LevelOne KVM-0217 Specifications

17-inch
Modularized KVM Console
H/W Version: 1
Product Overview
The LevelOne KVM-0217 is a compact and modular
KVM console drawer designed to be used in a
standard 19-inch server rack. It offers connectivity to 8
or 16 computers by depending on the LevelOne KVM
module that is installed (KCM-0831 or 1631). It features
a 17-inch retractable LCD monitor and keyboard with
built-in touchpad. Users can daisy chain up to seven
KVM-0217 together, providing control of up to 128
computers in total. The LevelOne KVM-0217 provides
a double layer password access control ensuring only
authorized users have access to connected computers.
Key Features
- Control servers and computers either locally via
control port or remotely via optional modules
through the module expansion slot
- Combo architecture with PC support for PS/2 and
USB interface
- Flexible auto-scan mode for flexible PC monitoring
- Locate Cat5 console up to 300 meters away from the
KVM switch.
- Built-in daisy chain port for cascading with
KVM-0831 or KVM-1631 up to 8 units
- Provide ACL (Access Control List) security function -
store up to 8 independent ACLs for controllable PCs
- Support Windows, NetWare, Unix, Linux, Mac OS and
Sun Microsystems
- 19" rackmount 1U size design KVM (Keyboard, video
and mouse) access over IP
* Features are based on KVM-0217 combined a LevelOne KVM mobule.

It supports an administrator and 8 user accounts, each
one with a separate and customizable profile.
Advanced Remote Management via optional
modules
LevelOne also offers a unique module for remote
server control. Just slide in the IP Console Module
(ACC-2000) to KCM-0831/1631 to access and manage
the server farm over the Internet using a standard
web browser. It supports a 1600x1200 pixel screen
resolution for high-quality viewing.
1. KCM Moudule Connector
1
Works Well With
KCM-0831
8-port Combo KVM Module
for KVM-0217
KCM-1631
8-port Combo KVM KVM
Module for KVM-0217
KVM-0217
