APPLICATION

The F118 In-Ceiling Media Air Cleaner uses a three-speed
direct-drive, forward-curve blower motor and a 95 percent
DOP particle filter to capture airborne particles such as dust,
soot, and cooking smoke from the air circulated through it.
When equipped with two CPZ™ modules, the air cleaner also
adsorbs gases and odors from the air passing through it. The
F118 is recommended for use in rooms with drop ceilings, and
for spaces with structural ceilings not higher than 16 feet (4.8
meters) where there is a minimum one-foot (0.3 meter)
clearance between the drop ceiling and the structural ceiling.
The air cleaner is designed to use the Coanda effect to
circulate air throughout the space. This effect is the tendency
of air to travel close to a wall contour when ejected from a jet.
The air cleaner draws contaminated air up from the center of
the room, forces it through the filters, and then blows the
filtered air out through the narrow ends of the air cleaner.
The Honeywell Trademark is used under license from Honeywell
Intellectual Properties, Inc. by Air-Pure Systems.
Honeywell International Inc. makes no representations or warranties
with respect to this product.
F118 In-Ceiling
Media Air Cleaner

FEATURES

• The DOP particle filter is 95 percent efficient at 0.3
micron particles, and more efficient on particles
smaller and larger.
• CPZ™ modules can reduce space odors.
• Circulates up to 425 cubic feet per minute (723 cubic
meters per hour).
• Provides Coanda air distribution by drawing in dirty
air, cleaning it, and bi-directionally recirculating the
filtered air throughout the space.
• Designed to overcome the increase in air flow
resistance normally caused by filter loading.
• White color cover complements the ceiling.
• Accessible three-speed pushbutton switch.
• Optional wall-mounted remote switch.
• Filters are easily removed and replaced.
• READ AND SAVE THESE
INSTRUCTIONS
Application ........................................................................
Features ...........................................................................
Specifications ...................................................................
Ordering Information ........................................................
Planning the Installation ...................................................
Installation ........................................................................
Operation ..........................................................................
Service .............................................................................
Parts list ............................................................................
Limited Two-Year Warranty .............................................. 12
PRODUCT DATA
Contents
1
1
2
2
3
4
8
8
9
68-0209-2

Advertisement

Table of Contents
loading

Related Manuals for Honeywell F118

Summary of Contents for Honeywell F118

  • Page 1: Table Of Contents

    When equipped with two CPZ™ modules, the air cleaner also • READ AND SAVE THESE adsorbs gases and odors from the air passing through it. The F118 is recommended for use in rooms with drop ceilings, and INSTRUCTIONS for spaces with structural ceilings not higher than 16 feet (4.8 meters) where there is a minimum one-foot (0.3 meter)

  • Page 2: Specifications

    Operating: Ambient temperatures usually below 77°F (25°C) M16213 PRE-FILTER (WRAPS) but occasionally as high as 104°F (40°C). PARTICULATE FILTER Fig. 1. Approximate dimensions of F118 in in. (mm). Humidity: Up to 95% relative humidity, non-condensing. Mounting: Air Volume: Hangs freely from structural ceiling.

  • Page 3: Planning The Installation

    — room use. — outdoor air quality. Assuming that the structural ceiling height is no higher than 16 ft (4.8m), one F118 set on high speed cleans 425 cfm, 25,500 cf/hr (723 m /hr). The number of air changes per hour determines the amount of air cleaning that occurs.

  • Page 4: Installation

    Sharp Edges. Can cause personal injury. See Fig. 4 and use these instructions to mount the F118 as Wear protective gloves and handle air cleaner care- part of a drop ceiling: fully to avoid cuts from sharp metal edges.
  • Page 5 F118 IN-CEILING MEDIA AIR CLEANER STRUCTURAL CEILING PLACE WIRE SUPPORTS AS CLOSE AS POSSIBLE T-BAR/DROP CEILING SUPPORT SYSTEM TO F118 SUPPORT SHOULDER POSITIONS, APPROXIMATELY 5 IN. (127 MM) FROM ENDS. 24 IN. 24 IN. (610 MM) (610 MM) 24 IN.

  • Page 6: Install Filters

    LOW SPEED 1.4A AT 120V - 60 HZ M16210A pletely supported. Fig. 5. Typical F118 120V, 60 Hz Wiring Diagram. IMPORTANT Avoid excessive pressure on individual adsorbent panels. BLACK BLUE 1.
  • Page 7 F118 IN-CEILING MEDIA AIR CLEANER F118 CABINET SPRING-LOADED PLUNGER (PULL APART THEN TOWARD YOU TO OPEN) UPPER EDGE OF FILTER MODULE CABINET CONCEALED WILL REST ON ABOVE DROP CEILING F118 CABINET TIP CPZ™ SORBENT FILTER MODULE SLIGHTLY TO INSERT INTO F118 CABINET...

  • Page 8: Operation

    However, at least 20 percent of a specified A very dirty filter reduces air cleaner airflow. ventilation code rate must be derived from outdoor air. The F118 Air Cleaner filtered and re-circulated air can supply the Opening/Closing Grille remaining 80 percent.

  • Page 9: Parts List

    F118 IN-CEILING MEDIA AIR CLEANER Motor NOTE: When tobacco smoke is a contaminant, both the par- ticle filter and the CPZ adsorbent filter must be ser- The motor is visible when the filter frame is removed. Inspect viced at the same time.
  • Page 10 F118 IN-CEILING MEDIA AIR CLEANER M14421 Fig. 10. F118 Air Cleaner components. 68-0209-2 Revised 11-07...
  • Page 11 F118 IN-CEILING MEDIA AIR CLEANER NOTES 68-0209-2 Revised 11-07...

  • Page 12: Limited Two-Year Warranty

    F118 IN-CEILING MEDIA AIR CLEANER LIMITED TWO-YEAR WARRANTY Air-Pure Systems warrants its air cleaner products to be free from defects in workmanship or materials under normal use and service, for a period of two (2) years from the date of purchase by the original end-user. If at anytime during the warranty period the product is defective or malfunc- tions, Air-Pure Systems, through the distributor or dealer, from which the product was purchased, or through an authorized warranty repair station, shall at Air-Pure Systems option, replace or repair the defective product or component.
