Maytag MGD3100D Manual

PRODUCT MODEL NUMBERS

MGD3100D, MGD4100D, MGD5100D, MGD7100D, MGD8100D
Front view:
38 / " Min.
3
4
(984 mm)
39" Max.
(990 mm)
Bottom view:
Back view:
(Steam Models Only)
5 / "*
3
4
(146 mm)
Vent
Gas
3 / "*
4
(18 mm)
(654 mm)
NOTE: Most installations require a minimum of 5" (127 mm)
clearance behind dryer for exhaust vent with elbow. See
"Venting Requirements."
Installation spacing for recessed area or closet installation
All dimensions show recommended and minimum spacing allowed.
Additional spacing should be considered for ease of installation and servicing.
■
Additional clearances might be required for wall, door, floor moldings, dryer venting, and gas line.
■
Additional spacing should be considered on all sides of the dryer to reduce noise transfer.
■
For closet installation, with a door, minimum ventilation openings in the top and bottom of the door are
■
required. Louvered doors with equivalent ventilation openings are acceptable.
Companion appliance spacing should also be considered.
■
27"
(686 mm)
6 / "
1
4
(159 mm)
(759 mm)
Water inlet
3 "*
/
1
2
(89 mm)
6 / "*
1
8
(156 mm)
14 / "
3
8
(365 mm)
25 / "
3
4

Gas Dryer

Recommended Installation Spacing:
29 / "*
7
8
5"
(127 mm)
Side view:
3"
(76 mm)
18" min.
(457 mm)
3"
(76 mm)
1"
1"
(25 mm)
(25 mm)
48 in. min.
2
(310 cm )
2
24 in. min.
2
(155 cm )
2
W10676163A
04/2014
