Crossfire BMF200.2 User Manual

Car audio

Hide thumbs Also See for BMF200.2:

Installation manual (20 pages)

page of 9

/ 9
Bookmarks

Quick Links

Download this manual See also: Installation Manual

BMF200.2 | BMF300.2 | BMF400.2 | BMF600.2 | BMF400.4 | BMF600.4

BMF800.5 | BMF250M | BMF500M | BMF1000D | BMF1700D

Need help?

Do you have a question about the BMF200.2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Crossfire BMF200.2

Page 1 BMF200.2 | BMF300.2 | BMF400.2 | BMF600.2 | BMF400.4 | BMF600.4 BMF800.5 | BMF250M | BMF500M | BMF1000D | BMF1700D...
Page 2 TABLE OF CONTENTS IMPORTANT PLEASE READ ALL INSTRUCTIONS BEFORE INSTALLING! IMPORTANT MESSAGE ........The quality of installation may affect the performance and reliability of your Crossﬁre product.
Page 3 CLASS A/B FEATURES CLASS D FEATURES Fully 2 Ohm Stable Stereo Operation 1 Ohm Stable Mono Operation Military Spec. Audiophile Grade Components Military Spec Audiophile Grade Components High Efﬁciency MOSFET Power Supplies High Efﬁciency PWM Power Supply Multi-Stranded Power Torroid Multi-Stranded Power Torroid Efﬁcient Bipolar Output Transistors Oversized Torroidial Core...
Page 4 POWER - GROUND - REMOTE SPEAKER OUTPUT All Crossﬁre ampliﬁers are optimized to work within 12.00 to 14.5 volts DC. Therefore, as a precaution, the vehicle’s electrical LOAD system should be checked for correct voltage supply with the help of a voltmeter. First, connect the test leads of the voltmeter to Please be aware of the minimum impedance you may apply to your particular model ampliﬁer.
Page 5 2 CHANNEL WIRING CONFIGURATIONS CLASS D WIRING CONFIGURATIONS SINGLE CHANNEL TWO CHANNEL The Class D ampliﬁers are single channel ampliﬁers. Unlike Crossﬁre Class A/B ampliﬁers, these operate as single channel, OPERATION (BRIDGED) OPERATION (STEREO) therefore one ampliﬁer cannot be bridged by itself. Please see diagram below. BASS BASS FREQ.
Page 6 Master: this setting will maintain the same phase as the signal applied to it. SINGLE INPUTS 1. Use this setting if the ampliﬁer is not bridged with another ampliﬁer. 2. When strapping the ampliﬁers, use this setting only on the ampliﬁer that is connected to the head unit. Getting a clear signal from the head unit to the ampliﬁer is very important.
Page 7 LOW LEVEL INPUT CONFIGURATIONS CLASS A/B LOW LEVEL INPUT CONFIGURATIONS CLASS D Please note that your ampliﬁer may differ from those shown on this page. The following page has ad- Please note that your ampliﬁer may differ from those shown on this page. ditional model ampliﬁers and connection diagrams and conﬁgurations.
Page 8 IMPORTANT!! CROSSFIRE LIMITED WARRANTY The majority of failures seen with Class D ampliﬁers are due to people using them in vehicles without the proper electrical con- This warranty gives you speciﬁc legal rights, and you may also have other rights, which vary from state to state. This warranty is only valid on Crossﬁre products purchased in the U.S.A.
Page 9 Telephone: (972) 5 70 - 0 80 0 Fa x : ( 9 7 2 ) 57 0 - 22 0 0 w ww. cr o s s f i r e c a r a u d i o. c om...

This manual is also suitable for:

Bmf400.2 Bmf600.2 Bmf400.4 Bmf600.4 Bmf800.5 Bmf250m ... Show all
