- Page 1 DEHLER 25Cr Owner Owner’s manual SchiffsnameName of yacht DEHLER 25 Cr Construction number Hull Identification Number Design category Dehler Segelyachten Industriegebiet Im Langel 59872 Meschede-Freienohl Telefon (02903) 440-0 Telefax (02903) 440-300 https://www.boat-manuals.com/...
-
Page 2: Table Of Contents
DEHLER 25Cr Contents ........................3 NDEX OF ILLUSTRATIONS ..........................4 NTRODUCTION ........................5 TICK ON NOTICES ...........................7 ESIGN ATEGORY ..........................7 DENTIFICATION ’ ........................8 ANUFACTURER LATE ........................ 11 ECHNICAL EGULATIONS , ..........................12 WNER ........................... 13 ECHNICAL DATA ....................14 RANING STROPS BEARING POINTS .................. -
Page 3: Index Of Illustrations
DEHLER 25Cr Index of illustrations ..........14 IGURE RANSPORT AND LOADING MEASUREMENTS FOR STANDARD KEEL ........................15 IGURE PLAN DECK ........................17 IGURE NTERIOR ........................18 IGURE AILS PLAN ......................... 19 IGURE NGINE ....................20 IGURE RINKING WATER SYSTEM ....................20... -
Page 4: Introduction
DEHLER 25Cr Introduction This manual has been written and compiled to make it possible for you to use your sailing yacht, a DEHLER 25, in a safe and pleasant way. Apart from many details regarding the yacht itself, the manual... -
Page 5: Stick On Notices - List
DEHLER 25Cr Stick on notices - List List of the most important information, indicated by stick on notices. Observance of the notices is very important for both the boat and its crew. Non-observance of the notices can lead to total loss of the boat and problems for the crew. As the skipper responsible for the boat’s safety you should inform new crew members about the notices and... - Page 6 DEHLER 25Cr Automatic fuse Sticker next to the automatic fuse 110V or 230V Shore connection Sticker Notice for fire extinguisher in front of Fire saloon sofa next to toilet room extinguisher When sailing, Sticker on inside locker galley and close the sea...
-
Page 7: Design Category
One of the requirements of the EC Directive on Pleasure Craft is that every boat must belong to a specific design category. The yacht type DEHLER 25 belongs to Design Category B. The Directive describes Design Category B as follows: Design Category B: Non coastal navigtion waves up to 4m, wind forces up to 8 Bft. -
Page 8: Anufacturer Plate
DEHLER 25Cr Manufacturer’s Plate The manufacturer’s plate on the companionway bulkhead starboard is a requirement of the EC Directive, giving certain data which are explained here. Explanation of the information required by the Directive: Design Category B: non coastal navigation waves up to 4, wind forces up to 8 Bft. - Page 9 DEHLER 25Cr the reference number of the certifying institute, in this case the Germanische Lloyd (see Statement of Conformity). https://www.boat-manuals.com/...
- Page 10 DEHLER 25Cr Statement of Conformity Dehler Deutschland GmbH Industriegebiet Im Langel D-59872 Meschede-Freienohl EC- Statement of Conformity according to EC-Directive “Pleasure Craft” 94/25/EC, Annex XV We hereby state that the sailing boat described hereunder complies with the basic safety and health requirements of the EC Directive “Pleasure Craft”, both in its concept and construction...
-
Page 11: Technical Regulations
DEHLER 25Cr Technical Regulations Appendix to the Statement of Conformity or Manufacturer’s Certificate Relevant Standards and/or Technical Regulations listed in the same order as in Annex I and Annex II of the Directive Annex I Design Category Annex I Principal data... -
Page 12: Dear Owner
We advise you first to familiarize yourself thoroughly with everything. All types of DEHLER 25 come up to the basic security needs conformable to rule 94/25/EG for pleasure vessels for design category "B". The sail territory is not limited. -
Page 13: Technical Data
DEHLER 25Cr Technical data Length Over All (LOA) max. 7,50 m Length Water Line (LWL) max. 6,70 m Beam max. 2,50 m Beam Water Line 2,32 m Keel I = Upside Down-keel Max. depth 1,50 m Keel II = Shallow wing keel Max. -
Page 14: Craning Strops - Bearing Points
DEHLER 25Cr Craning strops - bearing points Transport/winter cradle - bearing points Figure 1 Transport and loading measurements for standard keel https://www.boat-manuals.com/... -
Page 15: Plan Deck
DEHLER 25Cr Plan deck Figure 2 plan deck https://www.boat-manuals.com/... - Page 16 DEHLER 25Cr Legend of deck Legend of Interior 1= anchor locker 1= forward cabin 2= hatch forward cabin (escape hatch) 2= water tank 3= self taching rail 3= sofa-salon 4= fresh water tank fill in nozzle 4= supply batterie 5= shroud chaine plate...
-
Page 17: Interior
DEHLER 25Cr Interior Figure 3 Interior https://www.boat-manuals.com/... -
Page 18: Sails Plan
DEHLER 25Cr Sails plan Figure 4 Sails plan E = 3,70 m P = 10,00 m 2,75 m 9,40 m https://www.boat-manuals.com/... -
Page 19: Engine
DEHLER 25Cr Engine Figure 5 Engine 1. Engine 2. Centraflex shaft coupling 3. Volvo shaft seal 4. Stern tube 5. Zinc anode 6. Bearing block with bearing 7. Folding propeller 8. Propeller shaft https://www.boat-manuals.com/... -
Page 20: Drinking Water System
DEHLER 25Cr Drinking water system Holding tank Figure 7 Waste water system Figure 6 Drinking water system 1. Toilet 2. Sea cock 1. Watertank 3. Tank ventilation 2. Nozzle freshwater 4. Holding tank 3. Tank ventilation 5. T-piece 4. water pipe 6. -
Page 21: Toilet
DEHLER 25Cr Toilet Fuel system Figure 8 Toilet 1. Float for _ filling tank control 2. Ventilation 3. Deck suck-off Figure 9 Fuel system 4. Holding tank 5. Effluent supply line 6. Effluent removal line 1. Engine 7. Junction suck-off 2. -
Page 22: Circuit Diagram
DEHLER 25Cr Circuit diagram https://www.boat-manuals.com/... -
Page 23: Circuit Diagram Engine
DEHLER 25Cr Circuit diagram engine https://www.boat-manuals.com/... -
Page 24: Terminal Strips
DEHLER 25Cr Terminal strips Figure 10 Distribution boards 1. Terminal strip mast 2. Distribution salon port side 3.Distribution locker pantry https://www.boat-manuals.com/... -
Page 25: Instrument Panel
DEHLER 25Cr Instrument panel Figure 11 Instrument panel 1. Water pump 2. Interior lighting, port 3. Masthead light 4. Tricolour light 5. Anchor light 6. Bow and stern light 7. Navigation instruments 8. Bilge pump https://www.boat-manuals.com/... -
Page 26: Legend Of Stickers
DEHLER 25Cr Legend of stickers Liquid gas system 2 kg Camping „Gaz“ = Bow and stern light = Masthead light = Tricolour light = Anchor light = Navigation instruments = Water pump = Bilge pump = Interior lighting port = Interior lighting starboard... -
Page 27: Spirit Stove
DEHLER 25Cr Spirit stove 5. Exhaust There is an manufactors manual of the Rudder system cooker. Therefore we make no advises here. ATTENTION Please read the orginal manual of the cooker. Exhaust system Figure 14 Rudder system 1. Tiller bracket 2. - Page 28 DEHLER 25Cr https://www.boat-manuals.com/...
-
Page 29: Routing Of Halyards And Sheets
DEHLER 25Cr Routing of halyards and sheets Heating outlets Figure 15 Halyard routing 1. Jib halyard 2. Reef II 3. Reef I 4. Boom lift 5. Boom vang 6. Spi.-halyard 7. Main halyard 8. Jibsheet 9. Fockroller 10. Bedienleine Jüttvorrichtung... - Page 30 DEHLER 25Cr https://www.boat-manuals.com/...
-
Page 31: Hull Skin Fittings
DEHLER 25Cr Hull skin fittings 1. Skin fitting 1 _“ depth sounder 2. Skin fitting 1 _“ log 3. Skin fitting 3/4" sink outlet with quick- acting ball valve 4. Skin fitting 1 1/4" outlet for toilet or holding tank with quick-acting ball valve 5. -
Page 32: Outside Companies
DEHLER 25Cr Outside companies PART TYPE INFORMATION SUPPLYING FIRM Diesel engine Yanmar GM Operating instruction Fa. Marx, 20097 Hamburg Heater Eberspächer Technical description, J. Eberspächer, installation instruction, 73730 Esslingen operating instruction Bedieneinrichtung Eberspächer Operating instruction J. Eberspächer, 73730 Esslingen Temperature sensor Eberspächer... -
Page 33: Servicing
DEHLER 25Cr Servicing In your documents you will find comprehensive information regarding the assembly parts. This includes also servicing in order to achieve a trouble-free ELECTRICITY: operation and a long service life. All contact points have to be checked by... - Page 34 DEHLER 25Cr https://www.boat-manuals.com/...
-
Page 35: Repairs, Replacement Of Parts
DEHLER 25Cr REPAIRS, REPLACEMENT OF PARTS: In case you do not receive original parts please ask for the necessary working resp. ultimate strength in order to avoid problems resulting from too small parts, e. g. blocks. DECK REPAIRS: The Gelcoat coating is a special resin with colour pigments. -
Page 36: Environmental Protection Code
DEHLER 25Cr Environmental protection code Please help to protect the plant and animal life in our sailing estuaries by observing the following rules: 1. Maintain an adequate minimum distance 7. Help to keep our estuaries clean by not from reed beds when sailing or dumping rubbish in the water. -
Page 37: Warranty Card
DEHLER 25Cr Warranty Card Dehler – Warranty card We are convinced of the quality of our sailing boats and are therefore able to offer the following additional guarantee, over and above the various legal warranties of the European Community: In addition to legal guarantee, we guarantee for a period of 5 years the non-appearance of osmosis With this extended guarantee, you have the right to a repair or replacement of faulty parts. -
Page 38: Outside Companies
DEHLER 25Cr Outside companies Tel: 0221-5966-0, „radios“. The following is a list of companies whose guarantee and warranty terms you will find in your documents and who are prepared to meet the provisions with their service network. On the basis of our long-standing experience of dealing with our partners we know that matters are dealt with smoothly. - Page 39 DEHLER 25Cr https://www.boat-manuals.com/...
