- Page 1 AW58300HTA AW58300HTS User’s ManUal 5.8 GHz Outdoor 300 Mbps Wireless Ethernet Access Point and Subscriber Unit Radios AvaLAN Industrial-grade, long-range wireless Ethernet systems...
-
Page 2: Table Of Contents
Thank you for your purchase of this member of the 5.8 GHz Outdoor 300 Mbps family of wireless Ethernet radios. The AW58300HTA is a radio with dual omnidirectional antennas. It serves as an Access Point (master) in a point-to-multipoint network. The AW58300HTS is a radio with a dual flat panel high gain direc- tional antenna. -
Page 3: Quick Start Guide
User’s Manual Quick Start Guide To create a point-to-multipoint system, you need one AW58300HTA Access Point and one or more AW58300HTS Subscriber Units. We recommend connecting and powering up the units on the bench before deploying in the field because it is much easier to troubleshoot problems and to adjust the configuration if necessary without having to climb poles to do it. - Page 4 If you think that the IP address of the radio has been changed, you can find it using a utility available from the AvaLAN website. Go to www.avalanwireless.com and find the “Downloads” tab under the “Support” menu. On the Downloads page you should find the AW58100 IP Finder Utility.
-
Page 5: Operational Summary
Step 7. If there is more than one AW58300HTS in your system, repeat step 6 for each unit. Operational Summary Utilizing state of the art MIMO technology, the AW58300HTA/S achieves very high data rates through a combination of dual spacial streams and higher level OFDM modulation. The default RF configuration provides a 40 MHz channel bandwidth with 2 selectable non-overlapping channels to choose from. -
Page 6: Physical Setup
4. The AW58300HTS units have dual element high gain (23 dBi) directional flat panel antennas. The AW58300HTA unit has two antennas that are omnidirectional in the horizontal plane. It is important that the AW58300HTS antennas be pointed toward their Access Point AW58300HTA. Because the 3 dB beamwidth of the flat panel antennas is just 8°, careful aiming is very important −... -
Page 7: Digital Configuration
3. The initial page after a successful login is “Quick Set.” The content of this page is somewhat differ- ent for the AW58300HTA Access Point and for the AW58300HTS Subscriber Unit (see the screen shots in the Quick Start Guide). -
Page 8: Changing The Configuration - Step By Step
IP address. In the event of a lost pass- word, please contact AvaLAN technical support for assistance. If you are changing parameters over the RF link (we do not recommend this), be sure to make the remote changes first because the link will be broken if the SSIDs or Security Keys do not agree. - Page 9 AW58300HTA, HTS User’s Manual 2. Setting the User Password: • On the Main Menu at the left side of the browser window, click “System”, then click “Password.” • Enter the old password and the new password twice in the boxes indicated.
- Page 10 AW58300HTA, HTS User’s Manual • The Channel Width should be left at 20/40 MHz HT Above. This is the only supported option for this product. • The Frequency dropdown box provides many more choices than are useful (or even legal). The only supported choices here are 5805 MHz (the default) or 5745 MHz.
-
Page 11: Viewing Status Information
User’s Manual Viewing Status Information After configuring your AvaLAN radios and establishing links among them, you can use the browser interface to view status and troubleshooting Information. The initial “Quick Set” page will show whether the wireless link is operating and the current signal strength. For more comprehensive infor- mation, choose “Wireless”... - Page 12 AW58300HTA, HTS User’s Manual Most of the information on the top part of this page was covered in the Digital Configuration section of this manual. The status information in the lower part of the page is mostly self-explanatory. Here are a few additional notes: •...
-
Page 13: Advanced User Mode
The initial Quick Set page has two differences, a menu addition and a “Upgrade” file entry box: From time to time, AvaLAN may update the firmware for your radio. If this happens, the new version may be downloaded from www.avalanwireless.com by visiting the Downloads page under the Support Menu tab. - Page 14 AW58300HTA, HTS User’s Manual The Bandwidth Test is essentially a ping flood and may be performed with any device but is usually performed on the radio on the other end of the RF link. To run a test, do the following: •...
-
Page 15: Technical Specifications
Technical specifications CHARACTERISTIC SPECIFICATION/DESCRIPTION RF Data Rate Up to 300 Mbps Output power AW58300HTA Access Point 1 Watt EIRP with 6 dBi omnidirectional antenna Output power AW58300HTS Subscriber 4 Watts EIRP with 23 dBi directional antenna Unit Receiver Sensitivity -115 dBm for HTS and HTP configurations, -101 dBm for the HTA Frequency Range 5.725 - 5.850 GHz... -
Page 16: Limited Warranty
This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This warranty does not cover defects resulting from misuse or modification of the product.
