IN USE
When in use the power indicator turns green. The five progressive
performance bars will appear. A normally functioning unit should
two bars, you should check for the problem. Possible issues causing
the performance bars to lessen could be:
1. Blocked suction at the hose end
3. Air restrictive tool being used, such as a crevice tool
4. Full dirt receptacle
EMPTY DIRT RECEPTACLE
indicator will flash on the screen. This is an indication to check the dirt
receptacle and empty it. Since this is time based, you may find the dirt
Once the dirt receptacle is emptied, you push the return button to reset
unplugged, the empty dirt receptacle indicator will keep a memory of
its previous status and continue life measure.
the button lining up with the Enter symbol, and hold for 10 seconds.
SERVICE INDICATOR
turn the power unit off, unplug the power supply for 10 seconds
we recommend that you call for service.
This symbol may appear due to the following faults:
SYSTEM RUN TIME
Your Eureka central vacuum will track the total running time of the
system and notify you when it time for service.
vacuum service professional to diagnose your system, perform routine
maintenance and ensure optimum efficiency.
for more information.
for more information.
SCROLLING YOUR LCD
observe the dirt receptacle status, life monitor measure or most recent
recorded power level.
To scroll through these features simply push the button corresponding
with the right pointing arrow symbol.
and you will find Bucket Status. Yet another scroll will show you last
recorded performance levels of the power unit, using the Performance
customer service phone number.
The button lining up with the left scroll button will allow you to scroll
backwards through the screens.
BAG ADAPTOR
Your power unit can be fitted with an
bag for more convenient dirt disposal.
UTILITY VALVE
unit. This valve is present for your convenience, as it can help clean up
any dirt spilled close to the central vacuum.
EMPTYING THE DIRT RECEPTACLE
unit. To avoid suction loss make sure the receptacle is securely attached.
FILTER MAINTENANCE
The internal Triumph HEPA filter is permanent and self cleaning.
filter, please contact your local authorized dealer/distributor.
PAPER BAG FILTERS
The volume of the
use your central vacuum system, the dust bag may need to be changed
2-3 times per year – and can be obtained at your local dealer/distributor.
Instructions for changing the dust bag:
2. Loosen the dust bag from the intake tube, remove and dispose.
3. Place and press the new dust bag firmly into the tube.
4. Put the dirt receptacle back on the central power unit.
PARTIAL/TOTAL LOSS OF SUCTION POWER
®
replaceable
remove the dirt
- OPTIONAL
® paper bag is 22 liters. A full dust
