Summary of Contents for Crossfire XS-8K

  • Page 1 Owner’s Manual XS-8K XS-8X...
  • Page 2 4 Way Protection Circuit 24 dB/oct, Variable Low Pass Filter (Thermal, Voltage, Speaker Short and DC) 24 dB/oct, Variable Subsonic Filter Subwoofer Level Controler Included XS-8K Voltage Range: 8.5V ~16V XS-8X Voltage Range: 8.5V ~18V SPECIFICATIONS Rated Power Output XS-8K @ 12.5V...
  • Page 3 POWER CONNECTIONS HEAD UNIT FUSE 800A GROUND GROUND BATTERY Caution This ampli er is not supplied with a internal fuse. Make sure you install a in-line fuse holder from the postitive (+) terminal of battery. Recommend 800 Ampere fuse. +12V Power Connect the +12V terminal of the ampli er to the positive (+) terminal of the battery using the same diameter cable as the ground cable, making sure you install a in-line fuse holder, approximately 300 or 400 mm.
  • Page 4 RCA & SPEAKER CONNECTION XS-8K & XS-8X INPUT CONNECTION HEAD UNIT Wired Remote Control 4 ~ 1ohms XS-8K & XS-8X SPEAKER CONNECTION XS-8K & XS-8X Speaker Connection 1 4 ~ 2ohms XS-8K & XS-8X Speaker Connection 2 4 ~ 2ohms...
  • Page 5 When wiring two ampli ers to a single subwoofer, please make sure power handling capabilities will not be exceeded. When in strapped mode connection, XS-8K & XS-8X the minimum working impedance Caution !! is 2 Ohms. Any impedance (load) lower than 2 Ohms can damage the ampli ers.
  • Page 6 DUAL AMP POWER CONNECTION (STRAPPED) POWER CONNECTION Remote Turn-On FUSE 800A GROUND GROUND BATTERY FUSE 800A GROUND GROUND BATTERY XS-8K Operating Voltage: 8.5V to 16V at 1Ohm. Caution !! XS-8X Operating Voltage: 8.5V to 18V at 1Ohm. Strapped Minimum Impedance is 2 Ohms.
  • Page 7 If XS-8K & XS-8X shut down due to excessive heat, they will remain in thermal protection until ampli er reaches normal operating temperature. Before removing your ampli er, refer to the list below and follow the sugguested proceedures.
  • Page 8 Crossfire Car Audio 3247 Story Rd. West Irving, TX. 75038 972.570.0800 or 800.332.2771 www.crossfirecaraudio.com...
