6.1 WaveBrowser Overview and Controls

Button Panel
The Main program window consists of the following areas:
•
The Main Viewing Area: The large blue area.
•
The Button Panel: The left side of the window.
•
The Drop Down Volume List: Allows the selection of available Disk volumes.
The Main Viewing Area
Pictures are displayed in this area in Multi-Camera, and Single-Camera formats. Picture display order
is according to the information encoded by the unit used to create the original video data file.
Choose from the following displays:
•
16-way Multiscreen Display (Large and Medium)
•
4-way Display
•
Single Camera Display Large
•
Single Camera Display Medium
•
Single Camera Display Small
0150-0242D 82
Main Viewing
Area
Drop Down
Volume List
GE Security DVMRe Matrix
