Summary of Contents for Hisense PDP42W39PEU
- Page 1 PDP TV Service Manual Plasma display television Service Manual Classis: MST9E88L Product Type: PDP42W39PEU/ PDH4233NEU(2) PDH4233NEU(1) Ver 1.0 Hisense Electric co., Ltd. R&D Center PDP Institute 06, 2008 Hisense confidential...
-
Page 2: Table Of Contents
PGRADING 6.1 Get ready for upgrading....................19 6.2 Upgrading with the ISP_TOOL4.0.9................28 ......................33 ROUBLESHOOTING 8. P : ....................... 35 ROBLEM SOLUTIONS 9. S ......................36 TAND INSTALLING 10. PDP W ..........37 MOUNTING RACKET NSTALLATION UIDE Hisense confidential... -
Page 3: Service Manual
Afterimage on the Screen Displaying still images from Video games and PC for longer than a certain period of time may produce partial afterimages. To prevent this effect, reduce the brightness and contrast when displaying still images for a long time. Hisense confidential... - Page 4 2000m in height and do not install and operate there. Avoid operating the TV at temperatures below 5 (41°F) Warranty Warranty does not cover any damage caused by image retention; Burn-in is not covered by the warranty. Hisense confidential...
-
Page 5: Product Function Specifications
Input: (HDCP) Audio Input: YUV x 1 ,S-Video /AV x 1,PC analog (DB15) x 1 Audio audio output x 1 Output: headphone x 1 (Jack 3,5mm) Video video output x 1 Output: Other: Dimensions 1052mmX799mmX333mm (LXWXH) (including stand) Hisense confidential... -
Page 6: Product Function
·High end flat display ·HDMI input ·High definition compatible ·Wide Screen display optimized for cinema viewing ·Multimedia display :TV/PC ·High clear picture ·Audio equalizer ·Color enhancer ,contrast enhancer ·Two Scarts ,Scart1 (RGB/CVBS),Scart2(CVBS) 3. PDP panel spec 3.1General description S42AX-YD03 Hisense confidential... -
Page 7: Panel Block Diagram
PDP TV Service Manual Panel block diagram 3.2. 3.3.Power (PSU) description AC 100V ∼ 240V Standard Voltage Range AC 90V ∼ 265V Available Voltage Range Hisense confidential... -
Page 8: Power Block Diagram
PDP TV Service Manual 50Hz ∼ 60Hz(± 5Hz) Frequency Range 3.4.Power block diagram Hisense confidential... - Page 9 PDP TV Service Manual Hisense confidential...
- Page 10 PDP TV Service Manual Hisense confidential...
-
Page 11: Block Diagram
MST9E88L produced by MSTAR co., ltd. 4. Block Diagram 4.1. unite sketch map PDH4233NEU（1）LG Panel POWER SUPPLY CN801 CN804 CN803 CN802 XP24 XP25 XP26 MAIN BOARD 961A XP31 SCART BOARD XPK01 XPR01 SPEAKER KEY BOARD REMOTE BOARD. 970A 987A Hisense confidential... - Page 12 PDP TV Service Manual PDP42W39PEU/PDH4233NEU(2) ( samsung Panel) POWER SUPPLY CN803 CN804 XP26 MAIN BOARD XP31 SCART BOARD XPK01 XPR01 SPEAKER KEY BOARD REMOTE BOARD. 970A 987A Hisense confidential...
-
Page 13: Video Processing Diagram
PDP TV Service Manual 4.2. Video processing diagram TUNER SAW FILTER HS9455 TDQ-6FT/W TDA9886 HS6274 116H YPBPR VIDEO PDP module S-VIDEO S42AX-YD03 HDMI 9E88L FLASH SCART1 _CVBS PS25V040 SCART1_ RGB SDRAM HY5DU281622F SCART2 _CVBS VIDEO OUTPUT KEY/ REMOTE Hisense confidential... -
Page 14: Audio Processing Diagram
PDP TV Service Manual 4.3. Audio processing diagram VIDEO -L VIDEO-R AV-L TV-SIF AV-R AUDIO OUT YPBPR/PC-L YPBPR/PC-R Earphone Amplifier HDMI-IIS LM833 SCART1-L SCART1-R Speaker Amplifier SCART2-L TDA8932T SCART2-R Hisense confidential... -
Page 15: Factory/Service Osd Menu
The Factory OSD Menu comprises Factory Menu and Design Menu . 5.2.1、Factory Menu Factory Menu White Balance White Balance R DRV Auto Calibration G DRV B DRV LOGO R CUT OSD Language G CUT Country B CUT Option BRIGHT_H Factory Init CONTRAST _H Test Pattern BRIGHT_L Version: CONTRAST_L Hisense confidential... - Page 16 GREEN COLOR BLUE COLOR Option Factory Init SOURCE QingDao BRIGHT 0 HuangDao BRIGHT 50 Guiyang BRIGHT 100 Hungary CONTRAST 0 France CONTRAST 50 Austria CONTRAST 100 170 CLEAR PROTECTLY TOFAC CLEAR UNPROTECTLY HDMI Cable Standard PIXSHIFTNUMBER 1 PIXSHIFTTIME Hisense confidential...
- Page 17 PDP TV Service Manual Test Pattern Version BLUE Version: Panel Type: FLASH : 5.2.2、Design Menu Design Menu Picture Mode Sound Mode Sound Settings Power Save PIP Option MOVESHARPNESS LipSync Hisense confidential...
- Page 18 The above “Factory/Service OSD Menu” are reference only, please refer to the actual units to determine the appearances. We advise service hadn’t better amend factory data, because it is better settings data. Please do not tell user the purpose password. Hisense confidential...
-
Page 19: Software Upgrading
The software is upgraded by a burning tool- ISP_TOOL4.0.9, which can burn the program file *.bin to the main board of the unit 6.1 Get ready for upgrading 6.1.1 Install the ISP_TOOL4.0.9-------only for the first time update. 1、 Port Setting： Choose “system”option from the “control panel” Hisense confidential... - Page 20 PDP TV Service Manual Click the “system” icon as the following Choose the “hardware” option from the dialog window Click“device management” icon as the following Hisense confidential...
- Page 21 PDP TV Service Manual Choose the port (COM and LPT1) Choose the ECP print port (LPT1） Hisense confidential...
- Page 22 Click the port of print （LPT1）as the following Choose “port setting”option as the following Find the folder where the ISP_TOOL4.0.9 lies in. 2、 There are three folders/files in this folder together. DLPORTIO.dll and FTD2XX.DLL must be in the same folder Hisense confidential...
- Page 23 Click the Config button. And then a dialog window will show as below. “Port Type” setting is LPT1 “Base Addr ”setting is 0x378 Draw on the front of “pin 1 switch UART/I2c” Speed setting is 99 As following Hisense confidential...
- Page 24 PDP TV Service Manual Choose“SDA in”and setting “PIN” is “PIN10”。 Notes: Do not draw on the front of “Reverse High”。 As following Choose “SCL in”and setting “PIN” is “PIN11”。 Notes: Do not draw on the front of “Reverse High”。 As following Hisense confidential...
- Page 25 PDP TV Service Manual Choose “SDA out”and setting “PIN” is “PIN4” Notes: Draw on the front of “Reverse High”。 As following。 Choose “SCL out”and setting “PIN” is “PIN2” Notes: Draw on the front of “Reverse High” As following Hisense confidential...
- Page 26 PDP TV Service Manual After having finished all above, clicking the “Apply ”button to complete the configuration。 6.1.2 Hardware connecting You can update the software through a special tool (as following) Hisense confidential...
- Page 27 PDP TV Service Manual Connect the Debug board to the TV use VGA interface, the other parallel port to the computer, just as the following。 Hisense confidential...
-
Page 28: Upgrading With The Isp_Tool4.0.9
PDP TV Service Manual 6.2 Upgrading with the ISP_TOOL4.0.9 6.2.1 Double click the ISP_TOOL4.0.9 icon and a dialog window will show as following。 Click the“Read ”button。 Hisense confidential... - Page 29 PDP TV Service Manual Choose the update file from the folder。 Hisense confidential...
- Page 30 PDP TV Service Manual The update file has been chosen successfully。 Click the“Auto”button and choose parameters as following。 Click the“Run”button Click the“connect”button,then show a dialog box as following。 Hisense confidential...
- Page 31 PDP TV Service Manual If show above then click the“Run”button again and again，till show the following dialog window。 Hisense confidential...
- Page 32 If the update is successful, enter Factory Init Menu and select “Clear Unprotectly” a. Press VOL+ button to clear the EEPROM data. b. When the “Clear Unprotectly ” button becomes white, turn off the power. c. Restart the TV. Hisense confidential...
-
Page 33: Troubleshooting
Press [zoom]on the remote control to check whether it is in zoom mode Enlarged display The TV system has wrongly identified 625-lines system as 525-lines system. Change to another source (such as video, pc) and change back to TV to correct it Hisense confidential... - Page 34 Power indicator at the centre of the front panel. Normal state : blue; remote command state: blue flickering. L.LED? LVDS indicator on the logic processing board. Normal state: yellow flickering. OSD? Press [MENU] to display menu on the screen. Hisense confidential...
-
Page 35: Problem Solutions
If it is low, please check the circuit. 9.If the picture is not normal 16:9 mode or 4:3 mode when the signal equipment send 16:9 mode or 4:3 mode, please check the aspect mode whether is in “normal” mode. Hisense confidential... -
Page 36: Stand Installing
PDP TV Service Manual 9. Stand installing Hisense confidential... -
Page 37: Pdp Wall-Mounting Bracket Installation Guide
PDP TV Service Manual 10. PDP Wall-mounting Bracket Installation Guide READ CAREFULLY BEFORE INSTALLATION! THE INSTALLATION GUIDE SHOULD BE RETAINED FOR FUTURE REFERENCE. Hisense confidential... - Page 38 PDP TV Service Manual Hisense confidential...
- Page 39 PDP TV Service Manual Explode View Schematic Circuit Diagrams: Hisense confidential...
- Page 42 5Vstb_PDP R465 R466 R467 100R XP24 5Vstb +12V STANDBY STANDBY C426 R468 R470 5Vstb_PDP 5Vstb_PDP VOUT 0.1uF C180 VS_ON C184 C183 C181 SR34 0.1uF LM7808 47UF/ 16V R469 47UF/16V 0.1uF SR34 C427 NC/CON7_2.54 VCCH 0.1uF 5Vstb_PDP 5Vstb +12V XP25 R471 C194 C186 C195...
- Page 43 Vcc1.8 for MST9X88L AP1520 5Vstb VDDC 15uH R358 C343 R360 C347 C348 OCSET î ã C349 R361 470u R359 î ã C344 C345 C346 RB060L MARK MARK MARK MARK MARK 100n 100n 0.8*(1+3.9/3)=1.8V MARK MARK MARK MARK 1117-3.3 5Vstb +3.3AVDD Vout 10uH C240...
- Page 44 XS6A AV2-Vin+ R106 AV1_L AV1-Lin × ó É Ï R150 C104 R151 SCART2 Ê ä È ë ½ Ó ¿ Ú AV1_R » Æ C103 R110 470P AV2-Vin- XP31 560pF R152 Scart1_R Ö Ð R135 Scart1_L XS2B AV2-L AV2-Lin STZ6.2N ×...
- Page 45 VGA/5V R320 100R R326 47nF VGA-B+ C315 BIN+ 47nF VGA-G + R327 C316 GIN+ 47nF VGA-R+ R328 C317 RIN+ R337 C312 R334 R335 R336 47nF BAV99 BAV99 BAV99 R338 C318 BIN- 47nF C308 C309 C310 R339 C319 GIN- 47nF R340 C320 RIN- 0.1uF...
- Page 46 HDMIMUX3.3VHDMIMUX3.3V HDMIMUX3.3V HDMIMUX3.3V +3.3AVDD 0.1uF Rclamp0514m HDMI2 -RX2+ 10uF HDMIMUX3.3V HPD_SINK HDMI- DDC-SDA DATA2+ HPD2 SDA_SINK HDMI_SDA DATA2 SHIELD HDMI2-DDC-SDA HDMI- DDC-SCL HDMI2-RX2- SDA2 SCL-SINK HDMI_SCL DATA2- HDMI2-DDC-SCL HDMI2-RX1+ SCL2 DATA1+ DATA1 SHIELD TXCLK- HDMI2-RX1- TXCLK- DAT1A- HDMI2-RXC- TXCLK+ HDMI2-RX0+ TXCLK+ HDMI2-RXC+ DATA0+...
- Page 47 near output Location NearIC Pin. Location NearIC Pin. +3.3V near output +3.3V C12 7 C12 8 R15 4 R15 5 AMP-Rout AMP -R PH-Rout PH- R1ou t R162 C352 AMP-R PH-R1out BAV 99 RP4 .7K 2.2 uF 2.2 uF C15 2 R17 1 R17 2 47U F/16 V...
- Page 48 U23 PIN2 connected to PIN1 B/G,DK,I,L U23 PIN2 connected to GND L' I2C ADDRESS(R263 NC): 5V-IF READ is 0X87 5V-IF WRITE is 0X86 4.7K 4.7K 4.7K IF_TV IN414 8 NC/68 0K IF-AFT TUNER _IF 3904 R487 IF-AG C R443 10nF C332 0.1uF 0.1uF...
- Page 49 6VBuf2 12V_OP C446 NC/10 0 100u OP_VCC2 47UF/16V 2.2uF 0.1uF PH-R1 out1 PH- R1out PH-R1out 0R/10 K 12V_OP 12V_OP 0R/33 K R509 R514 R510 R515 NC/47K NC/47K NC/22 NC/22 NC/10 0pF R511 R516 Scart2_Rout Scart 2_Lout 0R/NC 0R/NC R512 R517 Scart 2_R Scart 2_L NC/3906...
- Page 50 12V_OP R498 R502 C452 Phone_L Phone_L 6VBuf1 12V_OP 100 u C447 R504 R496 C450 4.7uF R269 3906 +12V R506 100u NC/10k R277 R278 R500 OP_VCC1 R507 100K C273 C258 C272 FB/NC 2.2uF 0.1uF 4. 7UF C290 C415 OPVCC_SW OPVCC_SW C454 0.1uF 0.1uF R272...
- Page 51 AV1-Y AV2_out1 AV1-C Scart2_Rout1 Scart2_Lout1 AV2_out1 AV1_R AV1_L Scart-pin8 Scart-pin8 AV1-C AV1_L AV1-Y SCART2B Scart2_Lout1 AV1_R Scart2_Rout1 SCART1 ¾ É µ × Í ¼ × Ü º Å ¸ ü ¸ Ä Ê ý Á ¿ Ç © Ã ¸ ü ¸ Ä û...
- Page 52 5Vstb XPR01 IR-in 1 LED-R 1 RR04 RR03 LED-R 1 LED-R 1 3904 PNP-T 5Vstb 100R 100R NR01 RR01 RR02 330R 330R Ð è Ò ª ´ ® Á ª Ò » ¸ ö Ð ¡ µ ç è £ ¡ ¡ ñ Ô ò Ò £ ¿ Ø ² » Á é Ã 5Vstb VDR01 LR01...
