Summary of Contents for Safa Media SR-M180
- Page 1 SF69-00291A...
- Page 2 MP3 Voice Recorder SR-M180/M160 Thank you your purchasing a MP3 VOICE RECORDER. Please read this User Guide before you use your MP3 VOICE RECORDER. There is a warranty inside of manual. Please state the content of warranty when you purchase it.
- Page 40 Smart Audio & Future Audiopia SAFA MEDIA Co., Ltd.
-
Page 41: Special Features
Special features 1. Function to Record Maximum 297EA items & Function to Save 99EA MP3/WMA Files. 2. Function to Play MP3/WMA File. 3. Function to Save Additional Data File. (99 EA) 4. Fast saving to PC via USB1.1(Max 3.5Mbpx). 5. Convenient and easy to carry slim-line design. 6. -
Page 42: Table Of Contents
Table of Contents Special features ............... 1 Preparation Cautions and Warnings..........4 Check the components ..........5 Names of each part............6 LCD Indicator and Symbols ........... 8 Use of the batteries ............9 Getting Started..............10 How to Use Recording................11 Voice Recording.............12 - Recording with the Built-in microphone ....12 - Recording with the external microphone....12... - Page 43 Additional Function (Recorder) ........24 -Recording Date/Time Check Function .....24 Saving into the external appliance .......25 - To save into external audio (such as cassette recorder) - To save into a PC via USB ........25 Sound Map M ..............26 - Sound Map M Installation ..........26 - Connecting to your PC ..........27 - Sound Map M Configurtion ..........28 - PC file management ..........30...
-
Page 44: Cautions And Warnings
Cautions and Warnings Cautions 1. Do not attempt to open repair, or modify. 2. Do not use this product where the use of electronic devices is prohibited. (such as in aircraft, etc.) 3. Do not put this product or any of its accessories in your mouth. 4. -
Page 45: Check The Components
Check the components Recorder and accessories Adaptor for telephone Cable for telephone Main unit conversation recording conversation recording Stereo earphone USB cable External Microphone Audio Cable CD-ROM Battery (AAA X 1) User's manual... -
Page 46: Names Of Each Part
Names of each part Main Unit... - Page 47 Button Function It is the external line input connector. Liquid Crystal Display: it displays the current status. It is "Forward" button and is used to move to the next file. It is "Rewind" button and is used to move to the previous file. It is "Playback"...
-
Page 48: Lcd Indicator And Symbols
LCD Indicator and Symbols Description of Screen Display Folder displayed Folder display ( When Using as Mp3 Player) ( When Using as Recorder) Indication of File Index display Recording mode Indication of Recording Indication of Battery sensitivity mode Indication of Repetition VOR display Indication of Recording Indication of Recording... -
Page 49: Use Of The Batteries
Use of the batteries < Purchasing the product > Open the battery cover. Please open battery. To prevent batteries from discharging, remove the plastic pack. Insert the batteries. 1. Check the polarity of the batteries (Size "AAA") and close the cover. (Figure 2) (Figure 1) 2. -
Page 50: Getting Started
Getting Started Switching On (Figure 1-1) (Figure 1-2) Press the (PLAY/PAUSE) button to switch on the product. The product will switch to standby mode. Alternatively, you can press the (REC/PAUSE) button. Switching MP3 VOICE RECORDER Off The power will be automatically shut off if you do not do activate any functions for 1 minute. -
Page 51: Recording
Recording Please note the followings before you start recording Check that the product is in standby mode. Press and hold PLAY/PAUSE button in the stop state to turn off the power. If it is not established as Recorder Mode (the Mode of Picture 1-1), recording is impossible. Press the (Play/Pause) button to display the remaining recording capacity. -
Page 52: Voice Recording
Voice Recording Establish sensitivity of recording, folder, VOR function and tone quality (HQ, SP and LP) in prior to recording. Recording with the Built-in microphone Establish Recorder Mode through pushing MODE Key. You can use the function when the product is on the desk or table. 1 Direct the product's built-in microphone towards the source of the sound. -
Page 53: Recording With Line-In
Recording with line-in Establish sensitivity of recording, folder, VOR function and tone quality (HQ, SP and LP) in prior to recording. In case of LINE recording, too much volume can cause distortion of sound. Recording from external appliances (Audio, PC) 1. -
Page 54: Recording The General Telephone Conversation
Recording the general telephone conversation 1. Connect the audio cable in the MP3 VOICE RECORDER Audio Cable Connector (LINE). Connect the adapter and the telephone with the cable for telephone conversation recording. Then, connect the handset cable of the telephone to the adapter. 2. -
Page 55: Playback
Playback Recorded voice file playback Setup the recorder mode using MODE button before playing. Adjust the volume using VOLUME UP/DOWN button while playing. 1. Press the FOLDER/REPEAT button to select the (Figure 3-1) (Figure 3-2) Folder (A, B, C) you want. If there is no selection, current File will be played. -
Page 56: High-Speed Search
High-speed Search Present function is possible under both of Recorder and MP3 Player Modes. 1. If you push NEXT or BACK Key in the middle of Play over 0.5 second, display time will rapidly increase or decrease on LCD screen without sound while pushing it. 2 Release the button when you want to start playback. -
Page 57: Repetition Playback
Repetition Playback Present function is possible under both of Recorder and MP3 Player Modes. If you push (PLAY /PAUSE) Key under Repeat Play Mode, it will pause. Section Repetition -It repeats the specific section within one file. (Figure 3-5) 1. Press FOLD/REPEAT button briefly where you want to start the section repetition. -
Page 58: Folder Repetition
Folder Repetition (Figure 3-7) (Figure 3-8) It repeats all Files in one Folder. This function will be performed in the recorder or MP3 Player as the same function. 1. Please push FOLDER/REPEAT Key once for long time (about 2 seconds) under twice Play Mode. 2. -
Page 59: Deletion Of File
Deletion of File Deletion of one File (Figure 4-1) Deletion Time depends on the quantity of File. It operates under both of Recorder and MP3 Player Modes . 1. Press (STOP/DEL) button briefly during playback or stop state. The index number appears and DEL flashes while your Sound MAP still plays the music in delete standby state. -
Page 60: Menu Function
Menu Function MENU item order: SENSE BACK LIGHT Recorded voice quality Current time SCAN Time setup SENSE. It operates just under Stop Mode. Push the button once. It operates just Under Recorder Mode and does not enter into Menu Mode. Establishment of Mice Recording Sensitivity (Figure 5-1) (Figure 5-2) -
Page 61: Establishment Of Back Light
Establishment of Back Light (Figure 5-5) (Figure 5-6) It is the method to decide whether to turn on Back Light or not when you pushing Key. When you buy product first, it will be established as Back Light ON Mode . 1. -
Page 62: Time Check Function
Time Check Function (Figure 5-10) (Figure 5-11) When you insert batteries after you purchase the product, the time will start with 00:00:00, 01, Jan, 2003. If you do not replace the batteries within 2 minutes, the time will be as above. 1. -
Page 63: Clock Setting
Clock setting This is for setting the present date and time. 1. Please push MENU/HOLD Key six times for short time under Stop Mode. 2. In First Date Establishment Mode, Cusor will blink in front of Y(Year). (Figure 5-14) 3. Establish Date with VOLUME UP/DOWN Key. (Figure 5-15) 4. -
Page 64: Additional Function (Recorder)
Additional Function (Recorder) Recording Date/Time Check Function In case of recording, established Date/Time is saved. It is the function to check the time. (Figure 6-1) (Figure 6-2) 1. Please push MODE Key for long time under Stop Mode. (Figure 6-1) 2. -
Page 65: Saving Into The External Appliance
Saving into the external appliance To save into the external audio (such as cassette recorder) 1. Connect one end of the audio cable to the earphone jack of your recorder and the other end to the microphone input jack or AUX input jack of the external audio appliance. Main unit External appliance Audio Cable... -
Page 66: Sound Map M
Sound Map M Installation 1. Sound Map M Installation After inserting the installation CD into CD-ROM of your PC, it runs automatically and the following screenshots appear. Continue the installation process by pressing "NEXT" button on the following screenshot. Note) The requirements for PC necessary to install Sound Map M are: Windows 98SE/Me/2000/XP, USB 1,1... -
Page 67: Connecting To Your Pc
Connecting to your PC 2. Connecting to your PC Connect the recorder to your PC using the applied USB cable. When you connect to PC, do not connect an earphone with a line cable. In Windows 98SE/Me/2000, after connecting, the installation is finished automatically. -
Page 68: Sound Map M Configurtion
Sound Map M Configuration 3. Sound Map M Configuration 1) Sound Map M Configuration Selected PC folder Filter setup PC file Recorder file Information/Instructions Memory capacity... - Page 69 Sound Map M Configuration 2) Button description (1) PC file buttons Moves to the upper folder. Creates a new folder. Deletes the selected file. Converts the selected recorded file to WAVE format or vice versa. Refresh and display the contents. (2) Recorder file buttons After connecting, the color LCD flashes and the status of connection appears.
-
Page 70: Pc File Management
PC file management 4. PC file management 1) Sending files to the recorder (1) Select the files to send. (2) Select the folders in the recorder and click the "download" button. - Page 71 PC file management 2) Converting the recorded files (1) Select the files to convert. (2) Click the "convert" button.
-
Page 72: Recorder File Management
Recorder file management 5. Recorder file management 1) Sending files to PC (1) Select the files to send. 2) Click the "upload" button. - Page 73 Recorder file management 2) Deleting the selected files (1) Select the files you want to delete. (2) Click the "delete" button.
- Page 74 Recorder file management 3) Deleting all files. (1) Click the "format" button.
-
Page 75: Dvf Player User Guide
DVF player User's guide 1. How to play 1) Press ' ' button to open OPEN FILE window. 2) Select a file and open the file. 3) In the program status window, the selected file name and the total playback time will be displayed. 4) If you press ' ' button, the progress bar is moving and playback the file. - Page 76 DVF player User's guide 3. How to cut off the specific part of the file. 1) If you want to cut off the fore part of the file, (A) First, Place the progress bar at the point you want to cut off. (B) Press ' ' button.
-
Page 77: Specification
Specifications Item LP : 2730minutes (45hours) LP : 1350minutes Maximum Recording Time SP : 2184minutes (36hours) SP : 1070minutes HQ : 1197minutes (19hours) HQ : 590minutes MPEG Support MP3(8Kbps ~ 320Kbps) / WMA (64Kbps ~ 192Kbps) Memory Flash Memory(128MB) Flash Memory(64MB) File Structure Standard DOS File System (FAT 12/16) PC Interface... - Page 78 1. Malfunction due to user's negligence. 2. Malfunction due to unauthorized modification or repair 3. Malfunction due to natural hazards (such as fire, seawater, flood, or war). 4. When the warrantee period is expired. Smart Audio & Future Audiopia SAFA MEDIA Co., Ltd.
