invotel SX8600 User Manual

Problems
6. • Wire distance to adapter is too long, Centralize the
MOH works but audio
location of device to be as close as possible to all the
does not stop when call
is picked up in 1 or 3 phones. Try the 2 setting for maximum power.
settings.
• If you are re-wiring "daisy chain" wiring works better than
" star" or "home run" or Independent wiring
• Press FLASH button to stop the music.
All your phones need to be same model for activation
•
7. Some Phones work ,
in 1 or 2 settings. If you mix different phone models,
some do not
Use the 3 setting (refer to pages 3 or 4 for more
details)
Randomly Hold music The call needs to be on Hold min. 2 sec. before you
8.
•
starts to play by it self may pick it up.
or does not activate in When you hang up, wait 2 seconds before selecting
•
1, 2 or 3 settings the same line again.
Check for extra devices sharing that line like Message
•
indicator, Answering machine, Alarm system, Modem
etc. Use a "privacy module" between the line and that
extra device to keep them off the line when line is
being used by your phone.
Set your Alarm system and/or your DSL line to share
•
FAX line.
Excessive wiring- Total wire length per line must be
•
under 500 feet ( Ex: if you have 9 wall jacks -no matter
spare or a phone plugged in- each connected via a
100 foot wire to a common point then your total wire
length is 9 x 100=900 feet )
Use FLASH button to deactivate music.
•
Audio shuts off or Extensive audio volume. Lower the volume to proper
9. •
flickers level.
If for any reason the hold music is activated
•
Hold Music activates in
10.
inadvertently, it can always be deactivated by pressing
a conference call or
the FLASH button in any setting.
when two phones pick
Conference calls can be done a better way: Press
up at same time •
FLASH, you will get a dial-tone now dial the phone
number of the 2
two calls together.
Innovative Telecommunication Technology LLC.
1112 Montana Ave Suite 250 Santa Monica, CA 90403 USA
Toll-Free: 800-747-0708 Tel: 310-899-0078 Fax: 310-230-5346
®
Possible Cause / Solution
nd
party then press FLASH to join the
Plug the included AC adapter.
•
Confirm that all 4 Red LED lights in front of this unit are double BLINKING
•
• Use one of your telephones and unplug the cord for L1/L2 from it and connect it
to 1/2/3 PHONE LINES jack on SX8600 (the 1
1/2/3 TELEPHONE jack on SX8600 (3
provided phone cord, make sure you have dial tone on your lines 1 and 2
• Now unplug the cord for L3/L4 from your phone and connect it to 3/4 PHONE
LINES jack on SX8600 (the 2nd jack from 12VAC) and connect 3/4
TELEPHONE jack on SX8600 (4
phone cord, make sure you have dial tone on your lines 3 and 4
• Observe that as you connect the lines the blinking lights turn OFF.
existing lines the lights keep blinking and that is OK)
Alternatively you may use a splitter (T adapter) at the Wall jack to connect both
• • • •
this device and a telephone (in that case the 3
Set the volume to mid level.
•
• Insert the Flash card into the blue connector in the front of unit, the Green status
LED in the back of the unit will turn ON.
Please note that just one telephone is optionally connected to this
device, other telephones remain connected to their own wall jacks.
VOLUME
REC
SWITCH
A B C 1 2 3
BANK
STATUS 1 2
L1 L2
P16
Model # SX8600
Rev 24E5
All-In-One Auto Attendant + Greeting +
Music-On-Hold Player/Recorder/Adapter
(110V AC to 12V AC)
st
jack from 12VAC), now connect
rd
jack) to your telephone using the
th
jack) to your telephone using the provided
rd th
and 4 jacks are not connected)
3/4
MIC AUDIO
WALL
PHONE PHONE JACK
IN IN OUT L3/L4 L1/L2/L3 L3/L4 L1/L2/L3 12VAC
TELEPHONE PHONE LINES
Flash Card
L3 L4
(on non
1/2
110 V
AUDIO
TEST
WALL
JACK
600ma
