PDP TV Service Manual
Plasma display
television
Service Manual
Classis: MST9
Product Type: PDP3208(TPW3208)
Ver 1.0
Hisense Electric co., Ltd.
R&D Center PDP Institute
09, 2007
Hisense confidential
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDP3208 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hisense PDP3208

  • Page 1 PDP TV Service Manual Plasma display television Service Manual Classis: MST9 Product Type: PDP3208(TPW3208) Ver 1.0 Hisense Electric co., Ltd. R&D Center PDP Institute 09, 2007 Hisense confidential...
  • Page 2: Table Of Contents

    Service Manual…………………………………………………. -2- 1. Product Safety Servicing Guidelines……………………. -3- 1-1 Safety precautions………………………………………-3- 1-2 Product Safety notice…………………………………..-3- 2. Product Function Specifications…………………………..-4- product function……….……………………...-4- PDP3208 specifications…………..………………………-4- PDP3208 3. PDP panel spec……………………………………………...-6- 3-1 General description……………………………………..-6- 3-2 Panel block diagram……………………………………-7- 3-3 Power (PSU) description……………………………… -7- 3-4 Power block diagram…………………………………...-8-...
  • Page 3: Product Safety Servicing Guidelines

    2000m in height and do not install and operate there. Avoid operating the TV at temperatures below 5 ℃ (41°F) Warranty Warranty does not cover any damage caused by image retention; Burn-in is not covered by the warranty. Hisense confidential...
  • Page 4: Product Function Specifications

    PDP TV Service Manual Product Fuction Specifications 1.PDP3208 product function Hisense confidential...
  • Page 5: Pdp3208 Specifications

    ·HDMI input ·High definition compatible ·Wide Screen display optimized for cinema viewing ·Multimedia display :TV/PC ·High clear picture ·Audio equalizer ·Color enhancer ,contrast enhancer 2. PDP3208 specifications PDP3208 PDP panel Plasma panel 32'' Native Screen Resolution 852 x 480 Television system...
  • Page 6: Pdp Panel Spec

    PDP TV Service Manual PDP panel spec 1. General description Hisense confidential...
  • Page 7: Panel Block Diagram

    PDP TV Service Manual Panel block diagram 3.Power (PSU) description AC 100V ∼ 240V Standard Voltage Range AC 90V ∼ 265V Available Voltage Range 50Hz ∼ 60Hz(± 5Hz) Frequency Range Hisense confidential...
  • Page 8: Power Block Diagram

    PDP TV Service Manual 4.Power block diagram Hisense confidential...
  • Page 9: Signal Processing Diagram

    TDQ-6FT/ HS9457 TDA 9886 W126H HS6274 HDMI signal PC signal YPBPR signal PDP32F1 1 S_video Plasma 2 AV input 9E19 display 3 sound input key/remote picture/sound output Sound amp MP7722 Earphone amp earphone FLASH LM833 Hisense confidential...
  • Page 10: Service Mode And Adjustment

    LOGO R CUT OSD Language G CUT Country B CUT Option BRIGHT_H Factory Init CONTRAST _H Test Pattern BRIGHT_L Version: CONTRAST_L Auto Calibration LOGO Auto Color NULL Color Temp. Standard HISENSE RED COLOR WELCOME GREEN COLOR BLUE COLOR Hisense confidential...
  • Page 11 Guiyang BRIGHT 100 Hungary CONTRAST 0 France CONTRAST 50 Austria CONTRAST 100 170 CLEAR PROTECTLY TOFAC CLEAR UNPROTECTLY HDMI Cable Standard PIXSHIFTNUMBER 1 PIXSHIFTTIME Test Pattern Version BLUE Version: PDP3208_R1.00.20070811 Panel Type: LG PDP32F1 (852*480) FLASH : EN25F80 Hisense confidential...
  • Page 12 Sound Settings VOLUME 0 VOLUME 1 VOLUME 20 VOLUME 40 VOLUME 100 TVPRE SCALER VOLUME SCALER NOTE: We advise service hadn’t better amend factory data, because it is better settings data. Please do not tell user the purpose password. Hisense confidential...
  • Page 13: Software Updating

    PDP TV Service Manual Software updating PDP3208 software updating 1、You can update the software through a special tool (show as below) 2、Software Updating Operation 1.Connect the Debug board to the TV use VGA interface, then connect the Debug board to the computer, just as the pictures showing.
  • Page 14 PDP TV Service Manual 2.Set the ISP_TOOL4.0.9 -------only for the first time update. DLPORTIO.dll and FTD2XX.DLL must be in the same folder 1)Find the folder where the ISP_TOOL4.0.9 lies in. Hisense confidential...
  • Page 15 Note: DLPORTIO.dll and FTD2XX.DLL must be in the same folder. 2)Double click the ISP_TOOL4.0.9 icon, and then a dialog will show as below. 3)Click the Config button. And then a dialog will show as below. You should set the Config like what the picture shows. Hisense confidential...
  • Page 16 PDP TV Service Manual Hisense confidential...
  • Page 17 PDP TV Service Manual Hisense confidential...
  • Page 18 4) After you have finished all above, you should click the Apply button to complete the configuration. 3. Turn on the TV, then we can update. 4. Double click the ISP_TOOL4.0.9 icon, and then a dialog will show as below. 5. Click the Read button. And then do as shown below. Hisense confidential...
  • Page 19 PDP TV Service Manual 6. Find the update file in your computer. Hisense confidential...
  • Page 20 PDP TV Service Manual 7. Double click the update file. A dialog will show as below. Hisense confidential...
  • Page 21 PDP TV Service Manual 8. Click the Auto button. And then do as shown below. Hisense confidential...
  • Page 22 PDP TV Service Manual 9. Click the Connect button. And then do as shown below. Hisense confidential...
  • Page 23 PDP TV Service Manual 10. Click the Run button. 11. When the update is finished, a dialog will show as below. Hisense confidential...
  • Page 24: Pdp3208 Explode View And Bom

    PDP TV Service Manual PDP3208 Explode View and Bom Spare Parts List Main Spare Parts Name Part No. Type Hisense confidential...
  • Page 25: Troubleshooting

    Press [zoom]on the remote control to check whether it is in zoom mode Enlarged display The TV system has wrongly identified 625-lines system as 525-lines system. Change to another source (such as video, pc) and change back to TV to correct it Hisense confidential...
  • Page 26 Power indicator at the centre of the front panel. Normal state : blue; remote command state: blue flickering. L.LED? LVDS indicator on the logic processing board. Normal state: yellow flickering. OSD? Press [MENU] to display menu on the screen. Hisense confidential...
  • Page 27 If it is low, please check the circuit. 9.If the picture is not normal 16:9 mode or 4:3 mode when the signal equipment send 16:9 mode or 4:3 mode, please check the aspect mode whether is in “normal” mode. Hisense confidential...
  • Page 28: Stand Installing

    TV screen. 2. Lay this unit stably with screen downside. 3. Take out the base and assemble it with four screws (M6×12) as illustrated. NOTE: Failure to do so may result in breaking, denting and scratching the plasma display. Hisense confidential...
  • Page 29: Pdp Wall-Mounting Bracket Installation Guide

    PDP TV Service Manual PDP Wall-mounting Bracket Installation Guide Hisense confidential...
  • Page 30 PDP TV Service Manual Hisense confidential...
  • Page 31 CA35 CA35 VCC_USB5V C292 C292 600(4.5X3.2) 600(4.5X3.2) 0.1uF 0.1uF 100uF/16V 100uF/16V CN11 CN11 +12V_in 5Vstb 4.7uH 4.7uH R310 0R R310 0R BL-ON/OFF +12V_all1 +12V_all1 R311 0R R311 0R 47uF/16V 47uF/16V NC/600(4.5X3.2) NC/600(4.5X3.2) BL-ADJUST R314 0R R314 0R BL-ON/OFF B/240A B/240A 47uF/16V 47uF/16V U222...
  • Page 32 5V_STBY 5V_STBY R421 R421 5V_STBY 4.7K 4.7K R422 R422 R197 R197 STANDBY 4.7K 4.7K R195 R195 R424 R424 KEY1-in 4.7K 4.7K 3904 3904 MMCU-RESET KEY1-in R477 R477 C124 C124 0.1uF 0.1uF PD3(INT1) PC1(ADC1) R476 0 R476 0 LED_R PD4(XCK/T0) PC0(ADC0) 5V_STBY R474 0 R474 0...
  • Page 33 VCC_USB5V USB1_5V CN18 CN18 VCC_USB5V CON12 CON12 VCC1 528 amend VBUS USB1_M USB3_5V USB1_P USB1_5V USB2_5V USB1_P USB2_P USB2_5V ID_USB USB2_M GND1 VCC2 R357 R357 USB1_P USB1_5V USB1_M DMP_DTV-R DMP_DTV-L DMP_DTV-R MR_OUT ML_OUT DMP_DTV-L SC/RC_GREEN SC/RC_BLUE SC/RC_BLUE SC/RC_GREEN Y_OUT GND2 PB_OUT SC/RC_RED SC/RC_RED...
  • Page 34 0.81*(1+Rup/Rdown)=1.8V---Rup=10K, Rdown=8.2K Vcc3.3for MST9E19A analog AMS1117-3.3 AMS1117-3.3 Vcc1.8 for MST9E19A VDDC for MST9E19A Core +3.3Vstb 5Vstb 0.1uF 0.1uF 47uF/16V 47uF/16V 0.1uF 0.1uF 47uF/16V 47uF/16V 15uH 15uH VDDC VDDC AP1520 AP1520 5Vstb 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF...
  • Page 35 VDDP VDDP RP10 RP10 Location Near IC Pin. Location Near IC Pin. Location Near IC Pin. AMP-Rout AMP-R AUOutR3 AUOut3-R AUOutR2 AUOut2-R RP4.7KX4 RP4.7KX4 AMP-R AUOut3-R AUOut2-R RP4.7KX4 RP4.7KX4 BAV99 BAV99 CA13 CA13 47uF/16V 47uF/16V SCL_EXT SCL_EXT SDA_EXT 10nF 10nF 10nF 10nF SDA_EXT...
  • Page 36 HDMI_J HDMI_J HDMI-RX2+ R_TX2+ R_TX2+ DATA2+ HDMI-RX2- R_TX2- R_TX2- DATA2 SHIELD HDMI-RX1+ G_TX1+ G_TX1+ DATA2- HDMI-RX1- G_TX1- G_TX1- DATA1+ GND1 HDMI-RX0+ B_TX0+ B_TX0+ DATA1 SHIELD HDMI-RX0- B_TX0- B_TX0- DAT1A- GND2 HDMI-RXC+ TXCLK+ TXCLK+ DATA0+ HDMI-RXC- TXCLK- TXCLK- GND3 DATA0 SHIELD DATA0- CLK+ GND4...
  • Page 37 VGA/5V R108 R108 R109 R109 VGA-B+ 47nF 47nF BIN+ BIN+ R110 R110 VGA-G+ GIN+ 47nF 47nF GIN+ R111 R111 VGA-R+ 47nF 47nF RIN+ RIN+ R115 R115 D121 D121 D108 D108 D109 D109 R112 R112 R113 R113 R114 R114 R116 R116 INPAQ_VPORT INPAQ_VPORT INPAQ_VPORT...
  • Page 38 5VPI 5VPI R321 R321 Video_out2 SCART1_VOUT SCART1_VOUT R322 R322 Video_out1 Component Input Video_out1 R135 R135 R136 R136 R137 R137 R130 R130 R131 R131 R132 R132 CA19 CA19 47uF/16V 47uF/16V HD1_YIN SCART1_VOUT SCART1_VOUT SC/RC_RED SC/RC_RED SC/RC_RED SC/RC_RED CA17 47uF/16V CA17 47uF/16V SCART1-R R200 R200...
  • Page 39 U23 PIN2 connected to PIN1 B/G,DK,I,L U23 PIN2 connected to GND L' I2C ADDRESS(R263 NC): +5VA READ is 0X87 +5VA R219 R219 R220 R220 R221 R221 WRITE is 0X86 4.7K 4.7K R222 R222 R223 R223 4.7K 4.7K 4.7K 4.7K C133 C133 IF_TV NC/BA277...
  • Page 40 Audio OP(AUOUTL3/AUOUTR3; AUOUTL2/AUOUTR2) +12V_all R261 R261 6VBuf2 OP_VCC2 R262 R262 OP_VCC2 OP_VCC2 CA38 CA38 R263 R263 C168 C168 CA39 CA39 6VBuf2 0.1uF 0.1uF 100uF/16V 100uF/16V OP_VCC2 100uF/16V 100uF/16V C169 C169 0.1uF 0.1uF C170 C170 R264 R264 R265 R265 2.2uF 2.2uF Scart1_R Scart1_R C171...
  • Page 41 FOR TDA1308/PT2308 L26 FB,R298 NC; Vcc_jz FOR TL062 L26 NC,R298 0; CA51 CA51 +16V +5VA +12V_all 9vsc 47uF/35V 47uF/35V R346 R346 R317 R317 R347 R347 6VBuf1 R298 R298 R133 R133 R313 R313 1N4148 1N4148 CA40 CA40 100k 100k Vcc_jz 100uF/16V 100uF/16V OP_VCC1 R281...
