LevelOne
KVM-0115/KVM-0117
15 / 17-inch LCD KVM Rack Console

User Manual

Version 1.0-1305
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KVM-0115 and is the answer not in the manual?

Questions and answers

Summary of Contents for LevelOne KVM-0115

  • Page 1: User Manual

    LevelOne KVM-0115/KVM-0117 15 / 17-inch LCD KVM Rack Console User Manual Version 1.0-1305...
  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS 1. Please read these safety instructions carefully. 2. Please keep this User Manual for later reference. 3. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed detergent for cleaning. Use moisture sheet or clothe for cleaning. 4.
  • Page 3: Table Of Contents

    ............................9 3.6 P OSITION ............................9 3.7 L ANGUAGE ........................... 10 3.8 R ECALL ............................10 3.9 E ..............................10 3.10 P OWER NDICATOR ......................... 10 TECHNICAL SPECIFICATIONS ................... 11 KVM-0115 S PECIFICATIONS ......................11 KVM-0117 S PECIFICATIONS ......................13...
  • Page 4: Chapter 1 Introduction

    This user manual tell you how to install your KVM-0115 / KVM-0117, how to operate the OSD (On Screen Display) and the specifications. 1.2 PACKING LIST The complete KVM-0115/KVM-0117 package consists of: One 1U 19”...
  • Page 5: Chapter 2 Installation

    CHAPTER 2 INSTALLATION 2.1 Install Console to Cabinet 2.1.1 Before Installation 1. Before installation, please check all peripherals according to the list. Make sure the whole unit was not damaged and lost during shipping process. If you encounter any problem, please contact your local dealer.
  • Page 6: Installation Step

    2.1.3 Installation Step 1. Loose (not release) four rear screws then adjust rear bracket to fit your cabinet. 2. Install front and rear bracket on cabinet. 3. Tight-up four rear screws. 4. Repeat step 1~3 for the other side. 5. Push console into left and right rails. (Be careful when take out console.) 6.
  • Page 7: Replace Longer Bracket Step (For Rack Depth 828~1000Mm)

    7. Install three screws in rear of the console. (Both sides) 8. Finish installation as below. 2.1.4 Replace longer bracket Step (For rack depth 828~1000mm) Release six screws. 2. Take rear bracket out. Original bracket 3. Input rear long bracket to rear of the rail then adjust rear bracket to fit your cabinet. Tight-up 2~3 screws upon the length you need.
  • Page 8: Unload Step

    2.1.5 Unload Step 1. Make sure the console is lock. 2. Release three screws in rear of the console. (Both sides) 3. Unlock. 4. Pull console out until console lock. 5. Pull rail-release switch and pull console out.(Both sides. Be careful when pull out console.) rail-release switch 4.
  • Page 9: Connecting The Console And Configuring The Display Settings

    2.2 Connecting the console and Configuring the Display Settings Before connecting the rack mount console, make sure your computer has a video card. After you connect the console, please install the video card driver. The video driver is supplied by the video card manufacturer and may be found on the CDROM that came with your computer.
  • Page 10: Turning On The Console

    change. This behavior is normal. You can readjust the image using the monitor on-screen controls. For more information on the monitor on-screen controls, refer to Chapter 3. For more information on configuring the display settings, refer to the manual that came with your video card. 2.3 Turning on the Console Make sure all cables and the power cord are connected properly.
  • Page 11: Chapter 3 Panel Controls And Osd Functions

    CHAPTER 3 PANEL CONTROLS AND OSD FUNCTIONS Controls Description Soft power on/off button. Adjacent LED is lit when on. Auto-synchronize and scale down display to any valid factory Auto preset timings. ▲ Press to scroll the function you want to adjust. Press to scroll the function you want to adjust.
  • Page 12: Contrast

    3.4 Contrast 1. Press the “menu” button. 2. Use the “Down” and “Up” button to scroll, select “Contrast”. 3. Press the “menu” button to enter. 4. Use the “Down” and “Up” button to adjust the contrast of the display. 5. Press the “menu” button to enter. 3.5 Color 1.
  • Page 13: Language

    3.7 Language 1. Press the “menu” button. 2. Use the “Down” and “Up” button to scroll, select “Language”. 3. Press the “menu” button to enter. And you will see: English German French Italian Spanish 4. Use the “Down” and “Up” button to scroll. 5.
  • Page 14: Technical Specifications

    Technical Specifications KVM-0115 Specifications Display Size 15" Panel Type Active Matrix TFT LCD Resolution Capabilities Maximum Resolution up to 1024X768 (XGA) Pixel Pitch Supports 0.297mm x0.297mm Viewing Angle (CR>10) Right-Left view 130 (Typ) Up-Down View 100 (Typ) Contrast Ratio 400:1...
  • Page 15 Caps Caps Scroll Scroll Lock Lock Lock Lock Lock Lock...
  • Page 16: Kvm-0117 Specifications

    KVM-0117 Specifications Display Size 17" Panel Type Active Matrix TFT LCD Resolution Capabilities Maximum Resolution up to 1280X1024 (SXGA) Pixel Pitch Supports 0.264mm x0.264mm Viewing Angle (CR>10) Right-Left view 60~70 (Typ) Up-Down View 45~ 60(Typ) Contrast Ratio 450:1 Brightness White 250cd/m2 (Center 1 point Typ) Back Light Four Lamps for Back Light Supported Colors...
  • Page 17 Caps Caps Scroll Scroll Lock Lock Lock Lock Lock Lock...
