Shark V3800UK Owner's Manual

Cordless sweeper
Hide thumbs

Advertisement

Quick Links

V3800UK
OWNER'S GUIDE
www.sharkclean.eu

Advertisement

loading
Need help?

Need help?

Do you have a question about the V3800UK and is the answer not in the manual?

Questions and answers

Pam Mcclure
January 20, 2025

How do u empty dir t canister

0
1 comments:
Mr. Anderson
February 4, 2025

To empty the dirt canister on the Shark V3800UK:

1. Press the dust cup release pedal located at the lower portion of the handle and lift out the dust cup.
2. Press the dust cup empty button on the bottom of the dust cup to release the dirt.
3. Once empty, gently snap the dust cup back into place.

This answer is automatically generated

0

Related Manuals for Shark V3800UK

Summary of Contents for Shark V3800UK

  • Page 1 V3800UK OWNER’S GUIDE www.sharkclean.eu...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS For Household Use Only WARNING: WHEN USING YOUR SHARK CORDLESS ® SWEEPER, BASIC SAFETY PRECAUTIONS TO REDUCE THE RISK OF FIRE, ELECTRIC SHOULD ALWAYS BE FOLLOWED, INCLUDING SHOCK OR INJURY: THE FOLLOWING: 1. DO NOT charge this unit outdoors.

  • Page 3: Save These Instructions

    TO MAXIMISE THE LIFE OF YOUR LITHIUM ION 15. Use extra care when cleaning on stairs. BATTERIES: 16. DO NOT use to pick up flammable or combustible liquids such as gasoline or use in areas where they 1. Charge for 3.5 hours before initial use. may be present.
  • Page 4 QUICK START IMPORTANT: Before you can start using your new Cordless Sweeper, charge it for 3.5 hours. NOTE: The charging adapter will be shipped inside the packaging. Fig. 2 Fig. 3 Fig. 1 ASSEMBLE CLEAN Using your foot, press the power Insert the lower extension tube Pull back on the handle and button and push the unit forward...
  • Page 5 Fig. 4 Fig. 5 EMPTY When you’re finished cleaning, NOTE: Be careful not to Over a rubbish bin, empty the empty the No Touch Dust Cup. dust cup by pressing the bottom- accidentally turn the unit on. Simply press the dust cup empty button on the lower portion release pedal and lift out the of the handle.
  • Page 6 THIS MANUAL COVERS MODEL NUMBER: V3800UK 32 TECHNICAL SPECIFICATIONS Voltage: 7.2V Power: 22 Watts Charger Output: 10V 1000mA Euro-Pro and Shark are trademarks of Euro-Pro Operating LLC. All Li-Ion other brand names may be trademarks of their respective owners. FREEPHONE 0800 862 0453...

  • Page 7: Table Of Contents

    Contents Thank you for Assembly ....................8 purchasing the Shark ® Charging Your Shark Cordless Sweeper ............9 ® Cordless Sweeper. Using Your Shark Cordless Sweeper ............9 ® Emptying the No Touch Dust Cup ..............10 Storing Your Shark Cordless Sweeper ............10 ®...

  • Page 8: Assembly

    ASSEMBLY Fig. 1 COMPONENTS: ASSEMBLY OF YOUR Insert the lower extension tube into the head connector (a). Then CORDLESS SWEEPER: Main Unit insert the upper extension tube NOTE: The charging adapter will Power Button into the lower extension tube (b). be shipped inside the packaging.

  • Page 9: Charging Your Shark

    CHARGING YOUR SHARK CORDLESS SWEEPER ® Fig. 2 Fig. 3 Always make sure that the unit NOTE: When the power switch is The LED lights indicate battery is turned off. (Fig. 2) capacity. As the unit loses on the sweeper will not charge.

  • Page 10: Emptying The No Touch Dust Cup

    For easy insertion into the base, Cup. (Fig. 5) the debris into the rubbish bin. tip the No Touch Dust Cup (Fig. 6) slightly forward. STORING YOUR SHARK CORDLESS SWEEPER ® Fig. 9 Fig. 8 Properly storing your unit will...
  • Page 11 Once a month, wipe down the replace it. (Fig. 9) unit to the wire terminal connector unit with a dry cloth, including REMOVING AND REPLACING of the new Shark battery pack ® the area under the No Touch (XBTV3900) and replace the THE BATTERY Dust Cup.
  • Page 12 TROUBLESHOOTING GUIDE PROBLEM POSSIBLE REASONS AND SUGGESTED SOLUTION The unit will not operate or the Batteries need to be recharged. charging light is flashing Batteries are dead and need to be replaced. There is no power in the electrical outlet supplying the charging adapter. Try to charge using a different outlet.
  • Page 13 NOTES www.sharkclean.eu...
  • Page 14 NOTES FREEPHONE 0800 862 0453...
  • Page 15 NOTES www.sharkclean.eu...
  • Page 16 Power: 22 Watts Charger Output: 10V 1000mA COPYRIGHT © EURO-PRO OPERATING LLC 2014 Euro-Pro and Shark are trademarks of Euro-Pro Operating LLC. All other brand names may be trademarks of their respective owners. PRINTED IN CHINA V3800UK_32_140804_2 Li-Ion Illustrations may differ from actual product.

This manual is also suitable for:

V3800uk 32
