Programming With Code Lists - RCA RCU500 Operation Manual

Programming Your Universal Remote
Programming a Device using CODE LISTS
1. Find codes for each device and brand on
page numbers shown below.
Device
TV
VCR
LaserDisc Player 14
Satellite Receiver 14
Cable Box
Audio Equipment 15
2. Press and hold the TV, VCR1, VCR2•LD,
SAT•CABLE, or AUDIO button you want to
set up. SAT•CABLE can be programmed to
operate other Satellite Receivers.
3. Enter the three digit code from the
TV, VCR, Laserdisc Player, Satellite
Receiver, Cable Box, or Audio code list.
4. Release the device key.
5. With the device on, press another button,
for example CHANNEL UP. If the device
responds, no further programming is
required. If the device does not respond,
repeat 2-4 using another code.
6. Enter your device codes here for easy reference.
TV CODE
SAT•CABLE CODE
Page
12
13
14
VCR1 CODE
AUDIO
PRESS
& HOLD
ENTER
YOUR
CODE
RELEASE
VCR2•LD CODE
5
