SAFETY
READ AND FOLLOW ALL INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
1.
All applicable electrical codes must be followed during and after installation. All connections to be made by a qualified
electrician.
2.
Disconnect all power at the main circuit breaker before installing the PROZONE unit.
3.
WARNING - To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all
times.
4.
DANGER - Risk of electric shock.
5.
Replace damaged cord immediately.
6.
Do not bury cord.
7.
Connect only to a properly grounded, grounding type receptacle.
8.
Install at least 5 feet from the inside wall of the pool using non-metallic plumbing. The ozone generator is to be located one
foot above the maximum water level to prevent water from contacting electrical equipment. Install to provide drainage of
compartment for electrical components.
9.
A pressure wire connector is provided in the control box inside the unit to permit connection of a minimum No. 8 AWG (8.4
2
mm
) solid copper bonding conductor between this point and any metal equipment, metal enclosures of electrical
equipment, metal water pipe, or conduit within 5 feet (1.5 m) of the unit as needed to comply with local requirements.
10. Wear safety glasses when drilling and tapping holes for installation of unit.
11. WARNING: Short term inhalation of high concentrations of ozone and long term inhalation of low concentrations of ozone
can cause serious harmful physiological effects. Do not inhale ozone gas produced by this device.
12. Turn off power at source breaker before servicing the unit.
13. SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
•
Safety Instructions
•
Introduction to Ozone
•
Preparing for Installation
•
Installation of PZ2 Series Ozonators
•
Operation of PROZONE
•
Prozone Operation
•
Water Chemistry
•
Troubleshooting Guide
•
Installation Kit Inventory
PZ2 Series Manual
PROZONE INTERNATIONAL, Inc. Ozone Water Purification Systems
INSTALLATION GUIDE and
OPERATION MANUAL
Ozone Generator Systems
Prozone PZ2 Series
Advertisement
Table of Contents
Related Manuals for Prozone PZ2 Series
Summary of Contents for Prozone PZ2 Series
- Page 1 All applicable electrical codes must be followed during and after installation. All connections to be made by a qualified electrician. Disconnect all power at the main circuit breaker before installing the PROZONE unit. WARNING - To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
-
Page 2: Introduction To Ozone
INTRODUCTION TO OZONE Ozone (O ) is generated by irradiating air or oxygen (O ) with ultraviolet radiation. Ozone is a molecule of oxygen that is formed when three atoms of oxygen are bound together instead of the normal two atoms. The extra oxygen atom makes ozone the most powerful oxidizer and sanitizer readily available. - Page 3 Note: If Diatemateous Earth filter, install a 3/4 inch ball valve in the 3/4 inch hose line to the input side of the venturi. CAUTION: Make sure the voltage is the same as prescribed on the side of the Prozone ozone generator. Overvoltage will void customer warranty.
- Page 4 Prozone system and circulation pump should be activated simultaneously. Use N.E.C. or local code grounding and installation procedures for swimming pool equipment. CAUTION: Make sure the voltage is the same as prescribed on the side of the Prozone ozone generator. Overvoltage will void customer warranty.
-
Page 5: Water Chemistry
Prozone system and circulation pump should be started simultaneously. Use N.E.C. or local code grounding and installation procedures for swimming pool equipment. CAUTION: Make sure the voltage is the same as prescribed on the side of the Prozone ozone generator. Overvoltage will void customer warranty. -
Page 6: Troubleshooting Guide
The use of other chemicals is not usually required and they could cloud the pool water. TROUBLESHOOTING GUIDE PROBLEM PROBABLE CAUSE REMEDY No light from Loose wiring Check all wiring Prozone unit connections No power to unit Voltage compatibility Check power source Defective lamp or other internal component Return unit to dealer... - Page 7 PZ2-1 & PZ2-2 SERIES WITH DIRECT INJECTION Tee, Saddle, 1-1/2 inch or 1 each Valve, Check, ½ inch 2 inch x 3/4 inch Fitting, ½ inch MPT x 1/4 3 each Fitting, 3/4 inch MPT x ½ inch HB inch FP Bushing Hose, Polybraid, 1/4 inch 10 feet Clamp, Plastic, Black,...
