Garden Oasis NEW CASTLE FIREBOWL Owner's Manual

Hide thumbs

Advertisement

Table of Contents

OWNER'S MANUAL
PRODUCT NAME: NEW CASTLE FIREBOWL
Caution: For outdoor use only!
Product Code: 05355058-8
UPC Code: 035355631722
Date of Purchase:
/
/
.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEW CASTLE FIREBOWL and is the answer not in the manual?

Questions and answers

Related Manuals for Garden Oasis NEW CASTLE FIREBOWL

Summary of Contents for Garden Oasis NEW CASTLE FIREBOWL

  • Page 1 OWNER'S MANUAL PRODUCT NAME: NEW CASTLE FIREBOWL Caution: For outdoor use only! Product Code: 05355058-8 UPC Code: 035355631722 Date of Purchase:...

  • Page 2: Read Before Use

    Factory No.: HYFP30205-19 Style No.: 63172 READ BEFORE USE! WARNING For Outdoor Use Only! Use Propane Gas Only ! Propane cylinders sold separately. WARNING Improper installation, adjustment,alteration,service or maintenance can cause injury or property damage. Read the owner's manual Design certified under ANS Z21.97-2010 Standard thoroughly before installing or servicing this equipment.
  • Page 3 DANGER Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. WARNING *Do not use this firebowl for cooking. *Remove the PVC Cover from the firebowl before opening the appliance.
  • Page 4 FOR PROPANE GAS UNITS *The gas pressure regulator provided with the propane fire bowl must be used. *Do not attempt to disconnect the gas regulator or any gas fitting while your firebowl is in operation. *A dented or rusty propane cylinder may be hazardous and should be checked by your gas supplier prior to use. *Do not use a propane cylinder with a damaged valve and any other worn out parts.
  • Page 5 WARNING ! * Do not light or use gas unit if lava rocks are wet. Ensure lava rocks are completely dry before igniting as intense heat could cause the rock to crack. * Lava Rocks could hit somebody's face or eyes during initial start of this unit , so please keep away from the firebowl for the first 20 minutes after it has been ignited.
  • Page 6 ITEM ITEM SPECIFICATION SPECIFICATION M5*120cross recessed round Body head screws Door Burner M6 Nuts M6X15 screws Fire Bowl M4X10screws Heat Insulation Board M4 nuts Ignition Pin Thermocouple Gas Valve M8*30 Wing screw Control Knob Pulse Ignition Feet Regulator Guard Grounding Wire...
  • Page 7 ASSEMBLY INSTRUCTIONS * Please keep these owner's manual for future reference. *If you have opened the carton and removed all packages, please disregard the STEP 1 and 2. See the STEP 3 directly. STEP 1. (1) Open the carton and turn it upside down, make sure the 4 STEP 2.
  • Page 8 See WARNING and Figures : WARNING This screen must be clear and free of obstructions at all times to insure proper operation. The burner of the firebowl must be covered by lava rock completely. Otherwise the flame may be extinguished occasionally. See the Figure CORRECT and INCORRECT for reference.

  • Page 9: Routine Care

    Observe flame height when lit: Flame should possibly be a yellow/blue color between 2 to 10 inches high. TO EXTINGUISH ※ Push the Control Knob and turn clockwise to the "OFF" position. ※ Turn the cylinder valve on the gas tank clockwise to close the gas supply if not for use in a long time.(See below figure) IGNITER-PUSH HIGH ROUTINE CARE...
  • Page 10 Please refer to part numbers when reordering For questions or comments about product: Email:customerservice@bondmfg.com or Call toll-free:1-866-771-BOND(2663) Made in / Hecho en CHINA Distributed by Sears, Roebuck and Co., Hoffman Estates, IL 60179 See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com...
