Plug the included AC adapter. (110/240 V AC to 12V DC)
•
Confirm that all Red LED lights in front of this unit are double blinking
•
Use one of your telephones and unplug the cord for L1/L2 from it and connect it to L1/L2 IN jack on
•
SX8800, now connect L1/L2 OUT jack to your telephone using the provided phone cord, make sure
you have dial tone on your lines 1 and 2
If you have the SX8800-4L model unplug the cord for L3/L4 from your phone and connect it to L3/L4
•
IN jack on SX8800
telephone using the provided phone cord, make sure you have dial tone on your lines 3 and 4
Observe that as you connect the lines the blinking lights turn OFF.
•
blinking and that is OK)
Alternatively you may use a splitter (T adapter) at the Wall jack to connect both this device and a
• • • •
telephone
Please note: just one telephone
may be connected to this device,
other telephones remain connected
to their own wall jacks.
110/240 V
L3
L4
A B C
All-In-One Professional Music-On-Hold
Controller /Adapter
Models: SX8800-4L, SX8800-2L
(the rightmost jack)
(in that case the L1/L2 OUT jack and L3/L4 OUT in SX8800-4L are not connected)
12VDC
and connect L3/L4 OUT jack on SX8800
1 2 3
L1/L2
OUT
Audio
INPUT
Back of SX8800
L1 L2
A B C
Front of SX8800
Rev 29
nd
(2
jack from right)
(on non existing lines the lights keep
1/2
L1/L2
IN
to your
3/4
1 2 3
L3/L4
L3/L4
OUT
IN
Advertisement
Table of Contents
Related Manuals for invotel SX8800-4L
Summary of Contents for invotel SX8800-4L
- Page 1 SX8800, now connect L1/L2 OUT jack to your telephone using the provided phone cord, make sure you have dial tone on your lines 1 and 2 If you have the SX8800-4L model unplug the cord for L3/L4 from your phone and connect it to L3/L4 •...
- Page 2 2 on the phone, L2 LED on SX8800 must turn ON and you should hear audio from the phone Line 2 if you have the SX8800-4L: select line 3 on the phone, L3 LED on SX8800 must turn ON and you should hear audio from the phone Line 3 select line 4 on the phone, L4 LED on SX8800 must turn ON and you should hear audio from the phone Line 4 Double check your connections or adjust the volume if needed.
- Page 3 GE: 187, 2-9315-A, 2-9318, 2-9435-A -B -C, 2-9436-A, 2-9438-A, 2-9450-A -B -C -D -E -F, 2-9439-A to -EGL, 2-9451A, 2-9481, 2-9487GE2-A, 2-9488, 2-9638-A, 2-9975, 2-9488GE2-A IBM: 412, 412CID, 4900 ITL-4LT These phones are the most compatible and are available at http://www.invotel.com Northern Telecom: Unity Phonemate: PMG-4600...
- Page 4 A B C 1 2 3 Operation in B1, B2 settings: Hang up and set switches in front to B position and switches in the back to 1 position To activate: press then FLASH HOLD To deactivate just re-select that line and press FLASH Voice Deactivation: if the call has been on Hold at least a few seconds, it can also be deactivated by just speaking over the Audio for example say : “Hi I am Back”...
- Page 5 A B C 1 2 3 Operation in C1, C2 settings: Hang up and set switches in front to C position and switches in the back to 1 position C1 and C2 use “voice activation” method, this mode of operation supports most phones or brands by just using the Hold button but with slightly longer activation time (about 10 to 15 seconds after hold is pressed) In “Voice activation”...
-
Page 6: Package Content
Special Cases: Some phones like GE 2-9487GE2-A , GE 2-9488GE2-A and all RCA phones beep every few seconds when the calls are placed on Hold and may not work properly in C2 or B2 settings ( the beep may turn off the Hold Music in some cases) in that case use the B1 setting or use the A settings and increase the volume a bit so that the beeps are less noticeable to the callers. - Page 7 Adapter Trouble Shooting: Problems Possible Cause / Solution Adapter not working Unplug the 12VDC plug from the back of the SX8800 and or stopped working unplug the phone lines; Wait 60 seconds then plug them back in, make sure the AC adapter is plugged in securely. Adapter does not telephone was changed or power failure - do as above, activate or stopped...
- Page 8 LLC BE LIABLE FOR LOSS OF PROFITS OR BENEFITS, INDIRECT, SPECIAL, CONSEQUENTIAL OR OTHERWISE ARRISING FROM ANY BREACH OF THIS WARRANTY OR OTHERWISE. Innovative Telecommunication Technology LLC 1112 Montana Ave Suite 250 Santa Monica, CA 90403 USA http://www.invotel.com Phone: 310-899-0078 viii...
