Yacht Manual DEHLER 35 11.8 H ............................. 55 OSE CLAMPS 11.9 H ..........................56 EAT EXCHANGER 11.10 P WC ............................56 11.11 H ..........................56 OLDING TANK 11.12 P ..............................56 AINT 11.13 W ........................57 ORN AND SPARE PARTS 11.14 H...
Furthermore it is to the advantage of the owner to undertake maintenance and servicing of the Dehler 35 and thus maintain its value. Maintenance should only be done by experienced people. Changes which are done after delivery of the boat without any notice and confirmation by the yard are out of responsibility of the yard.
Yacht Manual DEHLER 35 This owner’s manual is not a course on boating safety or seamanship. If this is your first craft, or if you are changing to a type of craft you are not familiar with, for your own comfort and safety, please ensure that you obtain handling an operating experience before “assuming...
Page 8
Yacht Manual DEHLER 35 Cold-resistant Switch at navi place for boiler Please observe and head below cover WC manufacturer’s instructions! Fuse Sticker in space U-sofa port side A= see print Automatic fuse Sticker next to the automatic fuse 110V or 230V...
One of the requirements of the EC Directive on Pleasure Craft is that every boat must belong to a specific design category. The yacht type DEHLER 35 belongs to Design Category A. The Directive describes Design Category A as follows:...
Yacht Manual DEHLER 35 1.7 Manufacturer’s Plate The manufacturer’s plate on the companionway bulkhead starboard is a requirement of the EC Directive, giving certain data which are explained here. Explanation of the information required by the Directive: Design Category A: High Sea Maximum Load This weight indication includes.
A T Aa Other used directives: DESCRIPTION OF THE CRAFT D E - D E H 7 3 Craft identification number (CIN) Model description : Type or number : 35 Dehler Type of craft Type of main propulsion Sailing boat Motor boat...
Yacht Manual DEHLER 35 2. Description of the boat 2.1 Main data Length overall 10.51 m Length waterline 9.38 m Maximum beam 3.49 m Beam hull 3.49 m Draught hull Dhull 0.45 m Max. draught standard keel 1.95 m Side height midships 1.26 m...
Yacht Manual DEHLER 35 2.1.1 Load IMPORTANT When loading the craft, never exceed the maximum recommended load. Always load the craft carefully and distribute loads appropriately to maintain design trim (approximately level). Avoid placing heavy weight high up. Numbers of persons: 6 Persons...
The Directive requires a maximum number of persons on board as a defined recommendation when the boat is sailing in the conditions it is intended for. The Dehler 35 is designed for offshore navigation, that is to say trips of several days between different ports. Therefore we recommend the following: ·...
On the Dehler 35, the recommended lifting points are marked on the edge of the coaming. The forward lifting point corresponds to A, approx. 3.75 m from the front of the bow and the after lifting point to B, approx.
Yacht Manual DEHLER 35 3.2.1 Deck The deck is a sandwich construction. Balsa wood of different thicknesses is used as intermediate layer. In areas with a lot of strain reinforcements of aluminium, plywood or solid wood are used. Fittings such as genoa slides, halyard pegs, winches, deck hatches or rollers are screwed and sealed with a flexible silicone rubber substance.
Yacht Manual DEHLER 35 3.3.2 Rigging plan · The mast is placed in a mast rail under the deck: · Mast length 17.89 m · Boom length 4.89 m Section profile: Mast Selden C211/110, Boom 171/94 Boom is fitted with Selden automatic reefing system for reef 1 and reef 2. By this you are able to reef sail by only one line.
Yacht Manual DEHLER 35 3.3.4 Genoa slide / Main sheet traveller Genoa slide and main sheet traveller are adjusted progressively from the cockpit. The adjustable top setting of the genoa slide is particularly sensible with a foresail roller reefing system.
Yacht Manual DEHLER 35 3.7 Summary of halyard sizes Name Material Diameter Length Identifying thread Genoa halyard HMPE 10 mm 33 m blue Spinnaker halyard Liros-Herkules 10 mm 37 m Main sheet HMPE 10 mm 37 m white Main sheet...
4. Description of inboard systems 4.1 Engine installation The Dehler 35 is equipped with a Volvo engine installation and Saildrive. The table shows you the most important data. At the same time we would like to refer you to the extensive information provided by Volvo.
Yacht Manual DEHLER 35 4.1.3 Fuel tank A 88 l PE-diesel tank is installed under the forward port bunk in the saloon. It is filled through the screw cap on the main deck towards the front starboard side of the cabin roof structure (marked FUEL with symbol).
Yacht Manual DEHLER 35 Components 1. Return pipe 2. Feed pipe 3. Filter/Water separator 4. pump 5. Fuel tank 6. Filling cap 7. ventilation tube 8. heater (option) 9.Ventilation 12: F IGURE UEL LINES 4.1.5 Engine switch panel The engine switchboard with a control lever is installed in the cockpit’s coaming starboard.
Yacht Manual DEHLER 35 4.1 Fresh water, drinking water The Dehler 35 has a polyurethane water tank, with a capacity of 130 l. It is installed under sofa portside saloon. The filler cap is on the portside on the coaming. An electric pressure water pump with a secondary surge tank supplies the sink and the washbasin in the toilet area.
Yacht Manual DEHLER 35 4.3 Waste water pump We have installed a shower water suction pump in the locker space under the hand washbasin. At 12 l/min. the pump removes more water than can be provided by the water supply. If the water in the shower tray rises, this means that the filter is clogged and should be cleaned.
Yacht Manual DEHLER 35 4.4.2 Battery charger Sterling Name Standard Model PCU1230 Voltage 230/110V Power 30 Amp. Charging voltage 14,35-13,35V Charging characteristic IUoUo NOTE Please make yourself familiar with the safety instructions attached for the battery charger! 4.5 Onboard direct current system The 12 V direct current system is responsible for the power supply for all general use appliances.
Yacht Manual DEHLER 35 4.5.2 Arrangement of main fuses The following main fuses are to be found under the saloon sofa port side behind the batteries – depending on the equipment: 17: M IGURE AIN FUSES 1= Anchor winch 2= General consumption 3= steady plus Further distribution to the “general consumption”...
Yacht Manual DEHLER 35 18: C IGURE ONTROL PANEL WITH CONNECTION NUMBERS 4.5.3 Identifying the cables The following numbers are to be found on the electric cables. Thus it is possible to check the clamped connections and leads easily. 1 = Bow/Stern light...
Yacht Manual DEHLER 35 4.5.4 Additional fuses Apart from the fuses on the control panel and in the companion way, three more “in-line” fine wire fuses have been installed, in each case a 2 A fine fuse in the control cables of the indicator for the consumer batteries.
Yacht Manual DEHLER 35 4.5.7 Auxiliary supply Navigation lighting must have absolute priority. If there is a drop in capacity caused by a technical fault in the supply, all other consumers must first be switched off. Running the engine, even when sailing, can recharge the batteries, which enables you to switch on the second most important consumers .
Yacht Manual DEHLER 35 4.5.10 General consumers This particularly includes the interior lighting with sockets. All lights have an integral switch so that it is possible to use the electricity only where required. 4.5.11 Electric wiring diagram The wiring diagram helps the specialist when looking for faults. It shows in a diagram the layout of the 12 V and 230 V system.
Yacht Manual DEHLER 35 4.6 Bilge systems 4.6.1 Anchor locker The anchor locker is watertight from the boat. It empties outboard directly through an opening. 4.6.2 Cockpit The cockpit is drained through the bilge drains in the footspace port and starboard...
Yacht Manual DEHLER 35 NOTE The hand lever is easily accessible, fixed in locker seatlid 4.6.4 Piston pump A piston pump is an excellent bilge emptying device. Every boat should have one on board and it should always be accessible in the galley locker.
Yacht Manual DEHLER 35 4.7 Rudder system The rudder system only needs minimum maintenance. The rudder blade with rudder shaft is held in an upper and lower pendulum bearing. The power is transmitted from the cable drum on the steering column via a cross piece to the steering gear and from there to the rudder quadrant.
Yacht Manual DEHLER 35 4.7.2 Rudder blade and rudder bearing The rudder blade is a modern prebalanced GF synthetic profiled blade with considerable rudder force. The rudder shaft, diam. 44 mm, is made of stainless steel, offset and is narrower at the lower end.
Yacht Manual DEHLER 35 4.8 Gas installation The gas installation of the Dehler 35 for the cooker was installed in accordance with the German regulation, G 608, and in compliance with the European Standard EN 10239. The stamped test certificate is attached to the documentation for your boat.
Page 43
Yacht Manual DEHLER 35 Some additional hints on how to avoid problems with your gas installation: Close the valves of the supply pipe and the bottle, when you are not using the cooker. In emergencies, immediately close the valves. Regularly check the liquid gas installation, looking for possible leaks. Check all connections with soapy water or liquid detergents (For this the burner valves of the cooker must be closed and the bottle and installation valves must be opened).
Yacht Manual DEHLER 35 4.8 Pump - WC The WC on board is a commercially available pump toilet. The fresh water intake is opened and the contents are pumped out through the outlet valve. See also the supplier’s instructions for use.
Yacht Manual DEHLER 35 4.9.3 Holding tank indicator How full the holding tank is can be seen on the indicator in the navigation area. This should regularly be checked. NOTE The state of the holding tank must be regularly checked so that the ventilation pipe does not become clogged.
Fire protection 5.1 Fire Prevention During the construction of the Dehler 35 we have paid special attention to avoid the risk of fire. This includes careful consideration of the choice of materials, the distance between the cooker burner flames and the surrounding built-in furnishings and the onboard diesel engine, with the engine compartment lined with self-extinguishing insulation material.
Yacht Manual DEHLER 35 5.2 Active fire protection The well-known sources of risk on board are the cooker in the galley and the engine compartment If in spite of all preventive measures a fire occurs on board, you have at...
Yacht Manual DEHLER 35 5.4 In the event of fire in the galley Immediately close the gas supply valve! Extinguish the flames with the fire blanket. It can be re-used afterwards. If furnishing elements are on fire, use the fire extinguisher.
In order to make the sailing season less dependent on weather conditions and create a good interior climate in the Dehler 35, a Eberspächer Air Top 3500D diesel heater can be installed. The heater is installed at the starboard side aft in the stern storage space and is accessible through the starboard locker seat.
Yacht Manual DEHLER 35 6.2 Dispensing pump/Filter The dispensing pump and the fuel filter are mounted behind the diesel filter and are accessible through the cover in head. 6.3 Temperature control The control element is mounted on the panel in the navigation area. The heating can be steadily adjusted.
Yacht Manual DEHLER 35 7 . Hull openings, sea cocks Openings under the waterline are possible weak points, to which we have therefore paid a lot of attention. The hull openings are made of a brass alloy and where necessary fitted with a fast shut-off ball valve.
Yacht Manual DEHLER 35 7.1 Leak stoppers In the event of a seacock or hull opening being damaged your Dehler 35 is equipped with several leak stoppers made of soft wood, the diameters of those fit to the different sizes of hull opening so that each opening can be blocked.
9. Environmental protection 9.1 Fuel and oil When filling your Dehler 35 you should be extremely careful. A piece of cloth around the filling cap can avoid fuel getting from the fuel hose into the water. In your engine manual you will also find a diagram with a graph showing specific fuel consumption.
9.6 Antifouling Paint The part under the waterline of the Dehler 35 can be protected by antifouling paint, since growth and vegetation means more energy consumption just to run the boat. The range of protective paints is large, their effect is wide and therefore the type of paint can be suited to every type of water.
Yacht Manual DEHLER 35 10. Ten golden rules for water sports enthusiasts Avoid sailing into canebrakes, reed beds and all other densely covered shore areas. Avoid shingle, sand and mud banks (resting and feeding areas for birds) as well as shoreline copses.
Teak: Regularly wash with clear water. For a richer colour, sand lightly and impregnate with teak 11.2 Cleaning Clean the parts of the boat under the waterline of your Dehler 35 as soon as the boat is taken out of the water. High-pressure cleaning machines remove every kind of vegetation. The next task is the repair and cleaning of the gel coat and varnish.
Yacht Manual DEHLER 35 Rigging check: Wash the entire rigging abundantly with fresh water before winter storage. For winter storage you should examine the standing and running rigging, the halyard blocks and shroud bottle screws. Grooves in the pins: essential to change the pins.
Yacht Manual DEHLER 35 11.6 Engine and propeller The diesel engine must be made winterpoof. We recommend fitting a long hose on the nozzle of the water pump, see Volvo manual, preparing an anti-freeze mixture in a bucket and letting the engine draw in this mixture until it comes out at the exhaust.
Page 59
Yacht Manual DEHLER 35 NOTE Avoid major discharge of the batteries on board Even maintenance free batteries must be charged up in winter (charging condition at least 50%) so that they do not freeze Once a year all contacts should be checked and sprayed with a special spray Make yourself familiar with the electrical system, so that you can react quickly in the event of a fault.
Yacht Manual DEHLER 35 11.9 Heat exchanger IMPORTANT Heed the information supplied by SIGMA for maintenance and exchange of the thermostat and the heating element! When there is danger of freezing the heat exchanger must be emptied. How to do this is described in the manufacturer documents.
If you need spare parts and the original parts are not available, then you should pay attention to the characteristics given in the manual, to keep the Dehler 35 technically at the same high level as when you acquired it.
Page 62
St. Petersburger Str. 1, 20355 Hamburg Postfach 30 12 27, 20305 Hamburg Tel. 040 - 35 28 17, Fax - 34 42 27 If you have any questions about sailing or legal regulations, please contact the department for Waterways and Navigation. Here are also the addresses of the regional Navigation Authorities or those relevant in your case.
Yacht Manual DEHLER 35 14. Warranty In case of a warranty claim, please get in touch with your signatory. 15. Manufacturers’ Information This is a list of the firms whose guarantee and warranty conditions you will find in the documentation. These firms are ready to help you through their extensive service network.
