Jabra BT5010 User Manual

Jabra BT5010 User Manual

Hide thumbs Also See for BT5010:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
English
Content
2
4
5
5
6
7
9
11
A. Jabra BT5010 headset
12
1.
Light indicator (LED)
2.
Volume controls
13
3.
Charging socket
14
4.
Answer/End button
14
5.
On/Off + Pairing button
6.
Microphone
7.
Speaker
8.
Earhook
15
16
Before you begin setup, be sure all parts
have been above 32°F/0°C for at least 30
minutes.
English
In the box
B. Jabra Bluetooth Hub
9. Dial Tone Switch
10. Light indicator (LED)
11. Pairing button
12. Microphone volume control
13. AUX socket
14. Handset socket
15. Desk phone socket
16. Reset button
17. Desk stand socket (not for use with Jabra
BT5010 headset)
18. Power supply socket
C.
Desk stand
D.
Bluetooth Hub power supply
E.
Headset power supply
F.
Desk phone-Bluetooth Hub connection cord
G.
USB cable
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT5010 and is the answer not in the manual?

Questions and answers

Related Manuals for Jabra BT5010

Summary of Contents for Jabra BT5010

  • Page 1: Table Of Contents

    Speaker Quick Reference 15. Desk phone socket Earhook Operating the Answer/End button 16. Reset button 17. Desk stand socket (not for use with Jabra What the lights mean BT5010 headset) 18. Power supply socket Desk stand Bluetooth Hub power supply...

  • Page 2: Headset Setup And Charging

    English English Headset Setup and Charging Adjusting headset for your comfort Charging your headset Headset is preset for use on right ear. Switch if necessary. Charge via PC or Charge directly (handy for travel). Important: Make sure your headset is inactive while charging. Bend to fit.

  • Page 3: Bluetooth Hub Setup And Use (For Desk Phone)

    English English Bluetooth Hub Setup and Use (for Desk Phone) Connecting Bluetooth Hub with desk phone and power supply Making a test call on your desk phone to adjust settings If your desk phone has an electronic hookswitch lifter, or you are using a GN 1000 (remote •...

  • Page 4: Making And Ending A Call Via Desk Phone

    English English Making and ending a call via desk phone If your desk phone has an electronic hookswitch lifter, or you are using a GN 1000 (remote handset lifter), please refer to the User Manual on the CD-ROM for instructions. If dial tone is missing or unclear, slowly slide the Dial Tone Switch from A –...

  • Page 5: Answering An Incoming Call To Desk Phone

    English English Answering an incoming call to desk phone If your desk phone has an electronic hookswitch lifter, or you are using a GN 1000 (remote handset lifter), please refer to the User Manual on the CD-ROM for instructions. Begin talking. Place headset on ear.

  • Page 6: Mobile Phone Setup And Use

    English English Mobile Phone Setup and Use Mobile Phone Use Pairing headset to mobile phone (establishes Bluetooth connection) Making and ending a call from mobile phone See your mobile phone User Guide for Bluetooth pairing instructions. Place headset on ear. Dial number on mobile phone and tap Talk/Yes or similar. Press headset pairing button for 1 sec.

  • Page 7: Using Voice Dial

    English English Quick Reference Using Voice Dial (if your mobile phone supports this feature) Operating the Answer/End button Hear voice dial signal. (Mobile phone Press headset Answer/End button for 1 sec. dependent) How to… Headset Answer/End button action Make call via desk phone Make call via mobile phone Voice Dial* Press for 1 sec Redial last outgoing number* (from mobile phone)

  • Page 8: What The Lights Mean

    English English Quick Reference What the lights mean Blue Green Blue Green Headset Bluetooth Hub Green steady Charge complete Green steady Bluetooth Hub on Blue slow flash Headset on Blue steady Pairing in progress Blue fast flash Call in progress Blue flash 10 times Pairing successful Blue steady...
