- Page 1 CAT5 T-module R-Box KVM-9009v2.0 KVM Remote Console Kit User Manual V1.0 Digital Data Communications Asia Co., Ltd. http://www.level1.com 1 / 15...
-
Page 2: Table Of Contents
CAT5 T-module R-Box C o n t e n t s Introduction ..........................3 Main Features ........................4 Package contents ......................... 4 Product Line ........................4 System Installation ........................5 T-Module ..........................6 R-BOX ..........................7 3. Installation ............................. 9 R-Box Installation ....................... -
Page 3: Introduction
CAT5 T-module R-Box 1 Introduction The CAT5 KVM Extender, Transmitter Module (T-Module) + CAT5 Receiver (R-Box), enables user to access the computer, server or KVM switch up to 1000 feet (300 meters) away. The CAT5 Extender is a pair of devices for high-density applications where you want full use of keyboards, mouse, and monitor, but there is no room for a server nearby. -
Page 4: Main Features
CAT5 T-module R-Box Main Features ■ Locate CAT5 console up to 1000 feet (300 meters) away from the KVM switch with superior auto-adjust RGB signals capability ■ Collocate computers and servers on one location, ideal for hazardous or unsecured environments ■... -
Page 5: System Installation
CAT5 T-module R-Box 2 System Installation The figure below depicts the system installation of CAT5 Transmitter Module (T-Module) + CAT5 Receiver (R-Box) System Installation 5 / 15... -
Page 6: T-Module
CAT5 T-module R-Box 2.1 ACC-1001v2.0(T-Module) It’s the module for inserting to the extension slot of the Combo, CAT5 KVM. Using CAT5 cable to connect the T-module and R-BOX. 6 / 15... - Page 7 CAT5 T-module R-Box 2.2 KVM-9008v2.0(R-BOX) REMOTE LED LOCAL LED SELECT Button [front] USB Console Port: for connecting to USB type keyboard and mouse Local/Remote LED: Status Description The Local port is not selected. The Local port is selected and a computer connected to the Local port is power on.
- Page 8 CAT5 T-module R-Box [back] Power Jack: for connecting to the power adapter RJ-45 Port: for connecting to a CAT5 cable Console Port: for connecting to monitor Local Host Port: for connecting to the local host via 3-in-1 VGA cable 8 / 15...
-
Page 9: R-Box
CAT5 T-module R-Box 3. Installation R-Box Installation Install food pads --- turn R-Box upside down and refer to the following instructions for installation properly. Make sure the CAT5 cable is straight through type. Plug one end of CAT5 cable into RJ-45 connector of the T-module, and plug another end of CAT5 cable into RJ-45 port of the R-Box. -
Page 10: The 3-In-1 Vga Cable Installation
CAT5 T-module R-Box 3.2 The 3-in-1 VGA Cable Installation Note: It is recommended to power off all the computers and server before the installation. If the PS2 computer could not be turn off, please plug in the connectors in the following order: first, PS/2 mouse connector;...
