- Page 2 19535 56th Avenue, Suite 101 Surrey, BC, Canada V3S 6K3 604.530.5800 www.qimaging.com QImaging Technical Support Technical support is available to all registered users of QImaging products from 9am to 5pm Pacific Standard Time. support@qimaging.com 800.874.9789 http://www.qimaging.com/support www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1...
- Page 3 When you purchase an Extended Product Warranty Plan from QImaging, you are assured of our commitment to minimizing down times. Your needs are our top priority and we respond to them immediately. The QImaging service and support team is focused on expediting your request to provide a fast and complete solution.
-
Page 4: Table Of Contents
Exposure Controls ......................6 CARING FOR YOUR CAMERA ..................7 TROUBLESHOOTING ...................... 8 Resolving Problems with the Camera .................. 8 Unresolved Problems - Contacting QImaging Support ............9 GLOSSARY ........................10 APPENDICES ........................12 APPENDIX A: Rolera Bolt Dimensions ................12 www.qimaging.com... -
Page 5: Introduction
CHAPTER 1 INTRODUCTION Introducing the Rolera Bolt CMOS camera from QImaging. As a cost-effective solution, the Rolera Bolt is designed to meet the imaging requirements for a diverse set of applications ranging from IR-DIC to whole organism motility studies including fluorescence documentation of C. elegans and Drosophila larvae. Capable of streaming at 30 full frames per second with 1.3 mega-pixel resolution and 3e-read noise, the Rolera Bolt is... -
Page 6: Usb 2.0 Interface
The Rolera Bolt operates on both Windows based systems. QCapture Suite Software for both systems is available at www.qimaging.com. The easy-to-use QCapture software gives you complete control over the camera’s settings and image capture functions. QCapture Suite also includes a TWAIN-compliant interface that allows many Windows image-editing applications to acquire images using QImaging cameras. -
Page 7: Installation
Perform the following for connecting your camera. Remove the USB “B to A” cable from the camera box, and plug the USB “B” end of the cable into ■ the camera’s USB “B” socket. www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1... - Page 8 Figure 2: Camera USB B and Power Sockets Plug the USB “A” end of the cable into a USB “A” port on your computer ■ Camera Computer Figure 3: USB “B to A” Port Connection www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1...
-
Page 9: Camera Basics
C-mount end of the C to F mount adapter, rotating the camera until it is mounted securely. Then, carefully connect your F-mount optics to the open connector of the adapter until it is mounted securely. Use your optics controls to adjust focus. www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1... -
Page 10: Understanding The Led Indicators
The Rolera Bolt’s exposure controls allow the user to adjust the integration time for each acquisition. By increasing the exposure time, more light is captured by the CMOS sensor and the signal to noise ratio is increased. www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1... -
Page 11: Caring For Your Camera
If the image still appears dirty, gently wipe the face of the CMOS window with a small amount of ■ optical grade isopropyl alcohol and lens paper. Apply forced air again to remove any loose particles. ■ www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1... -
Page 12: Troubleshooting
This effect may also be caused by excessive infrared (IR) illumination. Verify that your camera or ■ optical system is blocking the IR. Contact QImaging to order an IR filter. Images that do not appear “sharp” If the image does not seem “sharp,” check the format of the lens or the coupler being used on the microscope. -
Page 13: Unresolved Problems - Contacting Qimaging Support
Rolera Bolt USER MANUAL Unresolved Problems - Contacting QImaging Support If you are still unable to resolve your problem, contact QImaging Support for assistance in one of four ways: http://www.qimaging.com/support/faq/ Visit for a list of all frequently asked questions. Your ■... -
Page 14: Glossary
The active collection of photons as done by an image sensor. Iris A diaphragm in the lens that opens or closes to set the aperture (the amount of light that passes through the lens to the CCD). www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1... - Page 15 Region of Interest (abbr.); Using software to actively select a specified region of the CMOS image to collect. This results in a smaller image display but has the potential of improving frame rate. second (abbr.); unit of measure for exposure time. microsecond (abbr.); unit of measure for exposure time. www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1...
-
Page 16: Appendices
Rolera Bolt USER MANUAL APPENDICES APPENDIX A: Rolera Bolt Dimensions 2.426 3.741 3.360 2.800 www.qimaging.com ©2013 QImaging. All rights reserved. QI_BOLT_UM_RevA1...
