    VESTEL Service Manual 17MB27-2 02.01.2008 TABLE OF CONTENTS INTRODUCTION....................3 GENERAL DESCRIPTION...................3 POWER CONSUMPTION..................6 MICROCONTROLLER PORT CONFIGURATION.........6 SIDE BOARDS AND CONNECTORS ..............7 Keypad ............................7 Infrared & LED ...........................7 DVB-T ............................8 DVD.............................9 LVDS ............................11 Inverter............................12 IC SPECIFICATIONS ..................13 Microcontoller/Video&Audio Processor (VCT4953G) ............13 Scaler/De-interlacer (MST5x7A-M)..................16...
  • Page 3: Introduction

    VESTEL Service Manual 17MB27-2 02.01.2008 6.12 SPDIF Switch (NLAST4599) ....................28 1 INTRODUCTION The purpose of this document is to define the operation of 17MB27 chassis, capable of driving 15” and 19” TFT LCD panels. It is aimed to provide information to engineering staff to understand the operation and specs of the TV.
  • Page 4 VESTEL Service Manual 17MB27-2 02.01.2008 • Teletext • IR Control (RC5 and other customer specific protocols) • “No Ident” Timer • Child Lock • Sleep Timer • WSS (16:9/4:3 Aspect Ratio Auto Switch) Sound Features • Equalizer • FM Radio •...
  • Page 5 VESTEL Service Manual 17MB27-2 02.01.2008 • OSD Color & Transparency Selection Electrical features • 12V 4.16A DC / 100 - 240V AC adapter for 15” TV • 12V 5.83A DC / 100 - 240V AC adapter for 19” TV • <1W standby power consumption...
  • Page 6: Power Consumption

    VESTEL Service Manual 17MB27-2 02.01.2008 There are three PWM output ports. PWM0 is assigned to analog/digital dimming control for the backlight, PWM1 is used for backlight on/off and panel logic power supply on/off control and PWM2 is used to control PC/HDMI switch IC (PI5V512).
  • Page 7: Side Boards And Connectors

    VESTEL Service Manual 17MB27-2 02.01.2008 PORT SIGNAL NAME TYPE FUNCTION NAME HDMI_HP_INV HDMI hot plug signal Switching control for Mstar bus and system I2C Safety VCTI_HS VCTI composite sync output FBIN DVD_SENSE DVD module detection Vert+ TV/DVB_SW IDTV/TV I2C and AGC switch control for tuner...
  • Page 8: Dvb-T

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 5.2.1: LED board connector Pin2 and pin3 carry the control signals for the LED. Pin4 carries the infra-red signal to the microcontroller. Pin5 is used to power up the LED board. DVB-T module board DVB-T module board (tdm1300) is used to receive digital terrestrial broadcast signals.
  • Page 9: Dvd

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 5.3.2: DVB-T data connector on 17mb27 Tdm1300 board has no tuner on it. Instead, the tuner of 17mb27 is used for both analogue and digital reception. Tuner is controlled by either the 17mb27 microcontroller (VCTI), or tdm1300 board microcontroller.
  • Page 10 VESTEL Service Manual 17MB27-2 02.01.2008 12V (500mA) is sent to DVD electronic card by power cable: Figure 5.4.1: DVD module board power connection on 17mb27 Y/C and/or CVBS video, stereo audio outputs and infra-red input of DVD module board is carried on data cable: Figure 5.4.2: DVD data connector on 17mb27...
  • Page 11: Lvds

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 5.4.3: DVD_SENSE connector on 17mb27 LVDS connector MST507A-M is used for single LVDS output and MST517A-M is used for dual LVDS output on 17mb27: Figure 5.5.1: Single LVDS output connector on 17mb27...
  • Page 12: Inverter

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 5.5.2: Dual LVDS output connector on 17mb27 Panel_Vcc1 is the power input for the panel LCD module. PIN7 signal is a logic 1 or 0 signal depending on the panel type. Inverter 12V power, backlight on/off control, and dimming control signal are sent to the inverter board:...
  • Page 13: Ic Specifications

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 5.6.1: Inverter connector on 17mb27 6 IC SPECIFICATIONS Microcontoller/Video&Audio Processor (VCT4913G) VCTI49xy is composed of microcontroller, video proccessor, display and deflection processor, sound proccessor and IF blocks as shown in below figure .
  • Page 14 VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.1.1: VCTI49xy block diagram...
  • Page 15 VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.1.2: Detailed block diagram of VCTI49xy VCTI49xyl family has two package types; PSSDIP88 and PMQFP144. PSSDIP88 package is chosen because of its convenience in the soldering process. PSSDIP88 package has two versions; 1 and 2.
  • Page 16: Scaler/De-Interlacer (Mst5X7A-M)

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.1.3: VCTI pinning diagram Scaler/De-interlacer (MST5x7A-M) The MST507A-M and MST517A-M are total solution graphics processing ICs for LCD displays with panel resolutions up to XGA and WXGA+ / SXGA+ respectively. They are configured with a high-speed integrated triple-ADC/PLL, a high quality display processing engine, and an integrated multi-purpose output display interface that can support all major panel interface formats.
  • Page 17 VESTEL Service Manual 17MB27-2 02.01.2008 MST has a built-in OSD generator with 291 character font programmable RAM. OSD generator supports 2/4/8 multi-color fonts, 8/16/256 color palette and 1K code attributes. MST also supports dual channel 6-bit/single channel 8-bit TTL panel interface and 6/8-bit LVDS panel interface.
  • Page 18 VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.2.2: Pinning of MST5x7A-M...
  • Page 19: Audio Amplifier (Tda2822)

    VESTEL Service Manual 17MB27-2 02.01.2008 PORT SIGNAL NAME TYPE FUNCTION NAME PWM0 AN/DIG_DIM Analog or digital dimming control PWM1 BKL_ON/OFF Backlight On/Off Control PVCC_ON/OFF Panel Logic Power On/Off control PWM2 PC/HDMI_SW O Video switching control Table 6.2.1: MST5x7A-M port allocation Audio Amplifier (TDA2822M) TDA2822M is a dual low-voltage power amplifier in 8-lead minidip package.
  • Page 20: Audio Matrix Switch (Tea6422D)

    VESTEL Service Manual 17MB27-2 02.01.2008 • Large output voltage swing Figure 6.4.1: TDA1308T block diagram Figure 6.4.2: Pinning of TDA1308T Audio Matrix Switch (TEA6422D) TEA6422D is a bus-controlled audio matrix switch in an SO28 plastic monopackage. The main features of TEA6422 D are: •...
  • Page 21: Hdmi Receiver (Anx9021)

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.5.1: TEA6422D pinning HDMI Receiver (ANX9021) The ANX9021 is an advanced multimedia receiver compliant with High Definition Multimedia Interface (HDMI) Specification 1.2. HDMI is the first transport standard to unify digital video, audio, and control da ta over lowcost cables.
  • Page 22 VESTEL Service Manual 17MB27-2 02.01.2008 • Dual-channel HDMI receiver supporting link data rate up to 1.65 Gbps • HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant • WideEye™ architecture for signal conditioning and equalization o support cable length up to 20m o better than 10E-12 bit error rate •...
  • Page 23: Video Switch (Pi5V512)

    VESTEL Service Manual 17MB27-2 02.01.2008 Video Switch (PI5V512) PI5V512 is a wide-bandwidth 5-port 2:1 mux/demux video switch with High-Z outputs. The main features of PI5V512 are: • High-performance, low-cost solution to switch between video sources • Wide bandwidth: 550 MHz •...
  • Page 24: Tuner (Dtt71306)

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.7.2: Pin configuration of PI5V512 Figure 6.7.3: Truth table of PI5V512 Tuner (DTT71306) DTT713xx is a digital terrestrial tuner designed for reception in VHF I, VHF III and UHF, compliant with the European digital terrestrial standard ETS 300744 and CENELEC standards EN 55013 and EN 55020.
  • Page 25: Saw Filter (X6966M)

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.8.1: Block diagram of DTT713xx SAW Filter (X6966M) X6966M is a SAW (Surface Acoustic Wave) band-pass filter at 36.125 MHz. Figure 6.9.1: Package of X6966M...
  • Page 26: I2C Switch (74Hct4053)

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.9.2: Pin configuration of X696M 6.10 I2C Switch (74HCT4053) 74HCT4053 is a triple 2-channel analog mux/demux with a common enable input. Each multiplexer/demultiplexer has two independent inputs/outputs (nY0 and nY1), a common input/output (nZ) and three digital select inputs (S1 to S3).
  • Page 27: Audio Dac (Cs4334)

    VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.10.3: Function table of 74HCT4053 6.11 Audio DAC (CS4334) CS4334 is a 8-pin, 24-bit, 96 kHz stereo D/A converter. The CS4334 family is based on Delta-Sigma modulation, where the modulator output controls the reference voltage input to an ultra-linear analog low- pass filter.
  • Page 28 VESTEL Service Manual 17MB27-2 02.01.2008 Figure 6.11.1: Block diagram of CS4334 6.12 SPDIF Switch (NLAST4599) The NLAST4599 is an advanced high speed CMOS single pole − double throw analog switch fabricated with silicon gate CMOS technology. It achieves high speed propagation delays and low ON resistances while maintaining low power dissipation.
  • Page 29 VESTEL Service Manual 17MB27-2 02.01.2008 • Chip Complexity: 38 FETs Figure 6.12.1: Pin assignment of NLAST4599 Figure 6.12.2: Logic symbol of NLAST4599 Figure 6.12.3: Function table of NLAST4599...
