INSTALLATION, OPERATION AND MAINTENANCE MANUAL
A MAJOR CAUSE OF OVEN-RELATED FIRES IS FAILURE
TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES)
TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST
IMPORTANCE THAT THIS OVEN BE INSTALLED ONLY IN
ACCORDANCE WITH THESE INSTRUCTIONS.
M
UGNAI N I
®
®
‡
‡
ˆ
ˆ
Mugnaini Commercial Gas Fired Ovens have been tested to:

ANSI Z83.11 & CAN/CGA–1.8
UL Subject 2162–2001 Safety Standards
NSF–4 Sanitation Standards
®
Mugnaini Series
COMMERCIAL GAS FIRED OVEN
Mugnaini Imports, Inc.
11 Hangar Way, Watsonville CA 95076
888.887.7206  │  831.761.7167  │  Fax:  831.728.5570
www.mugnaini.com  │  mugnaini@mugnaini.com


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G100 PA and is the answer not in the manual?

Questions and answers

Related Manuals for Mugnaini G100 PA

Summary of Contents for Mugnaini G100 PA

  • Page 1 I T A L Y ’ S O R I G I N A L P I Z Z A O V E N INSTALLATION, OPERATION AND MAINTENANCE MANUAL ‡ ‡ ˆ ˆ Mugnaini Commercial Gas Fired Ovens have been tested to:     ANSI Z83.11 & CAN/CGA–1.8 UL Subject 2162–2001 Safety Standards NSF–4 Sanitation Standards...

  • Page 2: For Your Safety

    READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS OVEN THIS MANUAL COVERS THE FOLLOWING TUSCANY SERIES MODELS: G100 PA G120 PA G140 PA G160X140 PA G180X140 PA ♦ ♦ ♦ ♦ WARNING WHEN THIS OVEN IS NOT PROPERLY INSTALLED, A FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS.

  • Page 3: Table Of Contents

    OPERATING AND MAINTENANCE INSTRUCTIONS CURING THE OVEN 8.1 CURING PROCESS 13 FIRING THE OVEN 9.1 OVEN TOOLS REQUIRED FOR OPERATING YOUR MUGNAINI WOOD FIRED OVEN 14 9.2 CONTROL BOX 15 9.3 DAILY OPERATIONS 16 9.4 DAILY START UP 16 9.5 PRE-HEAT 16 9.6 AUTOMATIC MODE 16...

  • Page 4: Installation Instructions

    NOTE: Once your oven is loaded onto a truck you have created a contract between you and the trucking company. Mugnaini Imports does not control the delivery of your oven. 1.1 DELIVERY LOCATION Proper planning is essential to a successful delivery. Be realistic about where you plan to take delivery of your oven;...

  • Page 5: Unloading, Moving And Setting The Oven

    Remove the lag bolts. The oven is now ready to be moved. 2.3 TOOLS REQUIRED • Diagonal cutters and razor knife • Hammer and pry bar • Screw gun and bits • Socket set Mugnaini Imports, Inc. PAGE 5 11 Hangar Way, Watsonville CA 95076 888.887.7206  │  831.761.7167  │  Fax:  831.728.5570 www.mugnaini.com  │  mugnaini@mugnaini.com...

  • Page 6: Moving The Oven

    Lift from under the body of the oven Move with pallet jack under stand Use bar across pallet jack to support oven Mugnaini Imports, Inc. PAGE 6 11 Hangar Way, Watsonville CA 95076 888.887.7206  │  831.761.7167  │  Fax:  831.728.5570...

  • Page 7: Clearances And Facades

    1/2” Concrete board Metal stud 1” Min Oven front 1” Min 1” Min Non-combustible oor or oor covering Clearances to Combustible Construction Mugnaini Imports, Inc. PAGE 7 11 Hangar Way, Watsonville CA 95076 888.887.7206  │  831.761.7167  │  Fax:  831.728.5570 www.mugnaini.com  │  mugnaini@mugnaini.com...

  • Page 8: Installation Accessories

    ® 3.3 INSTALLATION ACCESSORIES Side panels are available from Mugnaini to frame in the stand on freestanding ovens. If the base of the oven is to be completely enclosed; use the optional Gas Cover Panel Kit to ensure adequate combustion air reaches the burner.

  • Page 9: Venting The Oven

    SINGLE WALL AND B-TYPE VENT PIPES ARE NOT ACCEPTABLE FOR THIS TYPE OF APPLIANCE! IT IS IMPORTANT FOR THE INSTALLER TO CONTACT THE LOCAL BUILDING OR FIRE INSPECTOR TO DETERMINE WHICH VENTING METHOD IS ACCEPTABLE. Mugnaini Imports, Inc. PAGE 9 11 Hangar Way, Watsonville CA 95076 888.887.7206 ...

  • Page 10: Direct Venting With Factory Built Chimney

    (+/- 1”) behind the front panel 5.4 CONNECTING FACTORY BUILT CHIMNEY TO OVEN Mugnaini offers an optional Direct Vent Flue Adaptor for installation in the factory. Part# DVA is a flush mount adaptor designed to accept a standard Anchor Plate used with UL 103 double wall insulated chimney.

  • Page 11: Direct Venting With Factory Built Grease Duct

    (+/- 1”) behind the front panel 6.4 CONNECTING FACTORY BUILT GREASE DUCT TO OVEN Mugnaini offers an optional Direct Vent Flue Adaptor for installation in the factory. Part# GDV has a 2” weldable stainless stub for a field welded grease duct adaptor.

  • Page 12: Indirect Venting

    Type 1 Hood Placement SEEK OUT A QUALIFIED PROFESSIONAL TO DESIGN AND INSTALL YOUR VENTING SYSTEM. CHECK WITH LOCAL AUTHORITIES FOR SPECIFIC CODE REQUIREMENTS Mugnaini Imports, Inc. PAGE 12 11 Hangar Way, Watsonville CA 95076 888.887.7206  │  831.761.7167  │  Fax:  831.728.5570...

  • Page 13: Curing The Oven

    • Allow oven to come up to pizza temperature and maintain for 6 hours. • You may now cook as soon as the oven is up to temperature. Your Mugnaini gas fired oven is now fully cured and ready for service! Mugnaini Imports, Inc.

  • Page 14: Firing The Oven

    FIRING THE OVEN The Mugnaini Gas Fired Pizza Oven is an open hearth appliance designed to cook with high heat and a live fire. The oven may be utilized for a variety of cooking techniques such as high heat roasting, as a bake oven and of course a pizza oven.

  • Page 15: Control Box

    If the oven loses its flame, the Reset button will be illumined. Press the Reset button to relight the burner. If the burner goes out three times in a row contact Mugnaini service department to rectify the problem. 9.2.5 FIRE CONTROL The size or intensity of the flame can be changed by pressing the up or down arrows to achieve the desired flame.

  • Page 16: Daily Operations

    Photo instruction and oven accessories are available on our website: www.mugnaini.com Please call our office 888.887.7206 for more personalized instruction, to schedule a class or to purchase any accessories you may need.

  • Page 17: Cooking Environments

    WARNING THE BURNER SYSTEM MUST BE TURNED OFF IF THE DOOR IS FULLY CLOSED.NEVER USE WATER OR ICE TO LOWER TEMPERATURE INSIDE THE OVEN. Mugnaini Imports, Inc. PAGE 17 11 Hangar Way, Watsonville CA 95076 888.887.7206  │  831.761.7167  │  Fax:  831.728.5570...

  • Page 18: Maintenance Instructions

    Be careful to not over fire the oven. Note: The scheduled maintenance cycle may change according to oven usage, the products cooked and seasonal weather/HVAC changes. Mugnaini Imports, Inc. PAGE 18 11 Hangar Way, Watsonville CA 95076 888.887.7206 ...

  • Page 19: Limited Warranty

    Warranty Period by Mugnaini or its authorized representative. Any and all rights under this warranty or at law of Original Purchaser against Mugnaini shall terminate and be void in the event Warranty Claims are not submitted within the time set forth in the immediately preceding sentence.

  • Page 20: Mugnaini Imports, Inc

    11 Hangar Way Watsonville, California 95076 Before any Oven is returned for repair, written authorization must be obtained from Mugnaini or its authorized representative for the return and instructions, as to how and where the Oven should be shipped. Any Oven returned to Mugnaini for examination shall be shipped with all shipping charges prepaid, at Original Purchaser’s expense, via the means of transportation indicated as acceptable...

This manual is also suitable for:

G120 paG140 pa
