r o v i d e d b y :...
Page 562 SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. I n f o r ma t i o n P r o v i d e d b y :...
Page 563 I n f o r ma t i o n P r o v i d e d b y :...
Page 564 I n f o r ma t i o n P r o v i d e d b y :...
Page 565 I n f o r ma t i o n P r o v i d e d b y :...
Page 566 I n f o r ma t i o n P r o v i d e d b y :...
Page 567 I n f o r ma t i o n P r o v i d e d b y :...
Page 568 I n f o r ma t i o n P r o v i d e d b y :...
Page 569 I n f o r ma t i o n P r o v i d e d b y :...
Page 570 I n f o r ma t i o n P r o v i d e d b y :...
Page 571 I n f o r ma t i o n P r o v i d e d b y :...
Page 572 I n f o r ma t i o n P r o v i d e d b y :...
Page 573 National Highway Traffic Safety Administration of the U.S. Department of Transportation. It provides the purchas- ers and/or prospective purchasers of Toyota vehicles with infor- mation on truck-camper loading. Your Toyota dealer will help answer any questions you may have as you read this informa- tion.
Page 574 CAUTION ■ Loading precaution If a load is too far back, it can cause dangerous handling. If it is too far forward, the front axle may be overloaded. Cargo weight rating and proper matching When the truck is used to carry a slide-in camper, the total cargo load of the truck consists of the manufacturer’s camper weight figure, the weight of installed additional camper equipment not included in the manufacturer’s camper weight figure, the weight of camper cargo,...
Page 575 Access Cab models 2 people, 2TR-FE engine, 2WD except PreRunner: 750 lb. (340 kg) 4 people, 2TR-FE engine, 2WD except PreRunner: 450 lb. (204 kg) 2 people, 2TR-FE engine, PreRunner: 1000 lb. (453 kg) 4 people, 2TR-FE engine, PreRunner: 700 lb. (317 kg) 2 people, 1GR-FE engine, PreRunner: 950 lb.
Page 576 Gross axle and vehicle weight ratings Secure loose items to prevent weight shifts that could affect the bal- ance of your vehicle. When the truck camper is loaded, drive to a scale and weigh on the front and on the rear wheels separately to determine axle loads.
Page 577 ■ GAWR GAWR Front Rear 2WD models except PreRun- 2380 lb. (1075 kg) 2650 lb. (1200 kg) Regular Cab models 3000 lb. (1360 kg) 4WD models and 2755 lb. (1245 kg) Access Cab and PreRunner Double Cab models 3110 lb. (1410 kg) ■...
Page 578 PreRunner Cab type GVWR Vehicles with 2.7 L 4-cylinder (2TR-FE) Access Cab engine 5250 lb. (2380 kg) Vehicles with 4.0 L V6 (1GR-FE) engine Double Cab 5400 lb. (2445 kg) 4WD models Cab type GVWR Regular Cab 5100 lb. (2310 kg) Vehicles with 2.7 L 4-cylinder (2TR-FE) engine 5350 lb.
Page 579 I n f o r ma t i o n P r o v i d e d b y :...
Page 580 Alphabetical index Alphabetical index A/C..........248 Audio remote controls .... 303 ABS ...........200 Audio system Access doors ......43 Antenna....264, 418, 420 Active traction control Audio input .... 280, 288, 301 system ........190 AUX port ....... 301 Air conditioning filter....469 CD player ......267 Air conditioning system iPod........
Page 581 Alphabetical index ® Bluetooth audio..... 309 Child safety ® Bluetooth phone ....326 Airbag precautions ....97 Bottle holders ....365, 369 Battery precautions ..449, 538 Brake assist ......200 Child restraint system....108 Brakes Child-protectors.......41 Brake system warning buzzer How your child should wear ...
Page 582 Alphabetical index Daytime running light Emergency, in case of system ........166 Blown fuse ......474 Deck If the engine will not start ..532 Auxiliary boxes ......392 If the shift lever cannot be Deck ........391 shifted from P ..... 533 Deck hooks ......393 If the vehicle battery is Deck rails ......212...
Page 583 Alphabetical index Engine coolant Front passenger’s seat belt Capacity ....... 559 reminder light......508 Checking ......443 Front passenger’s seat belt Preparing and checking warning buzzer ......508 before winter ...... 219 Front seats Temperature gauge....157 Adjustment ......49 Engine coolant temperature Front side marker lights gauge ........
Page 584 Alphabetical index Hands-free system Interior lights (for cellular phone) ....326 Interior lights ......364 Hazard lights Personal lights ...... 364 Switch........496 Switch ........364 Head restraints Wattage......... 568 Adjusting ........58 Instrument panel light Headlights control ........158 Replacing light bulbs .....485 Switch........164 Jack Wattage.........568...
Page 585 Alphabetical index Lights Noise from under vehicle ..27 Automatic light off system ..166 Emergency flashers switch... 496 Odometer ........158 Fog light switch..... 167 Off-road precautions Hazard light switch ....496 Driving ........209 Headlights switch ....164 Vehicle ........207 Instrument panel light control dial......
Page 586 Alphabetical index Radiator ......436, 444 Seat belts Radio .........260 Adjustment ......63 Rear seat ALR .........65 Adjustment ......54 Automatic Locking Folding down......55 Retractor.......65 Raising the bottom Child restraint system cushion .........54 installation......112 Rear side marker lights Cleaning and maintaining ..422 Replacing light bulbs ..490, 493 ELR .........65 Switch........164...
Page 587 Alphabetical index Seatback table ......388 Storage feature......365 Service reminder Storage precautions ....215 indicators ......160 Stuck Shift lever If the vehicle becomes Automatic transmission ..146 stuck ........542 If the shift lever cannot be Sun visors.........373 shifted from P..... 533 Switch Manual transmission ....
Page 588 Alphabetical index Tachometer.......157 Tools ......... 515 Tailgate Total load capacity ....217 Removing the tailgate .....44 Towing Tailgate ........44 Bumper towing ...... 233 Tail lights Dinghy towing ....... 244 Replacing light bulbs ..490, 493 Emergency towing ....497 Switch........164 Fifth wheel trailer....231 Wattage.........568 Trailer towing ......
Page 589 Alphabetical index Warning buzzers Washing and waxing ....418 Key reminder ......510 Weight Brake system......505 Cargo capacity ......212 Seat belt reminder ....508 Cargo weight rating ....605 Warning lights Gross axle weight rating..607 ABS ........506 Gross combination weight Airbag system.......
Page 590 What to do if... What to do if... If you have a flat tire P. 515 A tire punctures P. 532 If the engine will not start The engine does not start P. 84 Engine immobilizer system P. 535 If the vehicle battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
Page 591 What to do if... ■ Instrument cluster ■ Center panel I n f o r ma t i o n P r o v i d e d b y :...
Page 592: Warning Lights
What to do if... ■Warning lights Brake system warning Slip indicator* light P. 507 Cruise control indicator light* P. 505 P. 507 Automatic transmission Charging system warning fluid temperature light warning light P. 506 P. 507 Open door warning light Low engine oil pressure warning light P.
Page 593 Memo I n f o r ma t i o n P r o v i d e d b y :...
Page 594: Gas Station Information
Cold tire inflation P. 564 pressure Engine oil capacity (Drain and refill P. 556 -reference) Toyota Genuine Motor Oil or equivalent Oil grade: P. 556 ILSAC multigrade engine oil Engine oil type Recommended oil viscosity: SAE 0W-20 (2.7 L 4-cylinder [2TR-FE] engine) SAE 5W-30 (4.0 L V6 [1GR-FE] engine)

Toyota 2012 Tacoma User Manual

Quick Links

Related Manuals for Toyota 2012 Tacoma

Summary of Contents for Toyota 2012 Tacoma

Table of Contents
