Appendix B: Troubleshooting

When Installing the PhatBox:
Problem
No lights come on at all.
The green light blinks for 15
seconds, then turns off, then
blinks for 15 seconds, then
turns off...this cycle rep eats
.
continuously
The green light blinks at a
steady rate for longer than 20
seconds.
Using the PhatBox:
Problem
The radio displays NO
MAGAZINE or CHK MAGAZINE.
Page 52
PhatNoise Car Audio System User Manual
3102-MAN Copyright 2003 PhatNoise Inc.
Cause/Solution
The PhatBox connector cable and/or head unit wiring
harness is connected incorrectly. Reconnect the
PhatBox connector cable and/or head unit wiring
harness correctly. Make sure each connection is
firmly connected.
Or,
The DMS cartridge is not fully inserted. Fully insert
the DMS cartridge.
Or,
A fuse in the car has blown. After checking for short
circuits in the wires, replace the fuse with one with
the same rating.
The DMS cartridge is not fully inserted. Fully insert
the DMS cartridge.
Or,
File(s) on your cartridge may be corrupt. Run the
PhatNoise DMS Doctor on your computer and follow
the recommendations.
You have updated the firmware on the DMS
cartridge and the PhatBox is reprogramming itself.
DO NOT REMOVE THE DMS CARTRIDGE. Allow the
PhatBox to reprogram itself for up to 10 minutes.
When reprogramming is complete, the lights will
turn off and stay off.
Cause/Solution
The system is still booting. Please wait up to 15
seconds for the system to boot, and switch back to
CD mode.
Or,
The DMS cartridge is not fully inserted. Fully insert
the DMS cartridge.
Or,
File(s) on your cartridge may be corrupt. Run the
PhatNoise DMS Doctor on your computer and follow
