ProForm 680 LT User Manual page 10

8. Remove the two ties from the bracket on the
Left Handrail (101).
Set the Left Handrail (101) on the Left Upright
(77). Attach the Left Handrail with three 5/16" x
3/4" Bolts (4) and three 5/16" Star Washers (9);
do not fully tighten the Bolts yet.
9. Remove the two ties from the bracket on the
Right Handrail (105).
Have a second person hold the Right Handrail
(105) near the Right Upright (79).
Insert the Upright Wire (86) into the bottom of
the Right Handrail (105) and pull it out of the
hole in the top of the Right Handrail.
Attach the Right Handrail (105) to the Right
Upright (79) with three 5/16" x 3/4" Bolts (4) and
three 5/16" Star Washers (9); do not fully
tighten the Bolts yet. Be careful not to pinch
the Upright Wire (86).
8
Ties
9
Hole
Ties
4
9
4
10
101
4
9
4
77
86
105
79
