  • Page 1 LCD TV OWNER’S MANUAL MODELS: RZ-23LZ25 RZ-23LZ55 RZ-26LZ55 RZ-27LZ55 RZ-32LZ55 nformation anual Please read included together before reading this manual and operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service.

  • Page 2: Table Of Contents

    Contents Installation Location and function of controls Remote control handset Battery installation / Front/ Rear Basic operation On and off / Programme selection Volume adjustment / Quick view Mute function On screen language selection On screen menus Menu selection Setting up TV stations Auto programme tuning Manual programme tuning Assigning a station name...

  • Page 3: Installation

    Installation Warning To prevent fire or shock hazard, do not expose the set to rain or moisture. Do not rub or strike the Active Matrix LCD with anything hard as this may scratch, mar, or damage the Active Matrix LCD permanently. Service Never remove the back cover of the set as this can expose you to high voltage and other hazards.
  • Page 4 Installation Connection of TV Pull the back cover backside while pushing the two tabs and then lift it up. 75 Ω on the back. For the best reception an Connect the aerial cable to the socket marked outdoor aerial should be used. To connect an additional equipment, see the Connection of external equipment section.

  • Page 5: Location And Function Of Controls

    Location and function of controls All the functions can be controlled with the remote control handset. Some functions can also be adjusted with the buttons on the side panel of the set. Only the remote control handset supplied will operate this set. Remote control handset Before you use the remote control handset, please install the MUTE...
  • Page 6 Location and function of controls 11. POWER switches the set on from standby or off to standby. 12. I/II selects the language during dual language broadcast. selects the sound output. 13. MENU selects a menu. MUTE POWER 14. PSM (Picture Status Memory) TV/AV MULTIMEDIA I/II recalls your preferred picture setting.
  • Page 7 Location and function of controls Front : The mark consists of blank or alphabet. RZ-23LZ25 Side panel RZ-23/26/27/32LZ55 Side panel (Volume Down/Up) 1. ON/OFF ( / I) adjusts the volume. switches the set on from standby or off to adjusts menu settings. standby.
  • Page 8 Location and function of controls Rear RZ-23LZ25 S-VIDEO INPUT VIDEO INPUT AUDIO INPUT PC SOUND INPUT DVI INPUT (RGB INPUT) ANTENNA INPUT EURO SCART1/2 RS-232C JACK SOCKET REMOTE CONTROL JACK AC INPUT...
  • Page 9 Location and function of controls Rear RZ-23/26/27/32LZ55 RZ-23LZ55 RZ-26/27/32LZ55 S-VIDEO INPUT COMPONENT IN COMPONENT DVD IN AUDIO INPUT PC SOUND INPUT DVI INPUT (RGB INPUT) ANTENNA INPUT EURO SCART1/2 RS-232C JACK SOCKET REMOTE CONTROL JACK AC INPUT...

  • Page 10: Basic Operation

    Basic operation On and off 1. Press the POWER, , TV/AV, MULTIMEDIA or NUMBER buttons to switch it on fully. 2. Press the POWER button. The set reverts to standby mode. 3. Pull out mains plugs to switch the set off. Note : If, while the set is switched on, the mains plug is disconnect- ed the set will switch to standby or power on when the mains plug is MUTE...

  • Page 11: On Screen Menus

    On screen menus Menu selection 1. Press the MENU button and then button to display each menu. 2. Press the button and then button to select a menu item. 3. Change the setting of an item in the sub or pull-down menu with button.

  • Page 12: Setting Up Tv Stations

    Setting up TV stations Channel Up to 100 TV stations can be stored by programme numbers (0 to 99). Auto programme Once you have preset the stations, you will be able to use the Manual programme or NUMBER buttons to scan the stations you have programmed. Programme edit Stations can be tuned using automatic or manual modes.

  • Page 13: Manual Programme Tuning

    Setting up TV stations Manual programme tuning Channel Auto programme Manual programme Manual programme lets you manually tune and arrange the Programme edit stations in whatever order you desire. Also you can assign a station Favourite programme name with five characters to each programme number. 1.

  • Page 14: Assigning A Station Name

    Setting up TV stations Assigning a station name Channel 1. Repeat the ‘Manual programme tuning’ steps 1 to 2. Auto programme Manual programme button to select Name. 2. Press the button and then Programme edit 3. Press the button and then use the .

  • Page 15: Programme Edit

    Setting up TV stations Programme edit Channel Auto programme This function enables you to delete or skip the stored programmes. Manual programme Programme edit Also you can move some stations to other programme numbers or Favourite programme insert a blank station data into the selected programme number. 1.

  • Page 16: Favourite Programme

    Setting up TV stations Favourite programme Channel Auto programme This function lets you select your favourite programmes directly. Manual programme Programme edit Press the MENU button and then button to select the Favourite programme Channel menu. to select Favourite 2. Press the button and then programme.

  • Page 17: Picture Adjustment

    Picture adjustment PSM (Picture Status Memory) Picture 1. Press the MENU button and then button to select the Contrast Picture menu. Brightness 2. Press the button and then button to select PSM. Colour Sharpness 3. Press the button and then button to select a picture set- ting on the PSM menu.

  • Page 18: Picture Adjustment Picture Format

    Picture adjustment Picture format You can watch TV in various picture formats; 16:9, 14:9, Zoom, Spectacle, Original, 4:3. Repeatedly press the ARC button to select your desired picture format. 16:9 You can enjoy the cinema (the picture format of 16:9) or general TV programme through the 16:9 mode.

  • Page 19: Sound Adjustment

    Sound adjustment SSM (Sound Status Memory) Sound You can select your preferred sound setting; Flat, Music, Movie or Speech and you can also adjust the sound frequency of the equalizer. Balance 1. Press the MENU button and then button to select the Sound menu.

  • Page 20: Sound Adjustment Stereo/Dual Reception

    Sound adjustment Stereo/Dual reception When a programme is selected, the sound information for the station appears after the programme number and station name disappear. Broadcast On Screen Display Mono MONO STEREO Stereo MUTE POWER DUAL I Dual TV/AV MULTIMEDIA I/II Mono sound selection In stereo reception if the stereo signal is weak, you can switch to mono by pressing the I/II button twice.

  • Page 21: Time Menu

    TIME Menu Clock Time Time You must set the time correctly before using on/off time function. Off time On time Auto off 1. Press the MENU button and then button to select the D D / E E Time menu. 2.
  • Page 22 TIME Menu Time Auto off Time Off time If you select On on the Auto off menu, the set will automatically On time Auto off switch itself to standby mode approximately ten minutes after a TV station stops broadcasting. 1. Press the MENU button and then button to select the D D / E E DE F G...

  • Page 23: Other Functions

    Other functions TV, AV and PC modes Setup Language Input Inputs can be set for TV, AV or PC mode. AV mode is used when a Child lock video cassette recorder (VCR), or other equipment is connected to Set ID the set.
  • Page 24 Other functions Child lock Setup Language Input The TV can be set so that the remote control handset is needed to Child lock control it. This feature can be used to prevent unauthorized view- Set ID ing. 1. Press the MENU button and then button to select the DE F G OK MENU...

  • Page 25: Teletext

    Teletext Teletext (or TOP text) is an optional function, therefore only a set with the teletext system can receive the teletext broadcast. Teletext is a free service broadcast by most TV stations which gives up-to-the-minute information on news, weather, television programmes, share prices and many other topics.
  • Page 26 Teletext TOP text The user guide displays four fields-red, green, yellow and blue at the bottom of the screen. The yellow field denotes the next group and the blue field indicates the next block. Block / group / page selection 1.
  • Page 27 Teletext Special teletext functions REVEAL Press this button to display concealed information, such as solutions of riddles or puzzles. Press this button again to remove the information from the display. MUTE POWER SIZE TV/AV MULTIMEDIA I/II Selects double height text. Press this button to enlarge the top half of the page.

  • Page 28: Connection Of External Equipment

    Connection of external equipment You can connect additional equipment, such as VCRs, camcorders etc. to your set. Examples are shown below. Aerial socket 1. Connect the RF out socket of the VCR to the aerial socket of the set. 2. Connect the aerial cable to the RF aerial in socket of the VCR. 3.

  • Page 29: Euro Scart Socket (Dvd)

    Connection of external equipment Euro scart socket (DVD) 1. Connect the Euro scart socket of the DVD to the Euro scart socket of the set. 2. Press the TV/AV button to select AV1 or AV2. 3. Press the PLAY button on the DVD. The DVD playback picture appears on the screen.

  • Page 30: Connection Of Pc

    Connection of PC PC in socket 1. Connect the signal cable from the monitor output socket of the PERSONAL COMPUTER to the PC input socket of the set. 2. Connect the audio cable from the PC to the PC SOUND sockets of the set.

  • Page 31: Pc Setup (Only Dvi-Analogue Mode)

    Connection of PC PC Setup (only DVI-Analogue mode) H-Position V-Position You can adjust horizontal/vertical position, clock, phase, and auto- Clock configure, reset as you prefer. Phase Auto Configure Reset 1. Press the MENU button and then button to select the Setup menu.

  • Page 32: External Control Device Setup; Rs-232C

    External Control Device Setup ; RS-232C - Connect the RS-232C input jack to an external control device (such as a computer or an A/V control system) and control the Monitor’s functions externally. - Connect the serial port of the control device to the RS-232C jack on the Monitor back panel. - RS-232C connection cables are not supplied with the Monitor.
  • Page 33 External Control Device Setup ; RS-232C Set ID Set ID - Use this function to specify a monitor ID number. - Refer to ‘Real Data Mapping 1’. See page 34. 1. Press the MENU button and then use button to select the D D / E E Setup Setup...
  • Page 34 External Control Device Setup ; RS-232C 05. Volume Mute (Command:e) 01. Power On (Command:a) G To control volume mute on/off. G To control Power On/Off of the TV. You can also adjust mute using the MUTE button on Transmission remote control. [k][a][ ][Set ID][ ][Data][Cr] Transmission Data 0 : Power Off...
  • Page 35 External Control Device Setup ; RS-232C 09. Color (Command:i) 15. Tune Command (Command:m a) G To adjust the screen color. G Tune channel to following Physical/major/minor number. You can also adjust color in the Picture menu. Transmission Transmission [m][a][ ][Set ID][ ][Data0][ ][Cr] [k][i][ ][Set ID][ ][Data][Cr] Data0: Programme Number Data Min : 0 ~ Max : 64...

  • Page 36: Troubleshooting Checklist

    Troubleshooting Checklist The operation does not work normally. • Check to see if there is any object between the product and the remote control causing obstruction. The remote control • Are batteries installed with correct polarity (+ to +, - to -)? doesn’t work •...
  • Page 37 Troubleshooting Checklist The audio function does not work. • Press the VOL (or Volume) button. Picture OK & • Sound muted? Press MUTE button. No sound • Try another channel. The problem may be with the broadcast. • Are the audio cables installed properly? No output from one •...

  • Page 38: Product Specifications

    Product Specifications Product Specifications Power Requirement/ RZ-23LZ25 *** : AC 100-240V~ 50/60Hz 1.4A / 120W Power Consumption RZ-23LZ55 *** : AC 100-240V~ 50/60Hz 1.4A / 120W RZ-26LZ55 *** : AC 100-240V~ 50/60Hz 1.5A / 130W RZ-27LZ55 *** : AC 100-240V~ 50/60Hz 1.5A / 130W RZ-32LZ55 *** : AC 100-240V~ 50/60Hz 2.0A / 160W RZ-23LZ25 *** : 631.8mm x 205.0mm x 499.6mm Dimensions...

  • Page 39: How To Join The Product Assembly To The Wall To Protect The Set Tumbling

    How to join the product assembly to the wall to protect the set tumbling Please set it up carefully so the product doesn’t fall over. Set it up close to the wall so the product doesn’t fall over when it is pushed backwards. The instructions shown below is a safer way to set up the product, which is to fix it on the wall so the product doesn’t fall over when it is pulled in the forward direction.
