OPERATOR AND PARTS MANUAL
Snowblower
Model 9620
072017
FK330

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALLIED 9620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Farm King ALLIED 9620

Summary of Contents for Farm King ALLIED 9620

  • Page 1 OPERATOR AND PARTS MANUAL Snowblower Model 9620 072017 FK330...

  • Page 3: Table Of Contents

    9620 Table Of Contents Manufacturer’s Statement: For technical reasons, Buhler Industries Inc. reserves the right to modify machinery design and specifications provided herein without any preliminary notice. Information provided herein is of descriptive nature. Performance quality may depend on soil fertility, applied agricultural techniques, weather conditions, and other factors.
  • Page 4 Oil Bath Gearbox - BU50505 PTO Shaft - F1696 PTO Shaft Long - F1695 Hydraulic Spout Deflector Cylinder 1.75” x 5” (Option) Additional Components Specifications And Shipping Kit Numbers Specifications Shipping Kit And Bundle Numbers Hardware Torque Values Warranty Farm King Base Limited Warranty...

  • Page 5: Warranty Registration Form

    Customer / Owner Signature: Remove this Warranty Registration Form from the Operator And Parts Manual. Make two copies of the form. Send original Warranty Registration Form to Farm King. Give one copy to the customer and the dealer will keep one copy.
  • Page 6 Warranty Registration Form - 9620...

  • Page 7: Introduction

    Farm King equipment. READ AND UNDERSTAND THIS OPERATOR AND PARTS MANUAL BEFORE OPERATING YOUR FARM KING EQUIPMENT. If you have any questions, see your Farm King dealer. This manual may illustrate options and accessories not installed on your Farm King equipment.
  • Page 8 Introduction - 9620...

  • Page 9: Owner's Information

    Model Number: and maintenance procedures. Serial Number: Farm King is continually working to improve its products. Farm King reserves the right to make The serial number plate (Item 1) [Figure 1] is any improvements or changes as deemed practical located on the top corner of the main frame.

  • Page 10: Equipment Identification

    Introduction - 9620 Equipment Identification Component Location - Front View HOIST MOUNT CHAIN DRIVE CHAIN GUARD Hydraulic Motor Mount CUTTING EDGE FOUR BLADE AUGER SKID SHOE...

  • Page 11: Component Location - Top View

    Introduction - 9620 Component Location - Top View SPOUT DEFLECTOR CHUTE OIL BATH GEARBOX UPPER THREE- POINT MOUNT LOWER THREE- POINT MOUNT PTO SHIELD LOWER THREE- POINT MOUNT...
  • Page 12 Introduction - 9620...

  • Page 13: Safety

    Safety - 9620 Safety Safety Instructions Safe Operation is The Operator’s Responsibility Safe Operation Needs A Qualified Operator Use Safety Rules Safety Rules For Power Take-Off (PTO) Driven Equipment Machine Requirements And Capabilities Transport Safety Fire Prevention Maintenance Operation Starting Electrical Hydraulic System Fueling...
  • Page 14 Safety - 9620...

  • Page 15: Safety Instructions

    • The written instructions from Farm King include the result in minor or moderate injury. It may also Warranty Registration, Dealer Inspection Report, be used to alert against unsafe practices.

  • Page 16: Use Safety Rules

    Safety - 9620 Use Safety Rules Safety Rules For Power Take-Off (PTO) Driven Equipment • Read and follow instructions in this manual and the tractor’s Operators Manual before operating. • Keep PTO shields and all guards in place. Replace damaged or missing shields and guards before •...

  • Page 17: Machine Requirements And Capabilities

    Safety - 9620 Machine Requirements And Capabilities Transport Safety • Fasten seat belt securely. If equipped with a foldable • Do not exceed 20 mph (32 kph). Reduce speed on Roll-Over Protective Structure (ROPS), only fasten rough roads and surfaces. seat belt when ROPS is up and locked.

  • Page 18: Fire Prevention

    Fueling components can cause a fire. Operation • The Farm King machine must be in good operating condition before use. • Check all of the items listed on the service schedule • Stop the engine and let it cool before adding fuel. No under the 8 hour column before operation.

  • Page 19: Welding And Grinding

    Safety - 9620 Welding And Grinding • Always clean the machine and equipment, disconnect the battery, and disconnect the wiring from the machine controls before welding. Cover rubber hoses, battery and all other flammable parts. Keep a fire extinguisher near the machine when welding. •...

  • Page 20: Safety Signs (Decals)

    Safety Signs (Decals) Follow the instructions on all the signs (decals) that are on the equipment. Replace any damaged signs (decals) and be sure they are in the correct locations. Equipment signs are available from your Farm King equipment dealer.

  • Page 21: Equipment Decals And Signs

    Safety - 9620 Equipment Decals And Signs Check and replace any worn, torn, missing, or hard to read decals on your equipment. Figure 4 910825 (Item 1) [Figure 4] 817585 (Propeller Model Not Shown) 815035 (Item 2) [Figure 4]...

  • Page 22: Safety Sign-Off Form

    Untrained operators and failure to follow instructions can cause injury or death. Farm King follows the general Safety Standards specified by the American Society of Agricultural and Biological Engineers (ASABE) and the Occupational Safety and Health Administration (OSHA). Anyone who will be operating and / or maintaining the snowblower must read and clearly understand ALL Safety, Operating and Maintenance information presented in this manual.

  • Page 23: Assembly

    Assembly - 9620 Assembly Preparing For Assembly PTO Shield Cutting Edge (Option) Hitch Discharge Spout Hydraulic Spout Deflector (Option) Hydraulic Spout Rotator...
  • Page 24 Assembly - 9620...

  • Page 25: Preparing For Assembly

    • Check all the components for damage. If any • Wait for all moving parts to stop. components are damaged or missing, contact your Farm King dealer. Park the tractor / equipment on a flat level surface. Place all controls in neutral, engage the park brake,...

  • Page 26: Pto Shield

    Assembly - 9620 PTO Shield Hitch Figure 5 Figure 7 Install the PTO shield (Item 1) to the top of the gearbox assembly using two 1/2” hex bolts and two lock washers (Item 2) [Figure 5]. Hook the spring through the hole in the shield and Align the hitch weldment (Item 1) [Figure 7] to the through the hole in the gusset plate underneath brackets on the main frame.

  • Page 27: Discharge Spout

    Assembly - 9620 Discharge Spout Figure 9 Figure 8 Attach the deflector (Item 1) to the discharge spout using one hinge rod (Item 2) [Figure 9] and one 1/8” x 1” cotter pin. Align the deflector adjustment rod (Item 3) on the spout mounts.

  • Page 28: Hydraulic Spout Rotator

    Assembly - 9620 Hydraulic Spout Rotator Figure 10 Align the motor assembly (Item 1) with the main frame mount (Item 2) [Figure 10] and attach with four 3/8” bolts and four 3/8” lock washers. Ensure that the manifold and hydraulic hose fittings are facing the snowblower hitch.

  • Page 29: Operation

    Operation - 9620 Operation Pre - Operation Checklist Entering The Operator’s Position Leaving The Operator’s Position Tractor Requirements Connecting The Snowblower To Tractor Connecting The PTO Driveline PTO Driveline Length Check PTO Driveline Bottoming Out Check Reducing The PTO Driveline Length PTO Driveline Engagement Check Connecting Hydraulic Hoses Disconnecting Hydraulic Hoses...
  • Page 30 Operation - 9620...

  • Page 31: Pre - Operation Checklist

    Operation - 9620 Pre - Operation Checklist Entering The Operator’s Position Before operating the snowblower for the first time Enter the operator’s position, start the engine, and and each time thereafter, check the following items: release the parking brake. Lubricate the equipment per the schedule outline in the Maintenance Section.

  • Page 32: Connecting The Snowblower To Tractor

    Operation - 9620 Connecting The Snowblower To WARNING Tractor Always inspect the tractor’s three-point hitch and snowblower’s three-point mounts before connecting. See the tractor’s owner’s manual. Move the tractor drawbar into the storage position or remove (if necessary) to prevent interference with snowblower operation.
  • Page 33 Operation - 9620 IMPORTANT Excessive backward tilt may cause the “U” joints to flutter resulting in PTO shear bolt failure. WARNING AVOID INJURY OR DEATH Keep fingers and hands out of pinch points when connecting disconnecting equipment.

  • Page 34: Connecting The Pto Driveline

    Operation - 9620 Connecting The PTO Driveline Figure 12 Stop the engine and leave the operator’s position (See “Leaving The Operator’s Position” Operator’s section). WARNING AVOID INJURY OR DEATH Warnings on the machine and in the manuals are for your safety. Failure to obey warnings can cause serious injury or death.

  • Page 35: Pto Driveline Length Check

    Operation - 9620 PTO Driveline Length Check PTO Driveline Bottoming Out Check Due to variations in distances between tractor PTO Stop the engine and leave the operator’s position shafts and implement input shafts, drivelines may (See “Leaving The Operator’s Position” need to be shortened or a longer shaft may be Operation section).

  • Page 36: Reducing The Pto Driveline Length

    Operation - 9620 Reducing The PTO Driveline Length Figure 14 Stop the engine and leave the operator’s position IMPLEMENT (See “Leaving The Operator’s Position” in the PTO SHAFT Operation section). Make sure the PTO driveline and all rotating components have come to a complete stop before leaving the operator’s position.

  • Page 37: Pto Driveline Engagement Check

    (from Step 3), the PTO driveline does not have adequate engagement and should be replaced • Keep bystanders away. with a longer driveline. See your Farm King dealer for available PTO drivelines. • Keep hands, feet, clothing and long hair away.

  • Page 38: Connecting Hydraulic Hoses

    Operation - 9620 Connecting Hydraulic Hoses Disconnecting Hydraulic Hoses The snowblower may be equipped with the fol- Release pressure and pull the male couplers out to lowing hydraulic options, if applicable. disconnect. Hydraulic spout deflector WARNING 2. Hydraulic discharge chute Push couplers into female couplers on the tractor until they are fully engaged and locked.

  • Page 39: Adjusting Skid Shoe Height

    Operation - 9620 Adjusting Skid Shoe Height Skid Shoe Settings: Decrease Working Depth - Lower skid shoes. WARNING Increase Working Depth - Raise skid shoes. Figure 17 AVOID INJURY OR DEATH Before you leave the operator’s position: • Always park on a flat level surface. •...

  • Page 40: Theory Of Operation

    Operation - 9620 Theory Of Operation FAN BLADE CAUTION ROTATION • Read operator and parts manual before operating the implement. • Do not permit riders. • Keep all guards and shields in place. • Keep hands, feet, clothing and hair away from moving parts.

  • Page 41: Transporting

    Operation - 9620 Transporting Verify that the tractor / tow vehicle is approved for transporting the equipment and that the equipment Always comply with federal, state, local and is securely attached to the tractor / tow vehicle. provincial laws regarding the transport of farm Verify safety chain is installed and properly equipment on pubic roadways.
  • Page 42 Operation - 9620...

  • Page 43: Maintenance

    Maintenance - 9620 Maintenance Service Schedule Chart Lubrication Recommendations Locations Oil Bath Gearbox Chains And Fasteners Safety Sign (Decal) Installation Storage And Return To Service Storage Return To Service...
  • Page 44 Maintenance - 9620...

  • Page 45: Service Schedule Chart

    Maintenance - 9620 Service Schedule Chart WARNING Instructions are necessary before operating or servicing equipment. Read and understand the Operator And Parts Manual and safety signs (decals) on equipment. Follow warnings and instructions in the manuals when making repairs, adjustments or servicing. Check for correct function after adjustments, repairs or service.

  • Page 46: Lubrication

    Maintenance - 9620 Lubrication Locations Recommendations IMPORTANT Always use a good quality multi-purpose / lithium base grease when lubricating the equipment. Fluid such as engine oil, hydraulic fluid, • Always use a hand-held grease gun. coolants, grease, etc. must be disposed of •...
  • Page 47 Maintenance - 9620 Figure 19 Figure 21 8-10 Apply two pumps of grease to the guard bushings (Item 1) [Figure 19]. Apply grease to spout clamps and rings (Item 1) Apply eight to ten pumps of grease to the [Figure 21]. telescoping member (Item 2) [Figure 19].

  • Page 48: Chains And Fasteners

    Maintenance - 9620 Chains And Fasteners Oil Bath Gearbox Figure 24 Periodically check all bolts and fasteners for tightness. Figure 23 REAR VIEW Check the oil level using the plug on the lid (Item 1) [Figure 24]. The correct level is even with the bottom of the plug.

  • Page 49: Safety Sign (Decal) Installation

    Maintenance - 9620 Safety Sign (Decal) Installation Storage And Return To Service Storage IMPORTANT Sometimes it may be necessary to store your Farm King snowblower for an extended period of time. Below is a list of items to perform before storage. When replacing safety signs (decals), the temperature must be above 10°...

  • Page 50: Return To Service

    Maintenance - 9620 Return To Service After the equipment has been in storage, it is necessary to follow a list of items to return the equipment to service. • Be sure all shields and guards are in place. • Lubricate the equipment. •...

  • Page 51: Parts Identification

    Parts Identification - 9620 Parts Identification Always give your dealer the Model, Color and Serial Number of your machine to assist them in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part.
  • Page 52 Parts Identification - 9620...

  • Page 53: Main Components

    Parts Identification - 9620 Main Components 29 20 12 16 13 27 28 26 31 26 11 11...
  • Page 54 Parts Identification - 9620 ITEM PART NUMBER DESCRIPTION QTY. 811792 3/8" X 1 1/2" HEX BOLT GR.5 (PL) 812362 5/16" LOCK NUT (PL) 812363 3/8" LOCK NUT (PL) 812364 1/2" LOCK NUT (PL) 812482 5/8" LOCK NUT (PL) 812623 WASHER - 5/16" SAE FLAT (PL) 812639 WASHER 0.625 SAE FLAT BS PL F1530...
  • Page 55 Parts Identification - 9620 ITEM PART NUMBER DESCRIPTION QTY. 965917 1 3/8" BEARING 965928 BUSHING - 0.84"OD X 0.109"W X 0.75" 965962 #60 13 T SPRKT 965968 14GA X 7 1/2" X 8" IDLER SHLD 965972 ROLLER CHAIN #60 X 117 W/ C & O...

  • Page 56: Discharge Spout

    Parts Identification - 9620 Discharge Spout...
  • Page 57 Parts Identification - 9620 ITEM PART NUMBER DESCRIPTION QTY. 818481 WELDMENT - 96" SPOUT BODY 818482 WELDMENT - 96" DEFLECTOR HINGE ROD 818483 WELDMENT - 96" DEFLECTOR 961012 #16 HAIR PIN CLIP 961876 1/2" X 1 1/2" CLEV PIN (PL) 965646 1/2"...

  • Page 58: Hydraulic Spout Rotator - F1545

    Parts Identification - 9620 Hydraulic Spout Rotator - F1545 ITEM PART NUMBER DESCRIPTION QTY. 816682 PTO MODELS HYD SPOUT ROTATION HOSE 816840 GEAR GUARD WELDT 817014 PINION GEAR 14 TEETH 818903 ASSEMBLY - MOTOR & MANIFOLD 907590 SPT HOSE HLDR WELDT 812026 5/16"...

  • Page 59: Cutting Edge (Option) - X3897

    Parts Identification - 9620 Cutting Edge (Option) - X3897 ITEM PART NUMBER DESCRIPTION QTY. 816325 CUTING EDGE - 96" SNOWBLOWER 81966 NUT LOCK (NYLON) 0.500NC PL 84048 WASHER 0.500 FLAT SAE Bs PL 906655 1/2" x 1-1/2" FL HD BOLT (SKT) (PL)

  • Page 60: Oil Bath Gearbox - Bu50505

    Parts Identification - 9620 Oil Bath Gearbox - BU50505...
  • Page 61 Parts Identification - 9620 ITEM PART NUMBER DESCRIPTION QTY. BU575901 BRG CONE (13687) BU575902 BRG CUP (13620) BU50444 STAKING LOCKNUT 1 3/8 BU50417-1 KEY .38"SQX1.38" BA,CW,SB BU50310 CASTING GEAR BOX BU50502 PINION SHAFT SPLINED-STRAIGHT BU50507 CROSS SHAFT S/B-Y960Q-'92 & UP BU50422-1 OIL SEAL 2.72X1.50X0.37 BU50415...

  • Page 62: Pto Shaft - F1696

    Parts Identification - 9620 PTO Shaft - F1696 ITEM PART NUMBER DESCRIPTION 817790 SHEAR BOLT CLUTCH R55 M10 817789 YOKE W/ QL BALL TYPE 817791 INBOARD YOKE FOR INNER TUBE 817800 YOKE W/ TUBE & SLEEVE 817793 CROSS KIT 817801 SPLINED TUBE 817795 ELASTIC PIN...

  • Page 63: Pto Shaft Long - F1695

    Parts Identification - 9620 PTO Shaft Long - F1695 ITEM PART NUMBER DESCRIPTION 817789 YOKE W/ QL BALL TYPE 817790 SHEAR BOLT CLUTCH R55 M10 817791 INBOARD YOKE FOR INNER TUBE 817792 INBOARD YOKE W/ TUBE & SLEEVE 817793 CROSS KIT 817794 SPLINED TUBE 817795...

  • Page 64: Hydraulic Spout Deflector Cylinder 1.75" X 5" (Option)

    Parts Identification - 9620 Hydraulic Spout Deflector Cylinder 1.75” x 5” (Option) PART NUMBER DESCRIPTION 24930M 1-3/4" ID X 5" STROKE CYLINDER 116983 HOSE 3/8 X 120 C/W FITTINGS 960913 CLEVIS PIN 1/2 X 1.8125 (PL) 9812430 COTTER PIN 1/8 X 1.00 (PL) 811918 ELBOW 90 9/16 SWMORB X 9/16 MJIC 24930M...

  • Page 65: Additional Components

    Parts Identification - 9620 Additional Components THREE-POINT MOUNTING PINS PTO ADDITIONAL HARDWARE PTO SHIELD SPRING ITEM PART NUMBER DESCRIPTION QTY. 812364 1/2" LOCK NUT (PL) 81627 1/2" X 3" HEX BOLT (PL) 911161 KEY 3/8"SQ. X 58mm 960135 PTO SHLD SPRG (#661) 965910 CAT 2 TOP LINK PIN 965911...
  • Page 66 Parts Identification - 9620...

  • Page 67: Specifications And Shipping Kit Numbers

    Specifications And Shipping Kit Numbers - 9620 Specifications And Shipping Kit Numbers Specifications Shipping Kit And Bundle Numbers Hardware Torque Values Metric Chart Imperial Chart...
  • Page 68 Specifications And Shipping Kit Numbers - 9620...

  • Page 69: Specifications

    Specifications And Shipping Kit Numbers - 9620 Specifications Shipping Kit And Bundle Numbers The following is a list of Kit Numbers for this MODEL 9620 product and the Bundle Numbers, Descriptions, and Quantities for each Kit. Cutting Width 96” Qty. Bundle Description Cutting Height...

  • Page 70: Hardware Torque Values

    Specifications And Shipping Kit Numbers - 9620 Hardware Torque Values Metric Chart...

  • Page 71: Imperial Chart

    Specifications And Shipping Kit Numbers - 9620 Imperial Chart...
  • Page 72 Specifications And Shipping Kit Numbers - 9620...

  • Page 73: Warranty

    Warranty - 9620 Warranty Farm King Base Limited Warranty Repair Parts Limited Warranty What Is Not Covered Authorized Dealer And Labor Costs Warranty Requirements EXCLUSIVE EFFECT OF WARRANTY AND LIMITATION OF LIABILITY...
  • Page 74 Warranty - 9620...

  • Page 75: Farm King Base Limited Warranty

    If Farm King determines that it will pay labor costs for warranty work, it will do so by issuing a credit to the dealer’s or distributor’s account.
  • Page 76 Corrections of defects and improper workmanship in the manner, and for the applicable time periods, provided for herein shall constitute fulfillment of all responsibilities of Farm King to the purchaser, and Farm King shall not be liable in negligence, contract, or on any other basis with respect to the subject equipment.
  • Page 78 www.farm-king.com 1330 43rd Street North Fargo, ND, 58102 Toll Free: 877.447.6008 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2017 Buhler Trading Inc. Printed in USA TSX:BUI a division of Buhler Industries Inc.
