AvaLAN AW58100HTA User Manual

5.8 ghz outdoor 100 mbps wireless ethernet access point and subscriber unit radios
Hide thumbs Also See for AW58100HTA:
Table of Contents

Advertisement

Quick Links

Download this manual
AW58100HTA
AW58100HTS
User's ManUal
5.8 GHz Outdoor 100 Mbps
Wireless Ethernet Access Point
and Subscriber Unit Radios
AvaLAN
Industrial-grade, long-range wireless Ethernet systems
W
I
R
E
L
E
S
S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW58100HTA and is the answer not in the manual?

Questions and answers

Related Manuals for AvaLAN AW58100HTA

Summary of Contents for AvaLAN AW58100HTA

  • Page 1 AW58100HTA AW58100HTS User’s ManUal 5.8 GHz Outdoor 100 Mbps Wireless Ethernet Access Point and Subscriber Unit Radios AvaLAN Industrial-grade, long-range wireless Ethernet systems...

  • Page 2: Table Of Contents

    Thank you for your purchase of this member of the 5.8 GHz Outdoor 100 Mbps family of wireless Ethernet radios. The AW58100HTA is a radio with dual omnidirectional antennas. It serves as an Access Point (master) in a point-to-multipoint network. The AW58100HTS is a radio with a dual flat panel high gain directional antenna.

  • Page 3: Quick Start Guide

    Activate the AW58100HTS units one at a time until they can be given distinct IP addresses. Step 1. Gather the parts: In addition to the AvaLAN radios and the accompanying AW-POE Power Over Ethernet Injectors and 12VDC power supplies, you will need at least 2 CAT5 cables and a PC with a LAN connection.
  • Page 4 Re-position antennas if necessary to bring the signal strength below -30 dBm. Utilizing state of the art MIMO technology, the AW58100HTA/S achieves very high data rates through a combination of dual spacial streams and higher level OFDM modu- lation.

  • Page 5: Physical Setup

    It is important that the AW58100HTS antennas be pointed toward their Access Point AW58100HTA. Because the 3 dB beamwidth of the flat panel an- tennas is just 8°, careful aiming is very important − especially over long distances.

  • Page 6: Connecting To The Radio

    AW58100HTA, HTS User’s Manual Connecting to the radio 1. Digital configuration is done by means of the radio’s built in browser interface. The unit should be powered on and connected at least temporarily to a network containing a computer that can run a conventional web browser.

  • Page 7: Changing The Configuration - Step By Step

    Recovery can be a time-consuming process and will require the help of AvaLAN Technical Support. If you are changing parameters over the RF link (we do not rec- ommend this), be sure to make the remote changes first because the link will be broken if the SSIDs or Security Pass Phrases do not agree.
  • Page 8 AW58100HTA, HTS User’s Manual 3. Setting the SSID: • On the Main Menu at the left side of the browser window, click “Wireless.” Then click anywhere in the “Wireless_Radio” row to bring up the “Interface <Wireless_Radio>” page. • The second line down in the content table shows the current SSID and pro- vides a text box to change it.
  • Page 9 User’s Manual AW58100HTA, HTS 5. Setting the Access Point Frequency Channel and Bandwidth: • On the Main Menu at the left side of the browser window, click “Quick Set.” This returns you to the page presented after login. • The default Frequency Channel is 5805 MHz. There are more choices available in the dropdown list than are legal or appropriate for this set of products.

  • Page 10: Viewing Status Information

    User’s Manual Viewing Status Information After configuring your AvaLAN radios and establishing links among them, you can use the browser interface to view status and troubleshooting Information. The initial “Quick Set” page will show whether the wireless link is operating and the current signal strength.
  • Page 11 This screen is a very tall window with several interesting sections shown on the next page. The top “General” section shows information that may be useful if you contact AvaLAN Technical Support. The “Signal” section shows transmit and receive signal strength overall and by in- dividual MIMO channel.

  • Page 12: Advanced Diagnostic Tools

    AW58100HTA, HTS User’s Manual Advanced Diagnostic Tools You may want to contact AvaLAN Technical Support for more guidance before using the additional tools described in this section. The radio’s browser interface unlocks some additional features if you login as an advanced user instead of the standard user described earlier in this manual.
  • Page 13 • Files - Lists the files associated with the web interface of the radio. This information may be useful when contacting AvaLAN Technical Support. You are cautioned not to de- lete or alter these files without instructions from AvaLAN Technical Support. (It is very easy to render your radio in- operative by doing so.)
  • Page 14 AW58100HTA, HTS User’s Manual 2. Flood Ping: This tool can be used to generate a continuous string of ping com- mands to any IP address the radio can see on its subnet. Ping uses ICMP (Internet Control Message Protocol) to request a packet from the target device, waits for a return and then immediately sends another request.
  • Page 15 Linux or MAC OSX by using a Windows emulator such as Wine. By clicking the discovery button labeled “...”, any AvaLAN AW58100 family products on your LAN will be reported. (You may also see other devices as well if they respond to the CDP protocol used by the utility.) The popup window will show the IP address of each...

  • Page 16: Frequency Channels

    This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This warranty does not cover defects resulting from misuse or modification of the product.
