Installation Guide
The PL-FD200 (FDD Unit) is an internally mounted 3.5 inch floppy disc
drive unit, designed for use with Pro-face's Panel Computer, hereafter
referred to as the "PL."
Corresponding PL unit: PL-X900,PL-X920 Series Units
All product names used in this document are the trademarks of their respective
manufacturers.
Pro-face: Digital Electronics Corporation
! ! ! ! !
Warning - Safety Precautions
• Be sure to confirm that the PL unit's power cord is disconnected prior to
installing PL-FD200, in order to prevent electrical shock.
• Do not attempt to modify the PL-FD200, due to the danger of fire or
electrical shock.
• Prior to installing the PL-FD200, be sure to read this Installation Guide's
"2. Installation" section completely to ensure that this unit is correctly
installed.
To Prevent Accidents
• Since the PL-FD200 is a precision instrument, be sure that it is neither
hit by nor pressed strongly against another object.
• Be sure that water, liquids, or metal particles are not allowed to contact
or enter this unit. Either of these may cause either a breakdown or an
electrical shock.
• Do not install or operate this unit in a location where there is direct
sunlight, excessive heat, dust or vibration.
• Do not store or operate this unit near chemicals, or where there are
chemical fumes.
• Do not use the PL-FD200 in locations where corrosive gasses are
present
• To prevent damage to file data, be sure to shut down the PL unit's OS
before turning OFF the main power.
PL-FD200
-1-
Advertisement
Table of Contents
Related Manuals for Digital Electronics Corporation PL-FD200
Summary of Contents for Digital Electronics Corporation PL-FD200
- Page 1 • Be sure to confirm that the PL unit’s power cord is disconnected prior to installing PL-FD200, in order to prevent electrical shock. • Do not attempt to modify the PL-FD200, due to the danger of fire or electrical shock.
- Page 2 Package Contents When you open the PL-FD200’s package, please check immediately that the following items are included. Installation Guide PL-FD200 (PL-FD200) Installation Guide Pro-face has taken the utmost care to insure the quality of this product when it was shipped. However, should, for any reason, problems or dam- age have occurred during shipping, please contact your local Pro-face representative immediately for service.
- Page 3 Hardware Specifications Performance Operation Mode 2MB mode record/write 1MB mode record/write Disc Type (3.5 inch) high density type (2HD) double density type (2DD) Unformatted Data 2M bytes 1M bytes Capacity Data Transmission 500k bits/second 250k bits/second speed Disc Rotation Speed 300 rpm Track Density 135 tpi...
- Page 4 WARNING Shock Danger! Be sure to disconnect the PL unit's WARNING: power cord prior to installing the PL-FD200. 1) Remove the lowermost of the PL’s blank panels (located on the PL's side face) by unscrew- ing that panel’s two(2) attach- ment screws.
- Page 5 Hardware Setup Connect a keyboard to the PL. Turn the PL’s power ON. After the message, “Press <DEL> to Enter SETUP” appears at the left bottom of the screen, hold down the [DEL] key. The setup utility will start and the following screen will appear. ROM PCI/ISA BIOS(2A5LEU1C) CMOS SETUP UTILITY AWARD SOFTWARE, INC.
- Page 6 After “SAVE to CMOS and EXIT (Y/N)? N” appears, press the [Y] key to quit the setup utility. Note Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the uses of this product.
