Page 1 Sara Wood Pellet Fire Registered Installer’s Manual PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD PELLET FIRE. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH.
Page 2 If you are a not a registered Nature’s Flame wood pellet ﬁ re installer, and do not have legitimate access to the necessary passwords to install and program the Sara Wood Pellet ﬁ re, you MUST NOT install or attempt to install this ﬁ re.
Page 3: Table Of Contents
Menu Descriptions ......... 10 Recommendations ........2 Pellet Quality ............ 2 Programming & Commissioning ....12 Spare Parts ............2 Sara Parameters - version BOX 03 ....12 Responsibility ........... 2 Technical Drawings ........14 Flammable Liquids ........... 3 Producer Statement and Dimensions - Sara Insert Pellet Fire ...3 Warranty Registration Form ......15...
Page 4: Introduction
Nature’s Flame declines all responsibility. The ﬁ re must be installed on a ﬂ oor with sufﬁ cient Generally Sara should be installed in a centrally located carrying capacity. If the existing building does not position within the home.
Page 5: Safety Warnings And Maintenance Recommendations
8 to see what is required. ATTENTION There are two critical components when installing a Sara Insert Wood Pellet ﬁ re: 1) Ensure the wall cavity is the necessary size. 2) Ensure relevant clearances to combustibles are adhered to both inside and outside the cavity.
Page 6: Flammable Liquids
In accordance with the requirements of AS/NZS • Poor maintenance. 2918:2001 Sara must be secured by seismic restraint. • Failure to observe the instructions in the manual. • Use not compliant with the safety instructions. Flammable Liquids •...
Page 7: Creating The Cavity
Creating the Cavity Additional Clearances to Combustibles As the Sara Insert Wood Pellet Fire is typically installed in new homes, it is necessary to build a compliant cavity that will house the ﬁ re and the frame. (K): from exhaust spigot to cavity wall 100mm The front facia of the enclosure must be made of a (L): from side of ﬁ...
Page 8 Installing into an existing cavity - Retro-ﬁ t As the Sara Insert Wood Pellet Fire is typically installed of 600mm above the top of the ﬁ re. Within the cav- in new homes, it is necessary to build a compliant ity, there must be a minimum of 600mm clearance to cavity that will house the ﬁ...
Page 9: Architectural Drawings
Architectural Drawings Example of Cavity Design - Section View 12mm ‘Micore’ board* 100mm 12mm ‘Micore’ board* ~200mm NOTES 1. Angle section for support ﬁ xed to timber frame/ﬂ oor using coach screws or ‘Dynabolts’ when ﬁ xing to concrete. 2. The joint for ﬁ re rated board* and Plasterboard located over frame member must be stopped to manufacturer’s instructions.
Page 10 100mm Page 7...
Page 11: Adjusting The Support Frame
Adjusting the Support Frame The Sara Wood Pellet Fire must be installed on the supplied, adjustable support frame. The height of this frame can be set at the home-owner’s desired height, up to a maximum of 530mm. The frame is adjusted by manipulating the bolts, which are located on each of the four legs to achieve the desired height.
Page 12: Television Clearances
14. Television Clearances Television If electrical equipment (eg Plasma TV, LCD TV or home theatre) is to be installed above the wood pellet ﬁ re, we recommend installing a mantle below the TV screen, or recessing the TV screen into the wall, for heat protection. 50mm (min) 50mm (min) The clearances shown are recommended minimums,...
Page 13: Flueing
AS/NZS2918:2001. 110mm minimum clearance if lined flue 150mm (minimum) NOTE: Sara must be installed on an approved, raised-stand, while Sara can be installed lower to the ﬂ oor with an optional 45mm base. Page 10...
Page 14: Controls And Menus
17. Controls and Menus 17.3 Menu Descriptions The ﬁ re has various functions arranged in different menus. Some of these menus are accessible by the user, others are protected by a password and accessible only by a qualiﬁ ed technician. 18:00 All operations assume the ﬁ...
Page 15 Set the desired day by using [1] or [2] according to Press (3) twice to return to the main screen. the table shown below. 17.3.3 Menu Four - View Settings Display Meaning In this menu you can check the values of the parameters Monday set in the control unit.
Page 16 17.3.6 Loading the Screw (Auger) are usually the best but different houses may work better on other settings. 4. Switch the power to the stove back on (if the unit Insert Models - Loading the Auger should only be is pulled out this will need pushing back into its carried out in OFF mode cradle) .
Page 17: Programming & Commissioning
ﬁ re installers and technicians will have access to these passwords. If you are not a Nature’s Flame approved installer or technician, please do not attempt to install, program or commission any pellet ﬁ re from Nature’s Flame. 18.1 Sara Parameters - version BOX 03 Before After Adjusted...
Page 18 Degrees PR37 °C / °F °C Blackout PR38 Re-ignition block PR39 T-extinction min PR40 Fan 2 threshold PR41 °C Comfort climate PR42 on / off Fan 2 speed - 1 PR43 Fan 2 speed - 2 PR44 Fan 2 speed - 3 PR45 Fan 2 speed - 4 PR46...
Page 19: Technical Drawings
19. Technical Drawings Black White Microswitch Black Brown Blue MICROPROCESSOR Clock SERIAL Black White Flat cable Page 16...
Page 20: Producer Statement And Warranty Registration Form
20. Producer Statement and Warranty Registration Form PRODUCER STATEMENT & WARRANTY REGISTRATION FORM Fax To: 03 348 1743 or Post To: PO Box 11-043, Sockburn, Christchurch 8443 or Scan & Email To PRODUCT (please tick one) Pellet Boiler Pellet Fire Apricus Solar Customer Details Installation Address:...
Page 24 inspiring people to love the experience of sustainable wood pellet heat 0800 PELLET (0800 735 538) info@naturesﬂ ame.co.nz www.naturesﬂ ame.co.nz Nature’s Flame PO Box 11-043 Sockburn, Christchurch, NZ...
