AirPatrol WiFi Version 2
Full Manual
for Android
V4.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WiFi Version 2 and is the answer not in the manual?

Questions and answers

Related Manuals for AirPatrol Lite WiFi Version 2

Summary of Contents for AirPatrol Lite WiFi Version 2

  • Page 1 AirPatrol WiFi Version 2 Full Manual for Android V4.2...

  • Page 2: Table Of Contents

    Index • Installation tips • What AirPatrol WiFi does? • Lights and buttons • WiFi Network • Installing AirPatrol Wifi • Quick Setup steps • AirPatrol WiFi setup • Sending commands (low heat mode) • Add / delete favourites • Alarms settings •...

  • Page 3: Installation Tips

    Installation tips Router/WiFi connection: • Enable 2.4GHz bandwidth only • Make sure network has WPA-PSK or WPA2-PSK security mode • Special characters (e.g. "&", "-", etc.) in WiFi password are not supported In case setup fails: • Do a full reset to controller by pressing Test and Pairing buttons at the same time until Power LED starts to blink •...

  • Page 4: What Airpatrol Wifi Does

    What AirPatrol WiFi does? AirPatrol WiFi is a heat pump and air conditioner (AC) controller you operate with a smart phone or tablet. It is compatible with all major manufacturers’ ACs and smartphones. (see www.airpatrol.eu for the complete list) The easiest way to use AirPatrol WiFi is with a Smartphone, using the AirPatrol app downloadable from Google Play (for Android phones ) or App Store (for iPhone).

  • Page 5: Lights And Buttons

    Lights and buttons The controller has 4 LED indicators and 2 buttons for easy setup. It also has hidden infrared (IR)LEDs that transmit your commands to the AC and IR receiver for auto-detection and custom presets. LED 1 - Power PAIRING button on –...

  • Page 6: Wifi Network

    WiFi Network • AirPatrol WiFi requires a router that is compatible with IEEE 802.11 b/g/n standards • Only IEEE 802.11a/ac (and other, more exotic 802.11) standards are not supported • AirPatrol WiFi supports WPA-PSK and WPA2-PSK security modes • Only 2.4GHz band is supported (5GHz band is not supported) •...

  • Page 7: Installing Airpatrol Wifi

    Installing AirPatrol WiFi AirPatrol WiFi should be mounted near AC’s or heat pump’s indoor unit, with its IR transmitter pointing to the unit. This way the IR beam reaches the AC’s sensor most efficiently. All mounting configurations are possible as long as IR transmission from the controller to the pump works. NB! Thick carpets and dark floors can distort the IR beam.

  • Page 8: Quick Setup Steps

    First please follow Quick Guide steps: Pairing Test...

  • Page 9: Airpatrol Wifi Setup

    AirPatrol WiFi Setup Start AirPatrol app and choose WiFi as controller type.
  • Page 10 AirPatrol WiFi Setup Controller ID Scan the QR code under your AirPatrol WiFi controller. Do not worry if you cannot read the QR code, you can enter the ID manually.
  • Page 11 AirPatrol WiFi Setup Controller ID App will notify you if QR code scanning was successful and you can proceed to the next step.
  • Page 12 In case QR code scanning was unsuccessful: AirPatrol WiFi Setup 1.1.2 1.1.1 Controller ID Controller ID Entering ID manually - please In case something went wrong or type the ID code of your cont- you are unable to scan QR code roller.
  • Page 13 AirPatrol WiFi Setup Connecting to WiFi & pairing Select WiFi for your AirPatrol controller. This is the WiFi network your AirPatrol controller will use for communication (for example your home WiFi)
  • Page 14 AirPatrol WiFi Setup Connecting to WiFi & pairing The app will check if you are already connected to WiFi network and suggests to connect to this network or change to another WiFi network.
  • Page 15 AirPatrol WiFi Setup Connecting to WiFi & pairing You will be then asked to enter your WiFi network password.
  • Page 16 AirPatrol WiFi Setup Connecting to WiFi & pairing Next you will be asked to pair AirPatrol App with AirPatrol WiFi controller. Pairing LED will light up Pairing...
  • Page 17 AirPatrol WiFi Setup Connecting to WiFi & pairing Next you will be asked to select temporary WiFi network for the pairing process. AirPatrol controller creates temporary WiFi to receive network information from your smartphone.
  • Page 18 AirPatrol WiFi Setup Connecting to WiFi & pairing In the app press the Connect Next choose the temporary button. WiFi network created by the controller. WiFi LED will turn on. After connection is estab- lished return to AirPatrol app by pressing the BACK button.
  • Page 19 AirPatrol WiFi Setup Connecting to WiFi & pairing AirPatrol controller is now connecting to WiFi network. After that your controller starts pairing with your smartphone.
  • Page 20 AirPatrol WiFi Setup Connecting to WiFi & pairing If the pairing process failed then: A) Check that WiFi password was entered correctly. B) Activate WPS on your WiFi router and press pairing button on your AirPatrol controller.
  • Page 21 AirPatrol WiFi Setup Connecting to WiFi & pairing You will be notified when pairing is successful. Pairing LED will turn off. Only Power and WiFi LEDs are on.
  • Page 22 AirPatrol WiFi Setup Information In the last step you are asked to select your AC brand, model and give it a name. After that press DONE.
  • Page 23 AirPatrol WiFi Main view This is the main view for AirPatrol App. Press the Power button at the top left corner to turn your heat pump ON/OFF.

  • Page 24: Sending Commands (Low Heat Mode)

    Sending commands Sending commands is easy, just select your desired settings and push send button. For example setting LOW HEAT mode: 1. Make sure the 2. Select MODE and 3. Press SEND button ON/OFF switch is ON LOW HEAT...

  • Page 25: Add / Delete Favourites

    Add / delete favourites 1. Choose your favourite 2. To activate the 3. To delete favourite settings and push the favourite just select it select it and press add favourite button. from the favourites bar delete favourite button. and press Send.

  • Page 26: Alarms Settings

    Alarms settings Notifications menu To manage alarms, press the Notifications menu on the main view. List of all the alarms is displayed for you. Alarms are set OFF by default.
  • Page 27 Alarms settings Alarms setup In order to turn alarm ON just press on it and remove the tick from "Alarm disabled" box. After that you can use up/down arrows to select the temperature that you would like to set the alarm trigger.
  • Page 28 Alarms settings Alarms setup After setting an alarm it will be displayed in alarms menu as well. To confirm all settings press Apply. All values are then sent to the controller and are applied.

  • Page 29: Local Weather Report

    Local weather report To see local weather report select Weather from the main view. You are then able to search your local region or any other location you like. The region you select will be shown in more detail and also later in the main view.

  • Page 30: Timer Function / Scheduled Events

    Timer function / Scheduled events Adding timers First select Timer menu and from there press Set scheduled event button. You will now see a menu for setting a timer. Follow the steps as you like and click DONE.
  • Page 31 Timer function / Scheduled events Adding timers Now set the temperature, mode and fan speed for the selected timer, also choose power ON or OFF. When you are finished press the Apply button. You may add unlimited timers by selecting Set Scheduled event from main view again and following the same steps with each timer.
  • Page 32 Timer function / Scheduled events Adding timers Scheduled events can be adjusted any time by clicking on them in the Timer menu. Your scheduled events are also displayed next to the Timer menu to remind you about upcoming and reoccurring timers.

  • Page 33: Menu Button

    Menu button There is also a menu button to: • add controller • create groups • change temperature between °C/°F • manage devices and contact support Find the Menu button at the top left corner on the main view.

  • Page 34: Celsius / Fahrenheit Conversion

    Celsius / Fahrenheit Switching between temperature modes You are able to change the temperature displays from Celsius to Fahrenheit and back. To do this just press the menu button in main view and select °C / °F. Now all temperatures are displayed in Fahrenheit. To switch back to Celsius just follow the same steps.

  • Page 35: Calibration Fg

    Calibration Calibrating room temperature You are able to calibrate the room temperature measured by your AirPatrol. To do this, go to Settings and press on Calibrate. From there you can select a value between +/- 10°C. Room temperature reading will then be adjusted according to your chosen value.

  • Page 36: Ifttt

    IFTTT AirPatrol WiFi can be integrated with IFTTT (If This Then That). To do this, go to ifttt.com or open IFTTT app and search for “AirPatrol”. To connect, enter the HWID and Authorization code which can be found under Settings in AirPatrol app. AirPatrol WiFi can also be integrated with Amazon Alexa voice control via IFTTT.
  • Page 37 Thank you! SAVE MONEY, GAIN COMFORT For more materials and support visit: www.airpatrol.eu/support...
