The Classic
Cast Iron
Stoves
Installer: Please leave these instructions with the
consumer.
Consumer: Please retain these instructions for
future use.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may
result causing property damage, personal in-
jury or loss of life.
FOR YOUR SAFETY: What to do if you smell
gas:
•
Do not touch any electrical switches
•
Do not try to light any appliance.
•
Do not use the phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone.
•
Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Refer to this manual.
For assistance or additional information consult
a qualified installer, service agency, or the gas
supplier.
15628-0-0903
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
AND
CAST IRON
DIRECT VENT FIREPLACE
MODEL
CIDV-30-20
EFFECTIVE DATE
SEPTEMBER, 2003
Cet appareil peut être installé dans une maison
préfabriquée (É.U. seulement) ou mobile déjà installée
à demeure si les règlements locaux le permettent.
Cet appareil doit être utilisé uniquement avec les types
de gaz indiqués sur la plaque signalétique. Ne pas
l'utiliser avec d'autres gaz sauf si un kit de conversion
certifié est installé.
AVERTISSEMENT: Quiconque ne respecte pas à
la lettre les instructions dans le présent manuel
risque de déclencher un incendie ou une explosion
entraíant des dommages matériels, des lésions
corporelles ou la perte de vies humaines.
POUR VOTRE SÉCURITÉ: Que faire si vous
sentez une odeur de gaz:
•
Ne pas tenter d'allumer d'appareil.
•
Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones se trouvant dans le
bâtiment où vous vous trouvez.
•
Évacuez la pièce, le bâtiment ou la zone.
•
Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions du
fournisseur.
•
Si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le service dos incendies.
AVERTISSEMENT: Une installation, un réglage,
une modification, un entretien ou une maintenance
incorrects peuvent entraîner des dommages
matériels, des lésions corporelles ou la perte de vies
humaines. Consulter le manuel des usagers fourn
avec ce générateur d'air chaud.
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for White Mountain Classic CIDV-30-20
Summary of Contents for White Mountain Classic CIDV-30-20
-
Page 1: Installation Instructions
OWNER'S MANUAL CAST IRON The Classic DIRECT VENT FIREPLACE Cast Iron MODEL Stoves CIDV-30-20 Installer: Please leave these instructions with the consumer. Consumer: Please retain these instructions for EFFECTIVE DATE future use. SEPTEMBER, 2003 This appliance may be installed in an aftermarket Cet appareil peut être installé... -
Page 2: Table Of Contents
Wiring ..........................27-28 Maintenance ........................29-30 Troubleshooting ......................... 31 How To Order Repair Parts ....................32 Parts List for CIDV-30-20 ....................32 Parts View for CIDV-30-20....................33 Parts List for Stove Casting ....................34 Parts View for Stove Casting ....................35 Optional Blower Installation Instructions .............. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION THIS IS A HEATING APPLIANCE DO NOT OPERATE THIS APPLIANCE WITHOUT FRONT PANEL INSTALLED • DO examine venting system periodically and replace • Due to high temperatures the appliance should be damaged parts. located out of traffic and away from furniture and draperies. -
Page 4: Safety Information For Users Of Lp Gas
SAFETY INFORMATION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires by point with the members of your household. Someday when there may not be a minute to lose, everyone's safety will and explosions. In its natural state, propane is odorless and colorless. -
Page 5: Introduction
INTRODUCTION Instructions to Installer This model is a direct vent gas appliance and is designed to operate Installer must leave instruction manual with owner after with all combustion air being siphoned from the outside of the installation. building and all exhaust gases expelled to the outside of the building. Installer must have owner fill out and mail warranty card Warning: This unit is not for use with solid fuel. -
Page 6: Specifications
SPECIFICATIONS Model CIDV-30 Input BTU/HR (KW/H) Maximum 30,000 (8.7) BTU/HR (KW/H) Minimum 21,000 (6.2) Height 27 3/4" (70.5cm) Width 25 1/2" (64.8cm) Depth 23" (58.4cm) Gas Inlet (Pipe) 1/2" (13mm) Floor to top of collar on vertical position of Vent Elbow 27 5/8"... -
Page 7: Gas Supply
GAS SUPPLY A manual main gas cock should be located in the vicinity of the Consult the current National Fuel Gas Code, ANSI Z223.1 CAN/ unit. Where none exists, or where its size or location is not CGA-B149 (.1 or .2) installation code. adequate, contact your local authorized installer for installa- Recommended Gas Pipe Diameter tion or relocation. -
Page 8: Clearances
CLEARANCES In selecting a location for installation, it is necessary to provide adequate accessibility clearances for servicing and proper opera- tion. Locating and Venting the Direct Vent Fireplace Clearances: When facing the front of the direct vent fireplace the minimum clearances to combustible construction (material) are the following: Top of appliance (ceiling) 36 (inches) -
Page 9: Appliance Hardware Package
Figure 5 APPLIANCE HARDWARE PACKAGE Appliance Hardware Package Parts List Part Part Quantity Description Number Supplied 1/4-20 x 1" Phillips Head Bolt R-3188 1/4-20 x 3/8" Phillips Head Bolt R-3646 1/4-20 x 1/2" Leveling Bolt R-3747 No. 10 x 1/2" R-2737 Hex Washer Head Screw 1/4-20 Washer Head Nut... -
Page 10: Assembly Of Stove Casting
ASSEMBLY OF STOVE CASTING Assembly of Stove Casting Detailed Instructions Follow (Figures 7, 8, 9, 10, 11, 12 and 13) 3. Refer to Figure 7, the leg pads will have the letter "A" and "B" Attention: Included in the hardware package are (8) 1/4" inside stamped into the metal. - Page 11 8. Position the completed portion of the casting in the 7. Refer to Figure 8, attach casting support to rear cover with (4) approximate location for installation as the completed 10 x 1/2" screws. The rear cover has (4) keyholes for assembly will be heavy.
- Page 12 ASSEMBLY OF STOVE CASTING (continued) 16. Attach casting front to outer casting as described in Step 11. 11. Refer to Figure 10, attach casting front to casting by using the 17. Place the casting top onto the outer casting. The casting top (4) retaining tabs on the casting front.
-
Page 13: Optional Stone Inlay Installation
OPTIONAL STONE INLAY INSTRUCTIONS Whenever the standard grill top is replaced with a stone inlay you Stone Inlay Hardware Package Parts List must install the top shield, which is provided with the stone inlay. Part Part Quantity Installation of Optional Stone Inlay Description Number Supplied... -
Page 14: Dvka-1 Vent Elbow Installation
DVKA-1 VENT ELBOW INSTALLATION Attention: A tube of furnace cement is provided in the Owner's Envelope. Apply furnace cement to the top, exterior edge on the cast iron flue outlet. Place the DVKA-1, vent elbow onto the flue outlet as you align the clearance holes on the vent elbow with the clearance holes on the vent elbow gasket. -
Page 15: Venting Fireplace
VENTING FIREPLACE Venting Graph (Dimensions in Feet) (Figure 16) Maximum vertical rise from appliance outlet = 25 feet (7.62m), 1. Determine the height of the center of the termination. Using the restrictor plate may be used above 10 feet. this dimension on the Venting Graph, locate the point it Maximum horizontal run from appliance outlet = 12 feet (3.66m). -
Page 16: Restrictor Plate Installation
VENTING FIREPLACE (continued) Sidewall Venting The maximum vertical and horizontal distances for one (1) 90° elbow are 25 feet and 12 feet, respectively. Vertical dimensions are based on top of fireplace to centerline of pipe. Horizontal dimensions are based on centerline of pipe to termination. CAUTION: Total vertical run MUST BE completed before starting horizontal run. -
Page 17: Termination Clearances
TERMINATION CLEARANCES Termination clearance for buildings with combustible and noncombustible exteriors. Figure 20 Vertical Sidewall Installations Since it is very important that the venting system maintain its Important! Minimum clearance between vent pipes and balance between the combustion air intake and the flue gas combustible materials is one inch (1") (25mm) on, bottom and exhaust, certain limitations as to vent configurations apply and sides and (2") (51mm) on top. -
Page 18: Vent Clearances
VENT CLEARANCES Figure 21 *Clearance above grade, veranda, porch, deck or balcony clearance to non-mechanical air supply inlet to building or [*12 inches (30cm) minimum] the combustion air inlet to any other appliance [*12 inches (30cm) minimum for appliances ≤ 100,000 Btuh (30 kW) clearance to window or door that may be opened [*9 inches (23cm) minimum for appliances <... -
Page 19: Vent System Identification
VENT SYSTEM IDENTIFICATION Installing Vent Components (Figure 22 and Figure 23) Begin the vent system installation by installing the first component, a straight pipe on the top of the appliance,or rotate the vent elbow to the horizontal positon then add horizontal and vertical pipe lengths and then a horizontal or vertical termination kit. -
Page 20: Framing And Finishing
FRAMING AND FINISHING Installing Support Brackets (Figure 24) A horizontal pipe support MUST BE used for each 3 feet of horizontal run. The pipe supports should be placed around 6-5/8 inch diameter pipe and nailed in place to framing members. There MUST BE a 2 inch clearance to combustibles above 6-5/8 inch diameter pipe and elbows and 1 inch clearance on both sides and bottom of 6-5/8 inch to combustibles on all horizontal pipe... -
Page 21: Horizontal Termination
Figure 27 Figure 28 HORIZONTAL TERMINATION Attach and secure the termination to the last section of horizontal venting by rotating and interlocking the ends as previously described. NOTE: Termination cap should pass through the wall firestop from the exterior of the building. Adjust the termination cap to its final exterior position on the building. -
Page 22: Vertical Termination
VERTICAL TERMINATION Vertical Terminations (Figures 30, 31 and 32) 3. Check for evidence of excessive condensate, such as water Locate and mark the center point of the venting pipe. Using a nail droplets forming in the inner liner and subsequently dripping on the underside of the roof and drive this nail through this center out at joints. -
Page 23: Log Placement
Vertical Through the Roof Applications Vertical runs of this vent systems must be supported every 4 feet Your Gas Fireplace has been approved for above the appliance flue outlet by wall brackets attached to the 6- a) Vertical installations up to 25 feet in height. 5/8 inch vent pipe and secured with nails or screws to structural b) Two sets of 45 degree elbow offsets within these vertical framing members. -
Page 24: Operating Guidelines
OPERATING GUIDELINES Before operating this heater, please review the safety warnings CAUTION: During the initial purging and subsequent pages at the beginning of this manual and those precautions and lightings, never allow the gas valve control knob to remain warnings listed below. depressed in the "pilot"... -
Page 25: Lighting Instructions
LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by •... -
Page 26: Pilot Flame Characteristics
PILOT FLAME CHARACTERISTICS Figure 35 shows a correct pilot flame pattern. The correct flame will be blue and will extend beyond the thermocouple and thermopile. The flame will surround the thermocouple and thermopile just below the tip. A slight yellow flame may occur where the pilot flame and main burner flame meet. -
Page 27: Wiring
Cleaning the Log Set and Firebox During the annual inspection and maintenance appointment, the service person should clean dust, lint, and any light accumulation from the logs and the firebox area. An extra-soft brush should be used on the logs as they are extremely fragile; a vacuum cleaner may be used on the firebox. - Page 28 WIRING (continued) Wiring Diagram (Figure 40) 1. Connect (1) wire from the 750 millivolt wall thermostat and (1) wire from appropriate accessory to the GREEN, stripped and bare wire from the ON/OFF/REMOTE wire harness. 2. Connect (1) wire from the 750 millivolt wall thermostat and (1) wire from appropriate accessory to the RED, stripped and bare wire from the ON/OFF/REMOTE wire harness.
-
Page 29: Maintenance
MAINTENANCE A qualified service person recommended by your Empire dealer 7. Insert a putty knife between glass and bottom corners on should conduct an annual inspection and maintenance of the frame. Carefully separate glass from frame. appliance, its venting, and the installation to keep it running safely 8. - Page 30 MAINTENANCE (continued) Cleaning Procedure IMPORTANT: Turn off gas before servicing appliance. It is 1. Let the unit cool if it has been operating. recommended that a competent service technician perform these 2. Shut off gas supply. check-ups at the beginning of each heating season. 3.
-
Page 31: Troubleshooting
TROUBLESHOOTING With proper installation and maintenance, your new Direct Vent Fireplace should provide years of trouble-free service. If you do experience a problem, refer to the Trouble Shooting Guide below. This guide will assist a qualified service person in the diagnosis of problems and the corrective action to be taken. -
Page 32: How To Order Repair Parts
Shipments contingent upon strikes, fires and all causes beyond our control. Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62222-0529 PARTS LIST FOR CIDV-30-20 PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide. -
Page 33: Parts View For Cidv-30-20
PARTS VIEW FOR CIDV-30-20 15628-0-0903 Page 33... -
Page 34: Parts List For Stove Casting
PARTS LIST FOR STOVE CASTING PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide. Index Part Index Part Number Description Number Description *CI-006 WINDOW RETAINING TAB * CI-007 RETAINING TAB - 4 REQUIRED R-3948 WINDOW (BLACK PAINT) R-3946... -
Page 35: Parts View For Stove Casting
PARTS VIEW FOR STOVE CASTING Models: CIFB-1, CIPB-1, CIPG-1, CIPS-1, CIPN-1, CIPR-1 15628-0-0903 Page 35... -
Page 36: Optional Blower Installation Instructions
OPTIONAL BLOWER INSTALLATION INSTRUCTIONS Installing Optional CIB-2 Blower Fan Control 1. Loosen, but do not remove, (4) hex-head screws located on The fan control is a non-adjustable automatic type The fan the exterior, bottom of the appliance. control will require between 5 and 10 minutes of main burner 2. - Page 37 Cleaning CAUTION: Label all wires prior to disconnection when The blower wheel will collect lint and could require cleaning servicing controls. Wiring errors can cause improper and once a year. If the air output decreases or the noise level dangerous operation. Verify proper operation after servicing. increases, it indicates a dirty wheel.
-
Page 38: Service Notes
SERVICE NOTES Page 38 15628-0-0903... -
Page 39: Service Notes
SERVICE NOTES 15628-0-0903 Page 39... - Page 40 PH: 1-800-851-3153 PH: 1-618-233-7420 FAX: 1-800-443-8648 FAX: 1-618-233-7097 Empire Comfort Systems, Inc. E-MAIL: info@empirecomfort.com Nine Eighteen Freeburg Ave. WEB SITE: www.empirecomfort.com Belleville, Illinois 62222-0529 Page 40 15628-0-0903...
