CLEARANCES TO COMBUSTIBLES
INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENT
MANUFACTURER.
When the unit is being installed on a combustible floor a 1/2" thick non-combustible
hearth pad must be installed under the unit. The pad must extend at least the width of the
appliance and at least the depth of the appliance plus 6" (152 mm) in front of the
appliance. This applies for both the freestanding unit and the insert.
Figure 5
Alcove Dimensions
Figure 6
14
