OperatOr and parts Manual
Snowblower
Model 1080 & 1200
082012
FK329

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1080 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Farm King 1080

Summary of Contents for Farm King 1080

  • Page 1 OperatOr and parts Manual Snowblower Model 1080 & 1200 082012 FK329...

  • Page 3: Table Of Contents

    Table of Contents - 1080 & 1200 Snowblower Table of Contents Introduction ..........................4 Safety ............................5 • Safety ..........................5 • General Safety ........................6 • Start-up Safety .........................6 • Operation Safety ......................6 • Transport Safety .......................6 • Service and Maintenance Safety ..................7 • Storage Safety ........................7...

  • Page 4: Introduction

    Farm King has years of snowblower manufacturing expertise and thousands of acreages, farms and cities depend on Farm King snowblowers. PTO-driven Farm King Snowblowers attach to a 3-point hitch. A hitch system, which is quick-hitch compatible, is standard on all models. This model is supplied with Category 2 pins, as well as conversion bushings to Category 3.

  • Page 5: Safety

    Safety - 1080 & 1200 Snowblower Safety Safety Instructions Remember, YOU are the key to safety. Good safety practices not only protect you, but also the people around you. Make these practices a working part of your safety program. Be certain that everyone operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions.

  • Page 6: General Safety

    • Read and understand the Operator’s Manual and all safety signs before operating, servicing, adjusting, repairing, or unplugging the equipment. • Do not attempt any unauthorized modifications to your Farm King product as this could affect function or safety, and could affect the life of the equipment.

  • Page 7: Service And Maintenance Safety

    Safety - 1080 & 1200 Snowblower Service and Maintenance Safety • Stop engine, set brake, remove ignition key, and wait for all moving parts to stop before servicing, adjusting, repairing, or unplugging. • Support the equipment with blocks or safety stands before working beneath it.

  • Page 8: Safety Sign Location

    Safety - 1080 & 1200 Snowblower Safety Decal Location DETAIL B...
  • Page 9 Safety - 1080 & 1200 Snowblower • Replace safety signs immediately should they become damaged, torn or illegible. Obtain replacements from your authorized dealer using the part numbers shown. Serial Number Model Number and Product Made in: P/N: 105420 rev.4...

  • Page 10: Assembly

    Assembly - 1080 & 1200 Snowblower Assembly Instructions The ports in the cylinder are both 9/16" ORB. Be sure that the CAUTION bottom edge of the deflectors are properly fitted in the guides before using the hydraulic control.

  • Page 11: Operation

    The PTO shaft uses two - 3/8" x 1" (10 x 25 mm) (Grade 2) hex bolts as shear bolts for 1080 snowblower and uses two - 3/8" x 1" (10 x 25 mm) (Grade 5) hex bolts as shear bolts for 1200 snowblower.

  • Page 12: Theory Of Operation

    Operation - 1080 & 1200 Snowblower 10. Periodically check all bolts for tightness. The bolt holding on the fan and the bearing bolts are of particular importance. Always stop snowblower for servicing or unplugging. The PTO DANGER should be disengaged before dismounting from the tractor.

  • Page 13: Bolt Torque

    Bolt Torque - 1080 & 1200 Snowblower Bolt Torque Checking Bolt Torque The tables shown below give correct torque values for various bolts and hex bolts. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide.
  • Page 14 Bolt Torque - 1080 & 1200 Snowblower Hydraulic Fittings Jam Nut or Straight SAE 37° (JIC) ORB Fitting Torque Swivel Nut Torque Dash Size Thread Size (lb-ft) (NM) (lb-ft) (NM) -4 (1/4) 7/16-20 16 - 14 20 - 22 11 - 10...
  • Page 15 Parts - 1080 & 1200 Snowblower THIS PAGE HAS INTENTIONALLY BEEN LEFT BLANK...

  • Page 16: Parts Drawings

    Parts - 1080 & 1200 Snowblower Gearbox Drawing REF 912874-BODY WELDT (1080) REF 912530-BODY WELDT (1200) 126 115 142 146...
  • Page 17 Parts - 1080 & 1200 Snowblower Item Part # Description 811751 3/4" x 5" Hex Bolt (Pl) 811752 1/2" x 4" Hex Bolt (Pl) 812026 5/16" x 1" Hex Bolt (Pl) 812362 Nut Lock (Steel) 0.313 Nc Grb (Pl) 812365 3/4"...
  • Page 18 985639 Ø 3/8" x 1/2" Socket Set Screw (Br) F9231 Standard Shaft (21 Spline, 1-3/8") - 1000 RPM - Gr 2 Shear Bolt 1080 F9232 Option Shaft (20 Spline, 1-3/4") - 1000 RPM - Gr 2 Shear Bolt 1080 F9235 Standard Shaft (21 Spline, 1-3/8") - 1000 RPM - Gr 5 Shear Bolt 1200...
  • Page 19 Parts - 1080 & 1200 Snowblower THIS PAGE HAS INTENTIONALLY BEEN LEFT BLANK...

  • Page 20: Flighting Drawing And Parts List

    Parts - 1080 & 1200 Snowblower Flighting Drawing REF 912874-BODY WELDT (1080) REF 912530-BODY WELDT (1200) 71.1 71.4 71.3 71.5 43.1 71.2 132 31 30...
  • Page 21 Parts - 1080 & 1200 Snowblower Item Part # Description 81592 3/8" Hex Nut (Pl) 81593 3/8" Lock Washer (Pl) 81636 1/2" Hex Nut (Pl) 81637 1/2" Lock Washer (Pl) 81678 5/8" Flat Washer Std (Pl) 84270 5/8" x 1-3/4" Hex Bolt (Pl) 84277 Bolt Hex 0.500 Nc x 1.50 Gr5 (Pl)

  • Page 22: Hitch Drawing And Parts List

    Parts - 1080 & 1200 Snowblower Hitch Drawing 24 23 23 24...
  • Page 23 Parts - 1080 & 1200 Snowblower Item Part # Description 12779 Hairpin Clip #9 811791 1/2" x 2" Hex Bolt (Pl) 812026 5/16" x 1" Hex Bolt (Pl) 81549 5/16" x 3/4" Hex Bolt (Pl) 81568 5/16" Hex Nut (Pl) 81569 5/16"...

  • Page 24: 4' Spout Drawing And Parts List

    Parts - 1080 & 1200 Snowblower 4' Spout Drawing REF O-RING# 913151...
  • Page 25 Parts - 1080 & 1200 Snowblower Item Part # Description 24995M Ø 1.75" x 5.0" Stroke Cylinder Assembly - Cream 812026 5/16" x 1" Hex Bolt (Pl) 812363 Nut Lock (Steel) 0.375 Grb (Pl) 813748 Washer, Fender, 1-1/2" Od x 5/16" Id (Pl) 81525 1/4"...

  • Page 26: Hydraulics Drawing And Parts List

    Parts - 1080 & 1200 Snowblower Hydraulics Drawing REF 0-RING# 913151 120 11...
  • Page 27 Parts - 1080 & 1200 Snowblower Item Part # Description 115371 Hose 3/8" x 156" c/w Fittings 811918 Elbow 90 9/16 Swmorb x 9/16 Mjic 115369 3/8" x 156" Hose 1/2" Mnpt x 9/16" Swfjic 24995M Ø 1.75" x 5.0" Stroke Cylinder Assembly - Cream...

  • Page 28: 7' Spout Drawing And Parts List

    Parts - 1080 & 1200 Snowblower 7' Spout Drawing 153.2 153.23 153.4 153.9 153.12 153.8 153.10 153.1 153.23 153.12 153.23 153.23 153.3 153.2 153.2 153.2 153.2 153.25 153.24 153.26.2 153.26 153.26.1 153.13 153.14 153.18 153.6 153.17 153.15 153.16 153.5 153.11 153.7...
  • Page 29 Parts - 1080 & 1200 Snowblower Item Part # Description 812026 5/16" x 1" Hex Bolt (Pl) 812080 Adaptor Str 3/4 Morb x 3/4 Mjic 812208 Nipple 1/2" Body 1/2" - 14 Nptf Quick Connect 812363 Nut Lock (Steel) 0.375 Grb (Pl) 813748 Washer, Fender, 1-1/2"...
  • Page 30 Parts - 1080 & 1200 Snowblower Item Part # Description 153.19 812363 Nut Lock (Steel) 0.375 Grb (Pl) 153.20 81570 3/8" Std Flat Wash (Pl) 153.21 86171 3/8" x 1-1/4" Hex Bolt (Pl) 153.22 912593L Spout Gear 54 Teeth 153.23 81638 1/2"...
  • Page 31 THIS PAGE HAS INTENTIONALLY BEEN LEFT BLANK...

  • Page 32: 10' Spout Drawing And Parts List

    Parts - 1080 & 1200 Snowblower 10' Spout Drawing 154.11 154.23 154.5 154.2 154.3 154.8 154.4 154.9 154.7 154.4 154.23 154.23 154.5 154.5 154.5 154.24 154.26.2 154.26.1 154.26 154.14 154.13 154.12 154.10 154.11 154.25 154.7 154.1 154.6 154.15 154.17 154.16 154.18...
  • Page 33 Parts - 1080 & 1200 Snowblower Item Part # Description 812026 5/16" x 1" Hex Bolt (Pl) 812080 Adaptor Str 3/4 Morb x 3/4 Mjic 812208 Nipple 1/2" Body 1/2"- 14 Nptf Quick Connect 812363 Nut Lock (Steel) 0.375 Grb (Pl) 813748 Washer, Fender, 1-1/2"...
  • Page 34 Parts - 1080 & 1200 Snowblower Item Part # Description 154.19 912593L Spout Gear 54 Teeth 154.20 812363 Nut Lock (Steel) 0.375 Grb (Pl) 154.21 81570 3/8" Std Flat Wash (Pl) 154.22 86171 3/8" x 1-1/4" Hex Bolt (Pl) 154.23 81638 1/2"...
  • Page 35 THIS PAGE HAS INTENTIONALLY BEEN LEFT BLANK...

  • Page 36: Decal Drawing And Parts List

    Parts - 1080 & 1200 Snowblower Decal Drawing DETAIL B...
  • Page 37 Parts - 1080 & 1200 Snowblower Item Part # Description 102893 Danger Decal 105420 Reference Plate JBI/FK Serial # 108431 Warning Check PTO Shaft 963206 Caution Decal 967388 Check Oil...

  • Page 38: Spout Cylinder Drawing And Parts List

    Parts - 1080 & 1200 Snowblower Spout Cylinder Drawing .010  .515 - .005 2X 9/16-18 FORB 10.88  15.88 EXTENDED SEAL KIT: P/N X3913 Item Part # Description 24995M Cylinder - 1.75 x 5.00 X3913 Seal Kit - Cylinder 1.75...

  • Page 39: Hydraulics Motor Drawing And Parts List

    Hydraulics Motor Drawing 5/16-18 UNC - 2B .2505  .0005 1.106  .008 Ø 1.000 - .001 1/4-20 UNC - 2B 4X 3/8-16 - 2B Item Part # Description 971518 Hydraulic Motor 913151 O-Ring Nom Id 1/2 x Nom Cs 3/32 x Nom Od 11/16...

  • Page 40: Pto Drawing And Parts List

    Shear Bolt, 3/8 - 16 x 1.00 Lg Gr5 967432 Shear Bolt, 3/8 - 16 x 1.00 Lg Gr2 F9231 Standard Shaft (21 Spline, 1-3/8") - 1000 RPM - Gr2 Shear Bolt 1080 F9232 Option Shaft (20 Spline, 1-3/4") - 1000 RPM - Gr2 Shear Bolt 1080 F9235 Standard Shaft (21 Spline, 1-3/8") - 1000 RPM - Gr5 Shear Bolt 1200...

  • Page 41: Shipping Kit And Bundle Numbers

    Shipping Kit and Bundle - 1080 & 1200 Snowblower Shipping Kit and Bundle Numbers The following is a list of Kit Numbers for this product and the Bundle Numbers, Descriptions, and Quantities for each Kit. Quantity Bundle Number Description 1000 RPM with Standard Spout (Y1200C)

  • Page 42: Warranty

    Repair Parts Limited Warranty Buhler Industries Inc. warrants Farm King replacement parts purchased after the expiration of the Buhler Industries Inc. Limited Warranty, and used and serviced as provided for in the Operator’s Manual, to be free from defects in materials or workmanship for a period of thirty (30) days from the invoice date for the parts.
  • Page 43 Warranty Requirements To be covered by warranty, each Farm King new product must be registered with Buhler Industries Inc. within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Buhler Industries Inc.
  • Page 44 Warranty - 1080 & 1200 Snowblower (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and you may also have other rights, which vary from province to province or state to state.
  • Page 46 www.farm-king.com 301 Mountain Street South Morden, Manitoba Canada R6M 1X7 Ph.: 204.822.4467 | Fax: 204.822.6348 Toll Free: 888.524.1004 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2012 Buhler Trading Inc. Printed in USA. TSX:BUI a division of Buhler Industries Inc.
