LCD TV

SERVICE MANUAL

CHASSIS : ML-041A
MODEL : RZ-30LZ50
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
website:http://biz.LGservice.com
e-mail:http://www.LGEservice.com/techsup.html

Advertisement

Table of Contents
loading

Related Manuals for LG RZ-30LZ50

Summary of Contents for LG RZ-30LZ50

  • Page 1: Service Manual

    LCD TV SERVICE MANUAL CHASSIS : ML-041A MODEL : RZ-30LZ50 CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

  • Page 2: Table Of Contents

    CONTENTS CONTENTS ....................2 PRODUCT SAFETY ..................3 SPECIFICATION ..................6 TIMING CHART ..................10 ADJUSTMENT INSTRUCTION..............11 TROUBLE SHOOTING ................16 BLOCK DIAGRAM...................21 WIRING DIAGRAM ..................23 EXPLODED VIEW .................. 24 EXPLODED VIEW PARTS LIST ..............25 REPLACEMENT PARTS LIST ............... 26 SVC. SHEET ....................

  • Page 3: Product Safety

    SAFETY PRECAUTIONS IMPORTANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.

  • Page 4: Servicing Precautions

    SERVICING PRECAUTIONS CAUTION: Before servicing receivers covered by this service unit under test. manual and its supplements and addenda, read and follow the 2. After removing an electrical assembly equipped with ES SAFETY PRECAUTIONS on page 3 of this publication. devices, place the assembly on a conductive surface such as NOTE: If unforeseen circumstances create conflict between the aluminum foil, to prevent electrostatic charge buildup or...
  • Page 5 IC Remove/Replacement Some chassis circuit boards have slotted holes (oblong) through Circuit Board Foil Repair which the IC leads are inserted and then bent flat against the Excessive heat applied to the copper foil of any printed circuit circuit foil. When holes are the slotted type, the following technique board will weaken the adhesive that bonds the foil to the circuit should be used to remove and replace the IC.

  • Page 6: Specification

    SPECIFICATION NOTE : Specifications and others are subject to change without notice for improvement. 1. Application range This specification is applied to ML-041A chassis. 2. Requirement for Test Testing for standard of each part must be followed in below condition. (1) Temperature: 25°C ±...
  • Page 7 5.General Specification(Monitor) Item Specification Unit Remark Panel 30” TFT WXGA LCD Frequency range DVI-I input H:31 ~ 61KHz, V: 56 ~ 75Hz 1) Contrast/ Brightness Control function 2) H- Position/ V-Position 3) Tracking : Clock/Phase 4) Auto Configure 5) Reset 1: Y Component Jack 3: Pb...
  • Page 8 6.Optical Feature(LCD Module) Item Specification Remark Viewing Angle R/L, U/D 170,170 170,170 170,170 <CR 10> Luminance Luminance(cd/ ) Typical Variation MAX/MIN Contrast Ratio ALL white/All back CIE Color Coordinates WHITE Typ. 0.284 0.285 0.289 Typ. 0.295 0.293 0.303 Typ. 0.631 0.635 Typ.
  • Page 9 8.Component Video Input(Y, P Resoluton H-freq(kHz) V-freqHz) Pixel clock Proposed 640 x 480 15.73 60.00 SDTV. DVD 480i RZ, RT, RM 640 x 480 15.63 59.94 SDTV. DVD 480i RZ, RT, RM 704 x 480 31.47 59.94 EDTV 480p RT, RM 720 x 576 15.625 50.00...

  • Page 10: Timing Chart

    TIMING CHART VIDEO SYNC << Dot Clock (MHz), Horizontal Frequency (kHz), Vertical Frequency (Hz), Horizontal etc... (µs), Vertical etc... (ms) >> Total Period Back Porch Video Active Time Front Porch Sync Duration Sync Mode Resolution Frequency Clock Polarity Sort 31.469 25.175 640x480 –...

  • Page 11: Adjustment Instruction

    ADJUSTMENT INSTRUCTION 1. Application Object 2.2.1 EDID DATA [DDC DATA Analog] This instruction is for the application to the LCD TV. 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F 2. Adjustment 00 FF FF FF FF FF FF 00 1E 6D 39 75 01 01 01 01 0C 0E 01 03 18 46 2B 78 EE E8 AA A1 57 49 9C 25 10 48 4B AB 8C 00 45 4F 61 4F 81 CF 01 01 01 01 2.1 Auto Gain/Offset adjustment...
  • Page 12 3. Shipping Conditions ITEM CONDITION REMARK Power Volume Level Main Pcture Input Main Last Channel Pr 01 Mute 16:9 Station Auto Program Manual Program Program Edit Favorite Program None Picture Dynamic Dynamic Contrast Brightness Colour Sharpness NTSC OPTION Tint Sound Flat Balance Special...
  • Page 13 *Option(PAL) ITEM CONDITION REMARK ITEM CONDITION REMARK Option 1 Option 3 Side AV 0: Side AV Off Language 0: Eng Only 1: Side AV On 1: EU5 SCART 0: SCART Off 2: 12 nations(Europe) 1: SCART On 3: Eng + Chines 0: PC Off 4: Eng + Arab + Urdu 1: PC On...
  • Page 14 EDID ADJUSTMENT Windows EDID V1.0 User Manual 2. EDID Read & Write 1) Run WinEDID.exe Operating System: MS Windows 98, 2000, XP Port Setup: Windows 98 => Don’t need setup Windows 2000, XP => Need to Port Setup. This program is available to LCD Monitor only. 1.

  • Page 15: Svc Remocon

    SVC REMOCON To turn the TV on or off POWER To turn the TV on automatically if the power is supplied to the TV. (Use the POWER ON POWER key to deactivate): It should be deactivated when delivered. To activate the mute function. MUTE To check TV screen image easily.

  • Page 16: Troubleshooting

    TROUBLESHOOTING No power :[A]Process (LED indicator off) Check short of main B/D Check 24V or 12V or Change Power B/D Faill of Power B/D Pass Check Output of Change L3, L1300 Faill L3, L1300 Pass Check Output of Change L808,L809 Change IC1300,IC4 or IC8 IC1300, IC4 or IC8 (F801,F802)
  • Page 17 No Raster :[B]Process Check LED Status Repeat A PROCESS on display unit Faill Check L900,L901 Change L900,L901, L902,L903 L902,L903 Faill Pass Check the input/ Change IC901 Output of IC901 Faill Pass Change inverter Check inverter connector or inverter Connector or inverter Faill Pass Change panel link...
  • Page 18 No Raster on Component signal Repeat [A] Process Pass Check the signal of Change Q310,Q315,Q316 Q310,Q315,Q316 Faill Pass Re-soldering or Check the input/ Change the defect part Faill output of IC1 Re-soldering or Check the input/output Change the defect part Faill of IC500, IC600 Pass...
  • Page 19 No Raster on AV Signa No Raster on TV(RF) signal (Video1,Video2, S-Video) Check 5V, 33V of TU1000 Repeat Check the output of Re-soldering or [A] Process TU1000 Faill Faill Change the defect part Pass Check the signal of Change C316,C317, C316,C317,Q308,Q313 Q308,Q313 Faill...
  • Page 20 No Sound Check the Change source input input source Faill Pass Re-soldering or Check the input/output Change the defect part of IC1 Faill Pass Re-soldering or Check the input/output Change the defect part of IC100,IC101 Faill Pass Check the speaker Change speaker Faill Pass...

  • Page 21: Block Diagram

    BLOCK DIAGRAM LA7222C...
  • Page 22 BLOCK DIAGRAM DESCRIPTION 1. Video controller unit and display data conversion unit The video controller unit receives the video signal inputted to the tuner, AV port (AV1, AV2, S-Video and component) and converts it to the analog RGB signal through the microcomputer (VCTI) combined with the video decoder that integrates various functions in one chip.

  • Page 25: Exploded View Parts List

    METAL ASSEMBLY, FRAME CMO 4951TKS157B METAL ASSEMBLY, FRAME RZ-30LZ50 C/SKD 6871TPT275A PWB(PCB) ASSEMBLY,POWER, RZ-30LZ50 POWER TOTAL BRAND ML-041A, 23",26",27",30",32" AUTOBAN LPL, AUO 6871TPT275C PWB(PCB) ASSEMBLY,POWER, RZ-30LZ50 POWER TOTAL BRAND CMO NON D/D 3313TP3003A MAIN TOTAL ASSEMBLY, RZ-30LZ50 LPL BRAND ML-041A...

  • Page 26: Replacement Parts List

    REPLACEMENT PARTS LIST For Capacitor & Resistors, the CC, CX, CK, CN, CH : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit in the CQ : Polyestor RS : Metal Oxide Film P/No. means as follows; CE : Electrolytic RN : Metal Film CF : Fixed Film RH : CHIP, Metal Glazed(Chip)
  • Page 27 DATE: 2004. 4. 20. DATE: 2004. 4. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION 0CK334CF94A "0.33UF 1608 16V 80%,-20% F(Y" C556 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R C557...
  • Page 28 DATE: 2004. 4. 20. DATE: 2004. 4. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R C938 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP 0CK106EF56A 10UF 3216 16V 10% X7R R/TP C939...
  • Page 29 DATE: 2004. 4. 20. DATE: 2004. 4. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C111 0CE475EK638 4.7UF KMG 50V 20% FM5 TP 5 C956 0CH8476H691 47UF 25V 20% 105STD (CYL) R/ C112 0CE475EK638 4.7UF KMG 50V 20% FM5 TP 5...
  • Page 30 DATE: 2004. 4. 20. DATE: 2004. 4. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION IC753 0IMMRSG036A "M24C02-WMN6T SGS-THOMSON 8P," L701 6210TCE001G HH-1M3216-501 CERATEC 3216MM IC907 0IMCRAL006A AT24C16AN-10SI-2.7 ATMEL 8P L800 6210TCE001G HH-1M3216-501 CERATEC 3216MM...
  • Page 31 DATE: 2004. 4. 20. DATE: 2004. 4. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION Q318 0TR387500AA CHIP 2SC3875S(ALY) BK KEC - R312 0RH4700D622 470 1/10W 5 D.R/TP Q500 0TR387500AA CHIP 2SC3875S(ALY) BK KEC - R313...
  • Page 32 DATE: 2004. 4. 20. DATE: 2004. 4. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION RA602 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R152 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP RA603 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100...
  • Page 33 DATE: 2004. 4. 20. DATE: 2004. 4. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R343 0RH1002D622 10K OHM 1 / 10 W 2012 5.00% R601 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP R348 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%...
  • Page 34 100 OHM 1/10 W 5% 1608 R/TP R920 0RJ4990D477 499 OHM 1/10 W 1% 1608 R/TP SW1600 140-313A TACT 2LEAD 100G(TA) LG C&D N R921 0RJ4990D477 499 OHM 1/10 W 1% 1608 R/TP SW1700 140-313A TACT 2LEAD 100G(TA) LG C&D N...
  • Page 37 Apr., 2004 P/NO : 3828TSL101W Printed in Korea...
