Digital Electronics Corporation PL-FD510 Installation Manual

Floppy disc drive

Advertisement

The PL-FD510 is an internally mounted 3.5 inch floppy disc drive unit, designed
for use with Proface's Panel Computer, PL-5910 Series Units, hereafter referred
to as the "PL."
Corresponding Product : PL-5910 Series Units
All product names used in this document are the trademarks of their respective
manufacturers.
Pro-face : Digital Electronics Corporation
• Be sure to confirm that the PL unit's power cord is disconnected prior to install-
ing the FDD unit, in order to prevent electrical shock.
• Do not attempt to modify the FDD unit, due to the danger of fire or electrical
shock.
• Prior to installing the FDD unit, be sure to read section "2. Installation" com-
pletely to insure that this unit is correctly installed.
• The PL is not appropriate for use with aircraft control devices, aerospace equip-
ment, central trunk data transmission (communication) devices, nuclear power
control devices, or medical life support equipment, due to these devices inher-
ent requirements of extremely high levels of safety and reliability.
• When using the PL with transportation vehicles (trains, cars and ships), disas-
ter and crime prevention devices, various types of safety equipment, non-life
support related medical devices, etc. redundant and/or failsafe system de-
signs should be used to ensure the proper degree of reliability and safety.
To prevent this unit from malfunctioning :
• Since the FDD unit is a precision instrument, be sure that it is neither hit by nor
pressed strongly against another object.
• Be sure that water, liquids, or metal particles are not allowed to contact or
enter this unit. Either of these may cause either a breakdown or an electrical
shock.
• Do not install or operate this unit in a location where there is direct sunlight,
excessive heat, dust or vibration.
• Do not store or operate this unit near chemicals, or where there are chemical
fumes.
• To prevent damage to file data, be sure to shut down the PL unit's OS before
turning OFF the main power.
Unit Disposal :
• When this product is disposed of, it should be done so according to your
country's regulations for similar types of industrial wastes.
PL-FD510

Installation Guide

WARNINGS

-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL-FD510 and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Electronics Corporation PL-FD510

  • Page 1: Installation Guide

    PL-FD510 Installation Guide The PL-FD510 is an internally mounted 3.5 inch floppy disc drive unit, designed for use with Proface’s Panel Computer, PL-5910 Series Units, hereafter referred to as the “PL.” Corresponding Product : PL-5910 Series Units All product names used in this document are the trademarks of their respective manufacturers.
  • Page 2: Package Contents

    Package Contents PL-FD510 Installation Guide PL-FD510 (This Guide) Brakets Attachment Screws (4) For PL-5910 Series For PL-5911 Series Proface has taken the utmost care to insure the quality of this product when it was shipped. However, should, for any reason, problems or damage have oc- curred during shipping, please contact your Proface representative immediately for service.
  • Page 3 Environmental Ambient Operating C to 45 Temperature Ambient Storage C to 60 Temperature Ambient Humidity 20%RH to 80%RH (no condensation) (During operation) Vibration Resistance 9.8m/s (10Hz to 25Hz) Shock Resistance (During shipping) 980.7m/s • The above specifications are for the FDD unit only. •...
  • Page 4 FDD’s Rear Blank (Filler) Panel 3) Unscrew the two rear face Blank Panel attachment screws, and remove the Blank Panel. (PL-5911T) 4) Attach the braket for PL-5911 Series that comes with the FDD unit to the FDD unit and secure it with the two (2) attachment screws.
  • Page 5 5) Insert the FDD unit into the PL. Be sure the connectors of the PL and the FDD unit are securely connected. Attach the FDD unit to the PL using the FDD unit's four (4) attachment screws. The necessary torque is 0.5 to 0.6N•m.
  • Page 6: Hardware Setup

    Hardware Setup Use the following steps to setup the hardware. Certain BIOS screen items may differ from those shown here due to new versions. 1) Connect a keyboard to the PL. 2) Turn the PL’s power ON. 3) After the message, “Press <DEL> to Enter SETUP” appears at the left bottom of the screen, hold down the [DEL] key.
  • Page 7 4) Use the cursor to select “STANDARD CMOS SETUP,” and the follow- ing screen will appear. Phoenix FirstBIOS(tm) Desktop CMOS Setup Utility Standard CMOS Features Date (mm:dd:yy): Thu, Feb 15 2007 Item Help Time (hh:mm:ss): 11 : 15 : 14 Menu Level IDE Primary Master HTS541020G9AT00...
  • Page 8 Please access our site anytime that you need help with a solution. http://www.pro-face.com/otasuke/ Note Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the uses of this product. © Copyright 2007 Digital Electronics Corporation.
