  • Page 1 Park Trailer Owner’s Manual Model Year 2009 www.jayco.com...
  • Page 2 WARNING: Read all instructions in this manual and component manufacturer supplied information before using your RV. This manual has been provided by Jayco, Inc. for the sole purpose of providing instructions concerning the operation and maintenance of this vehicle and its components. Nothing in this manual creates any warranty, either expressed or implied.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS & S EIGHT ISTRIBUTING YSTEM ARRANTY ERVICE .........1 ) ......23 BOUT ANUAL USTOMER UPPLIED ...5 ........22 HANGE DDRESS WNERSHIP EIGHT ABELS ......3 USTOMER ELATIONS ......2 & H USTOMER ESPONSIBILITY OWING ANDLING ......2 .......30 EALER ESPONSIBILITY REAKAWAY WITCH &...
  • Page 4 TABLE OF CONTENTS )..76 ONDITIONER QUIPPED LUMBING YSTEM ............52 ....76 OILET EPARTING HECKLIST ........45 ..........76 ATER EATER URNACE ATER RESSURE EGULATOR ) ......45 & M USTOMER UPPLIED TORAGE AINTENANCE ABS P .......... 80 ATER URIFICATION YSTEM LASTIC ).........48 &...

  • Page 5: Warranty & Service

    Please call your dealer or Jayco Jayco park trailer. We are excited to welcome Customer Service if you are unsure how to you to our growing park trailer family. Jayco is proceed. Always use the appropriate safety the largest privately held manufacturer of gear when servicing or maintaining your park recreation vehicles in the world.

  • Page 6: Customer Responsibility

    Call the Department of Transportation (DOT) trailers Vehicle Safety Hotline at 1-888- 327-4236 and a NHTSA representative will record your Jayco reserves the right to discontinue or complaint information (TTY: 1-800-424-9153 change specifications or design at any time or 1-202-484-5238).

  • Page 7: Change O F Address /Ocustomer Relations

    Registration and Customer Delivery Form” order of priority. This may include making a to Jayco within 10 days of delivery to second appointment for work not completed activate the applicable warranty coverage. or parts that the dealer may need to order.

  • Page 8: Jay Plus ™ Extended S Contract

    Brochure request info@jayco.com throughout the year. Parts email parts@jayco.com By belonging to the Jayco Travel Club, you Service email service@jayco.com will find new ways to enjoy your park trailer Website www.jayco.com and make friends all across the country. For...

  • Page 9: Wnership

    SECTION 1 WARRANTY & SERVICE...

  • Page 10: J C F Roadside Ra

    Either they or you MERGENCY OADSIDE SSISTANCE must call Jayco Customer Service to discuss applicable warranty coverage Jayco has teamed up with Coach-Net to offer prior repair work being 24/7 motorist assistance. We are offering this performed.

  • Page 11: Obtaining Service A Tj

    Parts for Jayco park trailers are distributed inspection, warranty maintenance exclusively by authorized Jayco dealers. services. Some dealers may be authorized Jayco does not sell parts retail direct or to service centers for those OEMs whose non-authorized dealers. If an original part is products warranted separately...
  • Page 12 SECTION 1 WARRANTY & SERVICE...
  • Page 13 SECTION 1 WARRANTY & SERVICE...
  • Page 14 SECTION 1 WARRANTY & SERVICE...

  • Page 15: N J D

    8-10 will not apply to this RV. The rental warranty, located on pages 12-14, applies in that situation. If, on the other hand, the Jayco dealer sells this RV to a retail customer then the rental warranty would not be applicable. The rental...

  • Page 16: Arranty

    SECTION 1 WARRANTY & SERVICE...
  • Page 17 SECTION 1 WARRANTY & SERVICE...
  • Page 18 SECTION 1 WARRANTY & SERVICE...

  • Page 19: Lanning

    SECTION 2 OCCUPANT SAFETY pet or valuable livestock will often depend on amping is a great way to enjoy the outdoors the plans that its owner has made in advance. with your family and friends. By following the proper precautions and planning, you can Familiarize yourself with the following help insure a safe, enjoyable and trouble-free weather terms:...

  • Page 20: Emergency Egress Window

    Jayco Customer Service at 1- 800-283-8267 for approval before you clean any debris, enter, move or repair your park trailer (failure to notify Jayco may result in loss of coverage). XTINGUISHER A portable fire extinguisher can save lives and property by putting out a small fire or containing it until the fire department arrives;...

  • Page 21: Smoke Alarm

    SECTION 2 OCCUPANT SAFETY classify household fire extinguishers into four Disposal types: Contact your local fire department, sanitation department environmental protection Rating Intended use department to find out what your local laws For use on fires involving combustible Type A stipulate before disposing of your used (non- materials such as wood, cloth and refillable) factory-installed dry chemical fire...

  • Page 22: Occupant Safety

    SECTION 2 OCCUPANT SAFETY be harmful to your hearing. The test button Individuals with medical problems, or who are will accurately test all functions. Never use an hard of hearing, should consider using open flame from a match or lighter to test the warning devices that provide both audible and smoke alarm;...

  • Page 23: Propane Alarm

    SECTION 2 OCCUPANT SAFETY arrived, the premises have been aired out and your CO alarm remains in its normal condition. If the CO alarm is not maintained and If your CO alarm reactivates within a 24-hour functioning properly according to OEM period, repeat steps 1-3 and call a qualified supplied instructions, you will not be appliance...

  • Page 24: Fuel Safety

    If the propane alarm does not test properly, have further questions, consult your dealer replace it immediately. Do not remove the or Jayco Customer Service for assistance. following label from your park trailer: □ Always shut OFF the tow vehicle engine while refueling.

  • Page 25: Tow Vehicle

    SECTION 3 PRE-TRAVEL INFORMATION o help ensure your traveling enjoyment, call EHICLE DENTIFICATION UMBER ahead for tourist information in each area that (VIN) E XPLAINED you will be visiting or traveling through. To The 17-digit VIN is the legal identification of help eliminate frustration, make sure you the completed park trailer and provides obtain the most current road maps.

  • Page 26: Upplied )

    1,200 lbs. The actual weight on the park trailer tires is 7,800 lbs. which is Vehicle weight labels are posted on Jayco within the weight rating of the tires. manufactured park trailers so you can make If you have further questions, please contact an informed decision before your purchase.

  • Page 27: Eight Distributing System

    Check all weight-distributing hitch to the proper height. equipment and load distribution. If the If you have additional questions, consult with problem cannot be solved immediately, your dealer. Jayco cannot be responsible for contact your Dealer service the suspension system of any tow vehicle.
  • Page 28 SECTION 3 PRE-TRAVEL INFORMATION weight evenly to distribute it to the tow vehicle Brake controller (customer supplied) front and rear axles and the trailer axle. The brake controller should be installed in the Consult with your dealer to familiarize yourself tow vehicle to work in conjunction with the with the operation and requirements of the park trailer electric brakes.

  • Page 29: Weighing Your Tow Vehicle Park Trailer

    SECTION 3 PRE-TRAVEL INFORMATION & EIGHING EHICLE RAILER It is important to redistribute the load to avoid component failure as well as to improve the handling characteristics of the Store items in areas designated for vehicle. storage. Do not store anything in the areas reserved converter, electrical...

  • Page 30: Pre-Travel Information

    SECTION 3 PRE-TRAVEL INFORMATION space on either side of the scale to Be sure to have a pen and notebook available accommodate park trailer being to write down items that you feel may be partially off the scale. needed in future travels, as well as noting the equipment you feel you need to become more 6.
  • Page 31 SECTION 3 PRE-TRAVEL INFORMATION Make sure the tongue jack (park trailer) is Bedding retracted to the travel position and the _ Blankets dolly wheel removed. _ Comforters _ Pillows Walk around your park trailer one last time _ Sheets to make sure everything is stored away _ Sleeping bags and the baggage compartments are closed and locked.
  • Page 32 SECTION 3 PRE-TRAVEL INFORMATION _ Safety pin or locking lever must be seated (if applicable) _ Secure shore line power cord _ Surge protector _ Satellite or cable wiring (if applicable) _ Test brakes for proper operation _ Tools _ AC voltage tester _ axe _ duct tape _ fuses and light bulbs (compatible with...
  • Page 33 SECTION 4 TOWING & HANDLING riving safety and protection against injury cannot be fully ensured. However, we recommend you pay special attention to the following: Do not leave children or pets unsupervised in the vehicle (even if children are secured The use of daytime running lights can by a child restraint system).

  • Page 34: Reakaway Switch

    A-frame, this switch will apply the industry, and it pertains to your trailer. If in trailer brakes if the trailer becomes detached doubt, contact your dealer or Jayco Customer from the tow vehicle. Attach the breakaway Service. switch lanyard to a permanent part of the tow vehicle (on a park trailer do not attach it to the &...

  • Page 35: Tabilizer Jacks

    SECTION 4 TOWING & HANDLING Fig. 4.2 7-way trailer plug Car end, rear view The connector plug may build up corrosion with extended use and should be cleaned periodically to insure good electrical contact. Make sure the connector plug is kept clean and protected from road elements as you travel.

  • Page 36: Ark Trailer Hitching Procedure

    SECTION 4 TOWING & HANDLING RAILER ITCHING ROCEDURE Hooking up your park trailer will become easier with practice. The following procedure Whenever possible, do not travel with will help until you become more experienced. waste in the holding tanks. Liquid or debris in the holding tank(s) may affect the towing 1.
  • Page 37 Towing items behind your Jayco trailer, or your park trailer. overloading the rear, will void the warranty Trust your intuition…...

  • Page 38: Mergency Stopping

    SECTION 4 TOWING & HANDLING the park trailer is parked in the desired MERGENCY OWING position. Parking After the park trailer is in the desired location, set the tow vehicle parking brake and place Never allow anyone to go under the the transmission in park.

  • Page 39: Hanging The Tire

    RV; they are not to be how critical proper tire maintenance is to the returned to your dealer or Jayco. If you have safety, operation and durability of your new questions regarding your tires, contact the park trailer.

  • Page 40: Heel Ugs

    Wheel lug nuts must be applied and appropriate service center. They are not to be maintained at the proper torque levels to returned to your dealer or Jayco. If you have prevent loose wheels, broken studs and questions regarding your tires, contact the...

  • Page 41: Lectrical System

    (failure to notify Jayco may result in loss of explosion or fire. coverage). □ Remove your rings, metal watchbands Always have faulty or damaged wiring and and any other metal jewelry before...

  • Page 42: Volt Circuit Breakers

    SECTION 6 ELECTRICAL SYSTEM – 50 AMP 120- VOLT IRCUIT REAKERS OWER The circuit breaker panel protects the 120-volt The 50 amp power cord is also commonly electrical system from overloads, shorts in the referred to as the “shore line power cord.” wiring shorts connected...

  • Page 43: Onverter

    SECTION 6 ELECTRICAL SYSTEM - 50 AMP When you are ready to leave, reverse the power cord connection process. Use care to prevent damaging the power cord electrical connection pins when connecting PLUG INTO 50-AMP SERVICE ONLY. disconnecting the shore line power cord. Grasp the plug to remove from the outlet;...

  • Page 44: Volt Dc Outlet

    SECTION 6 ELECTRICAL SYSTEM – 50 AMP caused by electric shock. The GFCI will not DC S VOLT YSTEM protect against short circuits or overloads. The majority of your park trailer lighting is Test all GFCI receptacles monthly powered by 12-volt electricity. The 12-volt DC The 120-volt AC electrical system must be on system is composed of components that will in order to test the GFCI.

  • Page 45: Volt Fuse Panel

    SECTION 6 ELECTRICAL SYSTEM - 50 AMP A fully charged auxiliary battery will read 12.7 ATTERY SOLATOR volts DC and 1.265 specific gravity at 80°F EHICLE USTOMER UPPLIED (32°C). The auxiliary battery is considered discharged at 11.8 volts DC by electronic You may want to consider the installation of a standards;...

  • Page 46: Quipped )

    SECTION 6 ELECTRICAL SYSTEM – 50 AMP 5. Insert a new fuse of the same specified voltage, amperage rating and type in the original location. Never use a higher rated replacement fuse. fuse panel label should kept permanently affixed to your park trailer. The fuses will not offer complete protection of the park trailer electrical system in the event of a power surge or spike.

  • Page 47: Onitor Panel

    SECTION 7 PLUMBING SYSTEMS here are two different water systems in your park trailer: the fresh water system and the waste water system. The fresh water system drink water deemed consists of the fresh water holding tank, fresh microbiologically unsafe or of unknown water connections, water pump, outside quality.

  • Page 48: Resh Water Connections

    SECTION 7 PLUMBING SYSTEMS 5. Enter the park trailer and open the cold RESH ATER OLDING water supply faucets to bleed air from the The fresh water tank can be filled by pressure water lines. filling through the fresh water inlet (called city 6.

  • Page 49: Water Heater

    SECTION 7 PLUMBING SYSTEMS is full, shut OFF the water pump and remove the non-toxic drinking water hose. ATER RESSURE EGULATOR USTOMER UPPLIED Not using a water pressure regulator when using city water may cause the o-rings to fail. To prevent damage to the plumbing Fig.
  • Page 50 SECTION 7 PLUMBING SYSTEMS even after water has been drained from the dripping from the P&T relief valve is to tank. Open the sink faucet at the sink and maintain an air pocket at the top of the water allow system to vent for five to ten minutes (or heater.

  • Page 51: Raining The Fresh Water Saucets

    SECTION 7 PLUMBING SYSTEMS 3. Open the faucet knobs and adjust them to Water heater bypass Use the factory installed water heater bypass, the desired temperature. available in most floor plans, to avoid filling To cease operation, close the faucet knobs the entire water heater with RV antifreeze.

  • Page 52: Lumbing System Volt Water Pump & Switch Athroom Shower Or Tub

    1. Be sure the water heater is ON and had sufficient time to heat the water. Each new park trailer is winterized with RV antifreeze before it leaves Jayco, Inc. To use 2. If dry camping, be sure your 12-volt water the water purification system the clear plastic pump is ON.

  • Page 53: System

    SECTION 7 PLUMBING SYSTEMS 2. Open the “exterior fresh holding tanks at an appropriate facility or tank drain” valve on the according to local public codes. permanent fresh water holding tank ANITIZING THE LUMBING YSTEM equipped). This knob turns 45° to open or close.

  • Page 54: Winterizing The Plumbing

    SECTION 7 PLUMBING SYSTEMS 5. Continue filling the fresh water tank with trailer may cause water supply lines and the clean (potable) water until it is full. water heater to freeze. No commodity or product should be added to the fresh water 6.

  • Page 55: Lack /Grey Water Holding Tlack /Grey Water System F S O Equipped )

    SECTION 7 PLUMBING SYSTEMS 6. Insert the clear hose into a container of exterior vent cap is attached to the roof and antifreeze solution (this quantity must be kept clear of obstructions to perform should be enough to winterize the park as intended.

  • Page 56: Lack & Grey Tank Drains

    SECTION 7 PLUMBING SYSTEMS accumulated waste debris or solids from the 5. Open the grey tank dump valve (close the sides of the holding tanks. dump valve when the grey holding tank is emptied). 6. Remove, clean and store the sewer hose. 7.
  • Page 57 SECTION 7 PLUMBING SYSTEMS and better sanitation system performance, it is advisable to always have four to six inches (10 - 15 cm) of water in the toilet. To prevent help toilet blockage, always use RV grade single-ply toilet paper. Do not flush paper towels, diapers, sanitary napkins or other foreign objects down the toilet.
  • Page 58 SECTION 7 PLUMBING SYSTEMS NTENTIONALLY LANK...
  • Page 59 Although both Jayco and your selling dealer test carefully for leakage, travel vibrations can loosen fittings. Continued maintenance is necessary for safe operation. The propane...

  • Page 60: Propane System

    SECTION 8 PROPANE SYSTEM Propane will not run through the appliances in EST THE ROPANE the liquid state. The volume of liquid propane YSTEM increases approximately 1-½% for every 10°F (5.5°C) it is warmed. Heat the propane 100°F (55°C) and the container liquid volume will increase 15%.
  • Page 61 SECTION 8 PROPANE SYSTEM following label should kept Have the park trailer checked for leaks at the permanently affixed to your park trailer. connections on the propane system soon after the purchase and the initial filling of each propane cylinder. When you have a new cylinder filled for the first time, make sure your propane supplier purges your new cylinder of trapped air.

  • Page 62: Installing Propanec

    SECTION 8 PROPANE SYSTEM 4. Attach the1/4” inverted flare x 11” Type-1 pigtail hose to the regulator inlet and the right hand swivel nut to the cylinder valve. The pigtail hose must be installed to avoid Main Supply Hose – Low Pressure tension or pulling stress at either end of Attach the main supply hose from the the hose.

  • Page 63: Propane Regulator

    SECTION 8 PROPANE SYSTEM technician for assistance immediately. Do not attempt to service a propane container overfill yourself. Propane regulators must always Maintenance installed with the regulator vent facing Propane gas is normally non-corrosive - you downward. Regulators that are not located need not worry about the inside of your in baggage compartments have been container.

  • Page 64: Sage

    SECTION 8 PROPANE SYSTEM valve causing propane “freeze-up.” Should & F OSES IPES UBES ITTINGS you experience propane “freeze-up,” close The hoses, pipes, tubes and fittings used in the main valve and wait 15 minutes before your propane system designed trying again.

  • Page 65: Traveling With Propane

    SECTION 8 PROPANE SYSTEM operated. Unless there is heavy use of hot water, the water heater consumption of propane is minimal. During cool temperature or high wind conditions, furnace consumption can be extremely high. To calculate your propane supply, take the BTU ratings for your propane appliances and divide that into the BTU availability.
  • Page 66 SECTION 8 PROPANE SYSTEM NTENTIONALLY LANK...

  • Page 67: Slideout System

    SECTION 9 SLIDEOUT SYSTEM Ensure that the trailer is level before Fig. 9.1 Transit bar operating the slideout room. Water leaks and other problems could result if the Some park trailers have transit bars that need slideout is operated without leveling the to be installed when the slideout room is in trailer.

  • Page 68: Lideout

    If the slideout is retracted, leave it in that this seal are cut at a 45° position. angle. The top of the Contact your dealer or Jayco Customer seal must overlap the Fig. 9.3 Exterior Service for repair assistance. side of the seal to avoid...

  • Page 69: Camping & Operating

    SECTION 10 CAMPING & OPERATING occupied campsites. Remember to keep your y purchasing your park trailer you have campsite tidy. Put refuse in containers entered into a lifestyle that encourages long- provided for that purpose, and please avoid lasting friendships. People who camp next to contaminating any lake or stream.

  • Page 70: Condensation

    SECTION 10 CAMPING & OPERATING If condensation is found in cabinets or ONDENSATION closets, open those doors slightly to equalize the temperature and provide ETUP ROCEDURE Condensation needs to be taken seriously. Ignoring it can damage the park trailer (damage caused by condensation is not warrantable), and more importantly could lead to mold or mildew issues which could be a health hazard.
  • Page 71 SECTION 10 CAMPING & OPERATING roof live load and total unit dead load. Load than 4’-0”. The required pier capacity bearing supports and footings may be subject equals 125 lbs. x opening width (ft.). to approval by your local enforcement agency. Installation Inspection Checklist Each pier must have sufficient capacity to To ensure proper park trailer installation...
  • Page 72 SECTION 10 CAMPING & OPERATING Blocking procedure Reminders before jacking: 1. Use only jacks in good condition with a minimum rating of 5 tons. 2. Use a steel plate (3/8” x 2 1/2”) between jack and steel “I”-beam to distribute the concentrated loads.
  • Page 73 SECTION 10 CAMPING & OPERATING 6. Level the park trailer within reasonable 2. Galvanized connection devices such as tolerances, using a 6 foot carpenter’s turnbuckles, eyebolts, strap buckles and level, water level or similar equipment. cable clamps should be rated at 3,150 The final height adjustment is obtained by working load minimum.

  • Page 74: Detachable Hitch

    SECTION 10 CAMPING & OPERATING 4. Remove electrical wiring and safety break- Cold Weather Usage When used in freezing or below freezing a-way switch from tongue by removing temperatures, the following precautions need 3/8” screws (could be 3 or more). to be taken: 5.

  • Page 75: Entrance Door Withs

    SECTION 10 CAMPING & OPERATING made. If you lose the keys, contact your OOTH INETTE QUIPPED dealer or a locksmith for assistance. The dinette is designed to seat up to four Make sure the keys are not inside the park adults and provide storage.

  • Page 76: Tv Antenna & Cable Tv

    SECTION 10 CAMPING & OPERATING 5. Place the seat and seat back cushions on On amplified models, 12-volt DC power is the extensions and repeat the process for required (refer to the OEM manual). After the the other dinette bench extension. antenna is in the full UP position, pull down on the round knob with both hands until it To close the extendable dinette, reverse the...

  • Page 77: Cooking With Propane

    SECTION 10 CAMPING & OPERATING OOKING ROPANE ITCHEN TOVE ANGE OR QUIPPED Do not turn the gas range burner controls ON and allow propane to escape before During and after use, do not touch or let lighting. clothing or other flammable material come in contact with the top burners (or heating elements), burner grates or other areas near the top burners or oven until they...

  • Page 78: Bbq Grill

    If you have any questions capacity is designed by weight, not contact your dealer or Jayco Customer volume, so you cannot necessarily use all Service. Do not use the oven as a storage available space.

  • Page 79: Patio Awning

    SECTION 10 CAMPING & OPERATING 2. Insert the plug and release the sleeve. 3. Push the plug until the sleeve snaps forward, locking the plug into the socket. Do not place clothing or other flammable material on or near the firebox. Never 4.

  • Page 80: Onditioner Quipped Eparting Amp Hecklist

    A special foam gasket is placed between the before operating your furnace If you have any roof material and the subframe of the air questions contact your dealer or Jayco conditioner to guard against water leakage. Customer Service. The air conditioner is subjected to wind...
  • Page 81 SECTION 10 CAMPING & OPERATING _ Move slideout in and lock it in place (if applicable) _ Position the booth dinette in the bed position for travel (if applicable) _ Refrigerator door locked _ Set refrigerator to 12-volt (if applicable) _ Water heater turned off _ Water pump turned off Exterior...
  • Page 82 SECTION 10 CAMPING & OPERATING NTENTIONALLY LANK...

  • Page 83: Leaning The Interior

    SECTION 11 STORAGE & MAINTENANCE function of appliances and elimination of epending upon your area and where your condensation (see Condensation). park trailer is stored, your vehicle may be a target for damage from rodents and insects. The following label should be left permanently To protect your park trailer, never leave food affixed to the park trailer: inside and ensure that all surfaces are clean.

  • Page 84: Torage & Maintenance Abs Plastic

    SECTION 11 STORAGE & MAINTENANCE and possibly damage the upholstery. This type of damage is not warrantable. ÉCOR TEMS Cleaning materials can be dangerous. Some are poisonous. Others are highly Décor items such as window treatments, night flammable. Some are dangerous if you pleated shades, mini blinds and décor glass breathe their fumes in a closed space.

  • Page 85: Abinetry & Tables

    SECTION 11 STORAGE & MAINTENANCE Grease spots and stubborn dirt can be cleaning agent in an inconspicuous area for cleaned off with an all-purpose spray cleaner. colorfastness. Harsh cleaners and organic solvents can Carpet (if so equipped) attack printed vinyl; they Vacuum regularly with a vacuum cleaner with recommended.

  • Page 86: Leaning The Exterior

    SECTION 11 STORAGE & MAINTENANCE hot, the vapor will condense on the reflector an ample amount of clean water and a car- and it will dim the surface. Replace a bulb washing mitt or sponge, wash the park trailer only with a new bulb of the same rating and from top to bottom.
  • Page 87 SECTION 11 STORAGE & MAINTENANCE stripping from freezing, treat it with a silicone spray. Waxing your park trailer Do not use a buffer and a buffing Wax your park trailer once or twice a year, or compound as it may damage the exterior when painted surfaces do not shed water surface.

  • Page 88: Oors & Locks

    SECTION 11 STORAGE & MAINTENANCE grease zerks in their ends. When grease is & S XTERIOR IDEWALL ENTS pumped into the zerk, it is channeled to the While you are cleaning the exterior roof, also inner bearing and then flows back to the outer inspect the roof vents (including sealants) for bearing and eventually back out the grease cracks and keep them clean.

  • Page 89: Oof Ladder (I F S O Equipped )

    SECTION 11 STORAGE & MAINTENANCE Sealants can be affected by ultraviolet ADDER QUIPPED exposure, air pollution, extreme temperatures Your park trailer may be equipped with an and exposure to other elements. Conditions optional roof ladder. The park trailer roof has such as rain, salt, dust and pollution may decking under the rubber roof membrane to increase the need to maintain your park...

  • Page 90: Torage Checklist

    SECTION 11 STORAGE & MAINTENANCE 1. Moldings 2. TV Antenna 3. Vents 4. Slideout Trim/ Moldings 5. Windows 6. Exterior Attachments 7. Clearance & Tail Lights include any items that are susceptible to TORAGE HECKLIST freezing. Prior to Storage _ Store your park trailer indoors, under a roof If storing for the winter, be sure the park trailer or purchase a breathable tarp to cover is winterized (refer to Sec.

  • Page 91: Aintenance Checklist

    SECTION 11 STORAGE & MAINTENANCE _ Remove snow loads from the top of your correctly “seated” after the tire change. park trailer to prevent damage to the unit’s Refer to the axle OEM operator’s manual. structure. Daily _ Ensure propane alarmr operation light is AINTENANCE HECKLIST green in color.
  • Page 92 SECTION 11 STORAGE & MAINTENANCE _ Inspect refrigerator combustion seals. _ Lubricate moving parts on the awning Have cleaned and adjusted as necessary hardware. (Awning option only.) by a qualified technician. (park trailer type _ Manually operate pressure- refrigerator only) temperature control lever on the water _ Inspect refrigerator door seals.

  • Page 93: Oem List

    SECTION 12 SPECIFICATIONS & GLOSSARY OEM L The following chart provides information to contact some of the individual original equipment manufacturers (OEM) of appliances/component parts that may be installed on your park trailer. The information listed in this chart is the latest available at the time of publication of this manual. If you have questions or concerns on component parts not listed here, contact your dealer for assistance.

  • Page 94: Oem Wheel Lug Torque Chart

    SECTION 12 SPECIFICATIONS & GLOSSARY OEM W HEEL ORQUE HART Wheel Lug Nut Diagrams: Wheel Torque Instructions: * All torque wrenches mentioned below must have settings visible for auditing purposes. Start lug nuts with fingers on studs to avoid cross threading. Stage 1, Torque: Impact lug nuts in a star pattern* until snug to rim.

  • Page 95: Ircuit Reakers

    SECTION 12 SPECIFICATIONS & GLOSSARY DC F ANEL AYOUT Below is a typical wiring layout. Your individual trailer may be different. 12-VOLT DC LAYOUT 20 RESET 10GA RED BED SLIDEOUT MOTOR 15 AMP 14GA PUR BATH/LAV AREA LIGHTS, BATH FAN 15 AMP 14GA GRN RESERVED FOR OPTION (RANGE HOOD &...

  • Page 96: S A R

    SECTION 12 SPECIFICATIONS & GLOSSARY PPROXIMATE LECTRICAL ATINGS Use actual amperage (or wattage divided by 120) of appliance being used whenever possible. 120 VOLT SYSTEM AIR CONDITIONER - COLEMAN MACH 13,500 BTU (RUN) 13.50-16.25 AMPS AIR CONDITIONER - COLEMAN MACH 13,500 BTU (START UP) 15.75-16.25 AMPS* BLENDER (ESTIMATED 300-400W) 2.50-3.50 AMPS...

  • Page 97: Lossary Of Terms

    BRITISH THERMAL UNIT (BTU) sell and/or service your camper by Jayco, Inc. Measurement of heat that is the quantity This term will be used in this context unless required to raise the temperature of one specified otherwise.

  • Page 98: Towing

    SECTION 12 SPECIFICATIONS & GLOSSARY FULL HOOK-UP SITE – A campsite that has HITCH WEIGHT – The amount of the city water, shore power and sewer hook-ups camper's weight that rests on the tow vehicle. or connections available. It should be approximately 10% - 15% with conventional trailers;...
  • Page 99 SECTION 12 SPECIFICATIONS & GLOSSARY SLEEPING CAPACITY WEIGHT RATING (SCWR) –The manufacturer’s designated number of sleeping positions multiplied by 154 pounds (70 kilograms). TIRE RATINGS - The MAXIMUM LOAD that a tire may carry is engraved on the sidewall, along with a corresponding COLD inflation pressure.
  • Page 100 SECTION 12 SPECIFICATIONS & GLOSSARY AGE IS NTENTIONALLY LANK...
