  • Page 1 AirPatrol WiFi Full Manual V1.0...

  • Page 2: Table Of Contents

    Index • What AirPatrol WiFi does? • Lights and buttons • WiFi Network • Installing AirPatrol Wifi • Quick Setup steps • AirPatrol WiFi setup • Sending commands (Low heat mode) • Add / delete favourites • Settings menu...

  • Page 3: What Airpatrol Wifi Does

    The easiest way to use AirPatrol WiFi is with a Smartphone, using the AirPatrol app downloadable from the Google Play (for Android phones ) or App Store (for iPhone). AirPatrol WiFi allows you to have long distance control over the mode of the pump, room temperature, fan speed and mode settings.

  • Page 4: Lights And Buttons

    PAIRING button Use the PAIRING button to pair your phone or tablet LED 2 - IR (InfraRed) LED with AirPatrol controller by following the steps on - transmitting IR signal described in mobile application. LED 3 - WiFi connection LED...

  • Page 5: Wifi Network

    • Only IEEE 802.11a/n/ac (and other, more exotic 802.11) standards are not supported. • AirPatrol WiFi supports open networks, WEP, WPA-PSK and WPA2-PSK security modes • Only 2.4GHz band is supported (5GHz band is not supported) • Make sure you have good WiFi signal at the place you are installing AirPatrol controller.

  • Page 6: Installing Airpatrol Wifi

    Test function. To see if AirPatrol WiFi can send commands to your AC or heat pump, turn off the pump and press the controller’s TEST button. When the connection is established, AirPatrol WiFi turns the pump on with its last...

  • Page 7: Quick Setup Steps

    First please follow Quick Guide steps: Pairing Test...

  • Page 8: Airpatrol Wifi Setup

    AirPatrol WiFi Setup Start AirPatrol app and choose WiFi as controller type.
  • Page 9 AirPatrol WiFi Setup Controller ID Scan the QR code under your AirPatrol WiFi controller. Do not worry if you cannot read the QR code, you can enter the ID manually.
  • Page 10 AirPatrol WiFi Setup Controller ID App will notify you if QR code scanning was successful and you can proceed to next step.
  • Page 11 In case QR code scanning was unsuccessful: AirPatrol WiFi Setup 1.1.1 Controller ID In case something went wrong or you are unable to scan QR code you can either choose scan again or enter ID manually. 1.1.2 Controller ID Entering ID manually.
  • Page 12 AirPatrol WiFi Setup Pair up Press pairing button on your controller to continue. Pairing LED will light up Pairing...
  • Page 13 AirPatrol WiFi Setup WiFi connection Connect your AirPatrol WiFi to WiFi network...
  • Page 14 AirPatrol WiFi Setup WiFi connection The app will check if you are already connected to WiFi network and propose to connect to this network or change to another WiFi network.
  • Page 15 AirPatrol WiFi Setup WiFi connection You will then be asked to enter your WiFi network password. In case you do not have a password protected network then leave it empty.
  • Page 16 AirPatrol WiFi Setup WiFi connection AirPatrol will now try to connect to the network you chose. WiFi LED blinks and turns on...
  • Page 17 AirPatrol WiFi Setup WiFi connection You will be notified if connection is successfully established.
  • Page 18 AirPatrol WiFi Setup Pairing with controller Next you will be asked to pair AirPatrol App with AirPatrol WiFi controller.
  • Page 19 AirPatrol WiFi Setup Pairing with controller Press Pairing button on the side of your AirPatrol WiFi controller and follow to the next step. Pairing...
  • Page 20 AirPatrol WiFi Setup Pairing with controller You will be notified if pairing was successful. Pairing LED will turn off. Only Power and WiFi LEDs are on.
  • Page 21 AirPatrol WiFi Setup Information In the last step you are asked to select your heat pump / AC brand and give it a name. After that press DONE.
  • Page 22 AirPatrol WiFi Main view This is the main view for AirPatrol App. To control your device just touch anywhere on the selected device area.
  • Page 23 AirPatrol WiFi Setup Information In the last step you are asked to select your heat pump / AC brand and give it a name. After that press DONE.

  • Page 24: Sending Commands (Low Heat Mode)

    Sending commands Sending commands is easy, just select your desired settings and push send button. For example setting LOW HEAT mode: 1. Make sure the 2. Select MODE and 3. Press SEND button ON/OFF siwtch is ON LOW HEAT...

  • Page 25: Add / Delete Favourites

    Add / delete favourites 1. Choose your favourite 2. To activate the 3. To delete favourite settings and push the favourite just select it select it and press add favourite button. from the bottom bar delete favourite button. and press SEND button.

  • Page 26: Settings Menu

    • change your heat pump / AC model SETUP • enter to SETUP menu • set alarms* • Enter VERSION menu • delete controller. From VERSION menu you can see • Firmware versioon VERSION • Controller uptime • WiFi network *Alarms function is available from December 2014...
