Summary of Contents for LevelOne KVM-0217

  • Page 1: User Manual

    LevelOne KVM-0217 17” Modularized KVM Console User Manual V1.0.0-0708...
  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS 1. Please read these safety instructions carefully. 2. Please keep this User Manual for later reference. 3. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed detergent for cleaning. Use moisture sheet or clothe for cleaning. 4.
  • Page 3: Table Of Contents

    ONTRAST 3.4 C ..........................19 OLOR 3.5 P ..........................19 OSITION 3.6 L .......................... 19 ANGUAGE 3.7 R ..........................20 ECALL 3.8 E ........................... 20 3.9 P ......................20 OWER NDICATOR TECHNICAL SPECIFICATIONS ....................21 KVM-0217 S ..................... 21 PECIFICATIONS...
  • Page 4: Chapter 1 Introduction

    This user manual tells you how to install your KVM-0217, how to operate the OSD (On Screen Display) and the specifications. For KVM switch functions, please refer to KCM-0831/1631 user manual.
  • Page 5: Chapter 2 Installation

    CHAPTER 2 INSTALLATION 2.1 Install Console to Cabinet 2.1.1 Before Installation 1. Before installation, please check all peripherals according to the list. Make sure the whole unit was not damaged and lost during shipping process. If you encounter any problem, please contact your local dealer.
  • Page 6 5. Screw (length = 6 mm) x 6 6. Screw x 8 7. Key x 2...
  • Page 7: Installation Step

    2.1.3 Installation Step 1. Adjust rail until two screws appear. rail two screws 2. Loose (Not remove) seven rear screws. 3. Adjust rail to fit your cabinet 4. Install front and rear bracket on cabinet.
  • Page 8 5. Tight seven rear screws up. 6. Repeat step 1~5 for the other side. 7. Push console into rails. (Be careful rear box loose when take out console from carton.) 8. Unlock and pull rail–lock switch (left and right at the same time) then push console to the end. lock unlock rail-lock switch...
  • Page 9: Replace Bracket A Step (For Cabinet Depth 828 ~ 1000 Mm)

    10. Finish installation as below. 2.1.4 Replace bracket A step (For cabinet depth 828 ~ 1000 mm): 1. Loose (Not remove) seven rear screws. 2. Release six screws. 3. Take rear bracket out. original bracket...
  • Page 10: Replace Bracket B And C Step (For Cabinet Depth Is 504 ~ 614 Mm)

    4. Adjust rail and input bracket A to rear of the rail then adjust bracket A to fit your cabinet. Install 2~3 screws (don’t tight-up) upon the length you need. One is forbidden. bracket A 5. Repeat step 1 ~ 4 for the other side. 6.
  • Page 11 4. Install four screws (don’t tight-up) to combine rail, bracket B and bracket C. bracket C bracket B 5. Repeat step 1 ~ 4 for the other side. 6. Repeat step 3 ~ 10 of install console to finish installation.
  • Page 12: Kvm Switch Module Installation

    2.2 KVM Switch Module Installation Before Installation: 1. Please check all peripherals according to the list before installation. To make sure that the whole unit was not damaged or lost during shipping process. If you encounter any problem, please contact with your local dealer. 2.
  • Page 13 2. Push KVM switch into the rails from rear of cabinet. plastic rail of KVM switch rear view of rail 3. Tight thumb screw of bracket A up to fix KVM switch in console and finish installation. (Both sides)
  • Page 14: Unload Steps

    2.3 Unload Steps 1. Make sure the console has locked and turned off. 2. Loose two thumb screws and pull modular KVM switch out. 2. Release three screws in rear of the console. (Both sides) 3. Unlock. 4. Pull console out until console lock.
  • Page 15 5. Pull rail-release switch and pull console out.(Both sides. Be careful when pull out console.) rail-release switch 1. Push rail-lock switch on the rail and push rail back.(Both sides) rail-lock switch on the rail...
  • Page 16: Connecting The Console And Configuring The Display Settings

    2.4 Connecting the console and Configuring the Display Settings Before connecting the rack mount console, make sure your computer has a video card. After you connect the console, please install the video card driver. The video driver is supplied by the video card manufacturer and may be found on the CD-ROM that came with your computer.
  • Page 17 Before you start, make sure that all the devices you will connect have been turned off. To prevent damage due to ground potential difference, make sure that all the devices during the installation are properly grounded. Consult your direct vendor for any technical issues if necessary.
  • Page 18: Chapter 3 Panel Controls And Osd Functions

    CHAPTER 3 PANEL CONTROLS AND OSD FUNCTIONS Controls Description Soft power on/off button. Adjacent LED is lit when on. Auto-synchronize and scale down display to any valid factory Auto preset timings. ▲ Press to scroll the function you want to adjust. ▼...
  • Page 19: Color

    3.4 Color 1. Press the “menu” button. 2. Use the “Down” and “Up” button to scroll, select “Color”. 3. Press the “menu” button to enter. And you will see: Icon Description 9300°K To set CIE coordinates at 9300°K color 7500°K To set CIE coordinates at 7500°K color 6500°K To set CIE coordinates at 6500°K color...
  • Page 20: Recall

    3.7 Recall Press the “menu” button. Use the “Down” and “Up” button to scroll, select “Recall”. Press the “menu” button to enter, and you will see: Yes/ No rightness, contrast, color and position Select “Yes”, the console will set the b to the factory default immediately.
  • Page 21: Technical Specifications

    Construction USA, UK, German, French, Spanish, Italian, Portuguese, eyboard Language Dutch, Swiss. Belgium, Swedish, Norwegian, Danish, Japan, Taiwan CE/FCC ertification * Power source is from KCM-0831 or KCM-1631; please be noted that KVM-0217 does not come with power input interface.
