Specifications

4 Technical data

Designation
Speaker Input
ANALOG Inputs
Loadbox
Speaker Thru
ANALOG Outputs
Headphones Output
54
Characteristics
Jack 6.35 mm (1/4") unbalanced (TS, Tip/Sleeve)
Maximum input voltage: 280 V AC (51 dBu)
Security load: 200 Ohms / 10 Watts
2 X Combo XLR - Jack 6.35 mm (1/4") balanced (TRS)/unbalanced (TS)
Maximum input level: 8.70 dBu
Input impedance: 20 kOhms balanced, 10 kOhms unbalanced
Reactive or Resistive load (relay), nominal impedance: 4 or 8 or 16 Ohms (switch)
Maximum admissible power: 150 W (assuming proper ventilation)
Maximum temporary admissible power : 200 W (assuming proper ventilation)
Cooled by temperature-controlled fan
High Impedance mode if a cabinet is connected to the THRU output (loadbox is discon-
nected).
Jack 6.35mm (1/4") unbalanced (TS)
2 x XLR balanced
Impedance: 600 Ohms balanced, 300 Ohms unbalanced
Maximum output level:
• (no load, balanced): 11.2 dBu
• (10 kOhm load, balanced): 10.7 dBu
• (no load, unbalanced): 5.1 dBu
• (10 kOhm load, unbalanced): 4.9 dBu
Stereo out, Jack 6.35mm (1/4")
